1 - MOTOR CASING WITH INDUCTOR
MAF-084652.A3
084652
|
-
|
|
|
|
1.1 - MOTOR CASING
MAF-205160.A4
205160
|
-
|
|
|
|
1.2 - INDUCTOR
MAF-084654.A5
084654
|
-
|
|
|
|
2 - ARMATURE BALANCED
MAF-088222.A3
088222
|
-
|
|
|
|
3 - LEVER JOINT
MAF-205143.A4
205143
|
-
|
|
|
|
4 - BEARING COVER
MAF-205147.A4
205147
|
-
|
|
|
|
5 - TENSIONING LEVER
MAF-205298.A5
205298
|
-
|
|
|
|
6 - CONTROL MODULE
MAF-077674.A3
077674
|
£130.23
|
£156.28
|
|
|
7 - BRUSH HOLDER
MAF-063148.A59
063148
|
£10.82
|
£12.98
|
|
|
8 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063176.A16
063176
|
£17.38
|
£20.86
|
|
|
9 - SEGMENT FOR TILTING
MAF-205148.A3
205148
|
-
|
|
|
|
10 - SEGMENT FOR TILTING
MAF-205149.A5
205149
|
-
|
|
|
|
12 - CLAMPING UNIT
MAF-205291.A4
205291
|
-
|
|
|
|
14 - GEAR CASING
MAF-205130.A3
205130
|
-
|
|
|
|
15 - BASE PLATE
MAF-205125.A1
205125
|
-
|
|
|
|
16 - TILTING SUPPORT
MAF-205128.A5
205128
|
£121.58
|
£145.89
|
|
|
17 - PROTECTIVE COVER
MAF-205139.A4
205139
|
£78.77
|
£94.52
|
|
|
20 - PUSH-BUTTON
MAF-205161.A4
205161
|
-
|
|
|
|
21 - HANDLE SHELL
MAF-205178.A4
205178
|
-
|
|
|
|
22 - HANDLE SHELL
MAF-205179.A5
205179
|
-
|
|
|
|
23 - HANDLE SHELL COVER
MAF-204513.A22
204513
|
£12.35
|
£14.82
|
|
|
24 - HANDLE INSERT
MAF-203877.A35
203877
|
£20.10
|
£24.12
|
|
|
25 - MOTOR COVER
MAF-205159.A3
205159
|
-
|
|
|
|
26 - SWIVEL RAIL
MAF-205167.A5
205167
|
-
|
|
|
|
27 - SWIVEL RAIL
MAF-205296.A5
205296
|
-
|
|
|
|
28 - PROTECTIVE COVER
MAF-206200.A
206200
|
-
|
|
|
|
29 - DEPTH SETTING
MAF-205151.A3
205151
|
-
|
|
|
|
30 - AIR CONDUCTING RING
MAF-205162.A3
205162
|
-
|
|
|
|
31 - COVER
MAF-205169.A4
205169
|
-
|
|
|
|
32 - FAN
MAF-205164.A4
205164
|
-
|
|
|
|
33 - HANDLE
MAF-205308.A9
205308
|
£15.68
|
£18.81
|
|
|
34 - PANEL
MAF-205155.A5
205155
|
-
|
|
|
|
35 - LEVER
MAF-205171.A4
205171
|
-
|
|
|
|
36 - SWITCH TRIGGER
MAF-205154.A5
205154
|
-
|
|
|
|
37 - INSULATING PLATE
MAF-202357.A10
202357
|
-
|
|
|
|
38 - LOCKING LEVER
MAF-206382.A4
206382
|
-
|
|
|
|
39 - PROTECTIVE DISK
MAF-205168.A3
205168
|
-
|
|
|
|
40 - PLUNGE LEVER HANDLE
MAF-205156.A3
205156
|
£13.12
|
£15.75
|
|
|
41 - PUSH-BUTTON
MAF-205180.A5
205180
|
£12.40
|
£14.88
|
|
|
42 - BRAKE LEVER
MAF-205142.A4
205142
|
-
|
|
|
|
43 - LOCKING LEVER
MAF-205158.A12
205158
|
-
|
|
|
|
44 - LOCK-OFF BUTTON
MAF-204510.A19
204510
|
£12.05
|
£14.46
|
|
|
45 - INDICATOR
MAF-205292.A3
205292
|
-
|
|
|
|
46 - HOSE CONNECTOR
MAF-205290.A10
205290
|
£19.09
|
£22.91
|
|
|
49 - RIVING KNIFE/SPLITTER SUPPORT
MAF-205138.A3
205138
|
-
|
|
|
|
