1 - HANDLE COVER
BSD-1607000925.A21
1607000925
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-1604220354.A6
1604220354
|
£33.74
|
£40.49
|
|
|
3/50 - FAN
BSD-1606610122.A40
1606610122
|
£2.94
|
£3.53
|
|
|
4 - SWITCH
BSD-2607200169.A13
2607200169
|
-
|
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A44
2600703013
|
£2.74
|
£3.29
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1581
2600703012
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-2601035001.A940
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A122
1601110483
|
£2.74
|
£3.29
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A459
1607328028
|
£5.57
|
£6.68
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1037
2600905032
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-1610905009.A85
1610905009
|
£15.46
|
£18.55
|
|
|
16 - BRUSH HOLDER
BSD-3604336001.A31
3604336001
|
-
|
|
|
|
21 - MANUFACTURER'S NAMEPLATE
BSD-1601110605.A1
1601110605
|
£2.94
|
£3.53
|
|
|
22 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A120
2912401019
|
£1.84
|
£2.21
|
|
|
24 - PROTECTIVE COVER
BSD-1605510157.A38
1605510157
|
£15.46
|
£18.55
|
|
|
26 - BEARING COVER
BSD-1605808062.A16
1605808062
|
-
|
|
|
|
27 - INTERMEDIATE RING
BSD-1600221003.A87
1600221003
|
£2.74
|
£3.29
|
|
|
28 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A818
2603410001
|
£1.84
|
£2.21
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591007.A7
1600591007
|
£2.74
|
£3.29
|
|
|
31 - SEALING CAP
BSD-1605500158.A24
1605500158
|
-
|
|
|
|
32 - INTERMEDIATE RING
BSD-1600502011.A202
1600502011
|
£2.74
|
£3.29
|
|
|
33 - SLOTTED SPRING PIN 6x22 DIN7346
BSD-2917780150.A1
2917780150
|
£1.75
|
£2.10
|
|
|
34 - COVER STRIP
BSD-1601099021.A10
1601099021
|
-
|
|
|
|
34 - COVER STRIP
BSD-1601099014.A10
1601099014
|
-
|
|
|
|
35 - HANDLE COVER
BSD-1605500159.A2
1605500159
|
-
|
|
|
|
35 - HANDLE COVER
BSD-1605500155.A10
1605500155
|
-
|
|
|
|
36 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A127
2603435042
|
£1.75
|
£2.10
|
|
|
38 - MOUNTING PLATE
BSD-1600134005.A1
1600134005
|
-
|
|
|
|
39 - CONICAL SPRING WASHER SW 36
BSD-1605703079.A5
1605703079
|
-
|
|
|
|
40 - CONICAL SPRING WASHER dia 30 MM
BSD-1605703080.A11
1605703080
|
-
|
|
|
|
41 - THREAD-FORMING TAP. SCREW DIN 7500-M 4x12
BSD-2914491409.A13
2914491409
|
£1.66
|
£1.99
|
|
|
42 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A464
1900905163
|
£11.30
|
£13.56
|
|
|
43 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A503
2916660014
|
£1.75
|
£2.10
|
|
|
44 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A204
1603414007
|
£2.29
|
£2.75
|
|
|
45 - CYLINDRICAL GEAR Z=41
BSD-1606320076.A31
1606320076
|
-
|
|
|
|
46 - DRIVE SHAFT M6. dia16 MM
BSD-1603124112.A11
1603124112
|
-
|
|
|
|
47 - EXTENSION SPRING
BSD-1604649001.A17
1604649001
|
-
|
|
|
|
48 - NOZZLE SOCKET
BSD-1600910019.A26
1600910019
|
£3.51
|
£4.21
