Makita EM4251 Petrol String Trimmer Spare Parts

An exploded drawing and spare parts listing for the Makita EM4251 Petrol String Trimmer

	Ex VAT	Inc VAT
3-3 - PROTECTOR ASSY EM4251/RBC255/2 MSP-6258060002.A3 6258060002	£39.16	£46.99
4-2 - PROTECTOR ASSY EM4251/RBC225 MSP-6258061002 6258061002	£28.51	£34.21
5-3 - PROTECTOR RBC260L/UMS281 MSP-140424-9.A5 140424-9	£17.13	£20.56
6-2 - SCREW ASSY M5x40 DBC260L/U MSP-0140059380.A4 140059380	£12.63	£15.16
6 - PAN HD SCREW M5X40 EM4251/434 MSP-0043605400.A2 43605400	£1.44	£1.73
7-1 - NUT M5 DBC260L/U/RBC3101 MSP-264035-7.A8 264035-7	£1.44	£1.73
8-1 - *SPACER DBC260L/RBC201/MS20C/ MSP-6271501501.A3 6271501501	£5.92	£7.11
8-2 - SPACER ER2650LH/2550/DUR362L MSP-450659-7.A9 450659-7	£2.50	£3.00
9 - *HANGER ASSY RBC221/230/260/E MSP-6254019000 6254019000	£12.95	£15.54
12 - LOOP HANDLE EM4251/MS221RPT25 MSP-6274004010 6274004010	£7.72	£9.27
13 - GUARD STAY EM4251/MS221/RPT2 MSP-6214014010 6214014010	£4.37	£5.24
14-1 - HANDLE HOLDER RBL2510 MSP-6214016020 6214016020	£8.42	£10.11
15-2 - *SCREW DBC260L/RBC281/MS2810 MSP-6214016030.A4 6214016030	£1.44	£1.73
15-3 - SCREW DBC260L/RBC281/MS2810 MSP-266845-8.A4 266845-8	£2.50	£3.00
15-1 - SOCKET HD BOLT M6X18 RPT250 MSP-6274004041 6274004041	£4.06	£4.87
16 - CONTROL LEVER ASSY EM4251 MSP-6245003000 6245003000	£91.48	£109.77
17-1 - GEAR CASE ASSY EM4251/RBC255 MSP-6213017003 6213017003	£187.80	£225.36
17-2 - GEAR CASE ASS'Y RBC225 MSP-6213017004 6213017004	£205.44	£246.53
17-4 - GEAR CASE RBC260L/U/RBC2110 MSP-125476-1.A2 125476-1	£84.29	£101.15
18-1 - SOCKET HEAD BOLT M5X25 DBC260 MSP-266805-0.A12 266805-0	£1.44	£1.73
19-1 - BALL BEARING 609ZZ EBH253L/BB MSP-210049-4.A28 210049-4	£4.21	£5.05
20 - OUTER SNAP RING RBC230/260/31 MSP-0031508000.A2 31508000	£1.44	£1.73
20-2 - PUTER SNAP RING RBC260L/U/RBL MSP-257986-1.A14 257986-1	£4.21	£5.05
22-1 - BALL BEARING 626ZZ DBC260L/U MSP-210083-4.A3 210083-4	£10.92	£13.10
23-1 - GEAR SET EM4251 MSP-6213021001 6213021001	£69.93	£83.92
23-2 - *CUTTER SHAFT SET RBC260L/U/R MSP-6243008002 6243008002	£64.28	£77.14
24-2 - BALL BEARING 6000DDU DBC260L/ MSP-210082-6.A5 210082-6	£15.58	£18.70
26-2 - RECEIVE WASHER DUR362/EM4251 MSP-332042-9.A4 332042-9	£23.62	£28.34
27-3 - CLAMP COMPL WASHER RBC260L/U/ MSP-168797-8.A3 168797-8	£2.24	£2.69
28-1 - NUT SPRING WASHER RBC260L/U/E MSP-264018-7.A7 264018-7	£1.20	£1.44
29-1 - GUARD RBC260L/U/RBC230/260/RB MSP-450653-9.A2 450653-9	£1.44	£1.73
