Makita G2800IS Generator Spare Parts

Home Details Reviews Delivery

An exploded drawing and spare parts listing for the Makita G2800IS Generator

	Ex VAT	Inc VAT
2 - VALVE GUIDE (OVERSIZE) G4300I MSP-2371420203.A1 2371420203	£7.67	£9.20
3 - STEM SEAL EW2050/EW2051/EW3051 MSP-2771601001.A1 2771601001	£2.49	£2.99
4 - OIL SEAL 25X38X7 G2800L/EW220 MSP-440250200 440250200	-
5 - BALL BEARING 62/68 MSP-600280021 600280021	-
6 - PIPE KNOCK 10.3DX8.5DX14L MSP-2771501103.A3 2771501103	£1.66	£1.99
7 - STUD M6X1X98 G2800/EW220 MSP-105060351 105060351	-
12 - OIL SEAL 25X42.25X6 G2800 MSP-440250210 440250210	-
13 - BALL BEARING 6205 EW2050H MSP-600250140.A0 600250140	-
13-2 - BALL BEARING 6205 EW2050H MSP-600250140.A1 600250140	-
14-2 - OIL GAUGE EW2050/EW2051/EW3051 MSP-2776360130.A1 2776360130	£6.50	£7.80
15-1 - *GASKET EW200R/ST MSP-X213160020.A0 X213160020	£1.66	£1.99
16 - FLANGE BOLT G4300IS/EW220 MSP-10408350 10408350	-
17 - CYLINDER HEAD G2800L MSP-2771300501 2771300501	£99.14	£118.97
18-2 - GASKET/HEAD EW2050/2051/3051 MSP-2771500143.A0 2771500143	£9.10	£10.92
19 - FLNAGE BOLT M8X1.25X16X68 MSP-110080240 110080240	-
20 - FLANGE BOLT M8X33 G4300IS MSP-110080310 110080310	-
23 - PIPE KNOCK 10.3DX8.5DX14L MSP-2771501103.A2 2771501103	£1.66	£1.99
24 - FLANGE BOLT G2400R/G1700I/G2 MSP-110060020.A6 110060020	-
27 - FLANGE NUT M14 G2800L/EW220R MSP-180140020 180140020	-
28 - WOODRUFF KEY G1700I/G2400R/G MSP-323030010 323030010	-
29 - CONNECTING ROD ASSY G2800 MSP-2772250110.A1 2772250110	£47.96	£57.55
30 - CONNECTING ROD BOLT G2800 MSP-2772300103.A1 2772300103	£2.49	£2.99
32B - PISTON 0.50 G2800L MSP-2772340403 2772340403	£23.65	£28.38
32-1 - PISTON STDEW2050/EW2051/EW3051 MSP-27723401J3.A0 27723401J3	£26.18	£31.42
32A - PISTON 0.25 O.S G2800L MSP-2772340303 2772340303	£23.65	£28.38
34 - CLIP EW2050/EW2051/EW3051 MSP-565160010 565160010	-
36-1 - PIN CAM SHAFT 9X78.5L G4300IS MSP-2773510101.A1 2773510101	£26.73	£32.08
38 - PIN (SPRING) 4X8X9 G4300IS MSP-2773860103.A2 2773860103	£1.66	£1.99
39-1 - RELEASE LEVER G2800L/EW220R MSP-2773640113.A2 2773640113	£14.30	£17.16
40 - CLIP 13.8X20.3X4 EW2050/EW3051 MSP-2773650103.A0 2773650103	£1.66	£1.99
41-4 - RETURN SPRING G2800I/G4300I MSP-2773870333.A1 2773870333	£2.49	£2.99
41-2 - RETURN SPRING G4300I/EW220 MSP-2773870313.A0 2773870313	£2.49	£2.99
42 - VALVE SPRING G4300IS/EW220R MSP-2793360103.A2 2793360103	£2.49	£2.99
43 - SPRING RETAINER G4300IS/EW220 MSP-2693370103.A0 2693370103	£4.03	£4.84
46 - COLLET VALVE G4300IS/EW220R MSP-13210KA031.A1 13210KA031	£1.66	£1.99
47-1 - TIMING CHAIN G2800L MSP-27735602H1.A0 27735602H1	£27.39	£32.87
49 - SPRING (TENSIONER) G4300IS MSP-2773710103.A1 2773710103	£2.49	£2.99
