1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084582.A1
084582
|
-
|
|
|
|
1.1 - INDUCTOR WITH COIL 230 V
MAF-084580.A0
084580
|
-
|
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-204223.A0
204223
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088138.A0
088138
|
£242.48
|
£290.98
|
|
|
3 - TACHOMETER CARRIER
MAF-038975.A70
038975
|
£20.14
|
£24.17
|
|
|
4 - PART NAME NOT AVAILABLE
MAF-203346.A1
203346
|
-
|
|
|
|
5 - CLAMPING SUPPORT, CPL.
MAF-038339.A2
038339
|
-
|
|
|
|
6 - STAR-SHAPED HANDLE
MAF-039082.A1
039082
|
£103.12
|
£123.75
|
|
|
7 - HANDLE
MAF-203824.A3
203824
|
-
|
|
|
|
8 - PART NAME NOT AVAILABLE
MAF-203827.A0
203827
|
£193.58
|
£232.29
|
|
|
10 - CASING
MAF-203717.A1
203717
|
-
|
|
|
|
11 - PART NAME NOT AVAILABLE
MAF-203829.A1
203829
|
-
|
|
|
|
12 - PART NAME NOT AVAILABLE
MAF-203715.A1
203715
|
£289.05
|
£346.86
|
|
|
13 - PART NAME NOT AVAILABLE
MAF-203833.A2
203833
|
-
|
|
|
|
14 - PART NAME NOT AVAILABLE
MAF-038319.A2
038319
|
-
|
|
|
|
15 - BEARING COVER
MAF-203721.A2
203721
|
-
|
|
|
|
16 - SHAFT BEARING
MAF-038323.A4
038323
|
-
|
|
|
|
17 - SUPPORT FOR TILTING DEVICE
MAF-038325.A1
038325
|
£75.34
|
£90.41
|
|
|
18 - BALL BEARING SUPPORT 607ZZ
MAF-038327.A6
038327
|
£50.76
|
£60.91
|
|
|
19 - SUPPORTING PIECE
MAF-038329.A2
038329
|
£10.00
|
£12.00
|
|
|
20 - PUSH-BUTTON
MAF-203821.A3
203821
|
-
|
|
|
|
21 - PLUNGE LEVER HANDLE
MAF-203176.A1
203176
|
-
|
|
|
|
22 - COVER, UPPER
MAF-203712.A1
203712
|
£40.91
|
£49.09
|
|
|
23 - COVER, LOWER
MAF-038345.A6
038345
|
£31.97
|
£38.36
|
|
|
24 - PART NAME NOT AVAILABLE
MAF-203825.A2
203825
|
-
|
|
|
|
25 - PART NAME NOT AVAILABLE
MAF-203822.A3
203822
|
-
|
|
|
|
26 - PART NAME NOT AVAILABLE
MAF-203723.A3
203723
|
-
|
|
|
|
27 - PART NAME NOT AVAILABLE
MAF-203724.A1
203724
|
-
|
|
|
|
28 - PART NAME NOT AVAILABLE
MAF-203726.A0
203726
|
-
|
|
|
|
29 - PAD
MAF-201872.A56
201872
|
-
|
|
|
|
30 - FAN
MAF-202348.A9
202348
|
-
|
|
|
|
31 - AIR CONDUCTING RING
MAF-203738.A1
203738
|
-
|
|
|
|
32 - MOTOR COVER
MAF-203713.A2
203713
|
-
|
|
|
|
33 - PART NAME NOT AVAILABLE
MAF-203725.A3
203725
|
-
|
|
|
|
34 - PART NAME NOT AVAILABLE
MAF-203747.A1
203747
|
-
|
|
|
|
35 - PART NAME NOT AVAILABLE
MAF-203748.A0
203748
|
-
|
|
|
|
36 - SETTING WHEEL
MAF-203729.A47
203729
|
-
|
|
|
|
38 - LEVER
MAF-203719.A1
203719
|
-
|
|
|
|
39 - GUIDE PLATE
MAF-038331.A3
038331
|
-
|
|
|
|
40 - HOLDING ANGLE
