1 - MOTOR HOUSING
BSD-2605104379.A0
2605104379
|
-
|
|
|
|
2 - FIELD 100-115V
BSD-2604220482.A0
2604220482
|
-
|
|
|
|
3 - ARMATURE 110-115V
BSD-2604010793.A10
2604010793
|
£46.82
|
£56.18
|
|
|
3/60 - FAN
BSD-2606610029.A31
2606610029
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-2607200210.A2
2607200210
|
£48.38
|
£58.06
|
|
|
5 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460207.A6
2604460207
|
£18.96
|
£22.75
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A656
2600707059
|
£3.72
|
£4.47
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1112
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601118270.A0
2601118270
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A108
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A1145
1900905018
|
£18.96
|
£22.75
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A213
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1024
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A360
2603490022
|
£1.75
|
£2.10
|
|
|
20 - REFERENCE PLATE
BSD-2601118271.A0
2601118271
|
-
|
|
|
|
24 - DRILLING SPINDLE 1/2
BSD-2606135013.A20
2606135013
|
£21.42
|
£25.71
|
|
|
26 - COMPRESSION SPRING
BSD-2604616002.A45
2604616002
|
£1.75
|
£2.10
|
|
|
27 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A409
1900905163
|
£11.30
|
£13.56
|
|
|
28 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A459
2916660014
|
£1.75
|
£2.10
|
|
|
29 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A311
2916650008
|
£1.75
|
£2.10
|
|
|
30 - FLAT KEY
BSD-2602300028.A55
2602300028
|
-
|
|
|
|
31 - RETAINING WASHER
BSD-2600101671.A244
2600101671
|
£1.75
|
£2.10
|
|
|
32 - SHIM 1.0 MM
BSD-2600101515.A14
2600101515
|
£1.95
|
£2.34
|
|
|
33 - CYLINDRICAL GEAR Z=48
BSD-2606317045.A2
2606317045
|
£14.72
|
£17.67
|
|
|
34 - CYLINDRICAL GEAR Z=36
BSD-2606317037.A206
2606317037
|
-
|
|
|
|
35 - SHIM 0.5 MM
BSD-2600101616.A228
2600101616
|
-
|
|
|
|
35 - SHIM 0.3 MM
BSD-2600101617.A91
2600101617
|
£1.75
|
£2.10
|
|
|
36 - CATCH DISK
BSD-2600190052.A193
2600190052
|
£7.78
|
£9.33
|
|
|
37 - CATCH DISK
BSD-2600190057.A106
2600190057
|
-
|
|
|
|
38 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A480
2600917003
|
£2.80
|
£3.36
|
|
|
39 - SHIM WASHER 0.2 MM
BSD-2600000012.A92
2600000012
|
£1.75
|
£2.10
|
|
|
39 - SHIM WASHER 0.5 MM
BSD-2600000014.A61
2600000014
|
£1.75
|
£2.10
|
|
|
39 - SHIM WASHER 1.35 MM
BSD-2600000030.A150
2600000030
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A617
1903230010
|
£1.75
|
£2.10
|
|
|
41 - ROTARY KNOB
BSD-2602026017.A49
2602026017
|
£7.36
|
£8.83
|
|
|
42 - SLOTTED SPRING PIN 4x30 MM DIN 7346
BSD-2917780105.A179
2917780105
|
£1.75
|
£2.10
|
|
|
44 - COVER DISC
BSD-2601328033.A71
2601328033
|
-
|
|
|
|
45 - TAPPING SCREW
BSD-2603435086.A360
2603435086
|
£1.75
|
£2.10
|
|
|
46 - HOUSING COVER
BSD-2605132025.A5
2605132025
|
£7.36
|
£8.83
|
|
|
47 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A143
2604465097
|
£5.58
|
£6.70
|
|
|
48 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1583
2603490017
|
£2.16
|
£2.59
|
|
|
49 - SHIM
BSD-2600150004.A310
2600150004
|
£2.16
|
£2.59
|
|
|
50 - SHIM WASHER 0.3 MM
BSD-2600101027.A216
2600101027
|
£1.75
|
£2.10
|
|
|
50 - SHIM WASHER 0.2 MM
BSD-2600101665.A61
