1 - HANDLE CPL.
MET-314000540.A199
314000540
|
£15.41
|
£18.49
|
|
|
2 - SPINDLE STOP COMPL.
MET-316040610.A104
316040610
|
£4.76
|
£5.71
|
|
|
3 - GEAR HOUSING COMPL.
MET-316097510.A1
316097510
|
-
|
|
|
|
4 - HEXAGON NUT W.RECESS
MET-341100940.A241
341100940
|
£3.20
|
£3.84
|
|
|
5 - BEVEL GEAR AND PINION
MET-316097540.A9
316097540
|
-
|
|
|
|
6 - BALL BEARING 8X 22X 7
MET-143116020.A39
143116020
|
-
|
|
|
|
7 - WASHER
MET-339007940.A2
339007940
|
-
|
|
|
|
8 - SEALING WASHER
MET-343392740.A96
343392740
|
£6.38
|
£7.65
|
|
|
9 - BALL BEARING 6X19X6
MET-143115870.A18
143115870
|
£5.62
|
£6.75
|
|
|
10 - ARMATURE COMPL. 230V
MET-310012740.A6
310012740
|
-
|
|
|
|
11 - RUBBER BUSHING
MET-344095260.A114
344095260
|
£3.20
|
£3.84
|
|
|
12 - SELF-TAP FILL H SCREW
MET-141116020.A940
141116020
|
£3.20
|
£3.84
|
|
|
13 - COMPENSATING WASHER
MET-339060160.A72
339060160
|
£3.20
|
£3.84
|
|
|
14 - O-RING 48 X 1
MET-344097550.A14
344097550
|
£1.50
|
£1.80
|
|
|
15 - SPINDLE M10
MET-341166750.A5
341166750
|
-
|
|
|
|
16 - WASHER
MET-339007790.A70
339007790
|
-
|
|
|
|
18 - FLANGE COMPL.
MET-316097490.A0
316097490
|
-
|
|
|
|
19 - FILL. HEAD SCREW
MET-141120070.A30
141120070
|
£1.50
|
£1.80
|
|
|
20 - CLAMPING NUT
MET-341102050.A10
341102050
|
£7.36
|
£8.83
|
|
|
21 - CLAMPING FLANGE
MET-341031890.A21
341031890
|
£4.76
|
£5.71
|
|
|
22 - FILLISTER HEAD SCREW
MET-141124060.A64
141124060
|
-
|
|
|
|
23 - WHEEL GUARD COMPL. dia100
MET-339203650.A3
339203650
|
-
|
|
|
|
24 - BAFFLE
MET-339151280.A25
339151280
|
-
|
|
|
|
25 - FIELD COIL 230V
MET-311012790.A1
311012790
|
-
|
|
|
|
26 - RATING PLATE
MET-338071230.A0
338071230
|
-
|
|
|
|
27 - MOTOR HOUSING
MET-315013900.A8
315013900
|
-
|
|
|
|
28 - CARBON BRUSH COMPL.
MET-316097560.A9
316097560
|
£9.99
|
£11.99
|
|
|
29 - BRUSH HOLDER COMPL.
MET-316097620.A6
316097620
|
-
|
|
|
|
30 - SWITCH
MET-343408260.A79
343408260
|
£7.36
|
£8.83
|
|
|
31 - CAPACITOR
MET-343255170.A20
343255170
|
-
|
|
|
|
32 - CABLE CLIP
MET-343362490.A485
343362490
|
£3.20
|
£3.84
|
|
|
33 - MOTOR CAP
MET-343446370.A6
343446370
|
-
|
|
|
|
34 - SELF-TAP. FILL. H. SCREW
MET-141116800.A210
141116800
|
£1.50
|
£1.80
|
|
|
35 - SWITCH SLIDE RED
MET-343412110.A17
343412110
|
£2.94
|
£3.53
|
|
|
36 - SWITCH ROD
MET-343446390.A20
343446390
|
-
|
|
|
|
37 - METABO PLATE
MET-338122540.A57
338122540
|
£1.50
|
£1.80
|
|
|
38 - CABLE W.CHINESE PLUG
MET-344499630.A1
344499630
|
-
|
|
|
|
39 - CABLE SLEEVE
MET-343446380.A2
343446380
|
-
|
|
|
|
40 - PIN SPANNER
MET-344163930.A35
344163930
|
£3.82
|
£4.59
|
|
|
41 - FIXED BEARING COVER
MET-315420080.A8
315420080
|
-
|
|
|
|
42 - FILLISTER HEAD SCREW
MET-141110460.A19
141110460
|
£1.50
|
£1.80
|
|
|
880 - GREASE 100G
MET-344130910.A358
344130910
|
£19.18
|
£23.02
|
|
|
1001 - DIAGRAM
MET-338510270.A1
338510270
|
-
|
|
|