MAF-038348.A2
038348
|
-
|
|
|
|
41 - CLAMPING PLATE
MAF-033933.A8
033933
|
-
|
|
|
|
42 - CLAMPING DISK
MAF-038364.A6
038364
|
£4.11
|
£4.93
|
|
|
43 - BRAKE LEVER
MAF-203820.A0
203820
|
-
|
|
|
|
44 - PART NAME NOT AVAILABLE
MAF-203739.A2
203739
|
-
|
|
|
|
45 - THREADED BUSHING
MAF-038350.A1
038350
|
-
|
|
|
|
46 - BEARING BUSH
MAF-203728.A1
203728
|
-
|
|
|
|
47 - BOLT
MAF-203815.A3
203815
|
-
|
|
|
|
48 - SPACER SLEEVE
MAF-039514.A3
039514
|
£6.82
|
£8.18
|
|
|
49 - PART NAME NOT AVAILABLE
MAF-203818.A1
203818
|
-
|
|
|
|
50 - PART NAME NOT AVAILABLE
MAF-203780.A0
203780
|
-
|
|
|
|
52 - PART NAME NOT AVAILABLE
MAF-203727.A3
203727
|
-
|
|
|
|
53 - WHEEL SHAFT
MAF-038332.A4
038332
|
-
|
|
|
|
54 - CLAMPING DISK
MAF-038356.A1
038356
|
-
|
|
|
|
57 - WASHER
MAF-203730.A2
203730
|
-
|
|
|
|
58 - PART NAME NOT AVAILABLE
MAF-203809.A0
203809
|
-
|
|
|
|
59 - PART NAME NOT AVAILABLE
MAF-065051.A0
065051
|
£7.24
|
£8.69
|
|
|
60 - WING SCREW
MAF-079080.A17
079080
|
£7.70
|
£9.24
|
|
|
61 - WING SCREW
MAF-079026.A9
079026
|
-
|
|
|
|
62 - PART NAME NOT AVAILABLE
MAF-085168.A1
085168
|
-
|
|
|
|
63 - PART NAME NOT AVAILABLE
MAF-085174.A3
085174
|
-
|
|
|
|
65 - CYLINDRICAL PIN
MAF-058209.A2
058209
|
-
|
|
|
|
66 - PART NAME NOT AVAILABLE
MAF-055255.A1
055255
|
-
|
|
|
|
67 - CYLINDRICAL PIN
MAF-058005.A9
058005
|
£2.88
|
£3.45
|
|
|
68 - CYLINDRICAL PIN
MAF-058052.A10
058052
|
-
|
|
|
|
69 - CYLINDRICAL PIN
MAF-058145.A3
058145
|
£2.42
|
£2.90
|
|
|
70 - THREADED PIN
MAF-005295.A0
005295
|
-
|
|
|
|
71 - THREADED PIN
MAF-005284.A87
005284
|
-
|
|
|
|
72 - THREADED PIN
MAF-005274.A16
005274
|
-
|
|
|
|
73 - SHIM RING
MAF-061049.A10
061049
|
£1.72
|
£2.07
|
|
|
74 - SHIM RING
MAF-061141.A9
061141
|
-
|
|
|
|
75 - SHIM RING
MAF-061080.A7
061080
|
-
|
|
|
|
76 - BOWDEN CONTROL CABLE, LONG
MAF-038357.A2
038357
|
-
|
|
|
|
77 - PART NAME NOT AVAILABLE
MAF-203742.A4
203742
|
-
|
|
|
|
79 - STAR-SHAPED HANDLE SCREW
MAF-079043.A6
079043
|
-
|
|
|
|
80 - PART NAME NOT AVAILABLE
MAF-087869.A3
087869
|
-
|
|
|
|
82 - PART NAME NOT AVAILABLE
MAF-038340.A3
038340
|
£7.51
|
£9.01
|
|
|
83 - CABLE CLAMP
MAF-029584.A126
029584
|
-
|
|
|
|
84 - PRESSURE SPRING
MAF-066154.A19
066154
|
-
|
|
|
|
85 - PRESSURE SPRING
MAF-066056.A3
066056
|
-
|
|
|
|
86 - PRESSURE SPRING
MAF-066053.A16
066053
|
£2.54
|
£3.05
|
|
|
87 - PRESSURE SPRING
MAF-066043.A176
066043
|
£3.04
|
£3.65
|
|
