1 - MOTOR HOUSING
BSD-3605108224.A13
3605108224
|
£10.61
|
£12.73
|
|
|
3/3/13 - BALL BEARING 7x19x6
BSD-2600905032.A1807
2600905032
|
£5.57
|
£6.68
|
|
|
4 - SWITCH
BSD-1607200199.A39
1607200199
|
£16.41
|
£19.69
|
|
|
5 - POWER SUPPLY CORD AUS 240V 4.15m 2 x 1.0mm PVC
BSD-160446010E.A1
160446010E
|
£18.96
|
£22.75
|
|
|
6 - GROMMET
BSD-1600703041.A13
1600703041
|
£1.84
|
£2.21
|
|
|
7 - FASTENING CLAMP
BSD-1601302024.A11
1601302024
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-3601110594.A2
3601110594
|
£2.74
|
£3.29
|
|
|
16 - BRUSH HOLDER
BSD-1601323025.A15
1601323025
|
£3.91
|
£4.69
|
|
|
16/17 - SPIRAL SPRING
BSD-1604652013.A438
1604652013
|
£1.84
|
£2.21
|
|
|
18 - SWITCH HANDLE
BSD-1602026088.A2
1602026088
|
£1.75
|
£2.10
|
|
|
19 - COMPRESSION SPRING
BSD-1604611026.A142
1604611026
|
£1.84
|
£2.21
|
|
|
20 - ADJUSTING SLIDE
BSD-1602319010.A15
1602319010
|
£1.84
|
£2.21
|
|
|
24 - COVER
BSD-1605500227.A23
1605500227
|
£2.16
|
£2.59
|
|
|
25 - HOUSING COVER
BSD-1605500251.A56
1605500251
|
£7.72
|
£9.27
|
|
|
26 - RUBBER RING
BSD-1600206036.A376
1600206036
|
£1.84
|
£2.21
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A308
1600591025
|
£2.61
|
£3.13
|
|
|
47 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A21
2603490021
|
£1.84
|
£2.21
|
|
|
48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A516
1613435034
|
£1.84
|
£2.21
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A64
2603490023
|
£1.84
|
£2.21
|
|
|
51 - SPEED GOVERNOR
BSD-1607233452.A0
1607233452
|
£71.84
|
£86.21
|
|
|
53 - LENS HEAD SCREW 4x32
BSD-2603490026.A225
2603490026
|
£1.84
|
£2.21
|
|
|
62 - RETAINING CLIP
BSD-1600119011.A12
1600119011
|
£2.27
|
£2.72
|
|
|
63 - RUBBER RING
BSD-1600206025.A210
1600206025
|
£2.16
|
£2.59
|
|
|
64 - O-RING 26.0x2.0 MM
BSD-1610210101.A41
1610210101
|
£2.80
|
£3.36
|
|
|
65 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A88
2916660010
|
£1.75
|
£2.10
|
|
|
67 - SHIM
BSD-3600150011.A21
3600150011
|
£1.84
|
£2.21
|
|
|
69 - SHIM 0.10 MM
BSD-1710102601.A9
1710102601
|
£1.75
|
£2.10
|
|
|
70 - INTERMEDIATE FLANGE
BSD-3605700225.A4
3605700225
|
£46.82
|
£56.19
|
|
|
72 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A129
1600905032
|
£5.58
|
£6.70
|
|
|
74 - GROOVE BALL BEARING 10x26x8
BSD-3600905156.A5
3600905156
|
£12.64
|
£15.17
|
|
|
75 - GROOVE BALL BEARING
BSD-3600905157.A9
3600905157
|
£12.64
|
£15.17
|
|
|
76 - PROTECTIVE SLEEVE
BSD-3605500194.A6
3605500194
|
£12.64
|
£15.17
|
|
|
81 - SPACER SLEEVE
BSD-3600400034.A7
3600400034
|
£5.57
|
£6.68
|
|
|
82 - SEALING DISK
BSD-3600103020.A1
3600103020
|
£5.30
|
£6.36
|
|
|
83 - COUPLING HALF
BSD-3606445047.A14
3606445047
|
£22.76
|
£27.31
|
|
|
84 - COUPLING HALF
BSD-3606445047.A15
3606445047
|
£22.76
|
£27.31
|
|
|
86 - CARRIER
BSD-3606337242.A1
3606337242
|
£5.57
|
£6.68
|
|
|
90 - CLAMPING UNIT
BSD-3607030482.A1
3607030482
|
£21.68
|
£26.01
|
|
|
95 - FLANGE
BSD-3600328043.A0
3600328043
|
£23.86
|
£28.63
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A158
1601008005
|
£4.26
|
£5.11
|
|
|
107 - INSULATING PART
BSD-1600712030.A3
1600712030
|
£1.75
|
£2.10
|
|
|
653 - SINGLE-HEAD ENG. WRENCH SW19
BSD-3607950024.A9
3607950024
|
£9.11
|
£10.93
|
|
|
654 - SINGLE-HEAD ENG. WRENCH SW13
BSD-3607950025.A5
3607950025
|
£7.72
|
£9.27
|
|
|
802 - POLE SHOE 230V
BSD-3607030475.A10
3607030475
|
£54.42
|
£65.30
|
|
|
803 - ARMATURE 230V
BSD-3607030476.A0
3607030476
|
£75.79
|
£90.95
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2909
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014176.A134
1607014176
|
£13.78
|
£16.54
|
|
|
810 - CARBON-BRUSH SET 10 x 1 607 014 176
BSD-1607000482.A5
1607000482
|
£93.88
|
£112.65
|
|
|
815 - PARTS SET
BSD-1607000378.A76
1607000378
|
£6.52
|
£7.83
|
|
|
818 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A147
2910110048
|
£1.84
|
£2.21
|
|
|
835 - FAN
BSD-1606610129.A94
1606610129
|
£2.16
|
£2.59
|
|
|
860 - CONNECTING CABLE
BSD-1604448023.A46
1604448023
|
£1.75
|
£2.10
|
|
|
861 - SPINDLE HOUSING
BSD-3607031668.A6
3607031668
|
£68.42
|
£82.10
|
|
|
880 - GRINDING SPINDLE
BSD-3607031667.A0
3607031667
|
£126.12
|
£151.34
|
|
|
890 - ROUND NUT
BSD-3603313006.A16
3603313006
|
£10.61
|
£12.73
|
|
