1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084594.A4
084594
|
-
|
|
|
|
1.1 - MOTOR CASING, EMPTY
MAF-203935.A0
203935
|
-
|
|
|
|
1.2 - INDUCTOR WITH COIL
MAF-084547.A7
084547
|
£88.61
|
£106.33
|
|
|
1.3 - SWITCH ROD
MAF-203943.A4
203943
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088187.A3
088187
|
£113.59
|
£136.31
|
|
|
6 - HANDLE SHELLS (PAIR)
MAF-203938.A4
203938
|
-
|
|
|
|
7 - SWITCH LEVER
MAF-203921.A0
203921
|
-
|
|
|
|
8 - PLUNGER, CPL.
MAF-205510.A4
205510
|
£188.10
|
£225.72
|
|
|
9 - SOLE PLATE P1-GP
MAF-204350.A0
204350
|
£86.72
|
£104.06
|
|
|
9.1 - BASE PLATE
MAF-203905.A1
203905
|
£86.72
|
£104.06
|
|
|
9.2 - SLIDING BASE
MAF-205506.A0
205506
|
£31.96
|
£38.35
|
|
|
9.3 - FLAT-HEAD SCREW
MAF-005399.A22
005399
|
£1.27
|
£1.52
|
|
|
11 - CLAMPING PLATE
MAF-204871.A0
204871
|
£14.55
|
£17.46
|
|
|
12 - GEAR CASING
MAF-205507.A2
205507
|
-
|
|
|
|
15 - COUNTERWIGHT
MAF-203909.A0
203909
|
-
|
|
|
|
16 - ROCKER
MAF-203931.A1
203931
|
£54.63
|
£65.56
|
|
|
21 - ROUE DENTÉE
MAF-203904.A4
203904
|
£87.82
|
£105.38
|
|
|
22 - TAKE-UP
MAF-203908.A1
203908
|
£40.57
|
£48.68
|
|
|
32 - BUSH
MAF-203915.A2
203915
|
-
|
|
|
|
33 - BUSH
MAF-203918.A2
203918
|
-
|
|
|
|
34 - GEAR CASING COVER
MAF-203903.A0
203903
|
-
|
|
|
|
35 - LATCH
MAF-203934.A3
203934
|
-
|
|
|
|
37 - FAN
MAF-203964.A3
203964
|
-
|
|
|
|
38 - MOTOR COVER
MAF-203948.A3
203948
|
-
|
|
|
|
39 - ENGAGING LEVER
MAF-203945.A2
203945
|
-
|
|
|
|
41 - AIR CONDUCTING RING
MAF-203942.A3
203942
|
-
|
|
|
|
42 - GASKET CUP
MAF-203919.A2
203919
|
£6.08
|
£7.30
|
|
|
46 - SLIDING BAR
MAF-204877.A3
204877
|
-
|
|
|
|
48 - GUARD BOW
MAF-203929.A0
203929
|
-
|
|
|
|
49 - CENTRIFUGAL DISK
MAF-203924.A0
203924
|
-
|
|
|
|
50 - TENSIONING LEVER
MAF-203961.A4
203961
|
£10.48
|
£12.57
|
|
|
51 - CLAMPING LEVER
MAF-203916.A2
203916
|
-
|
|
|
|
52 - LIMITATION
MAF-204875.A1
204875
|
-
|
|
|
|
53 - TACHOMETER CARRIER
MAF-205518.A3
205518
|
-
|
|
|
|
57 - LEVER
MAF-205508.A2
205508
|
£21.66
|
£25.99
|
|
|
58 - PRESSURE LEVER
MAF-205509.A4
205509
|
£73.42
|
£88.11
|
|
|
58.1 - ADJUSTING SLEEVE
MAF-203965.A3
203965
|
-
|
|
|
|
58.2 - PRESSURE LEVER
MAF-205514.A4
205514
|
-
|
|
|
|
58.3 - PULLING LEVER
MAF-203974.A3
203974
|
-
|
|
|
|
58.4 - PRESS-IN BOLT
MAF-204419.A4
204419
|
-
|
|
|
|
58.5 - BOLT
MAF-204876.A1
204876
|
-
|
|
|
|
58.6 - BEARING RING
MAF-204881.A3
204881
|
-
|
|
|
|
58.7 - CYLINDRICAL PIN
MAF-058046.A15
058046
|
£2.83
|
£3.40
|
|
|
58.8 - LOCKING WASHER
MAF-061024.A0
061024
|
-
|
|
|
|
58.9 - LOCKING WASHER
MAF-061025.A16
061025
|
-
|
|
|
|
58.10 - WASHER
MAF-062044.A3
062044
|
-
|
|
|
|
60 - WASHER
MAF-204355.A3
204355
|
-
|
|
|
|
62 - ECCENTRIC ARBOR
MAF-203967.A1
203967
|
-
|
|
|
|
65 - SPRING WIRE
MAF-203957.A3
203957
|
-
|
|
|
|
66 - SAFETY GUARD
MAF-204358.A0
204358
|
-
|
|
|
|
70 - SHAFT AXLE
MAF-204883.A3
204883
|
-
|
|
|
|
74 - ROLLER
MAF-204338.A4
204338
|
-
|
|
|
|
75 - LOCKING LEVER
