3 - PROTECTIVE COVER
BSD-3605500081.A10
3605500081
|
£12.04
|
£14.45
|
|
|
6 - BEARING SHAFT
BSD-3603105005.A1
3603105005
|
£6.52
|
£7.83
|
|
|
7 - ROLLER
BSD-3600309003.A7
3600309003
|
£5.30
|
£6.36
|
|
|
9 - LOCKING LEVER
BSD-3601902012.A16
3601902012
|
£10.10
|
£12.12
|
|
|
10 - REJECTION SLIDE
BSD-3601923001.A0
3601923001
|
£8.67
|
£10.41
|
|
|
11 - CLAMPING-FLANGE
BSD-3600390023.A0
3600390023
|
£40.80
|
£48.96
|
|
|
12 - ROUND NUT M14
BSD-3603345005.A11
3603345005
|
£21.52
|
£25.83
|
|
|
13 - PLAIN WASHER dia 42X22.2X4 MM
BSD-3609202041.A25
3609202041
|
£5.58
|
£6.70
|
|
|
14 - PUSH-BUTTON
BSD-3602305011.A14
3602305011
|
£1.95
|
£2.34
|
|
|
15 - TORSION SPRING
BSD-3604651004.A3
3604651004
|
£5.30
|
£6.36
|
|
|
16 - COILED SPRING
BSD-3604651006.A7
3604651006
|
£2.80
|
£3.36
|
|
|
17 - COILED SPRING
BSD-3604651005.A12
3604651005
|
£2.33
|
£2.80
|
|
|
20 - SAFETY CATCH
BSD-3601023003.A0
3601023003
|
£2.80
|
£3.36
|
|
|
21 - SHAPED SPRING
BSD-3604680002.A4
3604680002
|
£2.33
|
£2.80
|
|
|
22 - SPACER TUBE
BSD-3600300029.A12
3600300029
|
£4.26
|
£5.11
|
|
|
25 - SPACER SLEEVE
BSD-3600300028.A0
3600300028
|
£2.80
|
£3.36
|
|
|
26 - HANDLE
BSD-3601990002.A11
3601990002
|
£10.10
|
£12.12
|
|
|
27 - PROTECTIVE CAP
BSD-3605500078.A0
3605500078
|
£6.52
|
£7.83
|
|
|
28 - PAN HEAD SCREW M 10x12 MM
BSD-3603490015.A0
3603490015
|
£4.26
|
£5.11
|
|
|
29 - MANUFACTURER'S NAMEPLATE
BSD-3601119425.A12
3601119425
|
£2.33
|
£2.80
|
|
|
31 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1665
2603490023
|
£1.66
|
£1.99
|
|
|
32 - TORX OVAL-HEAD SCREW 4x40
BSD-2603490027.A164
2603490027
|
£1.66
|
£1.99
|
|
|
33 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1378
2603490017
|
£1.66
|
£1.99
|
|
|
35 - LOCKING WASHER
BSD-2916089079.A4
2916089079
|
£1.66
|
£1.99
|
|
|
37 - STRAIGHT PIN DIN 7-5m6x16-ST
BSD-2917511120.A1
2917511120
|
-
|
|
|
|
41 - REFERENCE PLATE
BSD-3601119076.A8
3601119076
|
£2.33
|
£2.80
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-BM4x40-8.8
BSD-2910021138.A9
2910021138
|
£2.33
|
£2.80
|
|
|
201 - MOTOR HOUSING
BSD-16051082CC.A4
16051082CC
|
£13.12
|
£15.75
|
|
|
202 - FIELD 220-230V
BSD-1604220220.A38
1604220220
|
£37.27
|
£44.72
|
|
|
204 - ON-OFF SWITCH
BSD-1607200086.A274
1607200086
|
£11.30
|
£13.56
|
|
|
204/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A522
2910110048
|
£1.66
|
£1.99
|
|
|
205 - POWER SUPPLY CORD I 4.15m 2 x 1.0mm H05VV-F
BSD-2604460102.A8
2604460102
|
-
|
|
|
|
206 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A125
2600703013
|
£2.33
|
£2.80
|
|
|
207 - FASTENING CLAMP
BSD-1601302017.A1040
1601302017
|
£1.66
|
£1.99
|
|
|
209 - MANUFACTURER'S NAMEPLATE
BSD-1601110665.A8
1601110665
|
£3.34
|
£4.01
|
|
|
212 - SUPPRESSION FILTER
BSD-1607328029.A35
1607328029
|
-
|
|
|
|
213 - BALL BEARING 7x19x6
BSD-2600905032.A1097
2600905032
|
£5.30
|
£6.36
|
|
|
214 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A105
1600905011
|
£5.58
|
£6.70
|
|
|
215 - FAN
BSD-1606610121.A193
1606610121
|
£1.66
|
£1.99
|
|
|
216 - BRUSH HOLDER
BSD-1600A003G4.A329
1600A003G4
|
£3.72
|
£4.47
|
|
|
217 - REFERENCE PLATE
BSD-3601110396.A11
3601110396
|
£3.72
|
£4.47
|
|
|
218 - COMPRESSION SPRING
BSD-1604611026.A624
1604611026
|
£1.66
|
£1.99
|
|
|
222 - ADJUSTING SLIDE
BSD-1602319002.A78
1602319002
|
£1.66
|
£1.99
|
|
|
223 - SWITCH HANDLE
BSD-1602026057.A349
1602026057
|
£1.97
|
£2.36
|
|
|
225 - HOUSING COVER
BSD-1600508010.A52
1600508010
|
£7.36
|
£8.83
|
|
|
226 - RUBBER BUSHING
BSD-1600502020.A12
1600502020
|
£1.66