30-2 - SCREW ASSY M5X12 DBC260L/U MSP-265195-8.A5 265195-8	£1.44	£1.73
32 - PAN HEAD SCREW RBC225/EM4251 MSP-0043105060 43105060	£1.44	£1.73
34 - LABEL/CAUTION EM4251 MSP-6249502400 6249502400	£17.86	£21.43
36-1 - CLAMP PROTECTION RBC201/MS20C MSP-346263-7 346263-7	£4.21	£5.05
38 - TAPPING SCREW RBC251/EM4251 MSP-0150059940.A6 150059940	£1.44	£1.73
40 - *LEVER RBC260L/U/MS4251/RPT25 MSP-6195006030.A2 6195006030	£10.77	£12.92
40-1 - LONG LEVER EBH253L MSP-451933-6.A2 451933-6	£5.78	£6.93
41-1 - STOP LEVER EBH253L MSP-451934-4.A4 451934-4	£7.18	£8.61
42 - ADJUST MS4251/4340L MSP-6215023050 6215023050	£14.51	£17.41
43 - WIRE SET MS4251 MSP-6245003010 6245003010	£59.92	£71.91
44 - WIRE EM4251 MSP-6245003020 6245003020	£21.89	£26.27
45 - *SPRING EH7500/U/EM4251/PTR25 MSP-6195006050.A7 6195006050	£2.18	£2.62
45-1 - TORSION SPRING EBH253L MSP-233568-3.A7 233568-3	£1.44	£1.73
46-1 - SOCKET HD BOLT M5X20 DBC260L MSP-266698-5.A3 266698-5	£1.44	£1.73
47-1 - HEX HALFNUT M5 404X BPJ140/18 MSP-931203-4.A14 931203-4	£1.44	£1.73
48-1 - TAPPING SCREW M4X20 EBH253U MSP-266584-0.A6 266584-0	£1.44	£1.73
49-3 - CYLINDER BLOCK SET MS4251/BCX MSP-5921005004 5921005004	£213.60	£256.32
49-2 - CYLINDER BLOCK SET MS4251/BCX MSP-5921005003 5921005003	£220.44	£264.53
52-2 - *ROCKER COVER ER2550/EBH2 MSP-140023-7 140023-7	£7.64	£9.17
54-1 - ROCKER COVER GASKET ER2550/EB MSP-162275-0.A5 162275-0	£2.02	£2.43
56-1 - RETAINER PLATE ER2550/EBH251L MSP-318440-1.A7 318440-1	£2.02	£2.43
60 - SOCKET HD BOLT M5X30 BCX2510 MSP-0119059500 119059500	£1.44	£1.73
63-3 - SOCKET HD BOLT M5X16 EPH1000 MSP-266812-3 266812-3	£1.44	£1.73
64-1 - OIL CASE ER2550/EBH253L/BHX25 MSP-318442-7.A5 318442-7	£6.55	£7.86
65-1 - CASE GASKET ER2550/EBH253L MSP-162276-8 162276-8	£2.65	£3.18
66-1 - OIL TUBE ER2550/EBH251L/341U MSP-424202-8.A5 424202-8	£3.74	£4.49
68-1 - OIL GAUGE ER2550/EBH251/341 MSP-450565-6.A6 450565-6	£2.18	£2.62
69-1 - *GASKET EPH1000/EM4340L/BCX25 MSP-0213169990 213169990	£2.18	£2.62
69-2 - GASKET ER2550/EBH251L/341U MSP-424100-6.A6 424100-6	£1.44	£1.73
70 - SCREW ASSY EM4340L MSP-0043605180.A5 43605180	£1.44	£1.73
74 - *INNER SNAP RING RBC260/EM425 MSP-0031432000.A8 31432000	£1.44	£1.73
75 - *BALL BEARING 6201DDRBC260/31 MSP-0600129950.A5 600129950	£11.39	£13.67
77-2 - SPACER ER2650LH/EM2651LH/EBH2 MSP-450569-8.A1 450569-8	£1.44	£1.73
77 - *SPACER EM4251/PTR2500/BCX251 MSP-6241500300 6241500300	£1.44	£1.73
