1 - MOTOR CASING WITH INDUCTOR
MAF-084507.A6
084507
|
-
|
|
|
|
1.1 - INDUCTOR WITH COIL
MAF-084508.A6
084508
|
£261.93
|
£314.32
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-203635.A30
203635
|
£96.30
|
£115.56
|
|
|
2 - ARMATURE, BALANCED
MAF-088153.A1
088153
|
-
|
|
|
|
3 - TACHOMETER CARRIER
MAF-038975.A53
038975
|
£20.14
|
£24.17
|
|
|
4 - CONTROL MODULE
MAF-077142.A6
077142
|
£181.20
|
£217.44
|
|
|
5 - BRAKE LEVER, CPL.
MAF-201122.A30
201122
|
-
|
|
|
|
6 - GEAR SHAFT, CPL.
MAF-202214.A0
202214
|
-
|
|
|
|
8 - TENSIONING LEVER
MAF-039806.A25
039806
|
£7.43
|
£8.92
|
|
|
12 - BASE PLATE
MAF-202180.A6
202180
|
-
|
|
|
|
13 - CASING
MAF-202182.A9
202182
|
£357.59
|
£429.11
|
|
|
14 - CASING COVER
MAF-202184.A0
202184
|
-
|
|
|
|
15 - GEAR CASING
MAF-202186.A1
202186
|
-
|
|
|
|
16 - TILTING SUPPORT, ASSEMBLED
MAF-202188.A3
202188
|
£347.60
|
£417.12
|
|
|
17 - PROTECTIVE COVER
MAF-202192.A5
202192
|
-
|
|
|
|
18 - PART NAME NOT AVAILABLE
MAF-204661.A1
204661
|
-
|
|
|
|
19 - SEGMENT FOR TILTING, REAR
MAF-202196.A8
202196
|
-
|
|
|
|
23 - HANDLE SHELLS (PAIR)
MAF-202518.A16
202518
|
-
|
|
|
|
24 - SWITCH LEVER
MAF-201114.A32
201114
|
£13.23
|
£15.88
|
|
|
25 - LOCKING LEVER
MAF-201745.A53
201745
|
£6.02
|
£7.22
|
|
|
26 - FAN
MAF-039182.A28
039182
|
£18.52
|
£22.23
|
|
|
27 - MOTOR COVER
MAF-039174.A12
039174
|
-
|
|
|
|
28 - HANDLE
MAF-033468.A17
033468
|
-
|
|
|
|
29 - SLIDING BLOCK
MAF-201129.A15
201129
|
-
|
|
|
|
30 - AIR CONDUCTING RING
MAF-202201.A4
202201
|
-
|
|
|
|
31 - LOCKING BOLT
MAF-202202.A20
202202
|
-
|
|
|
|
32 - HOSE CONNECTOR
MAF-202203.A4
202203
|
-
|
|
|
|
33 - LEVER
MAF-202204.A13
202204
|
-
|
|
|
|
34 - PAD
MAF-201872.A55
201872
|
-
|
|
|
|
35 - BOW HANDLE
MAF-202224.A13
202224
|
£18.55
|
£22.26
|
|
|
36 - END CAP
MAF-202229.A5
202229
|
-
|
|
|
|
38 - WASHER
MAF-034731.A8
034731
|
-
|
|
|
|
40 - COVERING RING
MAF-202205.A4
202205
|
-
|
|
|
|
41 - FIXTURE
MAF-202206.A8
202206
|
-
|
|
|
|
42 - ROUE DENTÉE
MAF-202207.A15
202207
|
-
|
|
|
|
43 - INDICATOR
MAF-202208.A4
202208
|
-
|
|
|
|
44 - RIVING KNIFE/SPLITTER
MAF-202209.A1
202209
|
-
|
|
|
|
45 - DISTANCE SLEEVE
MAF-035272.A10
035272
|
-
|
|
|
|
46 - BRAKE DRUM
MAF-201138.A10
201138
|
-
|
|
|
|
47 - GUIDE PIECE
MAF-201149.A4
201149
|
-
|
|
|
|
48 - FLANGE, FRONT
MAF-202215.A3
202215
|
-
|
|
|
|
49 - FLANGE, REAR
