1 - MOTOR HOUSING
BSD-1609310312.A0
1609310312
|
-
|
|
|
|
2 - NAMEPLATE
BSD-1609310210.A1
1609310210
|
-
|
|
|
|
3 - MANUFACTURER'S NAMEPLATE
BSD-1609310208.A0
1609310208
|
-
|
|
|
|
6 - DRIVE SHAFT
BSD-1609310313.A1
1609310313
|
-
|
|
|
|
7 - GROOVE BALL BEARING
BSD-1609310197.A1
1609310197
|
-
|
|
|
|
8 - SPRING RETAINING RING
BSD-1609310297.A0
1609310297
|
-
|
|
|
|
9 - PROTECTIVE CAP
BSD-1609310274.A0
1609310274
|
-
|
|
|
|
10 - STOP RING
BSD-1609310309.A1
1609310309
|
-
|
|
|
|
11 - COMPRESSION SPRING
BSD-1609310308.A0
1609310308
|
-
|
|
|
|
13 - ROTOR
BSD-1609310311.A1
1609310311
|
-
|
|
|
|
14 - DISC SPRING
BSD-1609310310.A0
1609310310
|
-
|
|
|
|
15 - HEX SOCKET HEAD CAP SCREW M 4x10 DIN 912-8.8
BSD-2910141120.A1
2910141120
|
£1.75
|
£2.10
|
|
|
16 - PERFORATED PANEL
BSD-1609310314.A0
1609310314
|
-
|
|
|
|
17 - STOP RING
BSD-1609310299.A1
1609310299
|
-
|
|
|
|
21 - SEAL RING
BSD-1609310157.A0
1609310157
|
-
|
|
|
|
25 - VALVE HOUSING
BSD-1609310262.A1
1609310262
|
-
|
|
|
|
31 - NEEDLE ROLLER A 3x17.8 G2 DIN 5402
BSD-1903201045.A1
1903201045
|
-
|
|
|
|
32 - CONTROL LEVER
BSD-1609310271.A4
1609310271
|
-
|
|
|
|
33 - NAMEPLATE
BSD-1601104578.A3
1601104578
|
-
|
|
|
|
34 - ROUND-HEAD GROOVED PIN
BSD-1609310358.A6
1609310358
|
-
|
|
|
|
35 - NEEDLE ROLLER A 3x23.8 G2 DIN 5402
BSD-1903201047.A4
1903201047
|
-
|
|
|
|
36 - BALL
BSD-1609310156.A3
1609310156
|
-
|
|
|
|
37 - COMPRESSION SPRING
BSD-1609310185.A1
1609310185
|
-
|
|
|
|
38 - SEAL RING
BSD-1609310011.A1
1609310011
|
-
|
|
|
|
39 - SCREW PLUG
BSD-1609310001.A2
1609310001
|
-
|
|
|
|
40 - HOSE FITTING
BSD-1609310043.A5
1609310043
|
-
|
|
|
|
41 - FITTING
BSD-1609310147.A0
1609310147
|
-
|
|
|
|
42 - SEAL RING
BSD-1609310154.A2
1609310154
|
-
|
|
|
|
43 - THROTTLE FLAP
BSD-1609310315.A1
1609310315
|
-
|
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A934
3601119236
|
£3.72
|
£4.47
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW 14
BSD-1907950508.A61
1907950508
|
£14.91
|
£17.89
|
|
|
651 - COLLET dia 6 MM
BSD-1608570061.A2
1608570061
|
-
|
|
|
|
755 - UNION NUT
BSD-3603340018.A1
3603340018
|
£23.86
|
£28.63
|
|
|
756 - COLLET dia 3 MM
BSD-1608570059.A6
1608570059
|
-
|
|
|
|
756 - COLLET dia 1/8
BSD-2608570070.A8
2608570070
|
-
|
|
|
|
756 - COLLET dia 6 MM
BSD-2608570071.A1
2608570071
|
£23.07
|
£27.68
|
|
|
756 - COLLET dia 1/4
BSD-2608570072.A12
2608570072
|
£33.74
|
£40.49
|
|
