2 - FIELD 230-240V
BSD-2604220480.A19
2604220480
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 230V
BSD-2604010763.A0
2604010763
|
-
|
|
|
|
3/60 - FAN
BSD-2606610049.A498
2606610049
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-2607200367.A37
2607200367
|
£7.78
|
£9.33
|
|
|
5 - POWER SUPPLY CORD I / BR 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460284.A3
2604460284
|
-
|
|
|
|
6 - GROMMET dia8.3-dia10.5x81 MM
BSD-1600703033.A4
1600703033
|
£2.16
|
£2.59
|
|
|
7 - CABLE CLIP
BSD-2601035001.A248
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601117953.A6
2601117953
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A600
1607328028
|
£5.30
|
£6.36
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A557
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A21
2600905052
|
£7.36
|
£8.83
|
|
|
16 - BRUSH HOLDER
BSD-2604449027.A52
2604449027
|
£1.75
|
£2.10
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A111
2603410001
|
£1.75
|
£2.10
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A155
1601110481
|
£2.16
|
£2.59
|
|
|
25 - BEARING FLANGE
BSD-2605719003.A4
2605719003
|
-
|
|
|
|
26 - ADJUSTING ECCENTRIC
BSD-2606110001.A18
2606110001
|
£3.72
|
£4.47
|
|
|
27 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A718
2600917003
|
£2.80
|
£3.36
|
|
|
28 - TOOTHED BELT WHEEL Z=19
BSD-2600324009.A49
2600324009
|
£2.52
|
£3.02
|
|
|
29 - TOOTHED BELT WHEEL Z=43
BSD-2606625009.A18
2606625009
|
£3.34
|
£4.01
|
|
|
30 - ROTARY HANDLE
BSD-2602026004.A32
2602026004
|
-
|
|
|
|
31 - TOOTHED BELT 17 MM. Z=89
BSD-2609995917.A35
2609995917
|
£8.67
|
£10.41
|
|
|
32 - GEAR COVER
BSD-2605510064.A18
2605510064
|
-
|
|
|
|
33 - SCALE PLATE
BSD-2601120000.A12
2601120000
|
£5.87
|
£7.04
|
|
|
34 - CAP-HANDLE
BSD-2605500105.A14
2605500105
|
£2.16
|
£2.59
|
|
|
35 - BRUSH-COVER
BSD-2605510063.A8
2605510063
|
-
|
|
|
|
37 - BEARING BRACKET
BSD-2605819011.A22
2605819011
|
£5.01
|
£6.01
|
|
|
38 - SHEET METAL COVER
BSD-2601098036.A56
2601098036
|
£2.16
|
£2.59
|
|
|
39 - GUIDE BUSHING
BSD-2600324008.A12
2600324008
|
£1.75
|
£2.10
|
|
|
40 - AIR-DEFLECTOR RING
BSD-2600290009.A10
2600290009
|
£3.72
|
£4.47
|
|
|
41 - SPRING PLATE
BSD-2601290016.A29
2601290016
|
£2.16
|
£2.59
|
|
|
42 - THREAD-FORMING TAP. SCREW M 5x12 MM
BSD-2603435027.A38
2603435027
|
£1.75
|
£2.10
|
|
|
43 - COILED SPRING PIN DIN 7343-5x2.5
BSD-2917800053.A31
2917800053
|
£2.16
|
£2.59
|
|
|
44 - SQUARE NUT M6
BSD-2603320004.A51
2603320004
|
£1.75
|
£2.10
|
|
|
45 - TORSION SPRING
BSD-2604651007.A5
2604651007
|
£1.75
|
£2.10
|
|
|
47 - RATCHET SPRING
BSD-2601254000.A45
2601254000
|
£1.75
|
£2.10
|
|
|
48 - SCREW AND WASHER ASSEMBLY
BSD-2603433000.A37
2603433000
|