MAF-202216.A1
202216
|
-
|
|
|
|
50 - ARBOR
MAF-202217.A10
202217
|
-
|
|
|
|
51 - SAW SHAFT
MAF-202222.A11
202222
|
£102.21
|
£122.65
|
|
|
52 - ROUE DENTÉE
MAF-202223.A2
202223
|
-
|
|
|
|
53 - SHOULDER BOLT
MAF-202227.A2
202227
|
-
|
|
|
|
54 - BOLT
MAF-202231.A5
202231
|
-
|
|
|
|
55 - GUIDE BAR
MAF-202232.A9
202232
|
£27.12
|
£32.55
|
|
|
56 - SHOULDER NUT
MAF-202234.A2
202234
|
-
|
|
|
|
57 - GUIDE FENCE EXTENSION
MAF-202233.A3
202233
|
-
|
|
|
|
59 - CABLE CLAMP
MAF-029584.A112
029584
|
-
|
|
|
|
60 - STOP BUFFER
MAF-034209.A31
034209
|
-
|
|
|
|
61 - BUFFER
MAF-037764.A17
037764
|
-
|
|
|
|
62 - HEXAGONAL NUT
MAF-201147.A21
201147
|
£7.42
|
£8.91
|
|
|
63 - SLEEVE
MAF-202225.A2
202225
|
-
|
|
|
|
64 - BOWDEN CABLE, CPL. (BLADE GUARD)
MAF-205494.A6
205494
|
£44.83
|
£53.80
|
|
|
65 - BOWDEN CABLE, CPL. (BRAKE)
MAF-202228.A19
202228
|
£48.03
|
£57.64
|
|
|
66 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A75
053020
|
£2.01
|
£2.41
|
|
|
67 - CYLINDER-HEAD SCREW
MAF-005505.A26
005505
|
-
|
|
|
|
69 - CYLINDER-HEAD SCREW
MAF-055038.A12
055038
|
£2.64
|
£3.17
|
|
|
70 - CYLINDER-HEAD SCREW
MAF-055044.A5
055044
|
-
|
|
|
|
71 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A179
055061
|
£1.71
|
£2.05
|
|
|
72 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A83
055062
|
-
|
|
|
|
73 - SHOULDER SCREW
MAF-055063.A30
055063
|
-
|
|
|
|
74 - CYLINDER-HEAD SCREW
MAF-055059.A18
055059
|
-
|
|
|
|
75 - OVAL-HEAD SCREW
MAF-055101.A35
055101
|
£2.04
|
£2.45
|
|
|
76 - OVAL-HEAD SCREW
MAF-055114.A37
055114
|
-
|
|
|
|
77 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A35
055124
|
-
|
|
|
|
78 - OVAL-HEAD SCREW
MAF-055129.A31
055129
|
-
|
|
|
|
79 - OVAL-HEAD SCREW
MAF-055068.A35
055068
|
-
|
|
|
|
80 - SHOULDER SCREW
MAF-055118.A37
055118
|
£2.41
|
£2.89
|
|
|
83 - HEXAGON-HEAD SCREW
MAF-005683.A5
005683
|
-
|
|
|
|
84 - HEXAGON-HEAD SCREW
MAF-005697.A19
005697
|
-
|
|
|
|
85 - TRUSS-HEAD SCREW
MAF-005726.A6
005726
|
-
|
|
|
|
88 - THREADED PIN
MAF-005230.A6
005230
|
-
|
|
|
|
90 - CYLINDRICAL PIN
MAF-058021.A16
058021
|
-
|
|
|
|
92 - HEXAGONAL NUT
MAF-005920.A42
005920
|
-
|
|
|
|
93 - SQUARE NUT
MAF-005953.A57
005953
|
-
|
|
|
|
94 - LOCKING NUT
MAF-005970.A24
005970
|
-
|
|
|
|
95 - LOCKING NUT
MAF-005999.A43
005999
|
-
|
|
|
|
96 - CAP NUT
MAF-005934.A14
005934
|
-
|
|
|
|
97 - CAP NUT