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-AM4x5-5.8
BSD-2910011115.A17
2910011115
|
£1.75
|
£2.10
|
|
|
50 - GUIDE BUSHING
BSD-1600309011.A9
1600309011
|
-
|
|
|
|
51 - BASE PLATE 358x151 MM
BSD-1608000107.A16
1608000107
|
-
|
|
|
|
52 - RUBBER BUFFER
BSD-1600305001.A24
1600305001
|
£1.75
|
£2.10
|
|
|
53 - SPACER BUSHING
BSD-1600309012.A23
1600309012
|
£1.84
|
£2.21
|
|
|
54 - RIVING KNIFE
BSD-1600025013.A14
1600025013
|
£3.34
|
£4.01
|
|
|
55 - WING NUT M6
BSD-1603339006.A204
1603339006
|
£2.64
|
£3.17
|
|
|
57 - PAN HEAD SCREW M6x170 MM
BSD-1603434005.A1
1603434005
|
-
|
|
|
|
58 - ADJUSTING PLATE
BSD-1601329015.A0
1601329015
|
£2.05
|
£2.46
|
|
|
61 - SPACER RING
BSD-1600201014.A11
1600201014
|
-
|
|
|
|
62 - THRUST MEMBER
BSD-1608040112.A2
1608040112
|
-
|
|
|
|
63 - WING SCREW
BSD-1603480022.A15
1603480022
|
-
|
|
|
|
64 - ROUND-HEAD BOLT DIN 603-M6x35
BSD-2910281207.A3
2910281207
|
£1.84
|
£2.21
|
|
|
65 - AUXILIARY HANDLE
BSD-1605133039.A24
1605133039
|
£8.92
|
£10.70
|
|
|
66 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A133
1907950006
|
£4.48
|
£5.37
|
|
|
67 - SUPPRESSOR BOX
BSD-1604503014.A23
1604503014
|
-
|
|
|
|
68 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A189
1600290016
|
£2.74
|
£3.29
|
|
|
69 - LOCKING RING
BSD-1600390013.A2
1600390013
|
£5.26
|
£6.31
|
|
|
70 - BLADE TERMINAL
BSD-1604477005.A179
1604477005
|
£2.74
|
£3.29
|
|
|
73 - COMPRESSION SPRING
BSD-1604611029.A10
1604611029
|
£1.38
|
£1.66
|
|
|
74 - THREAD-FORMING TAP. SCREW TT M5x30 MM
BSD-1603435022.A33
1603435022
|
£1.75
|
£2.10
|
|
|
77 - PAN HEAD SCREW DIN 923-M4x10-5.8
BSD-2910271120.A24
2910271120
|
£1.32
|
£1.58
|
|
|
80 - OVAL-HEAD SCREW DIN 7985-M6x16-4.8
BSD-2910641197.A2
2910641197
|
-
|
|
|
|
81 - STOPPING DEVICE
BSD-1603231011.A13
1603231011
|
-
|
|
|
|
82 - O-RING 46.0x1.1 MM
BSD-3600210124.A359
3600210124
|
£2.94
|
£3.53
|
|
|
83 - REFERENCE PLATE
BSD-1601110470.A79
1601110470
|
£1.84
|
£2.21
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014129.A38
1607014129
|
-
|
|
|
|
801 - SPIRAL SPRING
BSD-2604652008.A91
2604652008
|
-
|
|
|
|
803 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A439
1607000228
|
£23.86
|
£28.63
|
|
|
823 - COILED SPRING
BSD-1604651008.A5
1604651008
|
-
|
|
|
|
830 - ARMATURE WITH FAN 220-230V
BSD-1604010328.A7
1604010328
|
-
|
|
|
|
835 - HANDLE COVER
BSD-1607000925.A22
1607000925
|
-
|
|
|
|
836 - LOCKING LEVER
BSD-1602099003.A1
1602099003
|
-
|
|
|
|
837 - PIVOTING BLADE GUARD
BSD-1605510172.A16
1605510172
|
-
|
|
|
|
859 - PARTS SET
BSD-1607000197.A0
1607000197
|
-
|
|
|
|
872 - PARTS SET
BSD-1607000223.A14
1607000223
|
-
|
|
|
|
878 - PARTS SET
BSD-1607000192.A16
1607000192
|
-
|
|
|
|
878 - PARTS SET
BSD-1607000205.A32
1607000205
|
-
|
|
|
|
882 - SEALING DISK
BSD-1600135002.A16
1600135002
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1729
160111A3H3
|
£2.74
|
£3.29
|
|