78-1 - PIPE DAMPER 1 ER2550/EBH253L MSP-424191-7.A4 424191-7	£1.44	£1.73
78 - PIPE DAMPER 1 EM4251/BCX2510 MSP-6241500401 6241500401	£4.37	£5.24
79-1 - PIPE CAMPER 2 ER2550/EBH253L MSP-424107-2.A4 424107-2	£2.02	£2.43
80-1 - PIPE BRACKET 1 EM4251 MSP-6241500601 6241500601	£7.49	£8.99
81-2 - PIPE BRACKET 2 ER2550/EBH253L MSP-318271-8.A5 318271-8	£2.18	£2.62
81-1 - *PIPE BRACKET 2 EM4251 MSP-6241500701 6241500701	£7.49	£8.99
82 - SOCKET HEAD BOLT M5X12 DBC26 MSP-0119059900.A8 119059900	£1.44	£1.73
83 - *SOCKET HEAD BOLT M5X18 RBC23 MSP-0119059950.A9 119059950	£1.44	£1.73
84-1 - STAND SET ER2550/EBH253L MSP-195144-0.A7 195144-0	£1.47	£1.76
85-1 - SCREW ASSY M5X14 EPH1000/RBC2 MSP-266809-2.A24 266809-2	£1.44	£1.73
86-1 - *CRANKSHAFT ASSY BCX2500/2510 MSP-135374-1.A3 135374-1	£64.94	£77.93
86-2 - CRANKSHAFT ASSY ER2550/EBH253 MSP-135539-5.A2 135539-5	£40.32	£48.38
87-1 - OIL SEAL 12 BHX2500 2501 MSP-213147-3.A9 213147-3	£2.34	£2.81
87-2 - OIL SEAL 12 EM2653/EM2654/MS MSP-213089-1.A9 213089-1	£3.90	£4.68
88-1 - OIL SEAL 10 BHX2500 2501 MSP-213148-1.A8 213148-1	£2.81	£3.37
88-2 - OIL SEAL 10 UK360D/ER2650LH MSP-213769-9.A11 213769-9	£3.59	£4.31
89-1 - FLAT WASHER 23 ER2650LH/EM265 MSP-267400-9.A8 267400-9	£1.44	£1.73
90-1 - PISTON ER2650/EM2651//EN4951 MSP-318441-9.A10 318441-9	£7.80	£9.36
91 - *PISTON RING SET EM4251/BCX25 MSP-5922004000 5922004000	£24.48	£29.38
91-1 - PISTON RING SET EN4951/CS246.4 MSP-195145-8.A0 195145-8	£15.91	£19.09
92-1 - CLIP ER2650LH/EM2651LH/EBH253 MSP-233976-8.A2 233976-8	£1.44	£1.73
93-1 - PISTON PINT ER2650LH/EM2651LH MSP-257781-9.A18 257781-9	£1.44	£1.73
94-2 - SPACKER ER2650/EM2651/EN4951 MSP-424200-2.A5 424200-2	£1.44	£1.73
95-1 - CAM LIFTER ER2650LH/EM2651LH MSP-313169-4.A10 313169-4	£3.59	£4.31
96-2 - CAM GEAR ASSY EM2651LH/ER2650 MSP-125552-1.A4 125552-1	£12.32	£14.79
97-1 - PIN 5 ER2650/EBH/BHX/EM2511 MSP-268238-5.A7 268238-5	£1.44	£1.73
98-1 - PIN 4 ER2650LH/EBH/BHX2501 MSP-268239-3.A10 268239-3	£1.44	£1.73
99-1 - ROD 2.5 ER2650/EM2651/EN4951 MSP-256865-0.A7 256865-0	£1.44	£1.73
100-2 - ROCKET ARM ASSY ER2550LH/EM26 MSP-125554-7.A1 125554-7	£4.68	£5.62
101-2 - PIN 5 ER2650LH/2704/EBH/BHX25 MSP-256200-2.A16 256200-2	£1.44	£1.73
102-1 - COMPRESSION SPRING 9 ER2550 MSP-234108-0.A4 234108-0	£1.44	£1.73
103-1 - SPRING RETAINER ER2650L/EBH25 MSP-325668-4.A3 325668-4	£1.44	£1.73
104-2 - EXHAUST VALVE ER2650LH/EM2651 MSP-326366-3.A4 326366-3	£1.44	£1.73
104-1 - *EXHAUST VALVE ER2650LH/EM265 MSP-325669-2.A10 325669-2	-
