1 - MOTOR CASING WITH INDUCTOR 230 V
MAF-084640.A12
084640
|
£166.83
|
£200.20
|
|
|
1.1 - INDUCTOR WITH COIL
MAF-084540.A24
084540
|
£87.14
|
£104.57
|
|
|
1.2 - MOTOR CASING, EMPTY
MAF-202045.A23
202045
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088116.A3
088116
|
£177.19
|
£212.63
|
|
|
4 - GEAR CASING
MAF-201438.A10
201438
|
£138.16
|
£165.79
|
|
|
5 - BASE PLATE
MAF-201432.A0
201432
|
-
|
|
|
|
6 - TILTING SUPPORT
MAF-204030.A2
204030
|
-
|
|
|
|
7 - PROTECTIVE COVER
MAF-201439.A5
201439
|
-
|
|
|
|
8 - GEAR CASING COVER
MAF-200035.A11
200035
|
-
|
|
|
|
12 - HANDLE SHELLS (PAIR)
MAF-202741.A10
202741
|
-
|
|
|
|
13 - MOTOR COVER
MAF-200183.A11
200183
|
-
|
|
|
|
14 - SEGMENT FOR TILTING
MAF-200009.A5
200009
|
-
|
|
|
|
15 - PROTECTIVE COVER
MAF-205440.A1
205440
|
-
|
|
|
|
16 - COVER
MAF-200078.A13
200078
|
-
|
|
|
|
17 - AIR CONDUCTING RING
MAF-200013.A11
200013
|
-
|
|
|
|
18 - SLEEVE
MAF-200048.A14
200048
|
-
|
|
|
|
19 - FAN
MAF-200015.A27
200015
|
£7.85
|
£9.42
|
|
|
21 - LOCKING BOLT
MAF-202436.A15
202436
|
-
|
|
|
|
22 - SWITCH TRIGGER
MAF-201434.A8
201434
|
-
|
|
|
|
23 - CAP
MAF-202345.A17
202345
|
£5.74
|
£6.89
|
|
|
25 - BRAKE LEVER
MAF-202347.A30
202347
|
£6.25
|
£7.50
|
|
|
28 - SHEET METAL DEFLECTOR
MAF-200023.A5
200023
|
-
|
|
|
|
30 - LEVER JOINT
MAF-201442.A8
201442
|
£14.13
|
£16.96
|
|
|
33 - CLAMPING CLAWS
MAF-200050.A50
200050
|
£4.32
|
£5.18
|
|
|
34 - RIVING KNIFE/SPLITTER SUPPORT
MAF-201441.A12
201441
|
-
|
|
|
|
35 - RIVING KNIFE/SPLITTER
MAF-202580.A18
202580
|
£10.26
|
£12.31
|
|
|
37 - CLAMPING LEVER
MAF-201433.A14
201433
|
£7.90
|
£9.48
|
|
|
41 - GUIDE COLUMN, SHORT
MAF-202435.A10
202435
|
-
|
|
|
|
42 - GUIDE COLUMN, LONG
MAF-202434.A20
202434
|
£20.25
|
£24.30
|
|
|
43 - SAW SHAFT
MAF-200032.A2
200032
|
-
|
|
|
|
45 - PRESSURE BOLT
MAF-200034.A28
200034
|
-
|
|
|
|
46 - FLANGE, REAR
MAF-200038.A22
200038
|
-
|
|
|
|
47 - ECCENTRIC ARBOR
MAF-202433.A11
202433
|
£28.24
|
£33.89
|
|
|
52 - FLANGE, FRONT
MAF-200037.A8
200037
|
-
|
|
|
|
53 - PRESSURE BIT
MAF-202378.A34
202378
|
-
|
|
|
|
54 - STOP BUFFER
MAF-034209.A53
034209
|
-
|
|
|
|
55 - BRAKE LINING
MAF-202429.A31
202429
|
-
|
|
|
|
56 - RETRACTING SPRING
MAF-066090.A29
066090
|
-
|
|
|
|
57 - RETRACTING SPRING
MAF-066091.A15
066091
|
-
|
|
|
|
58 - RETRACTING SPRING
MAF-066092.A25
066092
|
£4.98
|
£5.97
|
|
|
59 - PRESSURE SPRING
MAF-066043.A153
066043
|
£3.04
|
£3.65
|
|
|
61 - PRESSURE SPRING
MAF-006657.A19
006657
|
-
|
|
|
|
