2 - FIELD 220-240V
BSD-2604220663.A4
2604220663
|
£23.86
|
£28.63
|
|
|
3 - ARMATURE 230-240V
BSD-2604011322.A5
2604011322
|
£52.15
|
£62.58
|
|
|
3/9 - FAN
BSD-2606610116.A11
2606610116
|
£2.33
|
£2.80
|
|
|
4 - SWITCH
BSD-2607200615.A1
2607200615
|
£8.67
|
£10.41
|
|
|
5 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A24
1607000386
|
£21.52
|
£25.83
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A893
2600703017
|
£2.33
|
£2.80
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116746.A2
2601116746
|
£2.33
|
£2.80
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329148.A6
2607329148
|
£7.36
|
£8.83
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A500
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A200
2600905052
|
£7.36
|
£8.83
|
|
|
16 - BRUSH HOLDER
BSD-2604449026.A91
2604449026
|
£1.66
|
£1.99
|
|
|
17 - BRUSH HOLDER
BSD-2604449027.A0
2604449027
|
£1.66
|
£1.99
|
|
|
19 - SCREW 4x16
BSD-2603490022.A200
2603490022
|
£1.66
|
£1.99
|
|
|
20 - THREAD-FORMING TAP. SCREW M4x12 MM
BSD-2603410049.A55
2603410049
|
£1.66
|
£1.99
|
|
|
25 - BEARING FLANGE
BSD-2605719033.A0
2605719033
|
£27.23
|
£32.68
|
|
|
26 - ADJUSTING ECCENTRIC
BSD-2606110001.A37
2606110001
|
£3.72
|
£4.47
|
|
|
28 - PULLEY WHEEL
BSD-2600324010.A1
2600324010
|
£4.26
|
£5.11
|
|
|
29 - PULLEY WHEEL
BSD-2600324012.A10
2600324012
|
£7.36
|
£8.83
|
|
|
30 - ROTARY HANDLE
BSD-2602026136.A1
2602026136
|
£5.58
|
£6.70
|
|
|
31 - V-BELT
BSD-2604736013.A8
2604736013
|
£10.10
|
£12.12
|
|
|
32 - GEAR COVER
BSD-2605510220.A3
2605510220
|
£7.36
|
£8.83
|
|
|
33 - SCALE PLATE
BSD-2601120009.A11
2601120009
|
£11.30
|
£13.56
|
|
|
34 - CAP-HANDLE
BSD-2605500184.A1
2605500184
|
£1.66
|
£1.99
|
|
|
35 - BRUSH-COVER
BSD-2605510208.A1
2605510208
|
£7.36
|
£8.83
|
|
|
38 - SHEET METAL COVER
BSD-2601098036.A32
2601098036
|
£1.95
|
£2.34
|
|
|
39 - GUIDE BUSHING
BSD-2600324008.A48
2600324008
|
£1.66
|
£1.99
|
|
|
40 - AIR-DEFLECTOR RING
BSD-2600290009.A33
2600290009
|
£3.72
|
£4.47
|
|
|
41 - SPRING PLATE
BSD-2601290016.A53
2601290016
|
£1.95
|
£2.34
|
|
|
42 - THREAD-FORMING TAP. SCREW M 5x12 MM
BSD-2603435027.A9
2603435027
|
£1.66
|
£1.99
|
|
|
44 - SQUARE NUT M6
BSD-2603320004.A89
2603320004
|
£1.66
|
£1.99
|
|
|
45 - TORSION SPRING
BSD-2604651007.A48
2604651007
|
£1.66
|
£1.99
|
|
|
47 - RATCHET CAP
BSD-2600590006.A1262
2600590006
|
£1.66
|
£1.99
|
|
|
48 - SCREW AND WASHER ASSEMBLY
BSD-2603433000.A66
2603433000
|
£1.66
|
£1.99
