1 - ARMATURE COMPL. 230V
MET-316063520.A2
316063520
|
£63.36
|
£76.03
|
|
|
2 - FIELD COIL 230 V ELEC
MET-311009770.A20
311009770
|
£54.94
|
£65.93
|
|
|
3 - CABLE WITH PLUG
MET-344494010.A18
344494010
|
£22.96
|
£27.55
|
|
|
4 - CABLE SLEEVE
MET-344097360.A209
344097360
|
£2.94
|
£3.53
|
|
|
5 - CABLE CLIP
MET-343362490.A638
343362490
|
£3.20
|
£3.84
|
|
|
6 - SELF-TAP. FILL. H. SCREW
MET-141117060.A558
141117060
|
£3.20
|
£3.84
|
|
|
7 - STRAND COMPL.
MET-344498880.A41
344498880
|
£1.50
|
£1.80
|
|
|
8 - MOTOR HOUSING
MET-315013660.A61
315013660
|
£15.41
|
£18.49
|
|
|
9 - SWITCH ROD
MET-343430940.A32
343430940
|
£1.50
|
£1.80
|
|
|
10 - SWITCH SLIDE H/L
MET-343397810.A31
343397810
|
£1.50
|
£1.80
|
|
|
11 - BALL BEARING 6X19X6
MET-143115690.A73
143115690
|
£3.82
|
£4.59
|
|
|
12 - RUBBER BUSHING
MET-344097870.A448
344097870
|
£1.50
|
£1.80
|
|
|
13 - BAFFLE
MET-343436590.A35
343436590
|
£3.82
|
£4.59
|
|
|
15 - 2 PART MOTOR CAP
MET-343430910.A2
343430910
|
£11.78
|
£14.13
|
|
|
16 - SELF-TAP. FILL. H. SCREW
MET-141113180.A181
141113180
|
£1.50
|
£1.80
|
|
|
17 - FILLISTER HEAD SCREW
MET-141123490.A52
141123490
|
£1.50
|
£1.80
|
|
|
18 - O-RING
MET-143195470.A13
143195470
|
£1.50
|
£1.80
|
|
|
19 - BEARING FLANGE
MET-315202610.A14
315202610
|
£30.06
|
£36.07
|
|
|
20 - OPEN-END SPANNER
MET-344160400.A18
344160400
|
£6.38
|
£7.65
|
|
|
21 - SIDE SUPPORT HANDLE COMPL.
MET-314001030.A33
314001030
|
£17.55
|
£21.06
|
|
|
22 - HANDLE
MET-344099150.A20
344099150
|
£9.62
|
£11.54
|
|
|
23 - SPINDLE HEAD COMPL.
MET-316051720.A7
316051720
|
£79.43
|
£95.32
|
|
|
24 - ELECTRONIC UNIT 230V
MET-343082710.A3
343082710
|
£42.65
|
£51.18
|
|
|
25 - SWITCH
MET-343409640.A24
343409640
|
£9.62
|
£11.54
|
|
|
26 - BRUSH HOLDER COMPL. CUT OUT 230V
MET-316046890.A28
316046890
|
£15.42
|
£18.51
|
|
|
27 - CARBON BRUSH SET CUT-OFF
MET-316046900.A39
316046900
|
£15.41
|
£18.49
|
|
|
28 - COLLET 1/4 WITH FLANGE NUT(DOUBLE FLAT)
MET-630821000.A6
630821000
|
-
|
|
|
|
30 - GEAR PARTS COMPL.
MET-316063500.A7
316063500
|
£11.78
|
£14.13
|
|
|
31 - COLLET 6MM WITH FLANGE NUT (DOUBLE FLAT)
MET-630820000.A9
630820000
|
£22.49
|
£26.99
|
|
|
35 - RATING PLATE
MET-338058270.A0
338058270
|
-
|
|
|
|
36 - PART NOT NEEDED
MET-399999990.A1182
399999990
|
-
|
|
|
|
61 - SPINDLE HEAD COMPL.
MET-316065220.A22
316065220
|
£54.94
|
£65.93
|
|
|
62 - BALL BEARING
MET-143115930.A30
143115930
|
£9.62
|
£11.54
|
|
|
63 - BALL BEARING 10X30X9
MET-143111090.A45
143111090
|
£19.18
|
£23.02
|
|
|
64 - RETAINING RING
MET-141180370.A17
141180370
|
£1.50
|
£1.80
|
|
|
65 - PLANET CARRIER
MET-341071120.A13
341071120
|
£54.94
|
£65.93
|
|
|
66 - BUTTING WASHER
MET-341080230.A11
341080230
|
£2.94
|
£3.53
|
|
|
67 - NEEDLE ROLLER
MET-143115440.A10
143115440
|
£1.50
|
£1.80
|
|
|
68 - 3EEDLE ROLLER AND CAGE
MET-143115450.A9
143115450
|
£6.38
|
£7.65
|
|
|
69 - COMPENSATING WASHER
MET-143115490.A42
143115490
|
£1.50
|
£1.80
|
|
|
70 - COMPENSATING WASHER
MET-143115470.A41
143115470
|
£1.50
|
£1.80
|
|
|
71 - LUEFTER MIT STAUBSCHUTZKORB
MET-316051700.A16
316051700
|
£7.36
|
£8.83
|
|
|
75 - SPINDLE LOCK
MET-316059800.A35
316059800
|
£13.63
|
£16.36
|
|
|
98 - O-RING
MET-143195530.A43
143195530
|
£2.94
|
£3.53
|
|
|
880 - GREASE 100G
MET-344130920.A169
344130920
|
£19.18
|
£23.02
|
|
|
1001 - WIRING DIAGRAM
MET-338505710.A70
338505710
|
-
|
|
|
