1 - MOTOR CASING WITH INDUCTOR
MAF-084586.A7
084586
|
£330.33
|
£396.40
|
|
|
1.1 - INDUCTOR 230 V
MAF-084615.A3
084615
|
£247.75
|
£297.30
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-203849.A10
203849
|
£102.66
|
£123.19
|
|
|
2 - ARMATURE 240v
MAF-088197.A5
088197
|
£365.95
|
£439.14
|
|
|
5 - BRAKE LEVER, CPL.
MAF-201122.A34
201122
|
-
|
|
|
|
6 - PART NAME NOT AVAILABLE
MAF-204568.A0
204568
|
-
|
|
|
|
8 - TENSIONING LEVER
MAF-039806.A2
039806
|
£7.81
|
£9.37
|
|
|
11 - COVER
MAF-204198.A1
204198
|
-
|
|
|
|
12 - BASE PLATE
MAF-202180.A1
202180
|
-
|
|
|
|
13 - CASING
MAF-202182.A6
202182
|
£375.48
|
£450.57
|
|
|
14 - CASING COVER
MAF-202184.A5
202184
|
-
|
|
|
|
15 - GEAR CASING
MAF-203839.A0
203839
|
-
|
|
|
|
16 - TILTING SUPPORT, ASSEMBLED
MAF-202188.A10
202188
|
£364.98
|
£437.98
|
|
|
16.2 - VERTICAL GUIDEWAY
MAF-202189.A11
202189
|
£82.11
|
£98.53
|
|
|
17 - PROTECTIVE COVER
MAF-202511.A4
202511
|
-
|
|
|
|
18 - PART NAME NOT AVAILABLE
MAF-204579.A2
204579
|
-
|
|
|
|
19 - SEGMENT FOR TILTING, REAR
MAF-202196.A12
202196
|
-
|
|
|
|
21 - ANGLE SCALE
MAF-077091.A7
077091
|
-
|
|
|
|
23 - PART NAME NOT AVAILABLE
MAF-204217.A12
204217
|
-
|
|
|
|
24 - SWITCH LEVER
MAF-204216.A11
204216
|
-
|
|
|
|
25 - LOCKING LEVER
MAF-201745.A46
201745
|
£6.32
|
£7.58
|
|
|
26 - FAN
MAF-039182.A23
039182
|
£19.45
|
£23.34
|
|
|
27 - MOTOR COVER
MAF-203862.A7
203862
|
-
|
|
|
|
28 - HANDLE
MAF-033468.A8
033468
|
-
|
|
|
|
29 - SLIDING BLOCK
MAF-201129.A1
201129
|
-
|
|
|
|
30 - AIR CONDUCTING RING
MAF-202201.A20
202201
|
-
|
|
|
|
31 - LOCKING BOLT
MAF-202202.A0
202202
|
-
|
|
|
|
32 - HOSE CONNECTOR
MAF-202203.A3
202203
|
-
|
|
|
|
33 - LEVER
MAF-202204.A9
202204
|
-
|
|
|
|
34 - PAD
MAF-201872.A66
201872
|
-
|
|
|
|
35 - BOW HANDLE
MAF-202224.A0
202224
|
£19.48
|
£23.37
|
|
|
36 - PART NAME NOT AVAILABLE
MAF-204562.A0
204562
|
-
|
|
|
|
37 - SETTING WHEEL
MAF-203729.A26
203729
|
-
|
|
|
|
38 - WASHER
MAF-034731.A15
034731
|
-
|
|
|
|
39 - HANDLE INSERT
MAF-203860.A14
203860
|
-
|
|
|
|
40 - COVERING RING
MAF-202205.A3
202205
|
-
|
|
|
|
41 - FIXTURE
MAF-202206.A11
202206
|
-
|
|
|
|
42 - ROUE DENTÉE
MAF-202207.A9
202207
|
-
|
|
|
|
43 - INDICATOR
MAF-202208.A17
202208
|
-
|
|
|
|
44 - RIVING KNIFE/SPLITTER
MAF-202513.A3
202513
|
-
|
|
|
|
45 - DISTANCE SLEEVE
MAF-035272.A20
035272
|
-
|
|
|
|
46 - BRAKE DRUM
MAF-201138.A5
201138
|
-
|
|
|
|
47 - GUIDE PIECE
MAF-201149.A7
201149
|
-
|
|
|
|
48 - FLANGE, FRONT
MAF-202215.A0
202215
|
-
|
|
|
|
49 - FLANGE, REAR
MAF-202216.A4
202216
|
-
|
|
|
|
