1 - MOTOR CASING WITH INDUCTOR
MAF-084434.A1
084434
|
-
|
|
|
|
2 - PART NAME NOT AVAILABLE
MAF-088118.A
088118
|
-
|
|
|
|
3 - BASE PLATE, CPL.
MAF-038983.A0
038983
|
-
|
|
|
|
3.1 - SLIDING SURFACE
MAF-201576.A0
201576
|
-
|
|
|
|
4 - PART NAME NOT AVAILABLE
MAF-038946.A
038946
|
-
|
|
|
|
7 - LOOM OF CABLES
MAF-085143.A1
085143
|
£9.93
|
£11.92
|
|
|
8 - MOTOR CASING, EMPTY
MAF-200234.A1
200234
|
-
|
|
|
|
9 - INDUCTOR WITH COIL
MAF-084441.A0
084441
|
-
|
|
|
|
10 - CONTROL MODULE
MAF-076275.A1
076275
|
£152.98
|
£183.57
|
|
|
12 - REVOLVING DEPTH CONTROL TURRET
MAF-038967.A0
038967
|
-
|
|
|
|
13 - PARALLEL GUIDE FENCE
MAF-038980.A4
038980
|
-
|
|
|
|
14 - KNURLED-HEAD SCREW
MAF-039366.A0
039366
|
-
|
|
|
|
15 - SLIDING BAR
MAF-038978.A0
038978
|
-
|
|
|
|
16 - FAN, UPPER
MAF-032355.A15
032355
|
£12.50
|
£15.00
|
|
|
17 - AIR CONDUCTING RING
MAF-038968.A4
038968
|
-
|
|
|
|
18 - SWITCH COVER, RED
MAF-038950.A1
038950
|
-
|
|
|
|
19 - INDICATOR
MAF-038951.A8
038951
|
-
|
|
|
|
20 - WASHER
MAF-033011.A0
033011
|
-
|
|
|
|
21 - MOTOR COVER
MAF-038969.A0
038969
|
-
|
|
|
|
22 - HANDLE
MAF-038970.A11
038970
|
£8.36
|
£10.03
|
|
|
23 - PRESSURE BOLT
MAF-038952.A9
038952
|
-
|
|
|
|
24 - SETTING WHEEL
MAF-038949.A0
038949
|
-
|
|
|
|
25 - HANDLE
MAF-039101.A11
039101
|
-
|
|
|
|
26 - HANDLE TAB
MAF-038962.A3
038962
|
-
|
|
|
|
27 - PART NAME NOT AVAILABLE
MAF-200732.A
200732
|
-
|
|
|
|
28 - KNURLED NUT
MAF-038953.A5
038953
|
-
|
|
|
|
29 - STROKE LIMITER
MAF-200730.A4
200730
|
-
|
|
|
|
30 - SETTING NUT
MAF-038956.A3
038956
|
-
|
|
|
|
31 - INDEX BOLT
MAF-038957.A1
038957
|
£23.99
|
£28.79
|
|
|
32 - SPACER RING
MAF-038958.A
038958
|
-
|
|
|
|
33 - TACHOMETER CARRIER
MAF-038975.A10
038975
|
£20.14
|
£24.17
|
|
|
34 - KNURLED-HEAD SCREW
MAF-038977.A1
038977
|
-
|
|
|
|
35 - TRAVERSE
MAF-038976.A4
038976
|
-
|
|
|
|
36 - GUIDE BAR
MAF-039115.A5
039115
|
-
|
|
|
|
37 - COLLET NUT
MAF-201574.A6
201574
|
£34.61
|
£41.53
|
|
|
38 - STEEL BALL
MAF-062042.A2
062042
|
-
|
|
|
|
39 - CABLE CLAMP
MAF-029584.A4
029584
|
-
|
|
|
|
40 - CABLE PROTECTING SLEEVE
MAF-086064.A13
086064
|
£3.37
|
£4.04
|
|
|
41 - MAINS CABLE 4 M (13.1 FT)
MAF-087323.A2
087323
|
£39.41
|
£47.29
|
|
|
42 - 2-POLE SWITCH
MAF-087548.A2
087548
|
£82.22
|
£98.67
|
|
|
43 - DEPTH SCALE
MAF-077602.A6
077602
|
-
|
|
|
|
44 - SPEED DIAGRAM
MAF-077613.A0
077613
|
-
|
|
|
|
45 - DEPTH STOP
MAF-038963.A5
038963
|
-
|
|
|
|
46 - COLLET NUT
MAF-200439.A1
200439
|
-
|
|
|
|
47 - PRESSURE SPRING
MAF-066043.A18
066043
|
£3.04
|
£3.65
|
|
|
48 - PRESSURE SPRING
MAF-066051.A9
066051
|
-
|
|
|
|
49 - PRESSURE SPRING
MAF-066063.A2
066063
|
-
|
|
|
|
50 - PRESSURE BIT
MAF-005286.A0
005286
|
-
|
|
|
|
51 - SEALING RING
MAF-065004.A4
065004
|
-
|
|
|
|
52 - PRESSURE SPRING