2600101665
|
£1.75
|
£2.10
|
|
|
50 - SHIM WASHER 0.5 MM
BSD-2600101667.A66
2600101667
|
£1.75
|
£2.10
|
|
|
51 - CABLE L=130 MM
BSD-2604448005.A391
2604448005
|
£1.75
|
£2.10
|
|
|
52 - EARTH CONDUCTOR
BSD-2604448097.A92
2604448097
|
£1.75
|
£2.10
|
|
|
54 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A805
2916660008
|
£2.16
|
£2.59
|
|
|
55 - CUPPED WASHER
BSD-2600500002.A185
2600500002
|
£1.75
|
£2.10
|
|
|
56 - FELT WASHER
BSD-2600108077.A33
2600108077
|
£1.75
|
£2.10
|
|
|
57 - RECEPTACLE
BSD-2600400008.A342
2600400008
|
£1.75
|
£2.10
|
|
|
61 - SHIM 0.3 MM
BSD-2600100607.A945
2600100607
|
£1.75
|
£2.10
|
|
|
62 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A512
2600914010
|
£2.80
|
£3.36
|
|
|
63 - HEADLESS SCREW
BSD-2603435070.A14
2603435070
|
£2.16
|
£2.59
|
|
|
64 - HEADLESS SCREW 65 MM
BSD-2603435071.A107
2603435071
|
-
|
|
|
|
66 - ADJUSTING SLIDE
BSD-2602033006.A15
2602033006
|
£2.80
|
£3.36
|
|
|
68 - SHIM WASHER
BSD-2600100618.A251
2600100618
|
£1.75
|
£2.10
|
|
|
69 - ROTARY KNOB
BSD-2602026038.A111
2602026038
|
-
|
|
|
|
71 - RATCHET CAP
BSD-2600590006.A1222
2600590006
|
£1.75
|
£2.10
|
|
|
72 - GASKET
BSD-2601073012.A21
2601073012
|
£1.75
|
£2.10
|
|
|
73 - CONNECTING CABLE L=110 MM
BSD-2604448146.A26
2604448146
|
£1.75
|
£2.10
|
|
|
75 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A156
2603490024
|
£1.75
|
£2.10
|
|
|
77 - CONNECTING CABLE L=68 MM
BSD-2604448100.A44
2604448100
|
£1.75
|
£2.10
|
|
|
78 - CONNECTING CABLE
BSD-2604448239.A1
2604448239
|
-
|
|
|
|
79/700 - CHUCK WRENCH SG2
BSD-2607950007.A1047
2607950007
|
£6.52
|
£7.83
|
|
|
80 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A6
2603421226
|
£1.75
|
£2.10
|
|
|
85 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A55
2604465086
|
£5.58
|
£6.70
|
|
|
653/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A867
2915011007
|
-
|
|
|
|
653/30 - WING SCREW M6x(15)55
BSD-1613480007.A304
1613480007
|
£1.75
|
£2.10
|
|
|
653/50 - CLAMPING PLATE M6
BSD-2608040014.A362
2608040014
|
-
|
|
|
|
653/60 - WING SCREW M6x20 MM
BSD-1613480008.A118
1613480008
|
£1.75
|
£2.10
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A268
1619P10682
|
£12.49
|
£14.99
|
|
|
754 - DEPTH-GAUGE
BSD-2603001019.A181
2603001019
|
£2.63
|
£3.16
|
|
|
779 - KEY CHUCK dia1.5-13 MM
BSD-1608571080.A63
1608571080
|
£27.23
|
£32.68
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321913.A36
2604321913
|
-
|
|
|
|
810/06 - RATCHET CAP
BSD-2601329051.A184
2601329051
|
£2.33
|
£2.80
|
|
|
810/06 - RATCHET CAP
BSD-2601322013.A163
2601322013
|
£1.75
|
£2.10
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A233
2600905039
|
£12.04
|
£14.45
|
|
|
825 - GEAR HOUSING
BSD-2605806996.A0
2605806996
|
-
|
|
|
|
843 - INTERMEDIATE FLANGE
BSD-2605700936.A64
2605700936
|
£46.82
|
£56.18
|
|
|
853 - CHANGE-OVER SWITCH
BSD-2607200231.A346
2607200231
|
£16.41
|
£19.69
|
|
|
859 - TOOTHED SHAFT Z= 10/22/29
BSD-2606100903.A24
2606100903
|
-
|
|
|
|
865 - STICKER
BSD-2601110076.A57
2601110076
|
-
|
|
|
|
867 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A70
2916080007
|
£2.61
|
£3.13
|
|
|
870 - PARTS SET
BSD-2607010226.A71
2607010226
|
£2.33
|
£2.80
|
|
|
888 - NAMEPLATE
BSD-160111A3HC.A49
160111A3HC
|
£2.61
|
£3.13
|
|