105-2 - INTAKE VALVE ER2650LH/BHX2501 MSP-326367-1.A10 326367-1	£4.68	£5.62
106-2 - STARTER COVER ASSY BHX2501 MSP-125917-7.A0 125917-7	£18.72	£22.46
107-1 - REEL ER2550/BHX2501/ER2650LH MSP-451937-8.A0 451937-8	£5.46	£6.55
108-1 - TAPPING SCREW M5X12 ER2650LH MSP-266585-8.A0 266585-8	£1.44	£1.73
109-1 - SPRIAL SPRING ER2650LH/EM2651 MSP-232258-5.A13 232258-5	£9.98	£11.98
110-1 - COLLAR ER2650LH/ER2550/EY2650 MSP-451938-6.A15 451938-6	£1.44	£1.73
111-1 - SWING ARM ER2650/ER2550/CS246 MSP-325923-4.A6 325923-4	£1.44	£1.73
112-1 - STARTER ROPE ER2550/BHX2501 MSP-444019-3.A0 444019-3	£1.44	£1.73
113-1 - STARTER KNOB ER2650LH/EM2651L MSP-424319-7.A4 424319-7	£2.34	£2.81
114-1 - PULLEY ER2550/BHX2501/ER2650L MSP-168483-1.A6 168483-1	£1.44	£1.73
115 - SCREW ASSY M4x25 RBC201/EM425 MSP-0043604250 43604250	£1.44	£1.73
115-1 - PAN HD SCREW M4X25 WR 195283- MSP-266807-6 266807-6	£1.44	£1.73
116 - *SPACER EM4251/BCX2510 MSP-0230049940 230049940	£1.44	£1.73
116-1 - SPACER ER2550/EBH253L/EM2511 MSP-331835-1.A2 331835-1	£1.44	£1.73
117-1 - TANK GUARD ER2550/EBH253L MSP-345964-4.A2 345964-4	£2.65	£3.18
118-1 - SCREW ASSY M5X12 EPH1000/RBC2 MSP-266808-4.A0 266808-4	£1.44	£1.73
120-3 - CARBURETOR ER2550/EBH253L MSP-168497-0.A2 168497-0	£55.31	£66.37
121-2 - PUMP BODY ER2650LH/EBH253L/34 MSP-140437-0.A0 140437-0	£28.51	£34.21
122-1 - CAM GEAR COVER GASKET ER2650L MSP-140438-8.A16 140438-8	£2.18	£2.62
123-1 - PRIMER PUMP COVER ER265/EM2511 MSP-346270-0.A27 346270-0	£4.83	£5.80
124-1 - PRIMER PUMP ER2650LH/BHX2501 MSP-424314-7.A27 424314-7	£4.83	£5.80
125-4 - DIAPHRAGM ASSY DCS230T MSP-168620-7.A30 168620-7	£18.72	£22.47
126-1 - METERING DIAPHRAGM GASET EBH MSP-442154-1.A24 442154-1	£3.59	£4.31
127-2 - PUMP DIAPHRAGM DCS230T/EB7600T MSP-DA00001144.A18 DA00001144	£14.21	£17.05
128-1 - PUMP GASKET ER2650LH/BHX2501 MSP-442155-9.A4 442155-9	£2.97	£3.56
129-2 - JET EM4251 MSP-5926002110.A0 5926002110	£15.26	£18.31
129 - JET EM4251 MSP-5926002110.A1 5926002110	£15.26	£18.31
129-3 - *JET RBC201/MS20C/BCX2510 MSP-5196002020.A1 5196002020	£13.88	£16.66
129-4 - JET ER2550/EBH253L/EM2511 MSP-325924-2.A2 325924-2	£9.67	£11.61
130-1 - O RING 2 ER2650LH/EBH253L/341 MSP-213538-8.A3 213538-8	£3.59	£4.31
131-1 - SROP RING E-3 ER2650LH/BHX250 MSP-257964-1.A17 257964-1	£2.81	£3.37
132-1 - SWIVEL ER2650LH/341U/BHX2501 MSP-325922-6.A21 325922-6	£5.46	£6.55
133 - *THROTTLE VALVE ASSY EM4251 MSP-5926002010 5926002010	£68.54	£82.25
