1 - MOTOR CASING WITH INDUCTOR
MAF-084456.A0
084456
|
-
|
|
|
|
2 - INDUCTOR WITH COIL
MAF-084455.A1
084455
|
-
|
|
|
|
3 - ARMATURE, BALANCED
MAF-088124.A1
088124
|
£374.00
|
£448.80
|
|
|
4 - MAIN BODY WITH FRONT BASE PLATE, ASSEMBLED
MAF-035151.A1
035151
|
-
|
|
|
|
5 - PART NAME NOT AVAILABLE
MAF-035148.A1
035148
|
-
|
|
|
|
6 - CENTERING SLEEVE
MAF-036054.A10
036054
|
-
|
|
|
|
7 - CONTROL MODULE
MAF-077145.A1
077145
|
-
|
|
|
|
8 - CLAMPING BAR
MAF-035152.A0
035152
|
-
|
|
|
|
10 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055100.A6
055100
|
-
|
|
|
|
12 - SHOULDER SCREW
MAF-036853.A3
036853
|
£8.87
|
£10.64
|
|
|
13 - CYLINDRICAL PIN
MAF-058125.A0
058125
|
£2.86
|
£3.43
|
|
|
14 - CUP SPRING
MAF-066027.A3
066027
|
£1.75
|
£2.10
|
|
|
15 - COVER
MAF-200863.A1
200863
|
-
|
|
|
|
16 - COVERING PLATE
MAF-035993.A2
035993
|
-
|
|
|
|
17 - LID
MAF-036034.A11
036034
|
-
|
|
|
|
18 - GUIDE RAIL
MAF-036854.A2
036854
|
-
|
|
|
|
19 - JACKET
MAF-036861.A1
036861
|
-
|
|
|
|
20 - ADHESIVE LABEL
MAF-077651.A0
077651
|
-
|
|
|
|
21 - DRIVING WHEEL, SMALL
MAF-200681.A2
200681
|
-
|
|
|
|
22 - DRIVING WHEEL, LARGE
MAF-038689.A1
038689
|
-
|
|
|
|
23 - MOTOR COVER
MAF-039174.A4
039174
|
-
|
|
|
|
24 - FAN
MAF-035138.A3
035138
|
£10.59
|
£12.71
|
|
|
25 - AIR CONDUCTING RING
MAF-035139.A8
035139
|
-
|
|
|
|
26 - CONNECTING CABLE, BLUE
MAF-075165.A1
075165
|
-
|
|
|
|
27 - CONNECTING CABLE, BLACK
MAF-075166.A0
075166
|
-
|
|
|
|
28 - PAD
MAF-201872.A40
201872
|
-
|
|
|
|
29 - BOUNDARY DISK
MAF-200680.A8
200680
|
-
|
|
|
|
30 - CLAMPING BARS, CPL.
MAF-201216.A0
201216
|
-
|
|
|
|
31 - SPACER DISK
MAF-035994.A10
035994
|
-
|
|
|
|
32 - HANDLE SHELLS (PAIR)
MAF-201222.A2
201222
|
-
|
|
|
|
33 - SPACER RING
MAF-038484.A3
038484
|
-
|
|
|
|
34 - PROTECTIVE TUBE
MAF-034779.A4
034779
|
-
|
|
|
|
35 - PROTECTIVE COVER
MAF-035140.A7
035140
|
£42.32
|
£50.79
|
|
|
36 - LEVER
MAF-035147.A4
035147
|
-
|
|
|
|
37 - CABLE CLAMP
MAF-029584.A71
029584
|
-
|
|
|
|
38 - KNIFE SUPPORTS (PAIR)
MAF-091581.A0
091581
|
-
|
|
|
|
39 - CUTTER HEAD, BALANCED
MAF-201215.A0
201215
|
-
|
|
|
|
40 - THREADED PIN
MAF-005284.A59
005284
|
-
|
|
|
|
41 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A29
055058
|
-
|
|
|
|
42 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A136
055061
|
£1.71
|
£2.05
|
|
|
43 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A50
055062
|
-
|
|
|
|
44 - OVAL-HEAD SCREW
MAF-055129.A10
055129
|
-
|
|
|