50 - RIVING KNIFE/SPLITTER
MAF-205141.A3
205141
|
-
|
|
|
|
51 - CLAMPING LEVER
MAF-205152.A4
205152
|
-
|
|
|
|
52 - RATCHET
MAF-205175.A5
205175
|
-
|
|
|
|
55 - BRAKE DRUM
MAF-202353.A6
202353
|
-
|
|
|
|
56 - GUIDE COLUMN
MAF-205173.A3
205173
|
-
|
|
|
|
57 - GUIDE COLUMN
MAF-205174.A5
205174
|
-
|
|
|
|
58 - SAW SHAFT
MAF-205132.A3
205132
|
-
|
|
|
|
59 - SHOULDER NUT
MAF-205294.A12
205294
|
-
|
|
|
|
60 - FLANGE, REAR
MAF-202352.A13
202352
|
-
|
|
|
|
61 - SHAFT AXLE
MAF-205172.A4
205172
|
-
|
|
|
|
62 - FLANGE DISK
MAF-202351.A5
202351
|
-
|
|
|
|
63 - STOP PLATE
MAF-205153.A11
205153
|
-
|
|
|
|
66 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055111.A23
055111
|
-
|
|
|
|
67 - OVAL-HEAD SCREW
MAF-055258.A15
055258
|
£1.73
|
£2.08
|
|
|
68 - OVAL-HEAD SCREW
MAF-055257.A27
055257
|
-
|
|
|
|
69 - SELF-TAPPING SCREW
MAF-055230.A65
055230
|
-
|
|
|
|
70 - SELF-TAPPING SCREW
MAF-055232.A54
055232
|
£1.77
|
£2.12
|
|
|
71 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055269.A4
055269
|
-
|
|
|
|
72 - CYLINDER-HEAD SCREW
MAF-055234.A33
055234
|
£1.25
|
£1.50
|
|
|
74 - CYLINDER-HEAD SCREW
MAF-055113.A13
055113
|
£2.78
|
£3.33
|
|
|
75 - HEXAGON-HEAD SCREW
MAF-056031.A11
056031
|
-
|
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-055236.A10
055236
|
£2.76
|
£3.31
|
|
|
77 - CYLINDER-HEAD SCREW
MAF-055055.A34
055055
|
£3.39
|
£4.07
|
|
|
79 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055246.A14
055246
|
-
|
|
|
|
80 - OVAL-HEAD SCREW
MAF-055264.A14
055264
|
-
|
|
|
|
81 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A194
055061
|
£1.79
|
£2.15
|
|
|
82 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055139.A21
055139
|
-
|
|
|
|
84 - THREADED PIN
MAF-052011.A32
052011
|
-
|
|
|
|
85 - THREADED PIN
MAF-005284.A89
005284
|
-
|
|
|
|
86 - THREADED PIN
MAF-005210.A4
005210
|
-
|
|
|
|
87 - LOCKING NUT
MAF-005986.A20
005986
|
-
|
|
|
|
88 - HEXAGON SAFETY NUT
MAF-059017.A14
059017
|
-
|
|
|
|
91 - CYLINDRICAL PIN
MAF-058019.A7
058019
|
-
|
|
|
|
92 - SPRING DOWEL SLEEVE
MAF-058229.A9
058229
|
-
|
|
|
|
93 - CYLINDRICAL PIN
MAF-058046.A24
058046
|
£2.98
|
£3.57
|
|
|
95 - CYLINDRICAL PIN
MAF-058225.A3
058225
|
-
|
|
|
|
97 - CUP SPRING
MAF-066165.A9
066165
|
-
|
|
|
|
98 - WASHER
MAF-061013.A107
061013
|
-
|
|
|
|
99 - LOCKING WASHER
MAF-061069.A85
061069
|
£1.57
|
£1.88
|
|
|
100 - WASHER
MAF-006101.A142
006101
|
£1.80
|
£2.16
|
|
|
101 - WASHER
MAF-034208.A15
034208
|
-
|
|
|
|
102 - LOCKING WASHER
MAF-061135.A29
061135
|
-
|
|
|
|
103 - SHIM RING
MAF-006160.A45
