Bostitch 5381612 Type REV 0 Nailer Spare Parts

Home Details Reviews Delivery

An exploded drawing and spare parts listing for the Bostitch 5381612 Type REV 0 Nailer

	Ex VAT	Inc VAT
1 - NO LONGER AVAILABLE BDE-000000-00.A65085 000000-00	-
2 - NO LONGER AVAILABLE BDE-000000-00.A65086 000000-00	-
3 - NO LONGER AVAILABLE BDE-000000-00.A65087 000000-00	-
5 - NO LONGER AVAILABLE BDE-000000-00.A65088 000000-00	-
6 - O RING BDE-3090618.A3 3090618	-
7 - NO LONGER AVAILABLE BDE-000000-00.A65089 000000-00	-
8 - DISC BDE-3927050.A0 3927050	-
9 - SHOCK ABSORBER BDE-3927480.A0 3927480	-
10 - VALVE BDE-3927040.A3 3927040	-
11 - NO LONGER AVAILABLE BDE-000000-00.A65090 000000-00	-
12 - NO LONGER AVAILABLE BDE-000000-00.A65091 000000-00	-
13 - RETAINER BDE-3927230.A3 3927230	-
14 - CYLINDER BDE-3927171.A1 3927171	£122.02	£146.42
15 - O RING BDE-3091580.A0 3091580	-
16 - O RING BDE-3091573.A3 3091573	-
17 - NO LONGER AVAILABLE BDE-000000-00.A65092 000000-00	-
18 - O RING BDE-3091593.A3 3091593	-
19 - RING BDE-3927900.A0 3927900	-
20 - BUMPER BDE-3927210.A0 3927210	-
21 - O RING BDE-3090580.A0 3090580	-
22 - PIN BDE-3927560.A3 3927560	-
23 - NO LONGER AVAILABLE BDE-000000-00.A65093 000000-00	-
24 - NO LONGER AVAILABLE BDE-000000-00.A65094 000000-00	-
25 - SPRING BDE-3052220.A3 3052220	-
26 - NO LONGER AVAILABLE BDE-000000-00.A65095 000000-00	-
27 - SAFETY KEY BDE-3927922.A1 3927922	-
28 - GASKET BDE-3099900.A0 3099900	£2.21	£2.65
29 - PIN BDE-3037558.A0 3037558	-
30 - NO LONGER AVAILABLE BDE-000000-00.A65096 000000-00	-
31 - SPRING BDE-3055110.A0 3055110	-
32 - PUSHER BDE-3928340 3928340	-
34 - NO LONGER AVAILABLE BDE-000000-00.A65097 000000-00	-
35 - NO LONGER AVAILABLE BDE-000000-00.A65098 000000-00	-
36 - NO LONGER AVAILABLE BDE-000000-00.A65099 000000-00	-
37 - NO LONGER AVAILABLE BDE-000000-00.A65100 000000-00	-
38 - NO LONGER AVAILABLE BDE-000000-00.A65101 000000-00	-
39 - NO LONGER AVAILABLE BDE-000000-00.A65102 000000-00	-
40 - PIN BDE-3035424.A3 3035424	-
41 - NO LONGER AVAILABLE BDE-000000-00.A65103 000000-00	-
42 - TRIGGER BDE-3748120.A2 3748120	£25.05	£30.06
43 - NO LONGER AVAILABLE BDE-000000-00.A65104 000000-00	-
44 - PIN BDE-3035424.A2 3035424	-
45 - NO LONGER AVAILABLE BDE-000000-00.A65105 000000-00	-
46 - NO LONGER AVAILABLE BDE-000000-00.A65106 000000-00	-
47 - NO LONGER AVAILABLE BDE-000000-00.A65107 000000-00	-
48 - SPACER BDE-3024310.A30 3024310	£1.66	£1.99
49 - NUT BDE-3011212.A12 3011212	-
50 - NO LONGER AVAILABLE BDE-000000-00.A65108 000000-00	-
51 - NO LONGER AVAILABLE BDE-000000-00.A65109 000000-00	-
52 - NO LONGER AVAILABLE BDE-000000-00.A65110 000000-00	-
53 - SPRING BDE-3050400.A1 3050400	-
54 - NO LONGER AVAILABLE BDE-000000-00.A65119 000000-00	-
55 - NO LONGER AVAILABLE BDE-000000-00.A65120 000000-00	-
56 - MAGAZINE BDE-3928830 3928830	£482.40	£578.88
57 - NO LONGER AVAILABLE BDE-000000-00.A65111 000000-00	-
58 - NO LONGER AVAILABLE BDE-000000-00.A65112 000000-00	-
59 - NO LONGER AVAILABLE BDE-000000-00.A65113 000000-00	-
60 - NO LONGER AVAILABLE BDE-000000-00.A65114 000000-00	-
61 - NO LONGER AVAILABLE BDE-000000-00.A65115 000000-00	-
62 - NO LONGER AVAILABLE BDE-000000-00.A65116 000000-00	-
63 - NO LONGER AVAILABLE BDE-000000-00.A65117 000000-00	-
64 - NO LONGER AVAILABLE BDE-000000-00.A65118 000000-00	-
65 - SPACER BDE-3024310.A29 3024310	£1.66	£1.99
66 - NO LONGER AVAILABLE BDE-000000-00.A65121 000000-00	-
67 - GASKET BDE-3099950.A13 3099950	-
69 - NO LONGER AVAILABLE BDE-000000-00.A65122 000000-00	-
70 - NO LONGER AVAILABLE BDE-000000-00.A65123 000000-00	-
71 - NO LONGER AVAILABLE BDE-000000-00.A65124 000000-00	-
72 - NUT Q BDE-3011212.A13 3011212	-
500 - NO LONGER AVAILABLE BDE-000000-00.A65125 000000-00	-

Attribute Name	Value
Brand	Bostitch