50 - PIN (TENSIONER) 6X13X34 G4300 MSP-2773690203.A0 2773690203	£2.49	£2.99
51-1 - CHAIN GUIDE G4300IS/EW220 MSP-20A3691303.A1 20A3691303	£3.51	£4.21
52-1 - PIN (ROCKER) G4300IS MSP-2773500401.A1 2773500401	£7.15	£8.58
53 - CLIP G4300IS/G1700I/EW220 MSP-31305000.A1 31305000	-
54 - LOCKER ARM (INTAKE) G4300IS MSP-2773620100.A0 2773620100	£15.51	£18.61
55 - ROCKER ARM (EXHAUST) G4300IS MSP-2773620200.A1 2773620200	£14.30	£17.16
56 - ADJUST SCREW M5 G4300G MSP-149050020.A0 149050020	-
57 - ADJUST SCREW M5 G4300G MSP-149050020.A1 149050020	-
58 - NUT M5 EW2050/EW2051/EW3051 MSP-170050030.A0 170050030	-
59 - NUT M5 EW2050/EW2051/EW3051 MSP-170050030.A1 170050030	-
60 - FLANGE BOLT G2400R/G1700I/G2 MSP-110060020.A1 110060020	-
62 - CLIP G4300IS/G1700I/EW220 MSP-31305000.A0 31305000	-
63 - BAFFLE 1 (CASE) G2800L MSP-2775271111 2775271111	£6.50	£7.80
63-2 - BAFFLE 1/CASE EW2050 MSP-20A5271101.A1 20A5271101	£10.66	£12.79
64 - FLANGE BOLT G2800L/EW220R MSP-10406160 10406160	-
66-1 - IGNITION COIL EW220R MSP-2777943111.A1 2777943111	£74.62	£89.55
67 - BOLT & WASHER ASSY G2400/G17 MSP-11406250.A0 11406250	-
69 - SPARK PLUG/NGK BR6HS G4300IS MSP-650140150 650140150	-
71-1 - OIL SENSOR EW220R MSP-2777630121.A0 2777630121	£28.60	£34.32
71 - OIL SENSOR G2800L MSP-2777630111 2777630111	£24.97	£29.96
73 - BOLT & WASHER ASSY G4300IS MSP-130060260 130060260	-
74 - STUD MUFFLER G4300I/G3500/350 MSP-105080290 105080290	-
75 - STUD G2800L MSP-105080510 105080510	-
76 - BOTTOM EXTENTION PLATE CP G28 MSP-33B3500101 33B3500101	£12.74	£15.29
77 - FLANGE BOLT M8X33 G4300IS MSP-110080270 110080270	-
81 - WASHER G4300IS MSP-200080080 200080080	-
83 - BAFFLE G2800L MSP-33B5260103 33B5260103	£3.25	£3.90
84 - FLANGE BOLT M6X23 G2800L MSP-110060160 110060160	-
85 - GASKET /MUFFLER G4300IS MSP-2773520113.A0 2773520113	£2.49	£2.99
86-1 - FLANGE NUT G4300I/G2400R/G170 MSP-23808000.A0 23808000	-
87-1 - TAIL SCREEN COVER G4300IS MSP-2773721003 2773721003	£5.07	£6.08
88 - SCREW ASSY EH561/G4300IS/G28 MSP-43505160 43505160	-
89-1 - NUT M5 DBC260L/U/RBC3101 MSP-264035-7.A1 264035-7	£1.66	£1.99
91 - BASE G2800L MSP-2773263208 2773263208	£23.65	£28.38
92 - PACKINGEW2050/EW2051/EW3051 MSP-2773260408.A1 2773260408	£2.49	£2.99
94 - ELEMENT G2800L MSP-2773266117 2773266117	£24.97	£29.96
95 - FLANGE NUT 6 EW200/G1300K/G2 MSP-23806000.A0 23806000	-
98-2 - GASKET 1/(INSULATOR G2800L/EW MSP-20A3590203.A1 20A3590203	£2.49	£2.99
99-2 - GASKET 2 (INSULATOR) G2800L MSP-20A3590303.A1 20A3590303	£2.49	£2.99
101 - BRACKET (A/C) 1 G2800L MSP-2773900401 2773900401	£5.98	£7.18
102 - FLANGE BOLT G1700I/G5500/5501 MSP-110060050 110060050	-
