2 - FELT WASHER
BSD-2600108076.A37
2600108076
|
-
|
|
|
|
3 - CUPPED WASHER
BSD-2600550019.A20
2600550019
|
-
|
|
|
|
4 - BALL BEARING dia15 MM
BSD-1900905110.A68
1900905110
|
£10.10
|
£12.12
|
|
|
5 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A229
2916660013
|
£2.16
|
£2.59
|
|
|
6 - DRILLING SPINDLE 1/2. SW 17
BSD-2606135011.A54
2606135011
|
£28.68
|
£34.41
|
|
|
7 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A314
2916650006
|
£1.75
|
£2.10
|
|
|
8 - SHIM 0.5 MM
BSD-2600100695.A200
2600100695
|
£1.84
|
£2.21
|
|
|
9 - CYLINDRICAL GEAR
BSD-2606316316.A19
2606316316
|
£27.23
|
£32.68
|
|
|
10 - CYLINDRICAL GEAR Z=45
BSD-2606316105.A30
2606316105
|
-
|
|
|
|
11 - FLAT KEY
BSD-2602300033.A20
2602300033
|
£5.87
|
£7.04
|
|
|
12 - SHIM 1.5 MM
BSD-2600101668.A46
2600101668
|
£2.94
|
£3.53
|
|
|
16 - SHIM 0.3 MM
BSD-2600100607.A1001
2600100607
|
£1.75
|
£2.10
|
|
|
17 - TOOTHED RACK
BSD-2603070010.A13
2603070010
|
-
|
|
|
|
18 - FORK LEVER
BSD-2602033002.A36
2602033002
|
-
|
|
|
|
19 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A126
2914501011
|
£1.75
|
£2.10
|
|
|
21 - ROTARY KNOB
BSD-2602026023.A45
2602026023
|
-
|
|
|
|
22 - RATCHET CAP
BSD-2600590006.A1098
2600590006
|
£1.84
|
£2.21
|
|
|
23 - RATCHET CAP
BSD-2600590006.A1099
2600590006
|
£1.84
|
£2.21
|
|
|
24 - SHIM WASHER
BSD-2600100618.A195
2600100618
|
£1.84
|
£2.21
|
|
|
26 - HEADLESS SCREW
BSD-2603435017.A51
2603435017
|
£2.61
|
£3.13
|
|
|
27 - HEADLESS SCREW
BSD-2603435018.A23
2603435018
|
-
|
|
|
|
29 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A445
2600914010
|
£2.94
|
£3.53
|
|
|
30 - FELT WASHER
BSD-2600108077.A5
2600108077
|
£1.84
|
£2.21
|
|
|
31 - CUPPED WASHER
BSD-2600500002.A208
2600500002
|
£1.75
|
£2.10
|
|
|
32 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A630
2600905021
|
£8.67
|
£10.41
|
|
|
33 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A780
2916660008
|
£2.16
|
£2.59
|
|
|
34 - HOLDING PIN
BSD-2603100036.A42
2603100036
|
-
|
|
|
|
35 - LOCKING WASHER DIN 6799-3.2
BSD-2916080906.A98
2916080906
|
£1.84
|
£2.21
|
|
|
36 - ARMATURE 230-240V
BSD-2604010858.A10
2604010858
|
£48.38
|
£58.06
|
|
|
37 - RECEPTACLE
BSD-2600400008.A319
2600400008
|
£1.75
|
£2.10
|
|
|
38 - BALL BEARING 7x22x7
BSD-1900905018.A1195
1900905018
|
£19.91
|
£23.89
|
|
|
39 - MOTOR HOUSING
BSD-2605104116.A32
2605104116
|
-
|
|
|
|
40 - FIELD 220-230V
BSD-2604220445.A21
2604220445
|
£28.59
|
£34.31
|
|
|
41 - CABLE L=130 MM
BSD-2604448005.A454
2604448005
|
£1.84
|
£2.21
|
|
|
42 - COVER DISC
BSD-2601328033.A96
2601328033
|
-
|
|
|
|
43 - SUPPRESSOR BOX L=93/85 MM
BSD-2604465071.A7
2604465071
|
-
|
|
|
|
44 - CARBON-BRUSH SET
BSD-2604321905.A388
2604321905
|
£11.87
|
£14.24
|
|
|
45 - BRUSH HOLDER
