1 - MOTOR CASING WITH INDUCTOR
MAF-084563.A2
084563
|
-
|
|
|
|
1.1 - MOTOR CASING
MAF-203454.A2
203454
|
-
|
|
|
|
2 - ARMATURE, BALANCED
MAF-088172.A4
088172
|
-
|
|
|
|
3 - GEAR CASING
MAF-203472.A0
203472
|
-
|
|
|
|
6 - BASE PLATE
MAF-203450.A2
203450
|
£198.64
|
£238.37
|
|
|
7 - GEAR CASING COVER
MAF-203025.A7
203025
|
£49.50
|
£59.40
|
|
|
9 - TRAVERSE
MAF-204283.A0
204283
|
£83.51
|
£100.21
|
|
|
10 - TILTING STOP
MAF-203442.A5
203442
|
£95.72
|
£114.87
|
|
|
14 - REVOLVING DEPTH CONTROL TURRET
MAF-203446.A3
203446
|
-
|
|
|
|
15 - BASE PLATE COVER
MAF-203027.A2
203027
|
£21.74
|
£26.09
|
|
|
16 - GUIDE STRIP
MAF-203028.A6
203028
|
£8.47
|
£10.17
|
|
|
17 - DEPTH STOP
MAF-203029.A6
203029
|
£9.79
|
£11.75
|
|
|
18 - INDICATOR
MAF-203030.A7
203030
|
-
|
|
|
|
21 - SIGHT WINDOW
MAF-203443.A4
203443
|
£15.51
|
£18.61
|
|
|
24 - MOTOR COVER
MAF-203455.A3
203455
|
-
|
|
|
|
25 - SLIDING COVER
MAF-203456.A2
203456
|
£3.30
|
£3.96
|
|
|
26 - SWITCH BUTTON
MAF-203045.A4
203045
|
£7.57
|
£9.08
|
|
|
27 - FAN
MAF-203182.A1
203182
|
£11.00
|
£13.20
|
|
|
28 - AIR CONDUCTING RING
MAF-203465.A3
203465
|
-
|
|
|
|
34 - DRIVING SHAFT
MAF-203692.A2
203692
|
£32.39
|
£38.87
|
|
|
35 - BEARING BOLT
MAF-203707.A0
203707
|
£13.86
|
£16.63
|
|
|
36 - ROUE DENTÉE
MAF-203452.A2
203452
|
-
|
|
|
|
37 - IDLER GEAR
MAF-203453.A2
203453
|
-
|
|
|
|
38 - STOP PIN (EACH)
MAF-203037.A4
203037
|
£7.92
|
£9.51
|
|
|
39 - GUIDE COLUMN, LONG
MAF-202434.A6
202434
|
£21.27
|
£25.52
|
|
|
40 - COLUMN
MAF-203447.A3
203447
|
-
|
|
|
|
41 - COLUMN
MAF-203448.A5
203448
|
-
|
|
|
|
42 - SPACER TUBE
MAF-203444.A5
203444
|
-
|
|
|
|
43 - GUARD BOW
MAF-203056.A5
203056
|
£6.12
|
£7.34
|
|
|
44 - CLAMPING DISK
MAF-203071.A7
203071
|
£6.48
|
£7.77
|
|
|
45 - TENSIONING SCREW
MAF-203445.A3
203445
|
-
|
|
|
|
46 - SLEEVE
MAF-203451.A5
203451
|
-
|
|
|
|
47 - SLIDING BEARING (EACH)
MAF-062089.A0
062089
|
£10.22
|
£12.26
|
|
|
48 - MAFELL DOWEL DRILL BIT
MAF-090097.A0
090097
|
£40.42
|
£48.50
|
|
|
51 - SPACER SLEEVE
MAF-203469.A1
203469
|
-
|
|
|
|
52 - WING NUT
MAF-076959.A4
076959
|
£4.88
|
£5.86
|
|
|
53 - WING SCREW
MAF-071008.A4
071008
|
-
|
|
|
|
57 - GROOVED BALL BEARING
MAF-006234.A9
006234
|
£15.42
|
£18.50
|
|
|
58 - GROOVED BALL BEARING
MAF-062010.A2
062010
|
£15.24
|
£18.29
|
|
|
59 - GROOVED BALL BEARING
MAF-062082.A2
062082
|
£18.77
|
£22.52
|
|
|
62 - PRESSURE SPRING
MAF-076911.A3
076911
|
-
|
|
|
|
63 - PRESSURE SPRING (EACH)
MAF-066143.A6
066143
|
£3.52
|
£4.22
|
|
|
64 - RETRACTING SPRING
MAF-006634.A6
006634
|
£3.63
|
£4.36
|
|
|
65 - LEG SPRING
MAF-066142.A2
066142
|
£6.22
|
£7.46
|
|
|
66 - TORSION SPRING
MAF-076211.A2
076211
|
-
|
|
|
|
68 - CARBON BRUSH
MAF-063170.A5
063170
|
£13.45
|
£16.14
|
|
|
69 - BRUSH HOLDER
MAF-063128.A0
063128
|
£2.23
|
£2.68
|
|
|
70 - SNAP-ACTION SWITCH
MAF-087910.A4
087910
|
£15.04
|
£18.05
|
|
|
71 - ANTI-INTERFERENCE MODULE
MAF-203471.A0
203471
|
£26.08
|