|
45 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055091.A13
055091
|
-
|
|
|
|
46 - OVAL-HEAD SCREW
MAF-055082.A3
055082
|
£1.37
|
£1.64
|
|
|
47 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A31
055086
|
-
|
|
|
|
48 - OVAL-HEAD SCREW
MAF-055101.A13
055101
|
£2.04
|
£2.45
|
|
|
50 - HEXAGON-HEAD SCREW
MAF-035103.A15
035103
|
£2.95
|
£3.54
|
|
|
51 - KNURLED KNOB
MAF-065029.A1
065029
|
£9.22
|
£11.06
|
|
|
52 - HEXAGONAL NUT
MAF-005939.A35
005939
|
-
|
|
|
|
54 - HEXAGONAL NUT
MAF-005924.A37
005924
|
£1.67
|
£2.00
|
|
|
56 - CYLINDER-HEAD SCREW
MAF-005505.A17
005505
|
-
|
|
|
|
57 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A20
055124
|
-
|
|
|
|
58 - LOCKING WASHER
MAF-061078.A0
061078
|
-
|
|
|
|
59 - GROOVED BALL BEARING
MAF-006260.A30
006260
|
£18.15
|
£21.78
|
|
|
60 - GROOVED BALL BEARING
MAF-006268.A8
006268
|
£15.30
|
£18.36
|
|
|
61 - GROOVED BALL BEARING
MAF-006280.A47
006280
|
£13.65
|
£16.38
|
|
|
62 - GROOVED BALL BEARING
MAF-006282.A51
006282
|
£14.68
|
£17.62
|
|
|
63 - GROOVED BALL BEARING
MAF-062073.A51
062073
|
£14.28
|
£17.14
|
|
|
67 - RETAINING RING
MAF-007141.A9
007141
|
£3.56
|
£4.27
|
|
|
68 - TOOTHED BELT
MAF-076110.A0
076110
|
£42.61
|
£51.13
|
|
|
69 - TACHOMETER CARRIER
MAF-038975.A25
038975
|
£20.14
|
£24.17
|
|
|
70 - HANDLE
MAF-035137.A8
035137
|
-
|
|
|
|
71 - CABLE PROTECTING SLEEVE
MAF-086065.A35
086065
|
£3.46
|
£4.15
|
|
|
73 - MAINS CABLE 10 M (32.8 FT.)
MAF-087612.A27
087612
|
£72.48
|
£86.98
|
|
|
74 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-087650.A6
087650
|
£20.06
|
£24.07
|
|
|
75 - 2-POLE SWITCH WITH LOCK-OFF BUTTON
MAF-087461.A2
087461
|
£44.07
|
£52.88
|
|
|
77 - SINGLE-END SPANNER
MAF-093258.A14
093258
|
£7.21
|
£8.65
|
|
|
78 - SEALING RING
MAF-065004.A30
065004
|
-
|
|
|
|
79 - REVERSIBLE HL KNIVES (PAIR)
MAF-091507.A1
091507
|
£31.15
|
£37.38
|
|
|
80 - WASHER
MAF-061015.A24
061015
|
-
|
|
|
|
81 - WASHER
MAF-037691.A6
037691
|
-
|
|
|
|
82 - BASE PLATE, FRONT
MAF-038463.A2
038463
|
-
|
|
|
|
83 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A64
053020
|
-
|
|
|
|
84 - SPACER RING
MAF-039007.A4
039007
|
-
|
|
|
|
85 - CHIP EJECTOR
MAF-039375.A1
039375
|
-
|
|
|
|
86 - FASTENING PIECE
MAF-039377.A1
039377
|
-
|
|
|
|
87 - SHOULDER SCREW
MAF-055063.A6
055063
|
-
|
|
|
|
88 - CUP SPRING
MAF-006660.A19
006660
|
-
|
|
|
|
89 - SHIM RING
MAF-061114.A8
061114
|
-
|
|
|
|
90 - WASHER
MAF-006100.A54
006100
|
£2.01
|
£2.41
|
|
