2 - FIELD 220-230V
BSD-1604220284.A98
1604220284
|
£31.79
|
£38.15
|
|
|
4 - SWITCH
BSD-1607200150.A12
1607200150
|
£22.60
|
£27.12
|
|
|
5 - POWER SUPPLY CORD GB 240V 4.15m 2 x 1.0mm H07RN-F
BSD-3604460077.A3
3604460077
|
£25.05
|
£30.06
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A122
2600703013
|
£2.74
|
£3.29
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A1047
1601302017
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118891.A3
1601118891
|
£4.48
|
£5.37
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328042.A118
1607328042
|
£6.85
|
£8.22
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A412
1610905025
|
£6.85
|
£8.22
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A525
1600905032
|
£5.58
|
£6.70
|
|
|
25 - HOUSING COVER
BSD-1600508016.A3
1600508016
|
£6.52
|
£7.83
|
|
|
26 - RUBBER RING
BSD-1600206036.A103
1600206036
|
£1.84
|
£2.21
|
|
|
27 - RUBBER RING
BSD-1600206025.A857
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A12
1600591025
|
£2.61
|
£3.13
|
|
|
30 - AIR-DEFLECTOR RING
BSD-1600591014.A294
1600591014
|
£2.74
|
£3.29
|
|
|
32 - GRINDING SPINDLE M14
BSD-3603523041.A6
3603523041
|
£40.80
|
£48.96
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-3600210124.A329
3600210124
|
£2.94
|
£3.53
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A221
1600136013
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A299
1600136014
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A221
1600136015
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A286
1600136020
|
£3.72
|
£4.47
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A13
1600290016
|
£2.74
|
£3.29
|
|
|
40 - RETAINING CLIP
BSD-1600119011.A538
1600119011
|
£2.27
|
£2.72
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A499
1600910018
|
£5.57
|
£6.68
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A425
1603300016
|
£1.84
|
£2.21
|
|
|
47 - PLASTIC-CUTTING SCREW St3.9x12
BSD-1603435042.A422
1603435042
|
£1.84
|
£2.21
|
|
|
49 - TORX OVAL-HEAD SCREW
BSD-3603435047.A12
3603435047
|
£2.61
|
£3.13
|
|
|
50 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A132
2912401420
|
£1.84
|
£2.21
|
|
|
51 - SPEED GOVERNOR 220-240V
BSD-1607233148.A6
1607233148
|
£57.14
|
£68.57
|
|
|
52 - LIGHT CONDUCTOR
BSD-3604460117.A9
3604460117
|
£2.94
|
£3.53
|
|
|
53 - CONNECTING CABLE L=50 MM
BSD-3604438020.A9
3604438020
|
£3.91
|
£4.69
|
|
|
55 - TORX OVAL-HEAD SCREW
BSD-1603435078.A271
1603435078
|
£1.84
|
£2.21
|
|
|
70 - COVER DISC
BSD-3600150023.A17
3600150023
|
£2.80
|
£3.36
|
|
|
81 - SHIM 0.2 MM
BSD-2600101022.A399
2600101022
|
£1.84
|
£2.21
|
|
|
104 - O-RING 4.0x1.0 MM
BSD-1600210034.A179
1600210034
|
£1.84
|
£2.21
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A26
1601008005
|
£4.26
|
£5.11
|
|
|
154 - DISTANCE PIPE
BSD-3600913010.A17
3600913010
|
£5.58
|
£6.70
|
|
|
155 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A88
2916660013
|
£2.16
|
£2.59
|
|
|
156 - GROOVE BALL BEARING 12x32x10
BSD-3600905130.A3
3600905130
|
£12.04
|
£14.45
|
|
|
157 - SEAL RING
BSD-3600105009.A7
3600105009
|
£6.52
|
£7.83
|
|
|
202 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A454
2605703014
|
£7.72
|
£9.27
|
|
|
203 - ROUND NUT M14
BSD-1603345043.A1271
1603345043
|
£9.11
|
£10.93
|
|
|
205 - REFERENCE PLATE
BSD-3601119236.A1502
3601119236
|
£3.91
|
£4.69
|
|
|
206 - STRAP-SHAPED HANDLE
BSD-3601303016.A6
3601303016
|
£66.68
|
£80.01
|
|
|
207 - HEX SCREW DIN 933 M10x16-8.8
BSD-2911061285.A13
2911061285
|
£2.27
|
£2.72
|
|
|
208 - PLAIN WASHER DIN 125-A10.5-ST
BSD-2916011017.A27
2916011017
|
£1.84
|
£2.21
|
|
|
301/1 - MOTOR HOUSING
BSD-1605108208.A6
1605108208
|
£11.87
|
£14.24
|
|
|
301/16 - BRUSH HOLDER
BSD-1601323025.A255
1601323025
|
£3.91
|
£4.69
|
|
|
301/17 - SPIRAL SPRING
BSD-1604652013.A962
1604652013
|
£1.84
|
£2.21
|
|
|
301/18 - SWITCH HANDLE
BSD-1602026057.A325
1602026057
|
£2.07
|
£2.48
|
|
|
301/19 - COMPRESSION SPRING
BSD-1604611026.A613
1604611026
|
£1.84
|
£2.21
|
|
|
301/20 - ADJUSTING SLIDE
BSD-1602319011.A24
1602319011
|
£1.75
|
£2.10
|
|
|
301/48 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A27
2912401005
|
£1.84
|
£2.21
|
|
|
650 - PIN-TYPE FACE-WRENCH
BSD-3607950017.A10
3607950017
|
-
|
|
|
|
651 - CUP WHEEL dia 125 MM
BSD-3608600008.A5
3608600008
|
£322.15
|
£386.58
|
|
|
803 - ARMATURE WITH FAN 220-240V
BSD-1604010650.A3
1604010650
|
£85.90
|
£103.08
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2796
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014010.A5
3607014010
|
£22.76
|
£27.31
|
|
|
821 - GEAR HOUSING
BSD-16058065B1.A10
16058065B1
|
£39.13
|
£46.96
|
|
|
824 - SUCTION HOOD
BSD-3605510040.A7
3605510040
|
£28.59
|
£34.31
|
|
|
828 - BEARING FLANGE
BSD-3605700158.A12
3605700158
|
£54.42
|
£65.30
|
|
|
829 - STRIP BRUSH
BSD-3600290054.A13
3600290054
|
£12.64
|
£15.17
|
|
|
835 - FAN
BSD-1606610132.A7
1606610132
|
£2.27
|
£2.72
|
|
|
838 - GEAR UNIT
BSD-1607000D4Y.A76
1607000D4Y
|
£21.42
|
£25.71
|
|
|
840 - PUSH-BUTTON
BSD-1607000253.A201
1607000253
|
£2.49
|
£2.99
|
|
|
866 - STRAP-SHAPED HANDLE
BSD-3607031584.A5
3607031584
|
£62.51
|
£75.01
|
|
|
890 - O-RING 20.35x1.78 MM
BSD-1600210039.A924
1600210039
|
£2.27
|
£2.72
|
|
|
899 - SILICONE SEALING SILASTIC 7091
BSD-3605430011.A8
3605430011
|
£23.86
|
£28.63
|
|