BSD-2604337003.A165
2604337003
|
£2.16
|
£2.59
|
|
|
46 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1519
2603490017
|
£2.27
|
£2.72
|
|
|
47 - TAPPING SCREW
BSD-2603435086.A373
2603435086
|
£1.84
|
£2.21
|
|
|
48 - SHIM 0.3 MM
BSD-2600101023.A223
2600101023
|
£1.84
|
£2.21
|
|
|
48 - SHIM 0.2 MM
BSD-2600101022.A376
2600101022
|
£1.84
|
£2.21
|
|
|
48 - SHIM 0.5 MM
BSD-2600101020.A256
2600101020
|
£1.84
|
£2.21
|
|
|
49 - SHIM
BSD-2600150004.A255
2600150004
|
£2.27
|
£2.72
|
|
|
50 - SWITCH
BSD-2607200209.A146
2607200209
|
£40.80
|
£48.96
|
|
|
51 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1040
2603410001
|
£1.84
|
£2.21
|
|
|
52 - SUPPRESSION CAPACITOR
BSD-2607329110.A24
2607329110
|
-
|
|
|
|
53 - CABLE
BSD-2604448003.A286
2604448003
|
-
|
|
|
|
54 - CABLE CLIP
BSD-2601035001.A1142
2601035001
|
£1.84
|
£2.21
|
|
|
55 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A69
2910611019
|
£2.94
|
£3.53
|
|
|
57 - GROMMET dia6.9 MM
BSD-2600707059.A669
2600707059
|
£3.91
|
£4.69
|
|
|
57 - GROMMET dia11.6-dia12.5x84 MM
BSD-2600707060.A8
2600707060
|
£2.61
|
£3.13
|
|
|
57 - GROMMET dia8.8 MM
BSD-2600707061.A368
2600707061
|
£2.80
|
£3.36
|
|
|
58 - HOUSING COVER
BSD-2605132040.A67
2605132040
|
-
|
|
|
|
59 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1562
2603490023
|
£1.84
|
£2.21
|
|
|
61 - STICKER
BSD-2601110913.A1
2601110913
|
-
|
|
|
|
62 - STICKER
BSD-2601110093.A74
2601110093
|
-
|
|
|
|
63 - CHANGE-OVER SWITCH
BSD-2607200198.A25
2607200198
|
-
|
|
|
|
64 - STICKER
BSD-2601110230.A5
2601110230
|
-
|
|
|
|
66 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A13
2603421226
|
£1.84
|
£2.21
|
|
|
67 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A194
1608571069
|
£25.05
|
£30.06
|
|
|
67 - CHUCK WRENCH SG2
BSD-2607950007.A1001
2607950007
|
£6.85
|
£8.22
|
|
|
70 - FAN
BSD-2606610049.A402
2606610049
|
£2.27
|
£2.72
|
|
|
653 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A233
1619P10682
|
£12.49
|
£14.99
|
|
|
654 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A909
2915011007
|
-
|
|
|
|
655 - CLAMPING PLATE M6
BSD-2608040014.A378
2608040014
|
-
|
|
|
|
656 - WING SCREW M6x(15)55
BSD-1613480007.A306
1613480007
|
£1.75
|
£2.10
|
|
|
656 - WING SCREW M6x20 MM
BSD-1613480008.A116
1613480008
|
£1.84
|
£2.21
|
|
|
800 - GEAR HOUSING
BSD-2605806972.A19
2605806972
|
-
|
|
|
|
801 - TOOTHED SHAFT Z= 10/20/29
BSD-2606308911.A26
2606308911
|
-
|
|
|
|
802 - INTERMEDIATE FLANGE
BSD-2605700932.A18
2605700932
|
-
|
|
|
|
805 - LOCKING WASHER DIN 6799-2.3
BSD-2916080005.A349
2916080005
|
-
|
|
|
|
825 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A8
2916080007
|
£2.74
|
£3.29
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2348
160111A3H3
|
£2.74
|
£3.29
|
|
