3 - PROTECTIVE COVER
BSD-3605500081.A4
3605500081
|
£12.04
|
£14.45
|
|
|
6 - BEARING SHAFT
BSD-3603105005.A6
3603105005
|
£6.52
|
£7.83
|
|
|
7 - ROLLER
BSD-3600309003.A14
3600309003
|
£5.30
|
£6.36
|
|
|
9 - LOCKING LEVER
BSD-3601902012.A10
3601902012
|
£10.10
|
£12.12
|
|
|
10 - REJECTION SLIDE
BSD-3601923001.A6
3601923001
|
£8.67
|
£10.41
|
|
|
11 - CLAMPING-FLANGE
BSD-3600390023.A6
3600390023
|
£40.80
|
£48.96
|
|
|
12 - ROUND NUT M14
BSD-3603345005.A6
3603345005
|
£21.52
|
£25.83
|
|
|
13 - PLAIN WASHER dia 42X22.2X4 MM
BSD-3609202041.A20
3609202041
|
£5.58
|
£6.70
|
|
|
14 - PUSH-BUTTON
BSD-3602305011.A9
3602305011
|
£1.95
|
£2.34
|
|
|
15 - TORSION SPRING
BSD-3604651004.A8
3604651004
|
£5.30
|
£6.36
|
|
|
16 - COILED SPRING
BSD-3604651006.A12
3604651006
|
£2.80
|
£3.36
|
|
|
17 - COILED SPRING
BSD-3604651005.A4
3604651005
|
£2.33
|
£2.80
|
|
|
20 - SAFETY CATCH
BSD-3601023003.A10
3601023003
|
£2.80
|
£3.36
|
|
|
21 - SHAPED SPRING
BSD-3604680002.A15
3604680002
|
£2.33
|
£2.80
|
|
|
22 - SPACER TUBE
BSD-3600300029.A2
3600300029
|
£4.26
|
£5.11
|
|
|
25 - SPACER SLEEVE
BSD-3600300028.A10
3600300028
|
£2.80
|
£3.36
|
|
|
26 - HANDLE
BSD-3601990002.A5
3601990002
|
£10.10
|
£12.12
|
|
|
27 - PROTECTIVE CAP
BSD-3605500078.A8
3605500078
|
£6.52
|
£7.83
|
|
|
28 - PAN HEAD SCREW M 10x12 MM
BSD-3603490015.A9
3603490015
|
£4.26
|
£5.11
|
|
|
29 - MANUFACTURER'S NAMEPLATE
BSD-3601119425.A5
3601119425
|
£2.33
|
£2.80
|
|
|
31 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1663
2603490023
|
£1.66
|
£1.99
|
|
|
32 - TORX OVAL-HEAD SCREW 4x40
BSD-2603490027.A166
2603490027
|
£1.66
|
£1.99
|
|
|
33 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1389
2603490017
|
£1.66
|
£1.99
|
|
|
35 - LOCKING WASHER
BSD-2916089079.A13
2916089079
|
£1.66
|
£1.99
|
|
|
37 - STRAIGHT PIN DIN 7-4MM6x28-C35K-RIKO
BSD-2917511104.A5
2917511104
|
£1.66
|
£1.99
|
|
|
41 - REFERENCE PLATE
BSD-3601119076.A6
3601119076
|
£2.33
|
£2.80
|
|
|
49 - THREAD-FORMING TAP. SCREW M4x30 DIN7500-1 T-20
BSD-1613490017.A38
1613490017
|
£1.66
|
£1.99
|
|
|
201 - MOTOR HOUSING
BSD-16051082CC.A8
16051082CC
|
£13.12
|
£15.75
|
|
|
202 - FIELD 220-230V
BSD-1604220220.A41
1604220220
|
£37.27
|
£44.72
|
|
|
204 - ON-OFF SWITCH
BSD-1607200086.A266
1607200086
|
£11.30
|
£13.56
|
|
|
204/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A518
2910110048
|
£1.66
|
£1.99
|
|
|
205 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07RN-F
BSD-1604460160.A0
1604460160
|
-
|
|
|
|
206 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A136
2600703013
|
£2.33
|
£2.80
|
|
|
207 - FASTENING CLAMP
BSD-1601302017.A1032
1601302017
|
£1.66
|
£1.99
|
|
|
209 - MANUFACTURER'S NAMEPLATE
BSD-1601110665.A3
1601110665
|
£3.34
|
£4.01
|
|
|
212 - SUPPRESSION FILTER
BSD-1607328029.A40
1607328029
|
-
|
|
|
|
213 - BALL BEARING 7x19x6
BSD-2600905032.A1086
2600905032
|
£5.30
|
£6.36
|
|
|
214 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A100
1600905011
|
£5.58
|
£6.70
|
|
|
215 - FAN
BSD-1606610121.A197
1606610121
|
£1.66
|
£1.99
|
|
|
216 - BRUSH HOLDER
BSD-1600A003G4.A324
1600A003G4
|
£3.72
|
£4.47
|
|
|
217 - REFERENCE PLATE
BSD-3601110396.A3
3601110396
|
£3.72
|
£4.47
|
|
|
218 - COMPRESSION SPRING
BSD-1604611026.A628
1604611026
|
£1.66
|
£1.99
|
|
|
222 - ADJUSTING SLIDE
BSD-1602319002.A86
1602319002
|
£1.66
|
£1.99
|
|
|
223 - SWITCH HANDLE
BSD-1602026057.A341
1602026057
|
£1.97
|
£2.36
|
|
|
225 - HOUSING COVER
BSD-1600508010.A50
1600508010
|
£7.36
|
£8.83
|
|
|
226 - RUBBER BUSHING
BSD-1600502020.A4
