Dewalt DWE396 Type 1 Universal Saw Spare Parts

An exploded drawing and spare parts listing for the Dewalt DWE396 Type 1 Universal Saw

	Ex VAT	Inc VAT
1 - HEX KEY BDE-322929.A21 322929	-
2 - LOOP HANDLE BDE-N097478.A5 N097478	£30.08	£36.10
3 - SCREW TORX BDE-324007-11.A147 324007-11	£1.50	£1.80
4 - SCREW.TEMP BDE-330019-21.A22 330019-21	£1.50	£1.80
5 - COVER RH BDE-N077126.A4 N077126	£3.80	£4.56
6 - BAR BDE-N233860.A0 N233860	£80.98	£97.18
7 - COVER LH BDE-N096981.A1 N096981	£3.80	£4.56
8 - LABEL BDE-N217152.A5 N217152	£1.50	£1.80
9 - FUNNEL BDE-N201132.A1 N201132	£2.78	£3.34
10 - CAP BDE-N092157.A0 N092157	£17.48	£20.97
11 - SCREW BDE-N125628.A1 N125628	£1.50	£1.80
12 - SCREW BDE-330065-06.A286 330065-06	£1.50	£1.80
13 - GRIP BDE-N127049.A5 N127049	£1.50	£1.80
14 - SPRING TORSION BDE-N119853.A4 N119853	£1.82	£2.19
15 - PIN BDE-N095820.A5 N095820	£4.69	£5.63
16 - SCREW BDE-N141827.A4 N141827	£1.50	£1.80
17 - CLAMP SA RH BDE-N915019.A2 N915019	£18.91	£22.69
20 - CLAMP SA LH BDE-N915018.A4 N915018	£24.39	£29.27
31 - SEAL BDE-N093430.A1 N093430	£4.69	£5.63
32 - BEARING BDE-N077123.A4 N077123	£12.17	£14.60
33 - O RING BDE-323711-41.A12 323711-41	£1.50	£1.80
34 - SHAFT BDE-N233863.A2 N233863	£74.15	£88.98
35 - BEARING SA BDE-N233864.A4 N233864	£12.17	£14.60
36 - SEAL BDE-N093431.A5 N093431	£3.80	£4.56
37 - GEARCASE COVER SA BDE-N233865.A0 N233865	£80.98	£97.18
38 - SCREW TORX BDE-324007-11.A146 324007-11	£1.50	£1.80
39 - O RING BDE-577744-00.A59 577744-00	£1.82	£2.19
40 - BEARING BDE-N077124.A1 N077124	£7.18	£8.62
41 - GEARCASE SA BDE-N233866.A3 N233866	£78.12	£93.74
42 - O RING BDE-N165967.A3 N165967	£1.50	£1.80
43 - BAFFLE FAN BDE-N097710.A3 N097710	£7.18	£8.62
44 - BEARING BDE-330003-64.A91 330003-64	£4.69	£5.63
45 - ARMATURE 120V LX BDE-N233868.A2 N233868	£99.47	£119.36
45 - ARMATURE 230V GB BDE-N233867.A0 N233867	£87.82	£105.39
46 - BEARING BDE-330003-60.A197 330003-60	£2.78	£3.34
47 - SCREW BDE-330065-21.A30 330065-21	£1.50	£1.80
48 - FIELD 115V LX BDE-N233870.A2 N233870	£65.52	£78.62
48 - FIELD 230V GB BDE-N233869.A0 N233869	£65.52	£78.62
49 - HOUSING MOTOR BDE-N088950.A0 N088950	£18.91	£22.69
50 - BRUSH HOLDER PAIR GB BDE-N233871.A0 N233871	£16.03	£19.24
50 - BRUSH HOLDER PAIR LX BDE-N233872.A2 N233872	£19.90	£23.88
62 - SLEEVE BDE-1007732-00.A10 1007732-00	£1.50	£1.80
64 - HOUSING BEARING BDE-N114803.A0 N114803	£2.26	£2.71
65 - SCREW BDE-330065-08.A355 330065-08	£1.50	£1.80
66 - SCREW BDE-324119-02.A117 324119-02	£1.50	£1.80
67 - END CAP BDE-N089033.A3 N089033	£7.85	£9.42
69 - SWITCH LOCK OFF BDE-N092849.A4 N092849	£2.78	£3.34
70 - CABLE GUIDE BDE-N113779.A3 N113779	£3.80	£4.56
71 - SPRING TORSION BDE-N097616.A0 N097616	£1.50	£1.80
72 - SWITCH LX BDE-N174721.A4 N174721	£30.08	£36.10
72 - SWITCH GB BDE-N174721.A5 N174721	£30.08	£36.10
73 - HANDLE SA BDE-N454961.A0 N454961	£12.17	£14.60
74 - CORD PROTECTOR BDE-584090-00.A96 584090-00	£1.50	£1.80
75 - CORD CLAMP BDE-329301-00.A56 329301-00	£1.50	£1.80
77 - CAPACITOR GB BDE-N127694.A0 N127694	£4.69	£5.63
77 - CAPACITOR LX BDE-N127694.A1 N127694	£4.69	£5.63
78 - CORDSET LX BDE-582319-51.A0 582319-51	£60.94	£73.13
78 - CORDSET GB BDE-582319-50.A2 582319-50	£37.35	£44.82
79 - SCREW BDE-N194430.A0 N194430	£1.50	£1.80
800 - GREASE 90 GMS BDE-870889-02.A748 870889-02	£7.85	£9.42
817 - LABEL BDE-N381771.A1 N381771	£1.50	£1.80
821 - RATING PLATE LX BDE-N195577 N195577	£1.50	£1.80
821 - RATING PLATE GB BDE-N195576 N195576	£1.50	£1.80
