2 - FIELD 230-240V
BSD-2604220480.A68
2604220480
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 230V
BSD-2604010763.A14
2604010763
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1607000231.A103
1607000231
|
£18.96
|
£22.75
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460403.A26
1604460403
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A295
2600703007
|
-
|
|
|
|
6 - GROMMET dia9.5 MM
BSD-2600703006.A89
2600703006
|
-
|
|
|
|
6 - GROMMET dia8.2 MM
BSD-2600703008.A36
2600703008
|
£1.75
|
£2.10
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1930
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118603.A5
2601118603
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329138.A11
2607329138
|
-
|
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A627
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A889
2600905052
|
£7.36
|
£8.83
|
|
|
16 - BRUSH HOLDER
BSD-2604449027.A100
2604449027
|
£1.75
|
£2.10
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1419
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1657
2603490022
|
£1.75
|
£2.10
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A354
1601110481
|
£2.16
|
£2.59
|
|
|
25 - BEARING FLANGE
BSD-2605719001.A3
2605719001
|
-
|
|
|
|
26 - ADJUSTING ECCENTRIC
BSD-2606110001.A52
2606110001
|
£3.72
|
£4.47
|
|
|
27 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A204
2600917003
|
£2.80
|
£3.36
|
|
|
28 - TOOTHED BELT WHEEL Z=19
BSD-2600324009.A9
2600324009
|
£2.52
|
£3.02
|
|
|
29 - TOOTHED BELT WHEEL Z=43
BSD-2606625009.A49
2606625009
|
£3.34
|
£4.01
|
|
|
30 - ROTARY HANDLE
BSD-2602026004.A38
2602026004
|
-
|
|
|
|
31 - TOOTHED BELT 17 MM. Z=89
BSD-2609995917.A4
2609995917
|
£8.67
|
£10.41
|
|
|
32 - GEAR COVER
BSD-2605510041.A20
2605510041
|
£5.01
|
£6.01
|
|
|
33 - SCALE PLATE
BSD-2601120000.A3
2601120000
|
£5.87
|
£7.04
|
|
|
34 - CAP-HANDLE
BSD-2605500105.A42
2605500105
|
£2.16
|
£2.59
|
|
|
35 - COVERING HOOD
BSD-2605510039.A0
2605510039
|
£2.52
|
£3.02
|
|
|
37 - BEARING BRACKET
BSD-2605819004.A38
2605819004
|
-
|
|
|
|
38 - SHEET METAL COVER
BSD-2601098036.A0
2601098036
|
£2.16
|
£2.59
|
|
|
39 - GUIDE BUSHING
BSD-2600324008.A55
2600324008
|
£1.75
|
£2.10
|
|
|
40 - AIR-DEFLECTOR RING
BSD-2600290006.A9
2600290006
|
-
|
|
|
|
41 - SPRING PLATE
BSD-2601290016.A6
2601290016
|
£2.16
|
£2.59
|
|
|
42 - THREAD-FORMING TAP. SCREW M 5x12 MM
BSD-2603435027.A55
2603435027
|
£1.75
|
£2.10
|
|
|
43 - COILED SPRING PIN DIN 7343-5x2.5
BSD-2917800053.A60
2917800053
|
£2.16
|
£2.59
|
|
|
44 - SQUARE NUT M6
BSD-2603320004.A116
2603320004
|
£1.75
|
£2.10
|
|
|
45 - TORSION SPRING
BSD-2604651007.A53
2604651007
|
£1.75
|
£2.10
|
|
|
47 - RATCHET SPRING
BSD-2601254000.A3
2601254000
|
£1.75
|
£2.10
|
|
|
48 - SCREW AND WASHER ASSEMBLY
BSD-2603433000.A2
2603433000
|
£1.75
|
£2.10
|
|
|
49 - HANDLE COVER
BSD-2605133006.A11
2605133006
|
£7.36
|
£8.83
|
|
|
50 - COILED SPRING PIN DIN 7343-3.5x8 MM
BSD-2917800303.A52
2917800303
|
£1.75
|
£2.10
|
|
|
51 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A182
2600100041
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.2 MM
BSD-1600100632.A266
1600100632
|
£1.75
|
£2.10
|
|
|
53 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A366
2916011010
|
£1.75
|
£2.10
|
|
|
54 - SINGLE-HEAD ENG. WRENCH
BSD-2607950504.A93
2607950504
|
£2.52
|
£3.02
|
|
|
55 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A5
2600905064
|
£11.30
|
£13.56
|
|
|
57 - CONNECTING CABLE L = 288 MM
BSD-2604448062.A27
2604448062
|
£1.32
|
£1.58
|
|
|
67 - COVER
BSD-2605510036.A21
2605510036
|
-
|
|
|
|
68 - SHRINKABLE TUBE
BSD-2600409020.A10
2600409020
|
£1.75
|
£2.10
|
|
|
72 - SQUARE NUT M8
BSD-2603320003.A2
2603320003
|
£1.75
|
£2.10
|
|
|
73 - ROUND NUT M6
BSD-2603342006.A33
2603342006
|
£1.75
|
£2.10
|
|
|
75 - RUBBER BUFFER
BSD-1603100036.A63
1603100036
|
£1.75
|
£2.10
|
|
|
86 - SET SCREW
BSD-2603400014.A1
2603400014
|
-
|
|
|
|
87 - HEX SCREW
BSD-2603450005.A12
2603450005
|
-
|
|
|
|
199 - STICKER
BSD-1601110265.A215
1601110265
|
-
|
|
|
|
655 - DEPTH-GAUGE
BSD-2607001045.A1
2607001045
|
£6.61
|
£7.93
|
|
|
656 - PARTS SET
BSD-2607001047.A13
2607001047
|
-
|
|
|
|
657 - STOP BRACKET
BSD-2608005015.A2
2608005015
|
£11.30
|
£13.56
|
|
|
771 - GRIP-SPRING TENSIONING E
BSD-2608040039.A50
2608040039
|
£21.68
|
£26.01
|
|
|
771/2 - CHANGEOVER SET
BSD-2607000136.A3
2607000136
|
-
|
|
|
|
771/10 - PLANING KNIFE
BSD-2608635341.A9
2608635341
|
£16.41
|
£19.69
|
|
|
786 - CHIPS BAG
BSD-2605411016.A11
2605411016
|
-
|
|
|
|
787 - CARRYING CASE
BSD-2605438119.A1
2605438119
|
-
|
|
|
|
788 - SUCTION CONNECTOR
BSD-2605702017.A2
2605702017
|
£5.24
|
£6.29
|
|
|
794 - CHANGEOVER SET
BSD-2607000136.A2
2607000136
|
-
|
|
|
|
795 - WIDTH STOP
BSD-2607001077.A39
2607001077
|
£34.12
|
£40.94
|
|
|
796 - KNIFE GUARD
BSD-2607001106.A3
2607001106
|
-
|
|
|
|
797 - BLADE SHARPENING DEVICE
BSD-2608133001.A1
2608133001
|
-
|
|
|
|
798 - STRAIGHTENING DEVICE
BSD-0603095000.A39
0603095000
|
-
|
|
|
|
799 - BASE
BSD-2608005034.A10
2608005034
|
-
|
|
|
|
801 - HOUSING
BSD-2605190901.A1
2605190901
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A38
2604321905
|
£11.30
|
£13.56
|
|
|
870 - PLANER HEAD
BSD-2603204908.A2
2603204908
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A4802
160111A3H3
|
£2.61
|
£3.13
|
|
