1 - MOTOR HOUSING
BSD-1619P07202.A3
1619P07202
|
£14.91
|
£17.89
|
|
|
2 - FIELD 230V
BSD-1619P05382.A0
1619P05382
|
£18.96
|
£22.75
|
|
|
3 - ARMATURE 230V
BSD-1619P05282.A2
1619P05282
|
£37.27
|
£44.72
|
|
|
3/6 - FAN
BSD-1619P05243.A0
1619P05243
|
£1.75
|
£2.10
|
|
|
4 - SWITCH
BSD-1619P07688.A3
1619P07688
|
£16.41
|
£19.69
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2x1 H05 RN-F
BSD-1604460700.A0
1604460700
|
£12.04
|
£14.45
|
|
|
6 - GROMMET dia 7mm
BSD-1619P14642.A7
1619P14642
|
£1.75
|
£2.10
|
|
|
7 - CABLE CLIP
BSD-2601035001.A775
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1619P31108.A0
1619P31108
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-1619P08938.A0
1619P08938
|
£2.16
|
£2.59
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A938
1900905018
|
£18.96
|
£22.75
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905005.A3
1610905005
|
£14.91
|
£17.89
|
|
|
16 - BRUSH HOLDER
BSD-1600A003G4.A307
1600A003G4
|
£3.72
|
£4.47
|
|
|
19 - SCREW 4x16
BSD-2603490022.A664
2603490022
|
£1.75
|
£2.10
|
|
|
21 - SPIRAL SPRING
BSD-2604652009.A255
2604652009
|
£1.75
|
£2.10
|
|
|
22 - TORX OVAL-HEAD SCREW 3x10
BSD-1619P00220.A76
1619P00220
|
£1.75
|
£2.10
|
|
|
23 - RETAINING SNAP RING
BSD-1619P07541.A0
1619P07541
|
£1.75
|
£2.10
|
|
|
24 - FORK LEVER
BSD-1619P07190.A3
1619P07190
|
£2.80
|
£3.36
|
|
|
26 - SCREW CAP
BSD-1619P07542.A3
1619P07542
|
£3.72
|
£4.47
|
|
|
28 - CONNECTING CABLE L=88 MM
BSD-2604448034.A258
2604448034
|
£1.75
|
£2.10
|
|
|
29 - SHIM WASHER 0.3 MM
BSD-2600101027.A100
2600101027
|
£1.75
|
£2.10
|
|
|
30 - SHIM
BSD-2600150004.A246
2600150004
|
£2.16
|
£2.59
|
|
|
31 - SPEED GOVERNOR
BSD-1619P07418.A2
1619P07418
|
£27.23
|
£32.68
|
|
|
32 - MAGNETIC DISK
BSD-2600290060.A3
2600290060
|
£2.80
|
£3.36
|
|
|
33 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A90
2603435015
|
£2.16
|
£2.59
|
|
|
34 - COVER DISC
BSD-1619P07186.A3
1619P07186
|
£1.75
|
£2.10
|
|
|
35 - SPRING RETAINING RING
BSD-1619P00428.A3
1619P00428
|
£1.75
|
£2.10
|
|
|
36 - RATCHET CAP
BSD-2600590006.A1041
2600590006
|
£1.75
|
£2.10
|
|
|
37 - ROTARY KNOB
BSD-1619P07193.A0
1619P07193
|
£4.26
|
£5.11
|
|
|
38 - ROTARY KNOB
BSD-1619P07188.A0
1619P07188
|
£1.75
|
£2.10
|
|
|
39 - CONNECTING CABLE
BSD-1619P08820.A3
1619P08820
|
£1.75
|
£2.10
|
|
|
40 - LOCKING WASHER
BSD-1619P00444.A1
1619P00444
|
£1.75
|
£2.10
|
|
|
41 - SHIM 0.5 MM
BSD-2600100568.A299
2600100568
|
£1.75
|
£2.10
|
|
|
42 - FAN COVER
BSD-1619P07205.A0
1619P07205
|
£1.75
|
£2.10
|
|
|
44 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8
BSD-2910141197.A105
2910141197
|
£1.75
|
£2.10
|
|
|
45 - SHIM
BSD-1619P07596.A0
1619P07596
|
£1.75
|
£2.10
|
|
|
47 - LOCKING WASHER 4 DIN 6799
BSD-2916080907.A20
2916080907
|
£2.16
|
£2.59
|
|
|
48 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1476
2915011007
|
-
|
|
|
|
50 - THREAD-FORMING TAP. SCREW
BSD-1619P07546.A3
1619P07546
|
£1.75
|
£2.10
|
|
|
51 - SHIM 0.3 MM
BSD-2600100515.A183
2600100515
|
£2.61
|
£3.13
|
|
|
53 - THREAD-FORMING TAP. SCREW
BSD-1619P07650.A0
1619P07650
|
£1.75
|
£2.10
|
|
|
54 - COUNTERWEIGHT
BSD-1619P07191.A1
1619P07191
|
£14.91
|
£17.89
|
|
|
55 - COVERING HOOD
BSD-1619P08936.A3
1619P08936
|
£1.75
|
£2.10
|
|
|
56 - ECCENTRIC COG WHEEL
