2 - FIELD 230-240V
BSD-2604220480.A12
2604220480
|
£21.68
|
£26.01
|
|
|
4 - SWITCH
BSD-1607200158.A7
1607200158
|
£8.67
|
£10.41
|
|
|
5 - POWER SUPPLY CORD GB 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460196.A23
1604460196
|
£21.52
|
£25.83
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A782
2600703017
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE GHO 26-82
BSD-2609130771.A7
2609130771
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-2609120049.A11
2609120049
|
£2.61
|
£3.13
|
|
|
16 - CARBON BRUSH HOLDER
BSD-2604449055.A0
2604449055
|
£2.16
|
£2.59
|
|
|
17 - COVER
BSD-2609100087.A10
2609100087
|
£1.75
|
£2.10
|
|
|
19 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A5
2912401420
|
£1.75
|
£2.10
|
|
|
20 - SCREW
BSD-2609110155.A11
2609110155
|
£1.75
|
£2.10
|
|
|
26 - ADJUSTING NUT
BSD-2609110131.A0
2609110131
|
£4.26
|
£5.11
|
|
|
28 - PULLEY
BSD-2609110268.A0
2609110268
|
£2.80
|
£3.36
|
|
|
29 - PULLEY
BSD-2609110267.A21
2609110267
|
£4.26
|
£5.11
|
|
|
30 - ROTARY KNOB
BSD-2609100186.A0
2609100186
|
£10.10
|
£12.12
|
|
|
31 - V-BELT
BSD-2609100410.A23
2609100410
|
£10.10
|
£12.12
|
|
|
32 - GEAR COVER
BSD-2609100024.A4
2609100024
|
£3.72
|
£4.47
|
|
|
33 - COMPRESSION SPRING
BSD-2609110077.A11
2609110077
|
£2.61
|
£3.13
|
|
|
35 - BRUSH-COVER
BSD-2609100023.A6
2609100023
|
£6.52
|
£7.83
|
|
|
37 - CAP-HANDLE
BSD-2609100140.A5
2609100140
|
£5.30
|
£6.36
|
|
|
38 - RATCHET DISC
BSD-2609110162.A4
2609110162
|
£2.61
|
£3.13
|
|
|
40 - AIR-DEFLECTOR RING
BSD-2609100028.A7
2609100028
|
£2.61
|
£3.13
|
|
|
41 - CONTACT STRAP
BSD-2601329053.A33
2601329053
|
£1.75
|
£2.10
|
|
|
43 - COILED SPRING PIN DIN 7343-5x2.5
BSD-2917800053.A13
2917800053
|
£2.16
|
£2.59
|
|
|
44 - SQUARE NUT M6
BSD-2603320004.A34
2603320004
|
£1.75
|
£2.10
|
|
|
47 - RATCHET SPRING
BSD-2601254000.A29
2601254000
|
£1.75
|
£2.10
|
|
|
49 - HANDLE COVER
BSD-2609100022.A4
2609100022
|
£7.36
|
£8.83
|
|
|
57 - CONNECTING CABLE L=233 MM
BSD-2604448181.A30
2604448181
|
£2.16
|
£2.59
|
|
|
58 - CONNECTING CABLE L=213 MM
BSD-2604448118.A44
2604448118
|
£1.75
|
£2.10
|
|
|
60 - DEFLECTOR PIPE
BSD-2609100148.A6
2609100148
|
£11.30
|
£13.56
|
|
|
74 - PLANING KNIFE
BSD-2608635341.A70
2608635341
|
£16.41
|
£19.69
|
|
|
75 - SHIFT-LEVER KNOB
BSD-2603340016.A19
2603340016
|
-
|
|
|
|
76 - GRIPPING WEDGE
BSD-2603111001.A37
2603111001
|
£13.12
|
£15.75
|
|
|
80 - KNIFE GUARD
BSD-2609100088.A7
2609100088
|
£4.26
|
£5.11
|
|
|
81 - SPRING
BSD-2609110109.A21
2609110109
|
£2.80
|
£3.36
|
|
|
654 - OFFSET SCREWDRIVER DIN 911 SW2.5
BSD-1907950003.A21
1907950003
|
£2.61
|
£3.13
|
|
|
656 - STOP BRACKET
BSD-2608005015.A42
2608005015
|
£11.30
|
£13.56
|
|
|
657 - SUCTION CONNECTOR
BSD-2605702023.A1
2605702023
|
-
|
|
|
|
657/1 - O-RING 4.0x1.5 MM
BSD-1610210043.A104
1610210043
|
£1.75
|
£2.10
|
|
|
657/2 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A176
2916011014
|
£1.75
|
£2.10
|
|
|
657/3 - WING SCREW M 6x16 MM
BSD-2603480003.A138
2603480003
|
£2.61
|
£3.13
|
|
|
657/4 - STOP BRACKET
BSD-1601332018.A45
1601332018
|
£3.72
|
£4.47
|
|
|
657/5 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A110
2910281201
|
£1.75
|
£2.10
|
|
|
657/6 - WING NUT
BSD-2609199008.A32
2609199008
|
£1.75
|
£2.10
|
|
|
801 - MOTOR HOUSING
BSD-2609199578.A3
2609199578
|
£59.53
|
£71.44
|
|
|
803 - ARMATURE 230-240V
BSD-2609199269.A8
2609199269
|
£37.27
|
£44.72
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A1024
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON BRUSH
BSD-2609120398.A8
2609120398
|
£11.30
|
£13.56
|
|
|
813 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A580
1610905025
|
£6.52
|
£7.83
|
|
|
814 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A8
2600905052
|
£7.36
|
£8.83
|
|
|
825 - BEARING FLANGE
BSD-2609110175.A7
2609110175
|
£37.27
|
£44.72
|
|
|
827 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A581
1610905025
|
£6.52
|
£7.83
|
|
|
855 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A41
2600905064
|
£11.30
|
£13.56
|
|
|
870 - PLANER HEAD
BSD-2609110193.A13
2609110193
|
£59.53
|
£71.44
|
|
