32 - SCREW
BSD-F016L66162.A8
F016L66162
|
£1.75
|
£2.10
|
|
|
40 - MOWER DECK
BSD-F016L66158.A4
F016L66158
|
£33.74
|
£40.49
|
|
|
41 - HOUSING
BSD-F016L66003.A10
F016L66003
|
£37.72
|
£45.27
|
|
|
42 - COVER PANEL
BSD-F016L66039.A10
F016L66039
|
£3.34
|
£4.01
|
|
|
43 - MOTOR HOOD
BSD-F016L66780.A33
F016L66780
|
£80.61
|
£96.73
|
|
|
43/1 - BATTERY TRAY
BSD-F016L65952.A13
F016L65952
|
£36.62
|
£43.95
|
|
|
43/2 - BATTERY COVER
BSD-F016L66663.A31
F016L66663
|
£7.92
|
£9.50
|
|
|
43/3 - MOTOR HOOD
BSD-F016L66779.A4
F016L66779
|
-
|
|
|
|
43/4 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A502
F016T49429
|
£1.75
|
£2.10
|
|
|
43/6 - INSULATOR
BSD-F016L66669.A7
F016L66669
|
-
|
|
|
|
43/8 - RELEASE LEVER
BSD-F016L66107.A29
F016L66107
|
£3.34
|
£4.01
|
|
|
43/9 - LOCKING DEVICE
BSD-F016L65988.A29
F016L65988
|
£1.95
|
£2.34
|
|
|
43/10 - SPRING
BSD-F016L66108.A21
F016L66108
|
£1.75
|
£2.10
|
|
|
52/01 - AXLE
BSD-F016L66465.A17
F016L66465
|
£3.34
|
£4.01
|
|
|
52/02 - LEVER
BSD-F016L90582.A58
F016L90582
|
-
|
|
|
|
52/03 - SPACER
BSD-F016L90583.A134
F016L90583
|
£2.33
|
£2.80
|
|
|
55 - CUTTER BLADE
BSD-F016L66005.A13
F016L66005
|
£31.64
|
£37.97
|
|
|
59 - BOLT M10x30
BSD-F016L66141.A73
F016L66141
|
£2.61
|
£3.13
|
|
|
61/01 - AXLE
BSD-F016L66464.A36
F016L66464
|
£4.75
|
£5.70
|
|
|
61/02 - LEVER
BSD-F016L90581.A133
F016L90581
|
£7.78
|
£9.33
|
|
|
61/03 - SPACER
BSD-F016L90585.A59
F016L90585
|
£1.75
|
£2.10
|
|
|
64 - RATCHET CAP 9 MM
BSD-F016F05700.A38
F016F05700
|
£1.95
|
£2.34
|
|
|
75/01 - HANDLE
BSD-F016L66182.A19
F016L66182
|
£33.74
|
£40.49
|
|
|
75/4 - SWITCH HOUSING
BSD-F016L66619.A3
F016L66619
|
£4.75
|
£5.70
|
|
|
75/5 - SWITCH HOUSING
BSD-F016L66235.A41
F016L66235
|
£3.34
|
£4.01
|
|
|
75/6 - CLAMPING PIECE
BSD-F016L66447.A20
F016L66447
|
£1.95
|
£2.34
|
|
|
75/7 - ON-OFF SWITCH
BSD-F016F05717.A62
F016F05717
|
£14.91
|
£17.89
|
|
|
75/8 - LEAF SPRING
BSD-F016L66416.A37
F016L66416
|
£1.66
|
£1.99
|
|
|
75/10 - PUSH-BUTTON
BSD-F016F05705.A31
F016F05705
|
£3.75
|
£4.50
|
|
|
75/11 - COMPRESSION SPRING
BSD-F016L66240.A17
F016L66240
|
£1.75
|
£2.10
|
|
|
75/14 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A506
F016T49429
|
£1.75
|
£2.10
|
|
|
75/27 - CABLE CLIP
BSD-F016L90575.A51
F016L90575
|
£1.75
|
£2.10
|
|
|
80 - COLLECTOR BOX BOTTOM
BSD-F016L65674.A21
F016L65674
|
£40.80
|
£48.96
|
|
|
82 - GUARD FLAP
BSD-F016L66137.A73
F016L66137
|
£13.32
|
£15.99
|
|
|
83/84 - HANDLE
BSD-F016L66441.A33
F016L66441
|
£4.75
|
£5.70
|
|
|
85 - SPRING
BSD-F016L66165.A202
F016L66165
|
£2.82
|
£3.39
|
|
|
99 - SPRING
BSD-F016L59327.A9
F016L59327
|
£2.80
|
£3.36
|
|
|
100 - SPRING
BSD-F016L65790.A14
F016L65790
|
£1.95
|
£2.34
|
|
|
101 - LINKAGE PART
BSD-F016L67260.A12
F016L67260
|
-
|
|
|
|
102 - RESTRICTOR
BSD-F016L66111.A29
F016L66111
|
£3.80
|
£4.56
|
|
|
452 - COMPANY LOGO ROTAK 37 LI
BSD-F016L66286.A19
F016L66286
|
£4.75
|
£5.70
|
|
|
503 - SPRING WASHER 1/2
BSD-F016L66173.A7
F016L66173
|
£1.75
|
£2.10
|
|
|
504 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A507
F016T49429
|
£1.75
|
£2.10
|
|
|
505 - SCREW
BSD-F016L65803.A57
F016L65803
|
-
|
|
|
|
506/1 - BOLT M6x50
BSD-F016L59277.A57
F016L59277
|
£3.80
|
£4.56
|
|
|
506/2 - WING NUT
BSD-F016L66136.A42
F016L66136
|
£4.26
|
£5.11
|
|
|
650 - SLIDE-IN ACCU PACKAGE PBA 36V 2.6Ah H-B Li
BSD-2607336107.A12
2607336107
|
-
|
|
|
|
651 - FAST CHARGER ROK 220/18-36V. 1h
BSD-2607225111.A7
2607225111
|
£103.14
|
£123.77
|
|
|
801/1 - DC MOTOR
BSD-F016104031.A6
F016104031
|
£218.41
|
£262.09
|
|
|
801/1/3 - PAN HEAD SCREW 4x35
BSD-F016L69251.A41
F016L69251
|
£1.75
|
£2.10
|
|
|
801/1/3 - SCREW M4x35
BSD-F016L66662.A8
F016L66662
|
£1.75
|
£2.10
|
|
|
801/2 - PRINTED-BOARD ASSEMBLY
BSD-F016104888.A6
F016104888
|
£93.88
|
£112.65
|
|
|
841/1 - COVER
BSD-F016104316.A25
F016104316
|
£8.49
|
£10.19
|
|
|
843/5 - WIRING HARNESS
BSD-F016104244.A6
F016104244
|
-
|
|
|
|
850 - WHEEL
BSD-F016103992.A48
F016103992
|
-
|
|
|
|
860 - WHEEL
BSD-F016103994.A38
F016103994
|
-
|
|
|
|
875/03 - CONNECTING CABLE
BSD-F016104140.A6
F016104140
|
£10.82
|
£12.99
|
|
|
875/18 - CONTROL BAR
BSD-F016103601.A43
F016103601
|
-
|
|
|
|
878 - BOTTOM HANDLE
BSD-F016L65571.A16
F016L65571
|
£21.52
|
£25.83
|
|
|
883 - COVER
BSD-F016103608.A66
F016103608
|
£27.23
|
£32.68
|
|
