1 - MOTOR HOUSING
BSD-3605108025.A10
3605108025
|
-
|
|
|
|
2 - STATOR 370W
BSD-3604090002.A62
3604090002
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220003.A11
3604220003
|
£81.81
|
£98.17
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A174
3605700005
|
£57.14
|
£68.57
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A14
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700009.A21
3605700009
|
-
|
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A1690
2600905032
|
£5.57
|
£6.68
|
|
|
9 - SPACER RING
BSD-2600202013.A168
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A23
2600202014
|
£11.87
|
£14.24
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A224
2916011012
|
£1.84
|
£2.21
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A31
2911061150
|
£2.74
|
£3.29
|
|
|
14 - CYLINDRICAL GEAR
BSD-3606316100.A120
3606316100
|
£21.52
|
£25.83
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A271
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR Z=16
BSD-3606316099.A14
3606316099
|
£22.76
|
£27.31
|
|
|
26 - PINION
BSD-3606300164.A0
3606300164
|
£37.27
|
£44.72
|
|
|
27 - STOP DISC
BSD-3600101001.A134
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A16
3606334000
|
£107.69
|
£129.23
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337003.A16
3606337003
|
£85.90
|
£103.08
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A464
3603201000
|
£1.84
|
£2.21
|
|
|
34 - SHIM WASHER
BSD-3600103002.A66
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A82
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A242
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337025.A3
3606337025
|
-
|
|
|
|
41 - GROOVE BALL BEARING 12x32x10
BSD-1900900302.A50
1900900302
|
-
|
|
|
|
45 - RADIAL SEAL
BSD-3600283000.A1
3600283000
|
-
|
|
|
|
54 - FITTING
BSD-3603458008.A130
3603458008
|
£9.11
|
£10.93
|
|
|
56 - VALVE BODY
BSD-3605190012.A2
3605190012
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A133
3600002000
|
£3.72
|
£4.47
|
|
|
65 - O-RING 15.6x1.8 MM
BSD-3600210003.A28
3600210003
|
£1.84
|
£2.21
|
|
|
66 - STRAIGHT PIN
BSD-3604710006.A12
3604710006
|
£9.11
|
£10.93
|
|
|
67 - CONTROL LEVER
BSD-3602053001.A9
3602053001
|
£2.80
|
£3.36
|
|
|
68 - BALL dia9 MM
BSD-3603230004.A3
3603230004
|
£3.91
|
£4.69
|
|
|
69 - COMPRESSION SPRING
BSD-3604616002.A114
3604616002
|
£2.27
|
£2.72
|
|
|
72 - STRAIGHT PIN 3M6x24 DIN 7-C35K
BSD-2917610083.A48
2917610083
|
£1.75
|
£2.10
|
|
|
73 - STRAIGHT PIN
BSD-3604710003.A57
3604710003
|
£6.85
|
£8.22
|
|
|
77 - HOLDING PIN
BSD-3603203004.A25
3603203004
|
£2.94
|
£3.53
|
|
|
78 - VALVE CONE
BSD-3603231000.A26
3603231000
|
£2.80
|
£3.36
|
|
|
80 - O-RING 1.8x1.0 MM
BSD-3600210002.A58
3600210002
|
£2.74
|
£3.29
|
|
|
91 - SILENCER
BSD-3601010001.A98
3601010001
|
£2.16
|
£2.59
|
|
|
92 - FILTER SCREEN
BSD-3600002004.A91
3600002004
|
£2.80
|
£3.36
|
|
|
93 - O-RING 14.0x3.0 MM
BSD-3600210009.A55
3600210009
|
£1.32
|
£1.58
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A352
160111A3HF
|
£3.91
|
£4.69
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A581
1601110481
|
£2.27
|
£2.72
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A588
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A947
3601119236
|
£3.91
|
£4.69
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445008.A6
3606445008
|
£85.90
|
£103.08
|
|
|
105 - BACKUP RING
BSD-3600364003.A0
3600364003
|
-
|
|
|
|
106 - COMPRESSION SPRING
BSD-3604615001.A13
3604615001
|
£2.74
|
£3.29
|
|
|
111 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A650
1903230007
|
£1.84
|
£2.21
|
|
|
112 - CLAMPING SLEEVE
BSD-3600311015.A43
3600311015
|
£31.64
|
£37.97
|
|
|
125 - RETAINING RING
BSD-3600224001.A39
3600224001
|
£3.72
|
£4.47
|
|
|
133 - HEX SOCKET HEAD CAP SCREW DIN 7984-M6x16-8.8
BSD-2910131197.A3
2910131197
|
-
|
|
|
|
134 - PLAIN WASHER
BSD-3600101055.A23
3600101055
|
£12.04
|
£14.45
|
|
|
650 - SILENCER
BSD-3607000073.A42
3607000073
|
£19.91
|
£23.89
|
|
|
652 - HOSE FITTING
BSD-2603386002.A23
2603386002
|
£5.30
|
£6.36
|
|
|
653 - SILENCER
BSD-3603462000.A201
3603462000
|
£17.22
|
£20.67
|
|
|
703 - HOSE FITTING dia 8 MM
BSD-3603386001.A43
3603386001
|
£16.41
|
£19.69
|
|
|
704 - SUPPORT CLAMP
BSD-3608040000.A111
3608040000
|
-
|
|
|
|
705 - AUXILIARY HANDLE M14
BSD-1602025022.A1343
1602025022
|
£13.41
|
£16.09
|
|
|
705 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1426
1602025030
|
£19.91
|
£23.89
|
|
|
706 - TAP CHUCK
BSD-3608502000.A19
3608502000
|
-
|
|
|
|
707 - TAP CHUCK
BSD-3608502001.A0
3608502001
|
-
|
|
|
|
708 - TAP CHUCK
BSD-3608502002.A4
3608502002
|
-
|
|
|
|
709 - TAP CHUCK
BSD-3608502003.A0
3608502003
|
-
|
|
|
|
710 - TWO-JAW DRILL JUCK
BSD-1608573003.A4
1608573003
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031025.A7
3607031025
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030248.A38
3607030248
|
£33.22
|
£39.87
|
|
|
840 - PARTS SET
BSD-3607010007.A35
3607010007
|
£19.91
|
£23.89
|
|
|
855 - O-RING 10x2 MM
BSD-1900210306.A72
1900210306
|
£1.84
|
£2.21
|
|