134-1 - PAN HD SCREW M3X8 ER2650LH/E MSP-266581-6.A27 266581-6	£1.44	£1.73
134-2 - SCREW DCS230T/EN4951SH/CS246.4 MSP-WJ00096364.A12 WJ00096364	£2.34	£2.81
135 - *PLUG RBC230/260/310/EM4251 MSP-5206008110.A0 5206008110	£2.65	£3.18
136-1 - TAPPING SREW M3X24 ER2550/EBH MSP-266582-4.A1 266582-4	£1.44	£1.73
137-1 - CONICAL SPRING 5-9ER2650 MSP-234183-6.A9 234183-6	£3.28	£3.93
137 - *PUMP SPRING EPH1000/4340L/BC MSP-5926002020.A0 5926002020	£5.78	£6.93
138-1 - WASHER ER2650LH/BHX2501/ER25 MSP-413140-9.A8 413140-9	£1.44	£1.73
139-2 - INLET SCREEN DCS230T/EA3201S MSP-WJ00014070.A17 WJ00014070	£1.44	£1.73
140-4 - INSULATOR ER2550/EBH253/EM2511 MSP-450559-1.A2 450559-1	£3.59	£4.31
141 - NUT M5 M4251/4340L MSP-0170059980.A0 0170059980	£1.44	£1.73
142 - NUT M6 EPH1000/RBL500/EM4251 MSP-0022706000.A6 0022706000	£1.44	£1.73
143 - NUT M6 EPH1000/RBL500/EM4251 MSP-0022706000.A9 0022706000	£1.44	£1.73
144-2 - INSULATOR GASKET ER2550/EBH25 MSP-413120-5.A4 413120-5	£1.44	£1.73
145-2 - CARBURETOR GASKET ER2550/EBH MSP-413121-3.A2 413121-3	£1.44	£1.73
146 - CARBURETOR INSULATOR EM4251 MSP-5923502000 5923502000	£7.49	£8.99
147-2 - H.S.H BOLT M5X18 ER2650LH/EH5 MSP-266787-6.A17 266787-6	£1.44	£1.73
147 - SCREW ASSY EM4340L MSP-0043605180.A0 0043605180	£1.44	£1.73
148-2 - ADJUST SCREW M6X16 EPH1000/EM MSP-325934-9.A1 325934-9	£1.44	£1.73
149 - CAP RBC525/EM4251/BCX2510 MSP-5246004150.A2 5246004150	£4.83	£5.80
150-1 - BREATHER PIPE ER2550/BHX2501 MSP-422041-0.A5 422041-0	£1.44	£1.73
151-4 - CLEANER PLATE ASS ER2550 MSP-125468-0.A6 125468-0	£16.28	£19.53
153-1 - CHECK VALVE ER2550/EBH251L/ MSP-424315-5.A0 424315-5	£1.44	£1.73
154-1 - CHECK VALVE ER2550/EBH251L MSP-424316-3.A17 424316-3	£4.06	£4.87
155-1 - CHECK VALVE PLATE ER2550/EBH2 MSP-451924-7.A4 451924-7	£1.44	£1.73
156-2 - SEPARATOR PLATE ER2550/EBH253 MSP-168576-4.A0 168576-4	£6.40	£7.68
157-1 - CHOKE LEVER ER2550/EBH251L MSP-451925-5.A3 451925-5	£2.40	£2.88
158-2 - AIR CLEANER ELEMENT ER2550 MSP-443141-3.A5 443141-3	-
159-1 - O RING 14 ER2550/EBH341/EM2511 MSP-213539-6.A6 213539-6	£1.44	£1.73
160-1 - O RING 15 ER2550/BHX2501/EBH MSP-213540-1.A1 213540-1	£1.44	£1.73
161-2 - CHOKE PLATE ER2550/341U/BHX25 MSP-450560-6.A3 450560-6	£1.44	£1.73
162-1 - PLATE EBH341U MSP-345919-9.A0 345919-9	£1.44	£1.73
163-1 - GASKET ER2550/341U/BHX2501 MSP-423376-2.A3 423376-2	£1.44	£1.73
164-2 - AIR CLEANER COVER ER2550/EBH MSP-450561-4.A4 450561-4	£2.02	£2.43