50 - ARBOR
MAF-202217.A12
202217
|
-
|
|
|
|
51 - SAW SHAFT
MAF-202222.A15
202222
|
£107.32
|
£128.78
|
|
|
52 - ROUE DENTÉE
MAF-204572.A0
204572
|
-
|
|
|
|
53 - SHOULDER BOLT
MAF-202227.A5
202227
|
-
|
|
|
|
54 - SHOULDER NUT
MAF-204210.A0
204210
|
-
|
|
|
|
56 - PART NAME NOT AVAILABLE
MAF-203835.A2
203835
|
-
|
|
|
|
59 - CABLE CLAMP
MAF-029584.A146
029584
|
-
|
|
|
|
60 - STOP BUFFER
MAF-034209.A19
034209
|
-
|
|
|
|
61 - BUFFER
MAF-037764.A18
037764
|
-
|
|
|
|
62 - HEXAGONAL NUT
MAF-201147.A13
201147
|
£7.80
|
£9.36
|
|
|
63 - SLEEVE
MAF-202225.A3
202225
|
-
|
|
|
|
64 - BOWDEN CABLE, CPL. (BLADE GUARD)
MAF-205494.A9
205494
|
£47.08
|
£56.49
|
|
|
65 - BOWDEN CABLE, CPL. (BRAKE)
MAF-202228.A20
202228
|
£50.43
|
£60.52
|
|
|
66 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A92
053020
|
£2.11
|
£2.53
|
|
|
68 - CYLINDER-HEAD SCREW
MAF-005590.A13
005590
|
-
|
|
|
|
69 - CYLINDER-HEAD SCREW
MAF-055038.A25
055038
|
£2.78
|
£3.33
|
|
|
70 - CYLINDER-HEAD SCREW
MAF-055044.A21
055044
|
-
|
|
|
|
71 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A196
055061
|
£1.79
|
£2.15
|
|
|
72 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A96
055062
|
-
|
|
|
|
73 - SHOULDER SCREW
MAF-055063.A18
055063
|
-
|
|
|
|
75 - OVAL-HEAD SCREW
MAF-055101.A57
055101
|
£2.14
|
£2.57
|
|
|
76 - OVAL-HEAD SCREW
MAF-055258.A16
055258
|
£1.73
|
£2.08
|
|
|
78 - OVAL-HEAD SCREW
MAF-055129.A20
055129
|
-
|
|
|
|
79 - OVAL-HEAD SCREW
MAF-055068.A34
055068
|
-
|
|
|
|
80 - SHOULDER SCREW
MAF-055118.A51
055118
|
£2.52
|
£3.03
|
|
|
81 - PART NAME NOT AVAILABLE
MAF-061182.A4
061182
|
-
|
|
|
|
82 - SHIM RING
MAF-061152.A9
061152
|
-
|
|
|
|
83 - HEXAGON-HEAD SCREW
MAF-005683.A20
005683
|
-
|
|
|
|
84 - HEXAGON-HEAD SCREW
MAF-005697.A20
005697
|
-
|
|
|
|
85 - TRUSS-HEAD SCREW
MAF-005726.A11
005726
|
-
|
|
|
|
86 - TRUSS-HEAD SCREW
MAF-057042.A15
057042
|
-
|
|
|
|
88 - THREADED PIN
MAF-005256.A9
005256
|
-
|
|
|
|
89 - RIBBED PIN
MAF-005881.A11
005881
|
-
|
|
|
|
90 - CYLINDRICAL PIN
MAF-058021.A23
058021
|
-
|
|
|
|
92 - HEXAGONAL NUT
MAF-005920.A44
005920
|
-
|
|
|
|
93 - SQUARE NUT
MAF-005953.A56
005953
|
-
|
|
|
|
94 - LOCKING NUT
MAF-005970.A25
005970
|
-
|
|
|
|
95 - LOCKING NUT
MAF-005999.A42
005999
|
-
|
|
|
|
96 - CAP NUT
MAF-005934.A12
005934
|
-
|
|
|
|
97 - CAP NUT
MAF-005946.A2
005946
|
-
|
|
|
|
98 - WASHER
MAF-061013.A89
061013
|
-
|
|
|
|
99 - WASHER
MAF-006102.A88
006102
|
-
|
|
|
|
100 - LOCKING WASHER
MAF-006113.A63
006113
|
£2.02
|
£2.43
|
|
|
101 - RETAINING RING
MAF-006167.A2
006167
|
-
|
