1 - GEAR HOUSING
BSD-2605806280.A7
2605806280
|
-
|
|
|
|
2 - INTERMEDIATE FLANGE
BSD-2605700168.A0
2605700168
|
-
|
|
|
|
7 - SHIM 0.50 MM
BSD-2600100613.A165
2600100613
|
£1.75
|
£2.10
|
|
|
8 - DRIVE SHAFT
BSD-2603124066.A27
2603124066
|
-
|
|
|
|
9 - SHIM 0.5 MM
BSD-2600100505.A56
2600100505
|
£1.32
|
£1.58
|
|
|
10 - CYLINDRICAL GEAR Z=41
BSD-2606325004.A2
2606325004
|
-
|
|
|
|
11 - SPACER BUSHING
BSD-2600400023.A9
2600400023
|
-
|
|
|
|
12 - CYLINDRICAL GEAR Z=42
BSD-2606325003.A17
2606325003
|
-
|
|
|
|
13 - BUSHING
BSD-2600322043.A5
2600322043
|
-
|
|
|
|
14 - RETAINING RING
BSD-1600224025.A64
1600224025
|
£2.61
|
£3.13
|
|
|
15 - COMPRESSION SPRING
BSD-2604630000.A2
2604630000
|
-
|
|
|
|
16 - PLAIN WASHER
BSD-2600101513.A53
2600101513
|
£1.75
|
£2.10
|
|
|
17 - O-RING 12x2 MM
BSD-1900210009.A10
1900210009
|
-
|
|
|
|
18 - FELT DISC
BSD-2600108020.A194
2600108020
|
-
|
|
|
|
19 - CUPPED WASHER
BSD-2600500008.A190
2600500008
|
-
|
|
|
|
20 - RECEPTACLE
BSD-2600400020.A128
2600400020
|
-
|
|
|
|
21 - ARMATURE PLATE
BSD-2600121002.A37
2600121002
|
-
|
|
|
|
22 - FAN
BSD-2606610040.A6
2606610040
|
-
|
|
|
|
23 - GROOVE BALL BEARING 10 MM DIN 625
BSD-2600905007.A205
2600905007
|
-
|
|
|
|
24 - ARMATURE 220V
BSD-2604010395.A0
2604010395
|
-
|
|
|
|
25 - BALL BEARING 7x22x7
BSD-1900905018.A823
1900905018
|
£18.96
|
£22.75
|
|
|
26 - SHIM
BSD-2600150004.A89
2600150004
|
£2.16
|
£2.59
|
|
|
28 - SHIM 0.5 MM
BSD-2600101020.A118
2600101020
|
£1.75
|
£2.10
|
|
|
28 - SHIM 0.2 MM
BSD-2600101022.A532
2600101022
|
£1.75
|
£2.10
|
|
|
28 - SHIM 0.3 MM
BSD-2600101023.A118
2600101023
|
£1.75
|
£2.10
|
|
|
29 - MOTOR HOUSING
BSD-2605104903.A79
2605104903
|
-
|
|
|
|
30 - POLE SHOE 220V
BSD-2604222241.A11
2604222241
|
-
|
|
|
|
33 - COVER DISC
BSD-2601328021.A34
2601328021
|
-
|
|
|
|
34 - COMPRESSION SPRING
BSD-2604611026.A254
2604611026
|
-
|
|
|
|
37 - CARBON-BRUSH SET
BSD-2604320906.A80
2604320906
|
-
|
|
|
|
38 - SPIRAL SPRING
BSD-2604652002.A173
2604652002
|
-
|
|
|
|
39 - SOCKET HEAD CAP SCREW
BSD-2603410010.A6
2603410010
|
-
|
|
|
|
41 - TAPPING SCREW DIN 7971-BZ2.9x6.5
BSD-2910211004.A376
2910211004
|
-
|
|
|
|
45 - PAN HEAD SCREW
BSD-2603410025.A33
2603410025
|
-
|
|
|
|
46 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A16
2916690003
|
£1.75
|
£2.10
|
|
|
47 - ON-OFF SWITCH
BSD-2607200043.A175
2607200043
|
-
|
|
|
|
48 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A453
2603410023
|
-
|
|
|
|
49 - SUPPRESSION FILTER
BSD-2607329051.A263
2607329051
|
-
|
|
|
|
50 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A24
2604460053
|
-
|
|
|
|
53 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A188
2600703011
|
£2.80
|
£3.36
|
|
|
53 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1322
2600703012
|
£2.80
|
£3.36
|
|
|
53 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A145
2600703013
|
£2.61
|
£3.13
|
|
|
54 - CABLE CLIP
BSD-2601035001.A310
2601035001
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A670
2910211021
|
£1.75
|
£2.10
|
|
|
56 - HOUSING COVER
BSD-2605132007.A47
2605132007
|
-
|
|
|
|
57 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1648
2910211019
|
£1.75
|
£2.10
|
|
|
58 - MANUFACTURER'S NAMEPLATE
BSD-2601007003.A101
2601007003
|
-
|
|
|
|
58 - NAMEPLATE
BSD-160111A3H3.A1103
160111A3H3
|
£2.61
|
£3.13
|
|
|
60 - ROUND-HEAD GROOVED PIN 2x3 DIN 1476 ST
BSD-2917724031.A79
2917724031
|
-
|
|
|
|
61 - SUSPENSION LOOP
BSD-2604682007.A0
2604682007
|
-
|
|
|
|
65 - BUSHING
BSD-2600300058.A72
2600300058
|
-
|
|
|
|
66 - BUSHING
BSD-3600328036.A16
3600328036
|
-
|
|
|
|
67 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A298
1903201042
|
£2.16
|
£2.59
|
|
|
800 - SPINDLE WITH GEAR Z=13/35
BSD-2606328900.A15
2606328900
|
-
|
|
|
|
801 - SPINDLE WITH GEAR Z=9/11
BSD-2606328901.A5
2606328901
|
-
|
|
|
|
802 - TWO-JAW DRILL JUCK M4-M12
BSD-1608573002.A0
1608573002
|
-
|
|
|
|
803 - GRIPPING WEDGE dia 5x18 MM/3.6 MM
BSD-1603110000.A24
1603110000
|
-
|
|
|
|
804 - HEXAGON SOCKET WRENCH
BSD-1607950002.A15
1607950002
|
-
|
|
|
|
805 - STUD BOLT
BSD-1603502000.A7
1603502000
|
£21.52
|
£25.83
|
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390002.A14
1600390002
|
-
|
|
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390003.A19
1600390003
|
-
|
|
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390004.A2
1600390004
|
-
|
|
|
|
806 - CLAMPING JAWS M 12x1.5
BSD-1600390005.A19
1600390005
|
-
|
|
|