103 - FLANGE BOLT G4300IS MSP-110060150 110060150	-
104 - BLOWER HOUSING G2800L MSP-2775200113 2775200113	£102.92	£123.51
105 - BOLT AND WASHER ASSY G2800L MSP-11406350 11406350	-
106 - BOLT AND WASHER ASSY G2800L MSP-11406450 11406450	-
107 - STR PIN 8X10 G4300IS MSP-9804008110 9804008110	£1.66	£1.99
108 - PLATE 3 G2800L MSP-2775600103 2775600103	£2.49	£2.99
110 - SPIRAL SPRING G4300IS MSP-2775040208 2775040208	£19.25	£23.10
111 - REEL G4300IS MSP-2775040308 2775040308	£18.04	£21.65
112 - STARTER ROPE G4300IS MSP-2775040808 2775040808	£12.09	£14.51
114 - RACHET G4300IS MSP-2775040408 2775040408	£2.55	£3.06
115 - FRICTION SPRING G4300IS MSP-2775040508 2775040508	£15.51	£18.61
116 - FRICTION PLATE G4300IS MSP-2775040708 2775040708	£5.07	£6.08
117 - RETAINING RING G4300IS MSP-2775040608 2775040608	£8.32	£9.98
119-1 - COOLING BLOWER G2800L MSP-2775410123 2775410123	£20.57	£24.68
120 - BAFFLE 2 (HEAD) G2800L MSP-2775270203.A0 2775270203	£11.00	£13.20
121 - FLANGE BOLT G2400R/G1700I/G2 MSP-110060020.A2 110060020	-
122 - DRIVING SHAFT G4300IS MSP-2772440103 2772440103	£52.36	£62.83
123 - FLANGE BOLT M8X27L G4300IS MSP-110100110 110100110	-
154 - COVER (MOTOR) G4300IS MSP-2776259508 2776259508	£10.53	£12.64
156 - SCREW G4300IS/G1700I MSP-2846245708.A0 2846245708	£1.66	£1.99
160 - SCREW G4300IS/G1700I MSP-2846245708.A1 2846245708	£1.66	£1.99
161 - FLANGE BOLT G2400R/G1700I/G2 MSP-110060020.A3 110060020	-
162 - CLAMP G4300IS/G3501R/G2800L MSP-566000250 566000250	-
165 - SPRING WASHER G4300IS MSP-32005000 32005000	-
167 - BEARING G4300IS MSP-34B2100108 34B2100108	£12.35	£14.82
168 - BOLT G4300IS MSP-100100200 100100200	-
169 - WASHER G4300IS MSP-200100160 200100160	-
170 - REAR COVER G4300IS MSP-34B2307101 34B2307101	£106.95	£128.34
171 - BOLT & WASHER ASSY G2400/G17 MSP-11406250.A1 11406250	-
172-1 - INV AND E/G C/U G2800IS MSP-KU51210401 KU51210401	£1234.48	£1481.37
173 - COVER G4300IS MSP-34B5500103 34B5500103	£18.04	£21.65
185 - BOLT AND WASHER ASSY G4300IS MSP-11408160.A0 11408160	-
188-1 - MOUNT (R) G2800L MSP-32B3021111 32B3021111	£14.30	£17.16
189-1 - MOUNT (L) G2800L MSP-32B3021211 32B3021211	£14.30	£17.16
190-1 - MOUNT (L) G2800L MSP-32B3020211 32B3020211	£14.30	£17.16
191-1 - MOUNT (R) G2800L MSP-32B3020111 32B3020111	£14.30	£17.16
192 - FLANGE NUT G4300I/G2400R/G170 MSP-23808000.A1 23808000	-
194 - BRAKE G4300IS MSP-34G5600210 34G5600210	£28.60	£34.32
195 - SPRING G4300IS MSP-34G5610213 34G5610213	£10.40	£12.48
196 - BOLT AND WASHER ASSY G4300IS MSP-11408160.A1 11408160	-
197 - EARTH WIRE G4300IS MSP-33B4809101 33B4809101	£4.68	£5.62
198 - EARTH WIRE G4300IS MSP-34B4809101 34B4809101	£5.33	£6.40
199-1 - DRAIN GUIDE MSP-34G5521121 34G5521121	£6.89	£8.27
