1 - ARMATURE 230V GB
BDE-868389-00.A5
868389-00
|
-
|
|
|
|
2 - FIELD 230V GB
BDE-868493-00
868493-00
|
-
|
|
|
|
3 - SWITCH
BDE-N566709.A30
N566709
|
£30.08
|
£36.10
|
|
|
4 - BRUSH
BDE-868054-00.A4
868054-00
|
-
|
|
|
|
5 - CORDSET (M/PLUG) GB
BDE-325612-01.A9
325612-01
|
£9.17
|
£11.00
|
|
|
6 - SCREW
BDE-249418-00.A1
249418-00
|
£1.42
|
£1.70
|
|
|
7 - PLATE
BDE-249010-01
249010-01
|
£5.72
|
£6.87
|
|
|
8 - KNOB
BDE-868063-01.A2
868063-01
|
-
|
|
|
|
9 - NUT
BDE-249411-10.A9
249411-10
|
-
|
|
|
|
10 - WASHER
BDE-868065-00.A2
868065-00
|
-
|
|
|
|
11 - SPINDLE
BDE-868055-00.A2
868055-00
|
£14.57
|
£17.48
|
|
|
12 - SUPPRESSOR
BDE-869213-00.A2
869213-00
|
-
|
|
|
|
13 - SCREW
BDE-249424-11.A1
249424-11
|
£1.42
|
£1.70
|
|
|
14 - HOUSING
BDE-249008-01.A4
249008-01
|
£30.08
|
£36.10
|
|
|
15 - SCREW
BDE-N456928.A14
N456928
|
£1.82
|
£2.19
|
|
|
16 - CLAMP
BDE-868069-00.A31
868069-00
|
£1.50
|
£1.80
|
|
|
17 - SCREW
BDE-949896-12.A131
949896-12
|
£1.50
|
£1.80
|
|
|
18 - PROTECTOR
BDE-720703-00.A44
720703-00
|
£1.50
|
£1.80
|
|
|
19 - CABLE CLAMP
BDE-910556.A72
910556
|
£1.42
|
£1.70
|
|
|
20 - SCREW
BDE-931469-02.A187
931469-02
|
£1.50
|
£1.80
|
|
|
22 - COVER
BDE-249011-01
249011-01
|
£1.42
|
£1.70
|
|
|
23 - HOUSING GEAR
BDE-868058-00.A0
868058-00
|
£112.86
|
£135.43
|
|
|
24 - BEARING
BDE-868768-16.A22
868768-16
|
£7.85
|
£9.42
|
|
|
25 - PLATE
BDE-868047-00.A0
868047-00
|
£7.85
|
£9.42
|
|
|
26 - FAN
BDE-868060-00.A0
868060-00
|
£3.22
|
£3.86
|
|
|
27 - NUT
BDE-868062-00.A0
868062-00
|
£1.42
|
£1.70
|
|
|
28 - WASHER
BDE-868048-00.A7
868048-00
|
£1.42
|
£1.70
|
|
|
29 - WASHER
BDE-933652-00.A39
933652-00
|
£1.50
|
£1.80
|
|
|
30 - BEARING 608
BDE-N110358.A24
N110358
|
£3.32
|
£3.99
|
|
|
31 - PLATE
BDE-868059-00.A6
868059-00
|
£3.70
|
£4.44
|
|
|
32 - PLATE
BDE-868057-00.A2
868057-00
|
-
|
|
|
|
33 - BASEPLATE
BDE-868056-00.A0
868056-00
|
£119.32
|
£143.19
|
|
|
34 - BUSH
BDE-868045-00.A0
868045-00
|
£10.85
|
£13.02
|
|
|
35 - NUT
BDE-868046-00.A2
868046-00
|
£7.64
|
£9.17
|
|
|
36 - WASHER
BDE-868042-00.A5
868042-00
|
£1.78
|
£2.13
|
|
|
37 - SPRING
BDE-868043-00.A0
868043-00
|
£3.70
|
£4.44
|
|
|
38 - SCREW
BDE-249424-31.A3
249424-31
|
£1.42
|
£1.70
|
|
|
39 - WASHER
BDE-868064-00.A0
868064-00
|
£1.78
|
£2.13
|
|
|
40 - SCREW
BDE-760242-00.A5
760242-00
|
£1.50
|
£1.80
|
|
|
41 - KNOB
BDE-941609-00.A8
941609-00
|
£5.72
|
£6.87
|
|
|
42 - ROLLER
BDE-868031-00.A0
868031-00
|
£1.42
|
£1.70
|
|
|
43 - SPANNER
BDE-868032-00.A5
868032-00
|
-
|
|
|
|
44 - SPANNER 13-17MM
BDE-941580-00.A24
941580-00
|
£7.85
|
£9.42
|
|
|
45 - NUT
BDE-326249-00
326249-00
|
£5.88
|
£7.06
|
|
|
46 - COLLET GB
BDE-326248-01
326248-01
|
£25.05
|
£30.06
|
|
|
47 - NUT
BDE-868052-00.A0
868052-00
|
£10.85
|
£13.02
|
|
|
48 - KNOB
BDE-868044-01.A2
868044-01
|
-
|
|
|
|
49 - WASHER M6
BDE-249221-00.A119
249221-00
|
£1.50
|
£1.80
|
|
|
50 - STUD
BDE-868061-00.A2
868061-00
|
£9.41
|
£11.29
|
|
|
51 - WASHER
BDE-860074-02.A88
860074-02
|
£1.50
|
£1.80
|
|
|
52 - KNOB
BDE-941536-01.A14
941536-01
|
-
|
|
|
|
53 - SCREW
BDE-860090-02.A40
860090-02
|
-
|
|
|
|
54 - WASHER
BDE-249233-00.A86
249233-00
|
£1.50
|
£1.80
|
|
|
55 - PLEXIGUARD
BDE-868037-00.A0
868037-00
|
£3.80
|
£4.56
|
|
|
56 - RIVET
BDE-868038-00.A3
868038-00
|
-
|
|
|
|
57 - HOLDER GUIDE
BDE-868041-00.A0
868041-00
|
£128.18
|
£153.81
|
|
|
58 - WASHER
BDE-868033-00.A1
868033-00
|
-
|
|
|
|
59 - PIN
BDE-868034-00.A14
868034-00
|
-
|
|
|
|
60 - FOLLOWER
BDE-868036-00.A5
868036-00
|
£3.80
|
£4.56
|
|
|
61 - FOLLOWER
BDE-868035-00.A1
868035-00
|
£14.19
|
£17.03
|
|
|
62 - SCREW
BDE-868039-00.A3
868039-00
|
-
|
|
|
|
63 - SCREW
BDE-868040-00.A3
868040-00
|
-
|
|
|
|
64 - SCREW
BDE-860205-04.A55
860205-04
|
£1.50
|
£1.80
|
|
|
65 - SHOE SA
BDE-868030-01.A2
868030-01
|
£4.58
|
£5.49
|
|
|
66 - SHOE
BDE-868030-00.A0
868030-00
|
£1.42
|
£1.70
|
|
|
67 - NUT M4
BDE-249232-00.A10
249232-00
|
£1.42
|
£1.70
|
|
|
68 - WASHER
BDE-249233-00.A85
249233-00
|
£1.50
|
£1.80
|
|
|
69 - SCREW
BDE-249424-06.A14
249424-06
|
£1.42
|
£1.70
|
|
|
70 - GUIDE SA
BDE-869394-00.A2
869394-00
|
-
|
|
|
|
821 - RATING PLATE GB
BDE-N049821
N049821
|
£2.71
|
£3.25
|
|