62 - BRUSH HOLDER
MAF-063160.A46
063160
|
£10.07
|
£12.08
|
|
|
63 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063164.A53
063164
|
£12.41
|
£14.89
|
|
|
64 - BRAKE DRUM
MAF-201452.A21
201452
|
£13.66
|
£16.39
|
|
|
65 - SKALE
MAF-077074.A2
077074
|
-
|
|
|
|
67 - GROOVED BALL BEARING
MAF-006282.A83
006282
|
£14.68
|
£17.62
|
|
|
68 - GROOVED BALL BEARING
MAF-006288.A40
006288
|
£8.82
|
£10.58
|
|
|
69 - GROOVED BALL BEARING
MAF-062065.A23
062065
|
£34.87
|
£41.84
|
|
|
71 - WING NUT
MAF-007996.A13
007996
|
-
|
|
|
|
73 - LOCKING WASHER
MAF-061069.A78
061069
|
£1.49
|
£1.79
|
|
|
75 - WING SCREW
MAF-079070.A14
079070
|
-
|
|
|
|
79 - SELF-TAPPING SCREW
MAF-055232.A58
055232
|
£1.68
|
£2.02
|
|
|
81 - SELF-TAPPING SCREW
MAF-055230.A94
055230
|
-
|
|
|
|
83 - CYLINDER-HEAD SCREW
MAF-055096.A52
055096
|
£2.11
|
£2.53
|
|
|
84 - CYLINDER-HEAD SCREW
MAF-055055.A38
055055
|
-
|
|
|
|
85 - CYLINDER-HEAD SCREW
MAF-055234.A34
055234
|
£1.19
|
£1.43
|
|
|
89 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A220
055061
|
£1.71
|
£2.05
|
|
|
93 - FLAT-HEAD SCREW
MAF-053029.A30
053029
|
£2.84
|
£3.41
|
|
|
94 - THREADED PIN
MAF-005284.A77
005284
|
-
|
|
|
|
95 - TRUSS-HEAD SCREW
MAF-005718.A12
005718
|
-
|
|
|
|
96 - FEDERSCHEIBE
MAF-061132.A35
061132
|
-
|
|
|
|
97 - RETAINING RING
MAF-061138.A35
061138
|
£2.29
|
£2.75
|
|
|
98 - WASHER
MAF-061013.A80
061013
|
-
|
|
|
|
99 - WASHER
MAF-006101.A143
006101
|
£1.54
|
£1.85
|
|
|
101 - SPIRAL DOWEL SLEEVE
MAF-058164.A7
058164
|
-
|
|
|
|
102 - WASHER
MAF-061167.A15
061167
|
£51.32
|
£61.59
|
|
|
103 - SEALING RING
MAF-065042.A28
065042
|
£1.63
|
£1.96
|
|
|
104 - CUP SPRING
MAF-066093.A9
066093
|
-
|
|
|
|
111 - PART NAME NOT AVAILABLE
MAF-085178.A4
085178
|
-
|
|
|
|
113 - CABLE PROTECTING SLEEVE
MAF-086064.A86
086064
|
£3.37
|
£4.04
|
|
|
115 - 2-POLE SWITCH WITH LOCK-OFF BUTTON
MAF-087828.A8
087828
|
£21.78
|
£26.14
|
|
|
117 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-076973.A9
076973
|
-
|
|
|
|
118 - MAINS CABLE 4 M (13.1 FT)
MAF-087323.A57
087323
|
£39.41
|
£47.29
|
|
|
120 - CABLE CLAMP
MAF-029584.A163
029584
|
-
|
|
|
|
500 - HOSE CONNECTOR
MAF-200042.A12
200042
|
£14.96
|
£17.95
|
|
|
502 - PARALLEL GUIDE FENCE
MAF-201436.A23
201436
|
£50.20
|
£60.24
|
|
|
508 - ALLEN KEY
MAF-093034.A66
093034
|
-
|
|
|
|
520 - CARRYING CASE MAFELL-MAX
MAF-095043.A30
095043
|
-
|
|
|
|
520.1 - LATCH
MAF-095074.A50
095074
|
-
|
|
|
|
521 - PLASTIC TRAY
MAF-095051.A0
095051
|
-
|
|
|
