2 - GROOVE BALL BEARING
BSD-3600900026.A27
3600900026
|
£5.26
|
£6.31
|
|
|
3 - GRINDING SPINDLE M15x1. SW 17
BSD-3603523010.A8
3603523010
|
-
|
|
|
|
4 - GROOVE BALL BEARING
BSD-3600900025.A1
3600900025
|
£9.11
|
£10.93
|
|
|
5 - THREADED RING
BSD-1603344003.A4
1603344003
|
£21.68
|
£26.01
|
|
|
6 - CYLINDRICAL GEAR Z=19
BSD-3606319012.A7
3606319012
|
-
|
|
|
|
9 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A749
2916660008
|
£2.16
|
£2.59
|
|
|
10 - CUPPED WASHER
BSD-2600500002.A128
2600500002
|
£1.75
|
£2.10
|
|
|
11 - FELT WASHER
BSD-2600108002.A18
2600108002
|
£2.27
|
£2.72
|
|
|
12 - RECEPTACLE
BSD-2600400008.A295
2600400008
|
£1.75
|
£2.10
|
|
|
13 - INTERMEDIATE FLANGE
BSD-2605700215.A8
2605700215
|
£45.67
|
£54.80
|
|
|
15 - SPACER SLEEVE
BSD-3600300020.A9
3600300020
|
£13.78
|
£16.54
|
|
|
16 - CUPPED WASHER
BSD-2600500009.A7
2600500009
|
£1.75
|
£2.10
|
|
|
17 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A112
2916640006
|
£1.84
|
£2.21
|
|
|
18 - SHIM
BSD-2600150005.A30
2600150005
|
£1.75
|
£2.10
|
|
|
19 - COVER RING
BSD-3600300074.A21
3600300074
|
£15.65
|
£18.78
|
|
|
20 - COLLET dia 3 MM
BSD-2608570077.A35
2608570077
|
£21.68
|
£26.01
|
|
|
20 - COLLET dia 6 MM
BSD-2608570129.A63
2608570129
|
£19.91
|
£23.89
|
|
|
20 - COLLET dia 8 MM
BSD-2608570081.A24
2608570081
|
£22.76
|
£27.31
|
|
|
20 - COLLET dia 1/8 (3.175 MM)
BSD-2608570078.A6
2608570078
|
£35.42
|
£42.51
|
|
|
20 - COLLET dia 6 MM
BSD-2608570129.A64
2608570129
|
£19.91
|
£23.89
|
|
|
20 - COLLET dia 1/4 (6.35 MM)
BSD-2608570080.A23
2608570080
|
-
|
|
|
|
21 - ROUND NUT
BSD-3603342009.A68
3603342009
|
£14.91
|
£17.89
|
|
|
22 - TAPPING SCREW DIN 7971-3.9x38
BSD-2910215093.A69
2910215093
|
-
|
|
|
|
23 - SHIM
BSD-2600101514.A5
2600101514
|
£1.75
|
£2.10
|
|
|
24 - FELT WASHER
BSD-1600205013.A7
1600205013
|
£1.84
|
£2.21
|
|
|
25 - SCREENING SLEEVE
BSD-3600400010.A10
3600400010
|
£6.85
|
£8.22
|
|
|
101 - MOTOR HOUSING
BSD-2605108058.A0
2605108058
|
£17.22
|
£20.67
|
|
|
102 - FIELD 220-230V
BSD-2604220491.A17
2604220491
|
£22.76
|
£27.31
|
|
|
103 - ARMATURE 220-230V
BSD-2604010899.A3
2604010899
|
£61.98
|
£74.38
|
|
|
104 - ON-OFF SWITCH
BSD-1607200086.A296
1607200086
|
£11.87
|
£14.24
|
|
|
104 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A627
2910110048
|
£1.84
|
£2.21
|
|
|
106 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A104
2600703011
|
£2.94
|
£3.53
|
|
|
107 - FASTENING CLAMP
BSD-1601302017.A990
1601302017
|
£1.84
|
£2.21
|
|
|
109 - STICKER