165 - *PIPE EPH1000/EM4251/4340L/BC MSP-5923503001.A0 5923503001	£2.65	£3.18
165-1 - PIPE ER2550/ EBH251/341/EM2511 MSP-422042-8.A0 422042-8	£1.44	£1.73
166-1 - SCREW ASSY M5X14 EPH1000/RBC2 MSP-266809-2.A14 266809-2	£1.44	£1.73
167-1 - SPARE PART MSP-265188-5.A4 265188-5	£1.44	£1.73
168-1 - HOSE CLAMP ER2550/2650/EM2511 MSP-345918-1.A22 345918-1	£1.44	£1.73
169-1 - EXHAUST MUFFLER ER2550/EBH253 MSP-168469-5.A1 168469-5	£8.27	£9.92
171-1 - MUFFLER COVER ER2550/EBH253L MSP-345915-7.A1 345915-7	£2.65	£3.18
172-1 - HEX SOCKET HD BOLT M5X40 BHX2 MSP-266440-4.A16 266440-4	£1.44	£1.73
173 - SCREW M5X6 EH7500/EM4251/4340 MSP-0140059962.A3 0140059962	£1.44	£1.73
174-1 - FUEL TANK ER2550/EBH253L/EM MSP-450566-4.A4 450566-4	£7.02	£8.42
174-3 - FUEL TANK ER2550/EBH253L/EM MSP-450566-4.A5 450566-4	£7.02	£8.42
175-1 - TUBE ER2550/EBH253/EM2511 MSP-168472-6.A2 168472-6	£5.46	£6.55
176-2 - GASOLIN FILTER ER2550/DCS230T MSP-163447-0.A18 163447-0	£3.42	£4.10
176-1 - GASOLIN FILTER ER2550/DCS230T MSP-163447-0.A55 163447-0	£3.42	£4.10
177-1 - HOSE CLAMP ER2550/EBH251L/341 MSP-345920-4.A22 345920-4	£1.44	£1.73
178-1 - FUEL TANK CAP ASSY EM4251/BCX MSP-5926012000 5926012000	£8.89	£10.67
179-2 - STRAP ER2550/EBH341U MSP-140436-2.A17 140436-2	£3.96	£4.75
180-1 - CAUTION PLATE ER2650LH/EM2651 MSP-810455-9.A20 810455-9	£1.44	£1.73
181-1 - PLATE ER2550/ EBH251L/341U MSP-424102-2.A12 424102-2	£1.44	£1.73
182-1 - GASKET ER2550/ EBH251L/341U MSP-424103-0.A3 424103-0	£1.44	£1.73
183-2 - DAMPER ER2550/EBH253L/EBH341U MSP-424104-8.A7 424104-8	£2.02	£2.43
183-1 - *DAMPER EPH1000/EM4251/4340L MSP-5196500302.A1 5196500302	£2.34	£2.81
184-4 - IGNITION COIL EBH341L/EM4340 MSP-168816-0.A2 168816-0	£15.91	£19.09
185-2 - *FLYWHEEL ER2550/ EBH253L MSP-318343-9.A2 318343-9	£14.82	£17.78
186-1 - PLUG CAP ER2550/341U/BHX2501 MSP-424105-6.A1 424105-6	£1.44	£1.73
187-1 - PLUG CAP SPRING ER2650LH/BHX2 MSP-324891-8.A25 324891-8	£1.44	£1.73
188-2 - LEAD UNIT EBH341/EM4340/EPH100 MSP-632E38-3.A1 632E38-3	£1.44	£1.73
189 - *WIRE EPH1000/EM4251/434 MSP-5257018001.A5 5257018001	£2.50	£3.00
190 - *GROMMET EPH1000/EH561/EM4251 MSP-5257500300.A4 5257500300	£1.44	£1.73
191-1 - HEX HD BOLT M6X16 EBH/BHX2501 MSP-265577-4.A3 265577-4	£1.44	£1.73
191 - BOLT ASSY RBC230/EM4251/4340L MSP-0011306160.A3 0011306160	£1.44	£1.73
192 - WASHER RBC230/525E/EM4251/MH MSP-0031206000.A6 0031206000	£1.44	£1.73
193 - SCREW ASSY M4X20 EM4251/MH25 MSP-0140049920.A3 0140049920	£1.44	£1.73