|
|
|
102 - LOCKING WASHER
MAF-006184.A61
006184
|
£1.58
|
£1.89
|
|
|
103 - WASHER
MAF-061044.A52
061044
|
£1.73
|
£2.08
|
|
|
104 - SHIM RING
MAF-061071.A15
061071
|
-
|
|
|
|
105 - RETAINING RING
MAF-061072.A17
061072
|
-
|
|
|
|
106 - LOCKING WASHER
MAF-061073.A43
061073
|
-
|
|
|
|
107 - LOCKING WASHER
MAF-061005.A24
061005
|
-
|
|
|
|
108 - LOCKING WASHER
MAF-061145.A12
061145
|
-
|
|
|
|
109 - LOCKING WASHER
MAF-061069.A56
061069
|
£1.57
|
£1.88
|
|
|
110 - SHIM RING
MAF-061164.A6
061164
|
-
|
|
|
|
111 - GROOVED BALL BEARING
MAF-006260.A59
006260
|
£19.06
|
£22.87
|
|
|
112 - GROOVED BALL BEARING
MAF-006280.A63
006280
|
£14.33
|
£17.20
|
|
|
113 - GROOVED BALL BEARING
MAF-006269.A32
006269
|
-
|
|
|
|
114 - GROOVED BALL BEARING
MAF-062073.A99
062073
|
£15.00
|
£18.00
|
|
|
115 - GROOVED BALL BEARING
MAF-062018.A27
062018
|
£27.36
|
£32.83
|
|
|
116 - GROOVED BALL BEARING
MAF-006294.A12
006294
|
£15.89
|
£19.07
|
|
|
117 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063180.A10
063180
|
£15.98
|
£19.17
|
|
|
118 - BRUSH HOLDER
MAF-063157.A11
063157
|
-
|
|
|
|
119 - SEALING RING
MAF-006591.A35
006591
|
£1.73
|
£2.08
|
|
|
120 - RETRACTING SPRING
MAF-035025.A11
035025
|
-
|
|
|
|
121 - CUP SPRING
MAF-066132.A5
066132
|
-
|
|
|
|
122 - PRESSURE SPRING
MAF-066043.A119
066043
|
£3.19
|
£3.83
|
|
|
123 - PRESSURE SPRING
MAF-066053.A29
066053
|
£2.67
|
£3.20
|
|
|
124 - CUP SPRING
MAF-066021.A18
066021
|
-
|
|
|
|
125 - RETRACTING SPRING
MAF-066112.A33
066112
|
£5.80
|
£6.96
|
|
|
126 - TORSION SPRING
MAF-066122.A13
066122
|
-
|
|
|
|
127 - ADHESIVE LABEL
MAF-070669.A10
070669
|
-
|
|
|
|
128 - ADHESIVE LABEL
MAF-070559.A0
070559
|
-
|
|
|
|
130 - WING NUT
MAF-065023.A5
065023
|
-
|
|
|
|
131 - HANDLE
MAF-038970.A49
038970
|
£8.78
|
£10.53
|
|
|
132 - WING SCREW
MAF-079070.A12
079070
|
-
|
|
|
|
133 - NAME PLATE
MAF-201166.A55
201166
|
£8.54
|
£10.25
|
|
|
135 - CABLE PROTECTING SLEEVE
MAF-086065.A71
086065
|
£3.63
|
£4.36
|
|
|
137 - 2-POLE SWITCH
MAF-087599.A27
087599
|
£53.30
|
£63.96
|
|
|
138 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A55
087612
|
£76.11
|
£91.33
|
|
|
139 - CONNECTING CABLE
MAF-087874.A5
087874
|
-
|
|
|
|
140 - PART NAME NOT AVAILABLE
MAF-070666.A1
070666
|
-
|
|
|
|
141 - CONNECTING CABLE
MAF-085176.A12
085176
|
£7.03
|
£8.44
|
|
|
142 - SEALING RING
MAF-006580.A9
006580
|
-
|
|
|
|
143 - TCT SAW BLADE
MAF-092526.A2
092526
|
£171.32
|
£205.58
|
|
|
501 - PARALLEL GUIDE FENCE
MAF-202523.A0
202523
|
-
|
|
|
|
505 - ALLEN KEY
MAF-093081.A11
093081
|
-
|
|
|