006160
|
£1.73
|
£2.08
|
|
|
104 - COMPENSATING DISK
MAF-006671.A11
006671
|
£2.14
|
£2.57
|
|
|
105 - SHIM RING
MAF-006127.A10
006127
|
-
|
|
|
|
107 - SNAP RING
MAF-061160.A12
061160
|
-
|
|
|
|
108 - RETAINING RING
MAF-061133.A6
061133
|
£3.46
|
£4.15
|
|
|
109 - SEALING RING
MAF-078173.A24
078173
|
-
|
|
|
|
110 - SEALING RING
MAF-065064.A3
065064
|
-
|
|
|
|
113 - PRESSURE SPRING
MAF-066096.A32
066096
|
£4.47
|
£5.36
|
|
|
114 - PRESSURE SPRING
MAF-006645.A13
006645
|
-
|
|
|
|
115 - PRESSURE SPRING
MAF-066177.A4
066177
|
-
|
|
|
|
117 - PRESSURE SPRING
MAF-006684.A4
006684
|
-
|
|
|
|
118 - PRESSURE SPRING
MAF-066043.A130
066043
|
£3.19
|
£3.83
|
|
|
119 - RETRACTING SPRING
MAF-066090.A32
066090
|
-
|
|
|
|
120 - RETRACTING SPRING
MAF-066134.A4
066134
|
£5.72
|
£6.86
|
|
|
121 - RETRACTING SPRING
MAF-066092.A29
066092
|
£5.22
|
£6.27
|
|
|
122 - LEG SPRING
MAF-066167.A3
066167
|
-
|
|
|
|
123 - LEG SPRING
MAF-066174.A4
066174
|
-
|
|
|
|
124 - CUP SPRING
MAF-066016.A29
066016
|
£1.82
|
£2.19
|
|
|
125 - FRAME
MAF-205144.A5
205144
|
-
|
|
|
|
128 - GROOVED BALL BEARING
MAF-062073.A90
062073
|
£15.00
|
£18.00
|
|
|
129 - GROOVED BALL BEARING
MAF-006268.A19
006268
|
£16.07
|
£19.28
|
|
|
130 - GROOVED BALL BEARING
MAF-006282.A74
006282
|
£15.42
|
£18.50
|
|
|
133 - BOWDEN CABLE
MAF-205286.A5
205286
|
£12.12
|
£14.55
|
|
|
134 - LABEL SELECTION OF SAW BLADES
MAF-205297.A5
205297
|
-
|
|
|
|
135 - RUBBER BUFFER
MAF-205289.A5
205289
|
-
|
|
|
|
136 - PRESSURE BIT
MAF-202378.A38
202378
|
-
|
|
|
|
138 - STOP BUFFER
MAF-034209.A30
034209
|
-
|
|
|
|
139 - BRAKE LINING
MAF-205176.A3
205176
|
-
|
|
|
|
140 - HOOK-AND-LOOP FASTENER BELT
MAF-205049.A23
205049
|
£5.66
|
£6.79
|
|
|
144 - WING SCREW
MAF-079091.A10
079091
|
-
|
|
|
|
146 - TCT SAW BLADE
MAF-092590.A4
092590
|
-
|
|
|
|
147 - CABLE PROTECTING SLEEVE
MAF-086064.A115
086064
|
£3.53
|
£4.24
|
|
|
148 - 2-POLE SWITCH WITH LOCK-OFF BUTTON
MAF-087862.A3
087862
|
-
|
|
|
|
149 - CABLE CLAMP
MAF-205672.A5
205672
|
-
|
|
|
|
150 - MAINS CABLE WITH PLUG
MAF-087888.A4
087888
|
-
|
|
|
|
201 - SETTING WHEEL
MAF-203729.A45
203729
|
-
|
|
|
|
202 - SEALING RING
MAF-065004.A64
065004
|
£1.72
|
£2.06
|
|
|
510 - ALLEN KEY
MAF-093034.A76
093034
|
-
|
|
|
|
530 - PARALLEL GUIDE FENCE
MAF-205323.A1
205323
|
-
|
|
|
|
531 - CARRYING CASE
MAF-095167.A
095167
|
-
|
|
|
|
532 - PLASTIC TRAY
MAF-095168.A
095168
|
-
|
|
|
|
537 - SUPPORT
MAF-205299.A
205299
|
-
|
|
|
|
538 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055205.A1
055205
|
-
|
|
|