BSD-3601110284.A1
3601110284
|
£3.34
|
£4.01
|
|
|
112 - SUPPRESSION CAPACITOR
BSD-3607328021.A1
3607328021
|
£10.61
|
£12.73
|
|
|
113 - BALL BEARING 7x22x7
BSD-1900905018.A1086
1900905018
|
£19.91
|
£23.89
|
|
|
114 - BALL BEARING 9x24x7
BSD-2600905095.A11
2600905095
|
£12.04
|
£14.45
|
|
|
116 - BRUSH HOLDER
BSD-1600A003G4.A503
1600A003G4
|
£3.72
|
£4.47
|
|
|
116 - BRUSH HOLDER
BSD-2601323022.A48
2601323022
|
£2.94
|
£3.53
|
|
|
119 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A105
2910211018
|
£1.75
|
£2.10
|
|
|
125 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A425
1613435034
|
£1.84
|
£2.21
|
|
|
126 - SPIRAL SPRING
BSD-2604652009.A126
2604652009
|
£1.84
|
£2.21
|
|
|
127 - SHIM
BSD-2600150033.A18
2600150033
|
£2.27
|
£2.72
|
|
|
128 - SHIM WASHER 0.5 MM
BSD-2600101667.A115
2600101667
|
£1.84
|
£2.21
|
|
|
128 - SHIM WASHER 0.3 MM
BSD-2600101027.A157
2600101027
|
£1.84
|
£2.21
|
|
|
128 - SHIM WASHER 0.3 MM
BSD-2600101027.A158
2600101027
|
£1.84
|
£2.21
|
|
|
129 - SHRINKABLE TUBE 25-1MM
BSD-2600409014.A10
2600409014
|
£1.75
|
£2.10
|
|
|
131 - HOUSING COVER
BSD-1600508011.A15
1600508011
|
£9.11
|
£10.93
|
|
|
133 - SWITCH HANDLE
BSD-1602026057.A437
1602026057
|
£2.07
|
£2.48
|
|
|
134 - ADJUSTING SLIDE
BSD-1602319002.A1
1602319002
|
£2.74
|
£3.29
|
|
|
135 - COVER DISC
BSD-2601328045.A185
2601328045
|
£2.16
|
£2.59
|
|
|
137 - CONNECTING CABLE L=52MM
BSD-2604448016.A28
2604448016
|
£1.75
|
£2.10
|
|
|
138 - CABLE
BSD-2604448149.A10
2604448149
|
£1.75
|
£2.10
|
|
|
139 - SUPPRESSION FILTER
BSD-2604465096.A12
2604465096
|
£5.30
|
£6.36
|
|
|
140 - COMPRESSION SPRING
BSD-1604611026.A562
1604611026
|
£1.84
|
£2.21
|
|
|
141 - SPEED GOVERNOR 230V
BSD-2607230013.A11
2607230013
|
£57.14
|
£68.57
|
|
|
150 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A35
2910211020
|
£2.16
|
£2.59
|
|
|
653 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A552
2607950511
|
£4.48
|
£5.37
|
|
|
801 - MOTOR HOUSING
BSD-2605108908.A10
2605108908
|
£24.45
|
£29.34
|
|
|
803 - GRINDING SPINDLE
BSD-3607031173.A6
3607031173
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A314
1607000227
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2242
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-2604320910.A31
2604320910
|
£10.10
|
£12.12
|
|
|
819 - SPINDLE BEARING
BSD-3607030417.A6
3607030417
|
£59.53
|
£71.44
|
|
|
819/1 - COVER RING 8.5 mm
BSD-2600501001.A31
2600501001
|
-
|
|
|
|
835 - FAN
BSD-2606610029.A57
2606610029
|
£2.74
|
£3.29
|
|