|
|
|
49 - HANDLE PLATE
BSD-2605409030.A1
2605409030
|
£21.68
|
£26.01
|
|
|
53 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A55
2916011010
|
£1.66
|
£1.99
|
|
|
54 - OFFSET SCREWDRIVER
BSD-2607950045.A20
2607950045
|
£1.95
|
£2.34
|
|
|
55 - GROOVE BALL BEARING 10x26x8
BSD-2600905064.A78
2600905064
|
£11.30
|
£13.56
|
|
|
57 - CONNECTING CABLE
BSD-2604448059.A22
2604448059
|
-
|
|
|
|
58 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1596
2603490023
|
£1.66
|
£1.99
|
|
|
60 - DEFLECTOR PIPE
BSD-2600409028.A7
2600409028
|
£10.10
|
£12.12
|
|
|
61 - PLUG-IN MODULE
BSD-2605500185.A1
2605500185
|
£4.26
|
£5.11
|
|
|
62 - SQUARE NUT M8
BSD-2603320003.A31
2603320003
|
£1.66
|
£1.99
|
|
|
63 - ROUND NUT M6
BSD-2603342006.A81
2603342006
|
£1.66
|
£1.99
|
|
|
70 - PLANER HEAD
BSD-2608584683.A1
2608584683
|
£68.42
|
£82.10
|
|
|
70/2 - PLANING KNIFE
BSD-2608635341.A49
2608635341
|
£16.41
|
£19.69
|
|
|
70/3 - GRIPPING WEDGE
BSD-2603111001.A16
2603111001
|
£13.12
|
£15.75
|
|
|
70/4 - SET SCREW
BSD-2603400016.A6
2603400016
|
£1.66
|
£1.99
|
|
|
70/6 - BEARING BRACKET
BSD-2605819012.A11
2605819012
|
£21.52
|
£25.83
|
|
|
70/7 - NEEDLE BEARING
BSD-2600914025.A5
2600914025
|
-
|
|
|
|
70/8 - COILED SPRING PIN DIN 7343-3.5x8 MM
BSD-2917800303.A42
2917800303
|
£1.66
|
£1.99
|
|
|
76 - KNIFE GUARD
BSD-2601329112.A3
2601329112
|
£2.33
|
£2.80
|
|
|
77 - TORSION SPRING
BSD-2604651016.A5
2604651016
|
£1.66
|
£1.99
|
|
|
80 - SPEED GOVERNOR 230-240V
BSD-2607233064.A9
2607233064
|
£57.05
|
£68.46
|
|
|
81 - CONTACT STRAP
BSD-2601329110.A4
2601329110
|
£1.66
|
£1.99
|
|
|
687/1 - STOP BRACKET
BSD-1601331039.A41
1601331039
|
-
|
|
|
|
687/2 - WING SCREW
BSD-2603480006.A7
2603480006
|
£2.33
|
£2.80
|
|
|
687/4 - O-RING 4.0x1.5 MM
BSD-1610210043.A84
1610210043
|
£1.66
|
£1.99
|
|
|
687/5 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A46
2916011014
|
£1.66
|
£1.99
|
|
|
687/6 - WING SCREW M 6x16 MM
BSD-2603480003.A161
2603480003
|
£2.33
|
£2.80
|
|
|
687/7 - STOP BRACKET
BSD-1601332018.A36
1601332018
|
£3.72
|
£4.47
|
|
|
687/8 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A181
2910281201
|
£1.66
|
£1.99
|
|
|
687/9 - HEX NUT
BSD-2610387875.A58
2610387875
|
£2.33
|
£2.80
|
|
|
801 - HOUSING
BSD-2605190918.A1
2605190918
|
£81.81
|
£98.17
|
|
|
808 - NAMEPLATE
BSD-160111A1NW.A0
160111A1NW
|
£2.33
|
£2.80
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014016.A5
2607014016
|
£11.30
|
£13.56
|
|