194 - CLUTCH SHOE RBC260L/U/MH2556 MSP-5928500000.A0 5928500000	£20.30	£24.36
195 - SPRING EM4251/MH2556/PTR2500 MSP-5928500100.A1 5928500100	£4.06	£4.87
196 - CLUTCH BOLT EM4251/PTR2500 MSP-5928500200.A0 5928500200	£2.81	£3.37
197-1 - WASHER 6 ER2650/EBH253/EN4951 MSP-267812-6.A4 267812-6	£1.44	£1.73
197 - *WASHER RBC260L/UEM4251/BCX25 MSP-5928500300 5928500300	£1.44	£1.73
198 - CYLINDER COVER EM4251/BCX251 MSP-5925500800 5925500800	£28.51	£34.21
199-1 - SCREW ASSY M5X12 EPH1000/RBC2 MSP-266808-4.A1 266808-4	£1.44	£1.73
200 - SCREW M4x16 EM4251/BCX2510 MSP-0043604160 43604160	£1.44	£1.73
201 - *PLUG COVER EM4251/BCX2510 MSP-5927500000 5927500000	£4.68	£5.62
202 - *CLAMP RBC525/MS20C/EM4251/43 MSP-0566059980.A0 0566059980	£2.34	£2.81
203 - LABEL/TRADE MARK EM4251 MSP-5929501001 5929501001	£4.37	£5.24
204-2 - PROTECTOR CLAMP EM4251/RBC225 MSP-346493-0.A1 346493-0	£6.40	£7.68
209-2 - CHECK VALVE ER2650LH/EBH251L MSP-424201-0.A18 424201-0	£1.44	£1.73
210-2 - HEX BOLT M5X12 BHX2501/EBH253 MSP-922213-2.A10 922213-2	£1.44	£1.73
211-1 - *SEPARATOR GASKET ER2550/EBH MSP-168577-2.A7 168577-2	£1.44	£1.73
212-1 - AIR CLEANER ELEMENT ER2550 MSP-443140-5.A4 443140-5	£2.29	£2.75
213 - *NUT M5 RBC230/260/310/2810 MSP-0022705000.A6 0022705000	£1.44	£1.73
213-2 - HEX FULL NUT M5 RP0900/AN510 MSP-931202-6.A13 931202-6	£1.44	£1.73
214-1 - CLAMP ER2550/EBH251/341/EM2511 MSP-450562-2.A2 450562-2	£1.44	£1.73
215-1 - HOSE CLAMP ER26/EM26/EA3601 MSP-282020-8.A18 282020-8	£1.44	£1.73
216-2 - SPARK ARRESTER ER2550/EBH253L MSP-324980-9.A5 324980-9	£1.44	£1.73
217-1 - INTAKE PIPE ER2550/EBH253L MSP-324961-3.A2 324961-3	£1.44	£1.73
218-1 - O-RING 10 ER2550/EBH253/EM2511 MSP-213078-6.A4 213078-6	£1.44	£1.73
220 - WASHER BUR360/EM2651LH/EBH253 MSP-413143-3.A11 413143-3	£1.44	£1.73
A01 - HOOK FOR 6207003002 MSP-6257500400.A1 6257500400	£8.58	£10.30
A01 - *BAND ASSY RBC230/260/EM4251 MSP-6207003002.A0 6207003002	£14.98	£17.97
A01-1 - HOOK FOR 6207003002 MSP-6257500400.A0 6257500400	£8.58	£10.30
A02-1 - *CUTTER COVER SET DBC260/RBC42 MSP-6418027000.A7 6418027000	£6.55	£7.86
A05 - NYLON CUTTING HEAD (ADAP/KIT) MSP-B-02945.A1 B-02945	£21.45	£25.74
A04-1 - OIL BOTTLE EM4250/EM4251 MSP-0722104600 722104600	£4.79	£5.75

Attribute Name	Value
Brand	Makita

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Makita EM4251 Petrol String Trimmer Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)