200 - FLANGE BOLT G2400R/G1700I/G2 MSP-110060020.A5 110060020	-
201 - SCREW G4300IS MSP-140060121 140060121	-
202 - FLANGE BOLT G2400R/G1700I/G2 MSP-110060020.A4 110060020	-
203 - WASHER G4300IS MSP-31112000 31112000	-
204 - COTTER PIN G4300IS MSP-51030250 51030250	-
205 - LABEL/(EARTH) G4300IS MSP-732002651 732002651	-
207 - TAPPING SCREW G4300IS/G1700I MSP-150040070.A0 150040070	-
208 - COVER (COCK) G4300IS MSP-33B4600103 33B4600103	£3.25	£3.90
209 - WASHER G4300IS MSP-31004000.A1 31004000	-
210 - BRACKET (COCK) G4300IS MSP-33B4601201 33B4601201	£7.28	£8.74
211 - SCREW AND WASHER ASSY G4300IS MSP-43606160 43606160	-
213 - SEAL SPONGE FC2 G4300IS MSP-34B5731103.A1 34B5731103	£2.49	£2.99
214 - SCREW G4300IS/G2400R/G2800L MSP-3534990408 3534990408	£1.66	£1.99
218 - GROMMET G4300IS MSP-2277500103 2277500103	£2.49	£2.99
219 - AC RECEPTACLE 240V-16A G2400 MSP-3534572718 3534572718	£80.78	£96.94
221 - NUT PB250/G4300IS/RBL250 MSP-21704000.A0 21704000	-
222 - WASHER G4300IS MSP-31004000.A0 31004000	-
224 - *MONITOR C/U INV2 G4300I MSP-KU31177011 KU31177011	£237.97	£285.56
224-1 - MONITOR C/U INV2 G4300IS MSP-KU31177041 KU31177041	£420.92	£505.11
226 - NUT PB250/G4300IS/RBL250 MSP-21704000.A1 21704000	-
231 - BRACKET G4300IS MSP-33B4601501 33B4601501	£6.24	£7.49
233 - TAPPING SCREW G4300IS/G1700I MSP-150040070.A1 150040070	-
235 - SCREW AND WASHER ASSY G4300IS MSP-31B7901103 31B7901103	£1.66	£1.99
238 - SCREW M5X18 MSP-3888800103 3888800103	£1.66	£1.99
239 - SPRING WASHER G2400R/G2800L MSP-3320005008 3320005008	£1.66	£1.99
240 - WASHER G2400R/G4300IS MSP-3534990308 3534990308	£1.66	£1.99
241 - NUT G2400R/G4300IS MSP-3534990208 3534990208	£1.66	£1.99
242 - LOCK WASHER G4300IS MSP-33005000 33005000	-
243 - WING NUT G2400R/G4300IS/G280 MSP-3534990108 3534990108	£4.16	£4.99
244 - CHOKE WIRE G4300IS MSP-33B4602101 33B4602101	£8.45	£10.14
245 - SCREW G4300IS MSP-140060190 140060190	-
249 - FRONT COVER (LOWER) CO G4300I MSP-33B5010101 33B5010101	£19.25	£23.10
250 - BRACKET (COVER) G4300IS MSP-33B3550101 33B3550101	£21.12	£25.34
251 - REAR COVER (UPPER) G4300IS MSP-33B5050101 33B5050101	£19.25	£23.10
253 - BOLT & WASHER ASSY G4300IS MSP-11106250 11106250	-
254 - FLANGE NUT 6 EW200/G1300K/G2 MSP-23806000.A1 23806000	-
255 - SEAL SPONGE FC1 G4300IS MSP-34B5731003 34B5731003	£14.30	£17.16
256 - SEAL SPONGE FC2 G4300IS MSP-34B5731103.A0 34B5731103	£2.49	£2.99
261-1 - COVER BOLT G4300IS MSP-34G5530301 34G5530301	£16.28	£19.54
262-1 - SPACER G4300IS MSP-34G5530401 34G5530401	£10.27	£12.32
265 - SEAL SPONGE (SIDE) G4300IS MSP-34G5732103 34G5732103	£5.46	£6.55
266-2 - MUFFLER COVER MSP-33B5621111 33B5621111	£93.10	£111.72