MAF-005946.A10
005946
|
-
|
|
|
|
99 - WASHER
MAF-006102.A69
006102
|
-
|
|
|
|
100 - LOCKING WASHER
MAF-006113.A62
006113
|
£1.92
|
£2.31
|
|
|
101 - RETAINING RING
MAF-006167.A9
006167
|
-
|
|
|
|
102 - LOCKING WASHER
MAF-006184.A74
006184
|
£1.50
|
£1.80
|
|
|
103 - WASHER
MAF-061044.A62
061044
|
£1.65
|
£1.98
|
|
|
104 - SHIM RING
MAF-061071.A2
061071
|
-
|
|
|
|
105 - RETAINING RING
MAF-061072.A19
061072
|
-
|
|
|
|
106 - LOCKING WASHER
MAF-061073.A34
061073
|
-
|
|
|
|
107 - LOCKING WASHER
MAF-061005.A16
061005
|
-
|
|
|
|
108 - LOCKING WASHER
MAF-061145.A1
061145
|
-
|
|
|
|
110 - SHIM RING
MAF-061164.A17
061164
|
-
|
|
|
|
111 - GROOVED BALL BEARING
MAF-006260.A67
006260
|
£18.15
|
£21.78
|
|
|
112 - GROOVED BALL BEARING
MAF-006280.A72
006280
|
£13.65
|
£16.38
|
|
|
113 - GROOVED BALL BEARING
MAF-006269.A9
006269
|
-
|
|
|
|
114 - GROOVED BALL BEARING
MAF-062073.A71
062073
|
£14.28
|
£17.14
|
|
|
115 - GROOVED BALL BEARING
MAF-062018.A32
062018
|
£26.06
|
£31.27
|
|
|
117 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063147.A30
063147
|
£14.72
|
£17.67
|
|
|
118 - BRUSH HOLDER
MAF-063148.A53
063148
|
£10.30
|
£12.36
|
|
|
120 - RETRACTING SPRING
MAF-035025.A13
035025
|
-
|
|
|
|
121 - CUP SPRING
MAF-066132.A14
066132
|
-
|
|
|
|
122 - PRESSURE SPRING
MAF-066043.A118
066043
|
£3.04
|
£3.65
|
|
|
123 - PRESSURE SPRING
MAF-066053.A37
066053
|
£2.54
|
£3.05
|
|
|
124 - CUP SPRING
MAF-066021.A4
066021
|
-
|
|
|
|
125 - RETRACTING SPRING
MAF-066112.A31
066112
|
£5.52
|
£6.63
|
|
|
126 - TORSION SPRING
MAF-066122.A5
066122
|
-
|
|
|
|
128 - ADHESIVE LABEL
MAF-070427.A0
070427
|
-
|
|
|
|
129 - DEPTH SCALE
MAF-077404.A0
077404
|
-
|
|
|
|
130 - WING NUT
MAF-065023.A15
065023
|
-
|
|
|
|
131 - STAR-SHAPED HANDLE
MAF-079046.A3
079046
|
-
|
|
|
|
132 - WING SCREW
MAF-079070.A25
079070
|
-
|
|
|
|
135 - CABLE PROTECTING SLEEVE
MAF-086065.A66
086065
|
£3.46
|
£4.15
|
|
|
136 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-087816.A5
087816
|
£17.15
|
£20.58
|
|
|
137 - 2-POLE SWITCH
MAF-087599.A36
087599
|
£50.76
|
£60.91
|
|
|
138 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A48
087612
|
£72.48
|
£86.98
|
|
|
139 - CONNECTING CABLE
MAF-087798.A8
087798
|
-
|
|
|
|
143 - TCT SAW BLADE
MAF-092525.A5
092525
|
£172.32
|
£206.79
|
|
|
505 - ALLEN KEY
MAF-093081.A22
093081
|
-
|
|
|
