Elu RAS1603---E Type 1 Radial Arm Saw Spare Parts

An exploded drawing and spare parts listing for the Elu RAS1603---E Type 1 Radial Arm Saw

	Ex VAT	Inc VAT
1 - NO LONGER AVAILABLE BDE-000000-00.A115800 000000-00	-
2 - NO LONGER AVAILABLE BDE-000000-00.A115801 000000-00	-
3 - WASHER M8 BDE-860073-03.A231 860073-03	£1.50	£1.80
4 - NO LONGER AVAILABLE BDE-000000-00.A115802 000000-00	-
5 - NUT BDE-949726-07.A15 949726-07	£1.50	£1.80
6 - WASHER BDE-860074-04.A96 860074-04	£1.50	£1.80
7 - SPACER BDE-863882-00.A2 863882-00	£1.50	£1.80
8 - NO LONGER AVAILABLE BDE-000000-00.A115803 000000-00	-
9 - KNOB BDE-866974-02.A2 866974-02	£1.50	£1.80
10 - STUD BDE-863880-00.A11 863880-00	£17.48	£20.97
11 - LEG BDE-863866-05.A0 863866-05	£45.14	£54.17
12 - WASHER M8 BDE-860073-03.A230 860073-03	£1.50	£1.80
13 - NO LONGER AVAILABLE BDE-000000-00.A115804 000000-00	-
16 - SCREW BDE-860089-18.A0 860089-18	£1.50	£1.80
17 - WASHER BDE-860074-01.A74 860074-01	£1.50	£1.80
18 - NO LONGER AVAILABLE BDE-000000-00.A115805 000000-00	-
20 - NUT BDE-860083-04.A470 860083-04	£1.50	£1.80
27 - NO LONGER AVAILABLE BDE-000000-00.A115806 000000-00	-
28 - NO LONGER AVAILABLE BDE-000000-00.A115807 000000-00	-
29 - NUT BDE-860655-01.A11 860655-01	-
30 - NO LONGER AVAILABLE BDE-000000-00.A115808 000000-00	-
31 - NO LONGER AVAILABLE BDE-000000-00.A115809 000000-00	-
32 - BOLT BDE-860085-03.A2 860085-03	£1.50	£1.80
33 - NO LONGER AVAILABLE BDE-000000-00.A115810 000000-00	-
34 - NO LONGER AVAILABLE BDE-000000-00.A115811 000000-00	-
38 - TABLE BDE-861218-00.A6 861218-00	£37.82	£45.38
39 - NO LONGER AVAILABLE BDE-000000-00.A115812 000000-00	-
40 - NO LONGER AVAILABLE BDE-000000-00.A115813 000000-00	-
41 - BOARD BDE-864878-00.A2 864878-00	-
43 - GUIDE BDE-864871-00.A1 864871-00	£25.70	£30.84
45 - SPANNER BDE-949752-01.A4 949752-01	£3.80	£4.56
46 - WRENCH 4 MM BDE-949882-01.A24 949882-01	£1.50	£1.80
47 - NO LONGER AVAILABLE BDE-000000-00.A115814 000000-00	-
49 - LEG BDE-863866-05.A1 863866-05	£45.14	£54.17
50 - SCREW BDE-942831-00.A5 942831-00	£1.50	£1.80
51 - NUT RH BDE-860083-05.A10 860083-05	£1.50	£1.80
52 - NUT BDE-860083-04.A469 860083-04	£1.50	£1.80

Attribute Name	Value
Brand	Elu
