1 - SPINDLE HOUSING
BSD-2605806375.A14
2605806375
|
£21.68
|
£26.01
|
|
|
2 - UNION NUT SW 17. dia 18.5 MM
BSD-2603312006.A35
2603312006
|
£6.52
|
£7.83
|
|
|
4 - SEAL BUSHING
BSD-2600300073.A8
2600300073
|
£6.52
|
£7.83
|
|
|
5 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A177
2916660013
|
£2.16
|
£2.59
|
|
|
6 - RETAINING CLIP DIN 471-15x1-FSt
BSD-2916650006.A370
2916650006
|
£1.75
|
£2.10
|
|
|
7 - CUPPED WASHER
BSD-2600500033.A143
2600500033
|
£2.61
|
£3.13
|
|
|
8 - FELT WASHER
BSD-2600108033.A13
2600108033
|
£1.75
|
£2.10
|
|
|
9 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1573
2603490023
|
£1.75
|
£2.10
|
|
|
10 - GROOVE BALL BEARING 15x32x9
BSD-2600905017.A12
2600905017
|
£10.10
|
£12.12
|
|
|
11 - SHIM 0.1 MM
BSD-1600102626.A38
1600102626
|
£2.16
|
£2.59
|
|
|
102 - FIELD 220-230V
BSD-2604220445.A20
2604220445
|
£27.23
|
£32.68
|
|
|
104 - SWITCH
BSD-2607200093.A1
2607200093
|
-
|
|
|
|
106 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A93
2600703011
|
£2.80
|
£3.36
|
|
|
107 - CABLE CLIP
BSD-2601035001.A1271
2601035001
|
£1.75
|
£2.10
|
|
|
109 - MANUFACTURER'S NAMEPLATE
BSD-2601116670.A0
2601116670
|
-
|
|
|
|
112 - SUPPRESSION FILTER
BSD-2607329118.A3
2607329118
|
£3.72
|
£4.47
|
|
|
113 - GROOVE BALL BEARING
BSD-2600905088.A0
2600905088
|
£9.49
|
£11.39
|
|
|
116 - BRUSH HOLDER
BSD-1600A003G4.A510
1600A003G4
|
£3.72
|
£4.47
|
|
|
118 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A949
2603410001
|
£1.75
|
£2.10
|
|
|
119 - SCREW 4x16
BSD-2603490022.A244
2603490022
|
£1.75
|
£2.10
|
|
|
120 - MANUFACTURER'S NAMEPLATE
BSD-2601116671.A6
2601116671
|
£3.80
|
£4.56
|
|
|
125 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1615
2603490017
|
£2.16
|
£2.59
|
|
|
126 - SPIRAL SPRING
BSD-2604652009.A113
2604652009
|
£1.75
|
£2.10
|
|
|
127 - SHIM
BSD-2600150033.A25
2600150033
|
£2.16
|
£2.59
|
|
|
128 - SHIM WASHER 0.3 MM
BSD-2600101027.A175
2600101027
|
£1.75
|
£2.10
|
|
|
128 - SHIM WASHER 0.2 MM
BSD-2600101665.A43
2600101665
|
£1.75
|
£2.10
|
|
|
128 - SHIM WASHER 0.5 MM
BSD-2600101667.A96
2600101667
|
£1.75
|
£2.10
|
|
|
130 - TAPPING SCREW DIN 7982-ST3.9x22C-H
BSD-2910601321.A226
2910601321
|
-
|
|
|
|
131 - HOUSING COVER
BSD-2600508036.A60
2600508036
|
£10.10
|
£12.12
|
|
|
132 - INTERMEDIATE PIECE
BSD-1600026000.A113
1600026000
|
£1.75
|
£2.10
|
|
|
134 - ADJUSTING SLIDE
BSD-2602319005.A10
2602319005
|
£1.75
|
£2.10
|
|
|
135 - COVER DISC
BSD-2601328045.A173
2601328045
|
£2.16
|
£2.59
|
|
|
136 - TAPPING SCREW
BSD-2603435086.A346
2603435086
|
£1.75
|
£2.10
|
|
|
137 - SUPPRESSION FILTER
BSD-1619P15513.A92
1619P15513
|
£4.75
|
£5.70
|
|
|
138 - CONNECTING CABLE L=119MM
BSD-2604448078.A1
2604448078
|
£1.75
|
£2.10
|
|
|
139 - CONNECTING CABLE L=86MM
BSD-2604448044.A114
2604448044
|
£1.75
|
£2.10
|
|
|
140 - SHRINKABLE TUBE
BSD-1610712034.A72
1610712034
|
£1.66
|
£1.99
|
|
|
141 - BALL
BSD-2603230002.A12
2603230002
|
£1.75
|
£2.10
|
|
|
160 - FAN
BSD-2606610050.A31
2606610050
|
-
|
|
|
|
656 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A103
2603101035
|
£2.80
|
£3.36
|
|
|
703 - COLLET dia 6 MM / dia 10 MM
BSD-2608570047.A8
2608570047
|
£10.82
|
£12.99
|
|
|
703 - COLLET dia 6.4MM=1/4 / dia 10MM
BSD-2608570048.A32
2608570048
|
£12.49
|
£14.99
|
|
|
703 - COLLET dia 8 MM / dia 10 MM
BSD-2608570049.A8
2608570049
|
£12.49
|
£14.99
|
|
|
757 - SINGLE-HEAD ENG. WRENCH SW17
BSD-1607950525.A14
1607950525
|
£2.70
|
£3.24
|
|
|
802 - UNION NUT SW 14
BSD-2603312001.A26
2603312001
|
-
|
|
|
|
803 - COLLET dia 6 MM / dia 8 MM
BSD-2608570065.A4
2608570065
|
-
|
|
|
|
803 - COLLET dia 6.4 MM=1/4/dia 8 MM
BSD-2608570066.A26
2608570066
|
£12.45
|
£14.94
|
|
|
805 - POWER SUPPLY CORD EU 2.6m 2 x 1.0 mm
BSD-1607000385.A249
1607000385
|
£14.91
|
£17.89
|
|
|
810 - MOTOR HOUSING
BSD-2605108904.A118
2605108904
|
£23.86
|
£28.63
|
|
|
811 - CARBON-BRUSH SET
BSD-2604320912.A77
2604320912
|
£10.10
|
£12.12
|
|
|
829 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A197
2910611006
|
£1.75
|
£2.10
|
|
|
830 - ARMATURE 220-230V
BSD-2604010915.A15
2604010915
|
£93.88
|
£112.65
|
|
|
833 - SWITCH HANDLE
BSD-2602026910.A9
2602026910
|
£3.80
|
£4.56
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2265
160111A3H3
|
£2.61
|
£3.13
|
|
