Bostitch 5381312 Type REV 0 Nailer Spare Parts

Home Details Reviews Delivery

An exploded drawing and spare parts listing for the Bostitch 5381312 Type REV 0 Nailer

	Ex VAT	Inc VAT
1 - NO LONGER AVAILABLE BDE-000000-00.A65126 000000-00	-
2 - NO LONGER AVAILABLE BDE-000000-00.A65127 000000-00	-
3 - NO LONGER AVAILABLE BDE-000000-00.A65128 000000-00	-
5 - NO LONGER AVAILABLE BDE-000000-00.A65129 000000-00	-
6 - O RING BDE-3090618.A2 3090618	-
7 - NO LONGER AVAILABLE BDE-000000-00.A65130 000000-00	-
8 - DISC BDE-3927050.A1 3927050	-
9 - SHOCK ABSORBER BDE-3927480.A1 3927480	-
10 - VALVE BDE-3927040.A2 3927040	-
11 - NO LONGER AVAILABLE BDE-000000-00.A65131 000000-00	-
12 - NO LONGER AVAILABLE BDE-000000-00.A65132 000000-00	-
13 - RETAINER BDE-3927230.A2 3927230	-
14 - NO LONGER AVAILABLE BDE-000000-00.A65133 000000-00	-
15 - O RING BDE-3091580.A1 3091580	-
16 - O RING BDE-3091573.A2 3091573	-
17 - NO LONGER AVAILABLE BDE-000000-00.A65134 000000-00	-
18 - O RING BDE-3091593.A2 3091593	-
19 - RING BDE-3927900.A1 3927900	-
20 - BUMPER BDE-3927210.A1 3927210	-
21 - O RING BDE-3090580.A1 3090580	-
22 - PIN BDE-3927560.A2 3927560	-
23 - NO LONGER AVAILABLE BDE-000000-00.A65135 000000-00	-
24 - NO LONGER AVAILABLE BDE-000000-00.A65136 000000-00	-
25 - SPRING BDE-3052220.A2 3052220	-
26 - NO LONGER AVAILABLE BDE-000000-00.A65137 000000-00	-
27 - SAFETY KEY BDE-3924922.A0 3924922	-
28 - GASKET BDE-3099900.A1 3099900	£2.21	£2.65
29 - PIN BDE-3037558.A1 3037558	-
30 - NO LONGER AVAILABLE BDE-000000-00.A65145 000000-00	-
31 - SPRING BDE-3055110.A1 3055110	-
32 - NO LONGER AVAILABLE BDE-000000-00.A65138 000000-00	-
34 - NO LONGER AVAILABLE BDE-000000-00.A65139 000000-00	-
35 - NO LONGER AVAILABLE BDE-000000-00.A65140 000000-00	-
36 - NO LONGER AVAILABLE BDE-000000-00.A65141 000000-00	-
37 - NO LONGER AVAILABLE BDE-000000-00.A65142 000000-00	-
38 - NO LONGER AVAILABLE BDE-000000-00.A65143 000000-00	-
39 - NO LONGER AVAILABLE BDE-000000-00.A65144 000000-00	-
40 - PIN BDE-3035424.A1 3035424	-
41 - NO LONGER AVAILABLE BDE-000000-00.A65146 000000-00	-
42 - TRIGGER BDE-3748120.A1 3748120	£25.05	£30.06
43 - NO LONGER AVAILABLE BDE-000000-00.A65150 000000-00	-
43 - TRIGGER BDE-3748120.A0 3748120	£25.05	£30.06
44 - PIN BDE-3035424.A0 3035424	-
45 - NO LONGER AVAILABLE BDE-000000-00.A65147 000000-00	-
46 - NO LONGER AVAILABLE BDE-000000-00.A65148 000000-00	-
47 - NO LONGER AVAILABLE BDE-000000-00.A65149 000000-00	-
48 - SPACER BDE-3024310.A31 3024310	£1.66	£1.99
49 - NUT BDE-3011212.A11 3011212	-
50 - NO LONGER AVAILABLE BDE-000000-00.A65151 000000-00	-
51 - NO LONGER AVAILABLE BDE-000000-00.A65152 000000-00	-
52 - NO LONGER AVAILABLE BDE-000000-00.A65153 000000-00	-
53 - SPRING BDE-3050400.A2 3050400	-
54 - NO LONGER AVAILABLE BDE-000000-00.A65162 000000-00	-
55 - NO LONGER AVAILABLE BDE-000000-00.A65163 000000-00	-
56 - MAGAZINE BDE-3925830 3925830	£404.44	£485.33
57 - NO LONGER AVAILABLE BDE-000000-00.A65154 000000-00	-
58 - NO LONGER AVAILABLE BDE-000000-00.A65155 000000-00	-
59 - NO LONGER AVAILABLE BDE-000000-00.A65156 000000-00	-
60 - NO LONGER AVAILABLE BDE-000000-00.A65157 000000-00	-
61 - NO LONGER AVAILABLE BDE-000000-00.A65158 000000-00	-
62 - NO LONGER AVAILABLE BDE-000000-00.A65159 000000-00	-
63 - NO LONGER AVAILABLE BDE-000000-00.A65160 000000-00	-
64 - NO LONGER AVAILABLE BDE-000000-00.A65161 000000-00	-
65 - SPACER BDE-3024310.A32 3024310	£1.66	£1.99
66 - NO LONGER AVAILABLE BDE-000000-00.A65164 000000-00	-
67 - GASKET BDE-3099950.A14 3099950	-
69 - NO LONGER AVAILABLE BDE-000000-00.A65165 000000-00	-
70 - NO LONGER AVAILABLE BDE-000000-00.A65166 000000-00	-
71 - NO LONGER AVAILABLE BDE-000000-00.A65167 000000-00	-
72 - NUT BDE-3011212.A10 3011212	-
500 - NO LONGER AVAILABLE BDE-000000-00.A65175 000000-00	-
