1/01 - HANDLE
BSD-F016102533.A1
F016102533
|
-
|
|
|
|
1/02 - GROOVED PIN 5.0x3.5 MM
BSD-F016102627.A3
F016102627
|
-
|
|
|
|
1/03 - COVERING HOOD
BSD-F016102556.A2
F016102556
|
-
|
|
|
|
1/04 - COVERING HOOD
BSD-F016102557.A0
F016102557
|
-
|
|
|
|
1/05 - MOLDED PART
BSD-F016102549.A0
F016102549
|
-
|
|
|
|
1/06 - SCREW 4.2x22 MM
BSD-F016102401.A0
F016102401
|
-
|
|
|
|
1/07 - AXLE
BSD-F016102559.A1
F016102559
|
-
|
|
|
|
1/08 - SEAL
BSD-F016102575.A1
F016102575
|
-
|
|
|
|
1/09 - WHEEL
BSD-F016102610.A2
F016102610
|
-
|
|
|
|
1/10 - FASTENING PART
BSD-F016102590.A2
F016102590
|
-
|
|
|
|
1/11 - CAP
BSD-F016102697.A0
F016102697
|
-
|
|
|
|
1/12 - COVER
BSD-F016102548.A2
F016102548
|
-
|
|
|
|
1/13 - SPREADER RIVET 6.0 MM
BSD-F016102618.A2
F016102618
|
-
|
|
|
|
2/01 - CONDENSER 40MF
BSD-F016102624.A1
F016102624
|
-
|
|
|
|
2/02 - SWITCH COVER
BSD-F016102655.A0
F016102655
|
-
|
|
|
|
2/03 - OVAL-HEAD SCREW M5x34 MM
BSD-F016102588.A2
F016102588
|
-
|
|
|
|
2/04 - CAM
BSD-F016102564.A2
F016102564
|
-
|
|
|
|
2/05 - PUSH BUTTON
BSD-F016102656.A2
F016102656
|
-
|
|
|
|
2/06 - PROTECTIVE COVER
BSD-F016102616.A0
F016102616
|
-
|
|
|
|
2/07 - SWITCH
BSD-F016102615.A1
F016102615
|
-
|
|
|
|
2/08 - GASKET
BSD-F016102574.A2
F016102574
|
-
|
|
|
|
2/09 - LEAF SPRING
BSD-F016102572.A2
F016102572
|
-
|
|
|
|
3/01 - CABLE
BSD-F016102619.A0
F016102619
|
-
|
|
|
|
3/02 - FUSE
BSD-F016102591.A1
F016102591
|
-
|
|
|
|
3/03 - SCREW
BSD-F016102657.A0
F016102657
|
-
|
|
|
|
3/04 - HOSE
BSD-F016102605.A1
F016102605
|
-
|
|
|
|
3/05 - FILTER
BSD-F016102545.A2
F016102545
|
-
|
|
|
|
3/06 - HOUSING COVER
BSD-F016102555.A0
F016102555
|
-
|
|
|
|
3/07 - SCREW M6x22 MM
BSD-F016102587.A1
F016102587
|
-
|
|
|
|
3/08 - WATER CONTAINER
BSD-F016102558.A2
F016102558
|
-
|
|
|
|
3/09 - VALVE
BSD-F016102609.A0
F016102609
|
-
|
|
|
|
4/01 - SCREW M8x75 MM
BSD-F016102626.A1
F016102626
|
-
|
|
|
|
4/03 - O-RING 9x1.5 MM
BSD-F016102597.A2
F016102597
|
-
|
|
|
|
4/04 - INSERT
BSD-F016102699.A1
F016102699
|
-
|
|
|
|
4/05 - STRAINER
BSD-F016102411.A1
F016102411
|
-
|
|
|
|
4/06 - THREADED CONNECTION 3/4
BSD-F016102409.A14
F016102409
|
-
|
|
|
|
4/07 - ROD
BSD-F016102785.A0
F016102785
|
-
|
|
|
|
4/08 - SPRING
BSD-F016102786.A2
F016102786
|
-
|
|
|
|
4/09 - DISC
BSD-F016102787.A0
F016102787
|
-
|
|
|
|
4/10 - O-RING
BSD-F016102788.A2
F016102788
|
£4.75
|
£5.70
|
|
|
4/11 - SCREW PLUG
BSD-F016102789.A0
F016102789
|
-
|
|
|
|
4/12 - O-RING
BSD-F016102855.A0
F016102855
|
-
|
|
|
|
4/13 - SEAL
BSD-F016102791.A2
F016102791
|
-
|
|
|
|
5/01 - CYLINDER HEAD
BSD-F016102578.A0
F016102578
|
-
|
|
|
|
5/02 - VALVE
BSD-F016102536.A2
F016102536
|
-
|
|
|
|
5/03 - O-RING 8.73x1.78 MM
BSD-F016102601.A0
F016102601
|
-
|
|
|
|
5/04 - O-RING 13.3x2.4 MM
BSD-F016102592.A1