£31.30
|
|
|
72 - CABLE PROTECTING SLEEVE
MAF-086064.A16
086064
|
£3.53
|
£4.24
|
|
|
73 - MAINS CABLE 4 M (13.1 FT)
MAF-077017.A8
077017
|
£33.49
|
£40.19
|
|
|
79 - HEXAGON-HEAD SCREW
MAF-056024.A3
056024
|
£5.48
|
£6.57
|
|
|
80 - CYLINDER-HEAD SCREW
MAF-055245.A2
055245
|
-
|
|
|
|
81 - THREADED PIN
MAF-005248.A6
005248
|
-
|
|
|
|
82 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055233.A26
055233
|
£1.79
|
£2.15
|
|
|
83 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055137.A5
055137
|
£2.13
|
£2.56
|
|
|
84 - OVAL-HEAD SCREW
MAF-055068.A2
055068
|
-
|
|
|
|
85 - SELF-TAPPING SCREW
MAF-055230.A2
055230
|
-
|
|
|
|
86 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055243.A13
055243
|
-
|
|
|
|
87 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055061.A55
055061
|
£1.79
|
£2.15
|
|
|
88 - SELF-TAPPING OVAL-HEAD SCREW
MAF-055058.A10
055058
|
-
|
|
|
|
89 - FLAT-HEAD SCREW
MAF-005390.A2
005390
|
-
|
|
|
|
90 - FLAT-HEAD SCREW
MAF-005399.A12
005399
|
£1.33
|
£1.60
|
|
|
91 - CYLINDER-HEAD SCREW
MAF-055029.A4
055029
|
-
|
|
|
|
92 - CYLINDRICAL OVAL-HEAD SCREW
MAF-055111.A7
055111
|
-
|
|
|
|
93 - THREADED PIN
MAF-052010.A12
052010
|
£3.54
|
£4.25
|
|
|
94 - THREADED PIN
MAF-005274.A1
005274
|
-
|
|
|
|
95 - THREADED PIN
MAF-052012.A1
052012
|
-
|
|
|
|
96 - SLIDING BAR
MAF-203066.A1
203066
|
-
|
|
|
|
99 - HEXAGONAL NUT
MAF-005911.A15
005911
|
-
|
|
|
|
100 - LOCKING NUT
MAF-005999.A2
005999
|
-
|
|
|
|
101 - STEEL BALL
MAF-062077.A5
062077
|
-
|
|
|
|
104 - WASHER
MAF-006100.A10
006100
|
£2.11
|
£2.53
|
|
|
105 - WASHER
MAF-006101.A30
006101
|
£1.62
|
£1.94
|
|
|
106 - SNAP RING
MAF-076918.A10
076918
|
£1.65
|
£1.98
|
|
|
107 - RETAINING RING
MAF-007102.A0
007102
|
£2.72
|
£3.27
|
|
|
108 - CYLINDRICAL PIN
MAF-058156.A5
058156
|
£3.63
|
£4.36
|
|
|
109 - WASHER
MAF-061015.A17
061015
|
-
|
|
|
|
110 - RETAINING RING
MAF-061009.A4
061009
|
-
|
|
|
|
501 - ALLEN KEY
MAF-093095.A4
093095
|
-
|
|
|
|
503 - CARRYING CASE MAFELL-MAX
MAF-095042.A8
095042
|
-
|
|
|
|
503.1 - LATCH
MAF-095074.A4
095074
|
-
|
|
|
|
504 - PLASTIC TRAY
MAF-095055.A4
095055
|
-
|
|
|
|
508 - BOX
MAF-203348.A2
203348
|
-
|
|
|
|
511 - ALLEN KEY WITH HANDLE
MAF-093282.A3
093282
|
£10.20
|
£12.24
|
|
|
512 - BOTTLE FOR GLUE
MAF-095059.A1
095059
|
-
|
|
|
|
514 - ANTI-SLIP MATS
MAF-095063.A7
095063
|
-
|
|
|
|
515 - MAFELL SPECIAL DOWELS
MAF-802010.A5
802010
|
-
|
|
|
|
517 - AUXILIARY STOP
MAF-203473.A0
203473
|
£14.67
|
£17.60
|
|
|
550 - MAFELL DOWEL DRILL BIT
MAF-090096.A6
090096
|
£32.72
|
£39.26
|
|
|
551 - MAFELL DOWEL DRILL BIT
MAF-090098.A6
090098
|
£49.08
|
£58.89
|
|
|
552 - MAFELL DOWEL DRILL BIT
MAF-090099.A1
090099
|
£61.59
|
£73.91
|
|
|
553 - MAFELL SPECIAL DOWELS
MAF-802000.A6
802000
|
-
|
|
|
|
554 - MAFELL SPECIAL DOWELS
MAF-802020.A6
802020
|
-
|
|
|
|
555 - MAFELL SPECIAL DOWELS
MAF-802030.A2
802030
|
-
|
|
|
|
556 - DOWEL NOZZLE Ø 8
MAF-095060.A1
095060
|
-
|
|
|