MAF-066089.A2
066089
|
-
|
|
|
|
53 - LOCKING WASHER
MAF-006184.A10
006184
|
£1.50
|
£1.80
|
|
|
55 - LOCKING WASHER
MAF-006183.A9
006183
|
-
|
|
|
|
56 - GUIDE COLUMN
MAF-038972.A8
038972
|
£30.77
|
£36.92
|
|
|
57 - SEALING RING
MAF-065007.A
065007
|
-
|
|
|
|
58 - PAD
MAF-201872.A7
201872
|
-
|
|
|
|
60 - INTERFERENCE SUPPRESSION CAPACITOR
MAF-087650.A0
087650
|
£20.06
|
£24.07
|
|
|
63 - CARBON BRUSH WITH AUTOMATIC CUT-OFF
MAF-063147.A18
063147
|
£14.72
|
£17.67
|
|
|
64 - BRUSH HOLDER
MAF-063148.A24
063148
|
£10.30
|
£12.36
|
|
|
68 - WING SCREW
MAF-079077.A0
079077
|
-
|
|
|
|
71 - HEXAGON-HEAD SCREW
MAF-005678.A1
005678
|
-
|
|
|
|
72 - SHOULDER SCREW
MAF-055169.A3
055169
|
-
|
|
|
|
73 - OVAL-HEAD SCREW
MAF-055152.A0
055152
|
-
|
|
|
|
74 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055086.A24
055086
|
-
|
|
|
|
75 - CAP NUT
MAF-005950.A1
005950
|
-
|
|
|
|
76 - CYLINDER-HEAD SCREW
MAF-005505.A4
005505
|
-
|
|
|
|
77 - FLAT-HEAD SCREW
MAF-053006.A7
053006
|
-
|
|
|
|
79 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A22
055061
|
£1.71
|
£2.05
|
|
|
80 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055124.A4
055124
|
-
|
|
|
|
81 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055062.A24
055062
|
-
|
|
|
|
82 - COUNTER-SUNK OVAL-HEAD SCREW
MAF-053020.A13
053020
|
-
|
|
|
|
83 - CYLINDER-HEAD SCREW
MAF-005531.A7
005531
|
-
|
|
|
|
84 - CYLINDER-HEAD SCREW
MAF-005534.A1
005534
|
-
|
|
|
|
85 - CYLINDER-HEAD SCREW
MAF-005526.A3
005526
|
-
|
|
|
|
86 - CYLINDER-HEAD SCREW
MAF-005538.A15
005538
|
-
|
|
|
|
87 - CYLINDER-HEAD SCREW
MAF-055037.A6
055037
|
-
|
|
|
|
88 - CYLINDER-HEAD SCREW
MAF-055040.A6
055040
|
-
|
|
|
|
89 - HEXAGONAL NUT
MAF-005911.A12
005911
|
-
|
|
|
|
90 - HEXAGONAL NUT
MAF-005939.A9
005939
|
-
|
|
|
|
91 - WASHER
MAF-061119.A6
061119
|
-
|
|
|
|
92 - WASHER
MAF-061013.A12
061013
|
-
|
|
|
|
93 - CUP SPRING
MAF-006660.A13
006660
|
-
|
|
|
|
94 - RETAINING RING
MAF-006195.A1
006195
|
-
|
|
|
|
95 - LOCKING WASHER
MAF-061106.A3
061106
|
£2.28
|
£2.74
|
|
|
96 - CUP SPRING
MAF-006663.A8
006663
|
-
|
|
|
|
98 - GROOVED BALL BEARING
MAF-062018.A4
062018
|
£26.06
|
£31.27
|
|
|
99 - GROOVED BALL BEARING
MAF-062073.A7
062073
|
£14.28
|
£17.14
|
|
|
102 - TUBULAR RIVET
MAF-058150.A3
058150
|
-
|
|
|
|
105 - THREADED PIN
MAF-005283.A5
005283
|
-
|
|
|
|
109 - WASHER
MAF-006130.A14
006130
|
-
|
|
|
|
505 - CHIP COLLECTOR
MAF-038986.A1
038986
|
£15.28
|
£18.33
|
|
|
506 - ADAPTER FOR ROUTER BIT
MAF-201575.A2
201575
|
£32.99
|
£39.59
|
|
|
507 - TEMPLATE GUIDE
MAF-038971.A6
038971
|
-
|
|
|
|
508 - SINGLE-END SPANNER
MAF-093020.A2
093020
|
-
|
|
|
|
509 - SINGLE-END SPANNER
MAF-093012.A3
093012
|
-
|
|
|
|
510 - COLLET
MAF-093256.A3
093256
|
£36.66
|
£43.99
|
|