BSD-1619P07192.A2
1619P07192
|
£21.52
|
£25.83
|
|
|
57 - NEEDLE-ROLLER ASSEMBLY
BSD-2600913040.A24
2600913040
|
£5.58
|
£6.70
|
|
|
58 - SHIM 0.3 MM
BSD-2600101047.A382
2600101047
|
£1.75
|
£2.10
|
|
|
59 - SPRING RETAINING RING 8x0.8 N31A MR7
BSD-2916640905.A59
2916640905
|
£1.75
|
£2.10
|
|
|
60 - RING
BSD-1619P08926.A0
1619P08926
|
£1.75
|
£2.10
|
|
|
63 - SEAL
BSD-1619P07194.A3
1619P07194
|
£1.75
|
£2.10
|
|
|
66 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A306
2603410048
|
£1.75
|
£2.10
|
|
|
67 - COMPRESSION SPRING
BSD-2604613000.A144
2604613000
|
£1.75
|
£2.10
|
|
|
68 - GUIDE BRACKET
BSD-1616B00224.A191
1616B00224
|
£11.32
|
£13.58
|
|
|
69 - LIFTING ROD
BSD-1619P12765.A1
1619P12765
|
£16.41
|
£19.69
|
|
|
70 - CLAMPING SADDLE
BSD-1619P06451.A0
1619P06451
|
£1.75
|
£2.10
|
|
|
71 - SLIDING PIECE
BSD-1619P12767.A11
1619P12767
|
£9.47
|
£11.36
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 7962-M3.5x8-10.9
BSD-2603421040.A129
2603421040
|
£1.75
|
£2.10
|
|
|
73 - SUPPORTING DISC 0.5 MM
BSD-2600112031.A4
2600112031
|
£1.75
|
£2.10
|
|
|
74 - SEAL RING 0.5 MM
BSD-2600290017.A128
2600290017
|
£1.75
|
£2.10
|
|
|
75 - SHIM 0.5 MM
BSD-2600101612.A95
2600101612
|
£1.75
|
£2.10
|
|
|
76 - FIXING PLATE
BSD-1619P07544.A2
1619P07544
|
£1.75
|
£2.10
|
|
|
77 - SEALING PLATE
BSD-1619P07545.A1
1619P07545
|
£1.75
|
£2.10
|
|
|
78 - STICKER
BSD-1619P07597.A2
1619P07597
|
£2.61
|
£3.13
|
|
|
79 - ROLLER LEVER
BSD-1619P07318.A0
1619P07318
|
£16.41
|
£19.69
|
|
|
83 - STRAIGHT PIN DIN 6325-4M6x24
BSD-2917530101.A38
2917530101
|
£2.80
|
£3.36
|
|
|
86 - ROTARY HANDLE
BSD-1619P07543.A1
1619P07543
|
£14.91
|
£17.89
|
|
|
87 - CARRIER BRACKET
BSD-2600423006.A34
2600423006
|
£1.75
|
£2.10
|
|
|
88 - O-RING
BSD-1619P06265.A4
1619P06265
|
£1.75
|
£2.10
|
|
|
89 - RATCHET
BSD-2606491011.A30
2606491011
|
£2.61
|
£3.13
|
|
|
90 - COUPLING HALF
BSD-2606491014.A26
2606491014
|
£7.36
|
£8.83
|
|
|
91 - SHIM
BSD-1619P00446.A2
1619P00446
|
£1.75
|
£2.10
|
|
|
92 - COMPRESSION SPRING
BSD-2604610040.A2
2604610040
|
£1.75
|
£2.10
|
|
|
93 - COMPRESSION SPRING
BSD-2604617004.A33
2604617004
|
£2.16
|
£2.59
|
|
|
94 - GUIDE SLEEVE
BSD-2600421001.A31
2600421001
|
£1.75
|
£2.10
|
|
|
95 - CLAMP SCREW
BSD-2603490011.A25
2603490011
|
£6.52
|
£7.83
|
|
|
96 - BASE PLATE
BSD-1619P07199.A3
1619P07199
|
£12.04
|
£14.45
|
|
|
97 - SET OF HANDLES
BSD-1619P07200.A0
1619P07200
|
£18.96
|
£22.75
|
|
|
98 - PROTECTIVE COVER
BSD-1619P07196.A0
1619P07196
|
£1.75
|
£2.10
|
|
|
651 - SPLINTERING PROTECTOR
BSD-2601016065.A49
2601016065
|
£5.30
|
£6.36
|
|
|
653 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A571
1907950006
|
£4.26
|
£5.11
|
|
|
808 - NAMEPLATE
BSD-1619P08869.A0
1619P08869
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604320912.A0
2604320912
|
£10.10
|
£12.12
|
|
|
810 - CARBON-BRUSH SET 10 x 2 604 320 912
BSD-1607000486.A15
1607000486
|
£63.50
|
£76.20
|
|
|
843 - GEAR HOUSING
BSD-1619P09136.A3
1619P09136
|
£40.80
|
£48.96
|
|
|
861 - NEEDLE BEARING
BSD-2600917900.A314
2600917900
|
£8.67
|
£10.41
|
|
|
865 - GEAR COVER
BSD-1619P09137.A0
1619P09137
|
£31.64
|
£37.97
|
|
|
881 - GUIDE ROLLER SET
BSD-1619P09138.A3
1619P09138
|
£7.36
|
£8.83
|
|
|
899 - RATCHET
BSD-1619P09139.A0
1619P09139
|
£2.80
|
£3.36
|
|
