Dewalt DW503-----B Type 1 Chip Collector Spare Parts

An exploded drawing and spare parts listing for the Dewalt DW503-----B Type 1 Chip Collector

	Ex VAT	Inc VAT
1 - COVER BDE-860445-00.A74 860445-00	£7.18	£8.62
2 - TIE ROD BDE-863119-00.A21 863119-00	£1.50	£1.80
3 - FAN BDE-860444-00.A9 860444-00	£4.69	£5.63
4 - END CAP BDE-860443-00.A54 860443-00	£4.69	£5.63
5 - RING BDE-860080-02.A116 860080-02	£1.50	£1.80
6 - BEARING BDE-868768-07.A197 868768-07	£7.85	£9.42
7 - NO LONGER AVAILABLE BDE-000000-00.A84541 000000-00	-
9 - NO LONGER AVAILABLE BDE-000000-00.A84542 000000-00	-
10 - NO LONGER AVAILABLE BDE-000000-00.A84543 000000-00	-
11 - NO LONGER AVAILABLE BDE-000000-00.A84544 000000-00	-
13 - NO LONGER AVAILABLE BDE-000000-00.A84545 000000-00	-
14 - SCREW BDE-330045-05.A278 330045-05	£1.50	£1.80
15 - NO LONGER AVAILABLE BDE-000000-00.A84546 000000-00	-
16 - NO LONGER AVAILABLE BDE-000000-00.A84547 000000-00	-
17 - SCREW BDE-860084-13.A22 860084-13	-
18 - NO LONGER AVAILABLE BDE-000000-00.A84548 000000-00	-
19 - NO LONGER AVAILABLE BDE-000000-00.A84549 000000-00	-
20 - SCREW BDE-949894-06.A15 949894-06	£1.50	£1.80
21 - NO LONGER AVAILABLE BDE-000000-00.A84550 000000-00	-
22 - NO LONGER AVAILABLE BDE-000000-00.A84551 000000-00	-
23 - SCREW BDE-860085-19.A40 860085-19	£1.50	£1.80
24 - NO LONGER AVAILABLE BDE-000000-00.A84552 000000-00	-
25 - NUT BDE-860083-04.A290 860083-04	£1.50	£1.80
26 - WASHER BDE-860074-03.A86 860074-03	£1.50	£1.80
27 - NO LONGER AVAILABLE BDE-000000-00.A84553 000000-00	-
28 - NO LONGER AVAILABLE BDE-000000-00.A84554 000000-00	-
29 - NO LONGER AVAILABLE BDE-000000-00.A84555 000000-00	-
31 - NO LONGER AVAILABLE BDE-000000-00.A84556 000000-00	-
33 - NO LONGER AVAILABLE PARTS NOT DRAWN BDE-000000-00.A84557 000000-00	-

Attribute Name	Value
Brand	Dewalt