£1.75
|
£2.10
|
|
|
49 - HANDLE PLATE
BSD-2605133026.A6
2605133026
|
£7.78
|
£9.33
|
|
|
50 - COILED SPRING PIN DIN 7343-3.5x8 MM
BSD-2917800303.A5
2917800303
|
£1.75
|
£2.10
|
|
|
51 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A78
2600100041
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.2 MM
BSD-1600100632.A6
1600100632
|
£1.75
|
£2.10
|
|
|
53 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A129
2916011010
|
£1.75
|
£2.10
|
|
|
55 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A25
2600905064
|
£11.30
|
£13.56
|
|
|
57 - CONNECTING CABLE L = 288 MM
BSD-2604448062.A127
2604448062
|
£1.32
|
£1.58
|
|
|
58 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A748
2603490023
|
£1.75
|
£2.10
|
|
|
60 - DEFLECTOR PIPE
BSD-2600409022.A13
2600409022
|
-
|
|
|
|
68 - SHRINKABLE TUBE
BSD-2600409020.A22
2600409020
|
£1.75
|
£2.10
|
|
|
72 - SQUARE NUT M8
BSD-2603320003.A53
2603320003
|
£1.75
|
£2.10
|
|
|
73 - ROUND NUT M6
BSD-2603342006.A60
2603342006
|
£1.75
|
£2.10
|
|
|
75 - RUBBER BUFFER
BSD-2603100053.A17
2603100053
|
£1.75
|
£2.10
|
|
|
81 - CONTACT STRAP
BSD-2601329053.A43
2601329053
|
£1.75
|
£2.10
|
|
|
86 - SET SCREW
BSD-2603400014.A40
2603400014
|
-
|
|
|
|
87 - HEX SCREW
BSD-2603450005.A34
2603450005
|
-
|
|
|
|
655 - DEPTH-GAUGE
BSD-2607001045.A28
2607001045
|
£6.61
|
£7.93
|
|
|
754 - SINGLE-HEAD ENG. WRENCH
BSD-2607950504.A35
2607950504
|
£2.52
|
£3.02
|
|
|
771/1 - GRIP-SPRING TENSIONING E
BSD-2608040039.A26
2608040039
|
£21.68
|
£26.01
|
|
|
771/10 - PLANING KNIFE
BSD-2608635341.A91
2608635341
|
£16.41
|
£19.69
|
|
|
786 - DUST BAG
BSD-2609170013.A26
2609170013
|
£27.23
|
£32.68
|
|
|
787 - CARRYING CASE
BSD-2605438474.A7
2605438474
|
-
|
|
|
|
788 - SUCTION CONNECTOR
BSD-2605702022.A12
2605702022
|
-
|
|
|
|
789 - PARALLEL-GUIDE
BSD-2607000102.A44
2607000102
|
£20.99
|
£25.19
|
|
|
795 - WIDTH STOP
BSD-2607001077.A28
2607001077
|
£34.12
|
£40.94
|
|
|
796 - KNIFE GUARD
BSD-2607001106.A17
2607001106
|
-
|
|
|
|
797 - BLADE SHARPENING DEVICE
BSD-2608133001.A15
2608133001
|
-
|
|
|
|
798 - STRAIGHTENING DEVICE
BSD-0603095000.A9
0603095000
|
-
|
|
|
|
799 - BASE
BSD-0603095002.A42
0603095002
|
-
|
|
|
|
801 - HOUSING
BSD-2605190914.A10
2605190914
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A997
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A574
2604321905
|
£11.30
|
£13.56
|
|
|
819 - SCREW 4x16
BSD-2603490022.A1573
2603490022
|
£1.75
|
£2.10
|
|
|
827 - GROOVE BALL BEARING 6x19x6
BSD-2600905037.A23
2600905037
|
-
|
|
|
|
837 - BEARING BRACKET
BSD-2605819004.A20
2605819004
|
-
|
|
|
|
870 - PLANER HEAD
BSD-2603204908.A29
2603204908
|
-
|
|
|
|
876 - KNIFE GUARD
BSD-2601329055.A10
2601329055
|
-
|
|
|