|
88 - PART NAME NOT AVAILABLE
MAF-066153.A3
066153
|
-
|
|
|
|
89 - RETAINING RING
MAF-006194.A11
006194
|
-
|
|
|
|
90 - RETAINING RING
MAF-061008.A8
061008
|
-
|
|
|
|
92 - GROOVED BALL BEARING
MAF-062018.A23
062018
|
£26.06
|
£31.27
|
|
|
93 - GROOVED BALL BEARING
MAF-006268.A20
006268
|
£15.30
|
£18.36
|
|
|
94 - GROOVED BALL BEARING
MAF-062010.A32
062010
|
£14.52
|
£17.42
|
|
|
95 - GROOVED BALL BEARING
MAF-062073.A92
062073
|
£14.28
|
£17.14
|
|
|
96 - GROOVED BALL BEARING
MAF-006269.A21
006269
|
-
|
|
|
|
97 - GROOVED BALL BEARING
MAF-006280.A80
006280
|
£13.65
|
£16.38
|
|
|
100 - CYLINDER-HEAD SCREW
MAF-055198.A3
055198
|
-
|
|
|
|
103 - CYLINDER-HEAD SCREW
MAF-055074.A32
055074
|
£2.12
|
£2.55
|
|
|
104 - CYLINDER-HEAD SCREW
MAF-005531.A12
005531
|
£2.76
|
£3.31
|
|
|
105 - CYLINDER-HEAD SCREW
MAF-055108.A18
055108
|
£1.28
|
£1.54
|
|
|
106 - OVAL-HEAD SCREW
MAF-055068.A36
055068
|
-
|
|
|
|
107 - FLAT-HEAD SCREW
MAF-005349.A3
005349
|
-
|
|
|
|
108 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A197
055061
|
£1.71
|
£2.05
|
|
|
109 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A74
053020
|
£2.01
|
£2.41
|
|
|
110 - OVAL-HEAD SCREW
MAF-055114.A13
055114
|
-
|
|
|
|
111 - OVAL-HEAD SCREW
MAF-055069.A46
055069
|
£2.16
|
£2.59
|
|
|
112 - OVAL-HEAD SCREW
MAF-055101.A63
055101
|
£2.04
|
£2.45
|
|
|
113 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A91
055233
|
£1.71
|
£2.05
|
|
|
114 - SELF-TAPPING SCREW
MAF-055230.A90
055230
|
-
|
|
|
|
115 - SELF-TAPPING SCREW
MAF-055232.A31
055232
|
£1.68
|
£2.02
|
|
|
116 - HEXAGON-HEAD SCREW
MAF-056026.A0
056026
|
£2.00
|
£2.40
|
|
|
117 - FLAT-HEAD SCREW
MAF-053026.A1
053026
|
-
|
|
|
|
119 - HEXAGONAL NUT
MAF-005924.A43
005924
|
£1.67
|
£2.00
|
|
|
121 - HEXAGONAL NUT
MAF-005911.A26
005911
|
-
|
|
|
|
123 - CLAMP
MAF-086063.A8
086063
|
-
|
|
|
|
124 - WOODRUFF KEY
MAF-007805.A12
007805
|
£2.59
|
£3.11
|
|
|
125 - WASHER
MAF-006102.A60
006102
|
-
|
|
|
|
126 - WASHER
MAF-006101.A115
006101
|
£1.54
|
£1.85
|
|
|
128 - TOOTHED WASHER
MAF-006118.A6
006118
|
-
|
|
|
|
129 - LOCKING WASHER
MAF-006183.A25
006183
|
-
|
|
|
|
130 - LOCKING WASHER
MAF-006114.A37
006114
|
-
|
|
|
|
131 - LOCKING WASHER
MAF-006113.A53
006113
|
£1.92
|
£2.31
|
|
|
133 - LOCKING WASHER
MAF-006184.A59
006184
|
£1.50
|
£1.80
|
|
|
135 - COMPENSATING DISK
MAF-006671.A15
006671
|
£2.04
|
£2.45
|
|
|
136 - TERMINAL STRIP 2-POL.