268 - SEAL RUBBER G4300IS MSP-33B5700503 33B5700503	£2.49	£2.99
270 - FLANGE BOLT G4300IS/G2400R MSP-110060080 110060080	-
271-1 - GLASS WOOL (M COVER) G4300IS MSP-33B5710513 33B5710513	£30.58	£36.70
274 - COVER (RECOIL KNOB) G430 MSP-34G5500101 34G5500101	£14.30	£17.16
275 - PLATE G4300IS MSP-34G5500201 34G5500201	£6.37	£7.64
279 - LABEL/(TRADE MARK-RC) G4300IS MSP-33B9713213 33B9713213	£5.33	£6.40
289 - FUEL TANK G2800L MSP-33B6010201 33B6010201	£154.98	£185.97
290 - FUEL TANK CAP G4300IS MSP-430590011 430590011	-
291 - FUEL FILTER G4300IS MSP-641540011 641540011	-
292 - FUEL GAUGE G4300IS MSP-648001500 648001500	-
293 - FUEL STRAINER ASSY G4300IS MSP-642010300 642010300	-
294 - FILTER G4300IS MSP-642009320 642009320	-
295 - RUBBER PACKING EW200R/ST MSP-642006440 642006440	-
296 - CUP G4300IS MSP-642007810 642007810	-
297 - PAN HEAD SCREW M3X8 G4300IS MSP-642004790 642004790	-
298 - FLANGE BOLT G2400R/G1700I/G2 MSP-110060020.A0 110060020	-
299 - HOSE CLAMP G1700I/G3500/3501R MSP-851060000.A0 851060000	-
300-2 - RUBBER PIPE (TANK COCK)G2800L MSP-33B6600213 33B6600213	£16.39	£19.67
301 - MESH PROTECTOR G4300IS MSP-2511730203 2511730203	£6.24	£7.49
302 - HOSE CLAMP G1700I/G3500/3501R MSP-561110020.A1 561110020	-
303 - HOSE CLAMP 13D G4300IS MSP-561130010.A0 561130010	-
304 - FLANGE BOLT G2400R/G4300IS MSP-110060220 110060220	-
305 - RUBBER (TANK) G2400R/G2800L MSP-3913900013 3913900013	£2.49	£2.99
306 - LABEL/(CAUTION) G4300IS MSP-33B9710213 33B9710213	£6.89	£8.27
307 - SPONGE 1 G1700I MSP-34G5733103 34G5733103	£7.28	£8.74
308 - SPONGE 2 G1700I MSP-34G5733203 34G5733203	£7.28	£8.74
309 - SCREEN G4300IS MSP-2773722003 2773722003	£2.49	£2.99
A01-1 - ACCESSORY TOOL KIT G4300IS/28 MSP-27790301J0.A1 27790301J0	£13.44	£16.13

Attribute Name	Value
Brand	Makita

Reviews Write your own review!

There are currently no reviews of this product.

Fill in the form below to add your review for Makita G2800IS Generator Spare Parts

Your Review
Title Required!
Rating Required!
Your Review Required!
Your Details
Your Name Required!
Your Location Required!
Email Address Required!Invalid email!

United Kingdom (Including N. Ireland)

On orders up to £40.00	Add £4.00 inc VAT (Royal Mail post)
On orders £40.00 to £130.00	Add £7.00 inc VAT (Courier)
On orders over £130.00	FREE (Courier)

Shopping Basket (0) £0.00

Makita G2800IS Generator Spare Parts

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search

Customization

Shopping Basket (0) £0.00

Information

Makita G2800IS Generator Spare Parts

Notify me

Your Review

Your Details

Carry On Shopping

Try these categories

Recently Viewed

Your Order

About Us

Other Links

Search