MAF-203955.A4
203955
|
-
|
|
|
|
76 - COLLET NUT
MAF-204337.A1
204337
|
-
|
|
|
|
78 - GASKET
MAF-203927.A2
203927
|
-
|
|
|
|
79 - FELT
MAF-203930.A0
203930
|
-
|
|
|
|
80 - FELT GASKET
MAF-203932.A3
203932
|
-
|
|
|
|
81 - FELT GASKET
MAF-205463.A1
205463
|
-
|
|
|
|
82 - COVERING DISC
MAF-204418.A0
204418
|
-
|
|
|
|
84 - BALL BEARING
MAF-062106.A0
062106
|
-
|
|
|
|
85 - GROOVED BALL BEARING
MAF-006292.A16
006292
|
£12.47
|
£14.96
|
|
|
88 - NEEDLE BEARING
MAF-062054.A3
062054
|
£26.32
|
£31.58
|
|
|
91 - SETTING WHEEL
MAF-204340.A3
204340
|
-
|
|
|
|
92 - CARBON BRUSH
MAF-063170.A9
063170
|
£12.81
|
£15.37
|
|
|
93 - BRUSH HOLDER
MAF-063128.A12
063128
|
£2.12
|
£2.55
|
|
|
94 - SNAP-ACTION SWITCH
MAF-087910.A7
087910
|
£14.32
|
£17.19
|
|
|
95 - CONTROL MODULE
MAF-077664.A0
077664
|
£68.60
|
£82.32
|
|
|
96 - CABLE PROTECTING SLEEVE
MAF-086064.A42
086064
|
£3.37
|
£4.04
|
|
|
97 - MAINS CABLE 4 M (13.1 FT)
MAF-077017.A11
077017
|
£31.90
|
£38.28
|
|
|
100 - STICKER
MAF-170222.A1
170222
|
-
|
|
|
|
103 - CUP SPRING
MAF-066165.A7
066165
|
-
|
|
|
|
104 - CUP SPRING
MAF-006664.A3
006664
|
£1.98
|
£2.38
|
|
|
106 - PRESSURE SPRING
MAF-066169.A4
066169
|
-
|
|
|
|
107 - PRESSURE SPRING
MAF-066072.A16
066072
|
£4.98
|
£5.97
|
|
|
108 - PRESSURE SPRING
MAF-066053.A8
066053
|
£2.54
|
£3.05
|
|
|
109 - TORSION SPRING
MAF-076211.A8
076211
|
-
|
|
|
|
111 - FLAT-HEAD SCREW
MAF-053037.A2
053037
|
-
|
|
|
|
112 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A76
055061
|
£1.71
|
£2.05
|
|
|
114 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A38
055058
|
-
|
|
|
|
116 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A42
055233
|
£1.71
|
£2.05
|
|
|
117 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A45
055086
|
-
|
|
|
|
118 - OVAL-HEAD SCREW
MAF-055115.A5
055115
|
-
|
|
|
|
119 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055153.A13
055153
|
-
|
|
|
|
121 - THREADED PIN
MAF-052011.A28
052011
|
-
|
|
|
|
122 - OVAL-HEAD SCREW
MAF-055143.A4
055143
|
-
|
|
|
|
123 - THREADED PIN
MAF-005274.A4
005274
|
-
|
|
|
|
127 - SHIM RING
MAF-061184.A0
061184
|
-
|
|
|
|
128 - RETAINING RING
MAF-006171.A10
006171
|
£1.92
|
£2.31
|
|
|
129 - LOCKING WASHER
MAF-061135.A22
061135
|
-
|
|
|
|
131 - SHIM RING
MAF-061050.A11
061050
|
£1.92
|
£2.31
|
|
|
132 - LOCKING WASHER
MAF-061025.A13
061025
|
-
|
|
|
|
134 - SPIRAL DOWEL SLEEVE
MAF-058186.A14
058186
|
-
|
|
|
|
140 - CYLINDRICAL PIN
MAF-058213.A3
058213
|
-
|
|
|
|
502 - HOSE CONNECTOR P1-AS
MAF-203917.A3
203917
|
£17.16
|
£20.59
|
|
|
503 - CHIP DEFLECTOR P1-SA
MAF-204353.A4
204353
|
£6.38
|
£7.66
|
|
|
504 - GLIDER P1-G
MAF-205464.A2
205464
|
£14.47
|
£17.36
|
|
|
505 - SPLINTER GUARD P1-SS
MAF-205447.A3
205447
|
£10.08
|
£12.09
|
|
|
511 - CARRYING CASE MAX, GR.I
MAF-095076.A3
095076
|
-
|
|
|
|
512 - PLASTIC TRAY FOR TK MAX
MAF-095077.A0
095077
|
-
|
|
|
|
518 - COVER SHEET
MAF-095160.A0
095160
|
-
|
|
|