F016102592
|
-
|
|
|
|
5/05 - SCREW
BSD-F016102581.A0
F016102581
|
-
|
|
|
|
5/06 - O-RING 12.0x2.0 MM
BSD-F016102595.A0
F016102595
|
-
|
|
|
|
5/07 - O-RING
BSD-F016102700.A1
F016102700
|
-
|
|
|
|
5/08 - OVERFLOW VALVE 18.0x2.5 MM
BSD-F016102538.A2
F016102538
|
-
|
|
|
|
5/09 - O-RING 18.0x2.5 MM
BSD-F016102593.A1
F016102593
|
-
|
|
|
|
5/10 - SCREW
BSD-F016102565.A0
F016102565
|
-
|
|
|
|
5/100 - CYLINDER HEAD
BSD-F016102532.A2
F016102532
|
-
|
|
|
|
5/11 - VALVE
BSD-F016102537.A0
F016102537
|
-
|
|
|
|
6/02 - GROOVED RING
BSD-F016102603.A0
F016102603
|
-
|
|
|
|
6/03 - WASHER
BSD-F016102562.A2
F016102562
|
-
|
|
|
|
6/04 - WASHER
BSD-F016102563.A0
F016102563
|
-
|
|
|
|
6/05 - GROOVED RING 14x22x7 MM
BSD-F016102602.A2
F016102602
|
-
|
|
|
|
6/06 - HOUSING
BSD-F016102552.A2
F016102552
|
-
|
|
|
|
6/07 - PISTON
BSD-F016102579.A2
F016102579
|
-
|
|
|
|
6/08 - SPRING
BSD-F016102569.A2
F016102569
|
-
|
|
|
|
6/09 - MOLDED PART
BSD-F016102547.A0
F016102547
|
-
|
|
|
|
6/10 - SERVICE KIT
BSD-F016102701.A1
F016102701
|
-
|
|
|
|
6/11 - SWITCH
BSD-F016102539.A0
F016102539
|
-
|
|
|
|
6/12 - SWITCH
BSD-F016102539.A1
F016102539
|
-
|
|
|
|
6/13 - CONSOLE
BSD-F016102551.A0
F016102551
|
-
|
|
|
|
6/14 - SPRING
BSD-F016102570.A0
F016102570
|
-
|
|
|
|
6/15 - GROOVED PIN 5.0x3.5 MM
BSD-F016102627.A2
F016102627
|
-
|
|
|
|
6/16 - SUPPORT
BSD-F016102550.A2
F016102550
|
-
|
|
|
|
6/17 - CLIP
BSD-F016102857.A2
F016102857
|
-
|
|
|
|
7 - MOTOR
BSD-F016S10281.A0
F016S10281
|
-
|
|
|
|
7/03 - WOBBLE PLATE
BSD-F016102608.A1
F016102608
|
-
|
|
|
|
7/05 - BALL BEARING
BSD-F016102630.A2
F016102630
|
-
|
|
|
|
7/06 - SHAFT SEAL
BSD-F016102604.A2
F016102604
|
-
|
|
|
|
7/07 - BEARING COVER
BSD-F016102554.A5
F016102554
|
-
|
|
|
|
8/01 - O-RING
BSD-F016102594.A2
F016102594
|
-
|
|
|
|
8/02 - SCREW M6x30 MM
BSD-F016102625.A0
F016102625
|
-
|
|
|
|
8/03 - BEARING COVER
BSD-F016102554.A4
F016102554
|
-
|
|
|
|
8/11 - IMPELLER
BSD-F016102582.A2
F016102582
|
-
|
|
|
|
8/12 - SCREW M6x22 MM
BSD-F016102587.A0
F016102587
|
-
|
|
|
|
8/13 - SPACER
BSD-F016102576.A2
F016102576
|
-
|
|
|
|
8/14 - SCREW M6x30 MM
BSD-F016102625.A1
F016102625
|
-
|
|
|
|
8/15 - RUBBER BUFFER
BSD-F016102573.A0
F016102573
|
-
|
|
|
|
8/16 - BEARING COVER
BSD-F016102553.A0
F016102553
|
-
|
|
|
|
8/17 - TOLERANCE RING
BSD-F016102589.A0
F016102589
|
-
|
|
|
|
8/18 - BALL BEARING
BSD-F016102631.A0
F016102631
|
-
|
|
|
|
9 - HANDLE
BSD-F016102666.A2
F016102666
|
-
|
|
|
|
10/01 - HOSE
BSD-F016102667.A12
F016102667
|
-
|
|
|
|
10/02 - O-RING
BSD-F016102530.A2
F016102530
|
-
|
|
|
|
10/04 - O-RING 9.25x1.78 MM
BSD-1609203577.A22
1609203577
|
-
|
|
|
|
10/05 - SPRAY TUBE
BSD-F016102668.A2
F016102668
|
-
|
|
|
|
10/06 - NOZZLE
BSD-F016102669.A0
F016102669
|
-
|
|
|