MAF-087872.A0
087872
|
-
|
|
|
|
137 - PART NAME NOT AVAILABLE
MAF-203816.A4
203816
|
-
|
|
|
|
139 - PROTECTIVE TUBE
MAF-201250.A13
201250
|
-
|
|
|
|
141 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063176.A11
063176
|
£16.56
|
£19.87
|
|
|
142 - BRUSH HOLDER
MAF-063148.A72
063148
|
£10.30
|
£12.36
|
|
|
145 - PART NAME NOT AVAILABLE
MAF-038363.A4
038363
|
£20.62
|
£24.75
|
|
|
146 - THREADED EYE-BOLT
MAF-057018.A10
057018
|
-
|
|
|
|
147 - CONNECTING CABLE
MAF-085169.A3
085169
|
-
|
|
|
|
148 - CONNECTING CABLE
MAF-085170.A1
085170
|
-
|
|
|
|
149 - CABLE PROTECTING SLEEVE
MAF-086064.A103
086064
|
£3.37
|
£4.04
|
|
|
150 - SKALE
MAF-203734.A3
203734
|
£10.21
|
£12.25
|
|
|
151 - MAINS CABLE 10 M (32.8 FT.)
MAF-087863.A1
087863
|
-
|
|
|
|
152 - SEALING RING
MAF-065004.A65
065004
|
£1.63
|
£1.96
|
|
|
153 - PART NAME NOT AVAILABLE
MAF-052013.A2
052013
|
-
|
|
|
|
156 - RUBBER BUFFER
MAF-077047.A0
077047
|
£16.23
|
£19.48
|
|
|
157 - CONNECTING CABLE
MAF-085133.A6
085133
|
-
|
|
|
|
158 - CONTROL MODULE
MAF-077635.A1
077635
|
£120.16
|
£144.19
|
|
|
159 - SPEED DIAGRAM
MAF-077630.A2
077630
|
-
|
|
|
|
160 - PART NAME NOT AVAILABLE
MAF-085137.A2
085137
|
-
|
|
|
|
161 - PART NAME NOT AVAILABLE
MAF-085138.A3
085138
|
-
|
|
|
|
162 - WASHER
MAF-062050.A4
062050
|
-
|
|
|
|
163 - AXIAL WASHER
MAF-062081.A3
062081
|
-
|
|
|
|
164 - CABLE BINDER
MAF-076492.A17
076492
|
-
|
|
|
|
502 - BAND SAW BLADES, 10 PIECES
MAF-092335.A0
092335
|
£24.16
|
£28.99
|
|
|
503 - BAND SAW BLADES, 10 PIECES
MAF-092336.A3
092336
|
£20.16
|
£24.19
|
|
|
504 - BAND SAW BLADES, 1 PIECE
MAF-092337.A2
092337
|
£34.99
|
£41.99
|
|
|
507 - HANDLE
MAF-204038.A1
204038
|
-
|
|
|
|
508 - PARALLEL GUIDE FENCE
MAF-039386.A3
039386
|
£72.60
|
£87.12
|
|
|
509 - PART NAME NOT AVAILABLE
MAF-078178.A1
078178
|
-
|
|
|