|
£1.99
|
|
|
227 - RUBBER RING
BSD-1600206025.A874
1600206025
|
£1.95
|
£2.34
|
|
|
229 - AIR-DEFLECTOR RING
BSD-1601328005.A157
1601328005
|
£1.95
|
£2.34
|
|
|
231 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A65
2916660013
|
£1.95
|
£2.34
|
|
|
233 - O-RING 46.0x1.1 MM
BSD-3600210124.A325
3600210124
|
£2.80
|
£3.36
|
|
|
235 - SHIM 0.2 MM
BSD-1600136010.A163
1600136010
|
£1.66
|
£1.99
|
|
|
235 - SHIM 0.3 MM
BSD-1600136011.A166
1600136011
|
£1.66
|
£1.99
|
|
|
235 - SHIM 0.1 MM
BSD-1600136012.A157
1600136012
|
£1.66
|
£1.99
|
|
|
236 - SPRING WASHER
BSD-1600150011.A259
1600150011
|
£1.66
|
£1.99
|
|
|
237 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A17
1600290016
|
£1.95
|
£2.34
|
|
|
238 - CROWN GEAR Z=35
BSD-1606333235.A24
1606333235
|
£63.50
|
£76.20
|
|
|
239 - SPIRAL SPRING
BSD-1604652013.A981
1604652013
|
£1.66
|
£1.99
|
|
|
240 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A60
2916660009
|
£1.66
|
£1.99
|
|
|
241 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A513
1600910018
|
£5.30
|
£6.36
|
|
|
242 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A87
1600905006
|
£12.04
|
£14.45
|
|
|
243 - BEVEL GEAR Z=9
BSD-1606333234.A0
1606333234
|
£37.27
|
£44.72
|
|
|
245 - HEX NUT M7. SW10
BSD-1603300016.A448
1603300016
|
£1.66
|
£1.99
|
|
|
247 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A201
2910211018
|
£1.66
|
£1.99
|
|
|
248 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A415
1613435034
|
£1.66
|
£1.99
|
|
|
249 - THREAD-FORMING TAP. SCREW
BSD-1603435026.A62
1603435026
|
£1.66
|
£1.99
|
|
|
250 - TORX OVAL-HEAD SCREW
BSD-2914201508.A108
2914201508
|
£1.66
|
£1.99
|
|
|
251 - SPEED GOVERNOR 220-230V
BSD-1607233008.A8
1607233008
|
£27.23
|
£32.68
|
|
|
253 - CONNECTING CABLE L=95 MM
BSD-1604448005.A101
1604448005
|
£2.80
|
£3.36
|
|
|
254 - CONNECTING CABLE L=40 MM
BSD-1604448006.A21
1604448006
|
£1.95
|
£2.34
|
|
|
255 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A75
2912401021
|
£1.66
|
£1.99
|
|
|
651 - SPLITTING TOOL
BSD-3607959000.A1
3607959000
|
-
|
|
|
|
700 - PARALLEL-GUIDE
BSD-3607000060.A9
3607000060
|
£16.68
|
£20.01
|
|
|
700/20 - STOP PIN
BSD-3603101002.A12
3603101002
|
-
|
|
|
|
700/30 - O-RING 5.94x3.53 MM
BSD-3600210024.A17
3600210024
|
£1.95
|
£2.34
|
|
|
700/40 - WING SCREW M 6x16 MM
BSD-2603480003.A192
2603480003
|
£2.33
|
£2.80
|
|
|
739 - WALL CHASER dia 115x22.2x2.2 MM
BSD-3608640001.A12
3608640001
|
-
|
|
|
|
752 - PIN-TYPE FACE-WRENCH
BSD-1607950043.A152
1607950043
|
£4.02
|
£4.83
|
|
|
802 - PARTS SET
BSD-3607031206.A12
3607031206
|
£40.80
|
£48.96
|
|
|
804 - PARTS SET
BSD-3607031656.A11
3607031656
|
£46.37
|
£55.64
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A256
1607014116
|
£11.30
|
£13.56
|
|
|
813 - PUSH-BUTTON
BSD-1607000253.A214
1607000253
|
£2.49
|
£2.99
|
|
|
818 - PARTS SET
BSD-3607031207.A0
3607031207
|
£23.86
|
£28.63
|
|
|
821 - GEAR HOUSING
BSD-1605806480.A99
1605806480
|
£46.37
|
£55.64
|
|
|
823 - ROTARY KNOB
BSD-3607031547.A0
3607031547
|
£11.30
|
£13.56
|
|
|
828 - BEARING FLANGE
BSD-1607000936.A14
1607000936
|
£27.23
|
£32.68
|
|
|
830 - ARMATURE WITH FAN 220-230V
BSD-1604010248.A58
1604010248
|
£40.80
|
£48.96
|
|
|
831 - TORX OVAL-HEAD SCREW
BSD-2914201508.A109
2914201508
|
£1.66
|
£1.99
|
|
|
832 - TAPPING SCREW DIN 7971-BZ3.9x38
BSD-2910211093.A4
2910211093
|
£1.66
|
£1.99
|
|
|
833 - PARTS SET
BSD-3607031208.A12
3607031208
|
£63.50
|
£76.20
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2807
160111A3H3
|
£2.33
|
£2.80
|
|