1600502020
|
£1.66
|
£1.99
|
|
|
227 - RUBBER RING
BSD-1600206025.A866
1600206025
|
£1.95
|
£2.34
|
|
|
229 - AIR-DEFLECTOR RING
BSD-1601328005.A165
1601328005
|
£1.95
|
£2.34
|
|
|
231 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A68
2916660013
|
£1.95
|
£2.34
|
|
|
233 - O-RING 46.0x1.1 MM
BSD-3600210124.A313
3600210124
|
£2.80
|
£3.36
|
|
|
235 - SHIM 0.1 MM
BSD-1600136012.A149
1600136012
|
£1.66
|
£1.99
|
|
|
235 - SHIM 0.2 MM
BSD-1600136010.A155
1600136010
|
£1.66
|
£1.99
|
|
|
235 - SHIM 0.3 MM
BSD-1600136011.A174
1600136011
|
£1.66
|
£1.99
|
|
|
236 - SPRING WASHER
BSD-1600150011.A267
1600150011
|
£1.66
|
£1.99
|
|
|
237 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A25
1600290016
|
£1.95
|
£2.34
|
|
|
238 - CROWN GEAR Z=35
BSD-1606333235.A20
1606333235
|
£63.50
|
£76.20
|
|
|
239 - SPIRAL SPRING
BSD-1604652013.A977
1604652013
|
£1.66
|
£1.99
|
|
|
240 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A57
2916660009
|
£1.66
|
£1.99
|
|
|
241 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A519
1600910018
|
£5.30
|
£6.36
|
|
|
242 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A92
1600905006
|
£12.04
|
£14.45
|
|
|
243 - BEVEL GEAR Z=9
BSD-1606333234.A4
1606333234
|
£37.27
|
£44.72
|
|
|
245 - HEX NUT M7. SW10
BSD-1603300016.A441
1603300016
|
£1.66
|
£1.99
|
|
|
247 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A194
2910211018
|
£1.66
|
£1.99
|
|
|
248 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A413
1613435034
|
£1.66
|
£1.99
|
|
|
249 - THREAD-FORMING TAP. SCREW
BSD-1603435026.A69
1603435026
|
£1.66
|
£1.99
|
|
|
250 - TORX OVAL-HEAD SCREW
BSD-2914201508.A119
2914201508
|
£1.66
|
£1.99
|
|
|
251 - SPEED GOVERNOR 220-230V
BSD-1607233008.A12
1607233008
|
£27.23
|
£32.68
|
|
|
253 - CONNECTING CABLE L=95 MM
BSD-1604448005.A95
1604448005
|
£2.80
|
£3.36
|
|
|
254 - CONNECTING CABLE L=40 MM
BSD-1604448006.A25
1604448006
|
£1.95
|
£2.34
|
|
|
255 - TORX OVAL-HEAD SCREW
BSD-2914201508.A120
2914201508
|
£1.66
|
£1.99
|
|
|
651 - SPLITTING TOOL
BSD-3607959005.A4
3607959005
|
£21.68
|
£26.01
|
|
|
700 - PARALLEL-GUIDE
BSD-3607000060.A4
3607000060
|
£16.68
|
£20.01
|
|
|
700/20 - STOP PIN
BSD-3603101002.A8
3603101002
|
-
|
|
|
|
700/30 - O-RING 5.94x3.53 MM
BSD-3600210024.A29
3600210024
|
£1.95
|
£2.34
|
|
|
700/40 - WING SCREW M 6x16 MM
BSD-2603480003.A191
2603480003
|
£2.33
|
£2.80
|
|
|
739 - WALL CHASER dia 115x22.2x2.2 MM
BSD-3608640001.A2
3608640001
|
-
|
|
|
|
752 - PIN-TYPE FACE-WRENCH
BSD-1607950043.A145
1607950043
|
£4.02
|
£4.83
|
|
|
802 - PARTS SET
BSD-3607031206.A6
3607031206
|
£40.80
|
£48.96
|
|
|
804 - PARTS SET
BSD-3607031656.A6
3607031656
|
£46.37
|
£55.64
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A253
1607014116
|
£11.30
|
£13.56
|
|
|
813 - PUSH-BUTTON
BSD-1607000253.A226
1607000253
|
£2.49
|
£2.99
|
|
|
818 - PARTS SET
BSD-3607031207.A6
3607031207
|
£23.86
|
£28.63
|
|
|
821 - GEAR HOUSING
BSD-1605806480.A95
1605806480
|
£46.37
|
£55.64
|
|
|
823 - ROTARY KNOB
BSD-3607031547.A6
3607031547
|
£11.30
|
£13.56
|
|
|
828 - BEARING FLANGE
BSD-1607000936.A19
1607000936
|
£27.23
|
£32.68
|
|
|
830 - ARMATURE WITH FAN 220-230V
BSD-1604010248.A56
1604010248
|
£40.80
|
£48.96
|
|
|
831 - TORX OVAL-HEAD SCREW
BSD-2914201508.A118
2914201508
|
£1.66
|
£1.99
|
|
|
832 - TAPPING SCREW DIN 7971-BZ3.9x38
BSD-2910211093.A9
2910211093
|
£1.66
|
£1.99
|
|
|
833 - PARTS SET
BSD-3607031208.A5
3607031208
|
£63.50
|
£76.20
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2811
160111A3H3
|
£2.33
|
£2.80
|
|
