1 - MOTOR HOUSING
BSD-3605108145.A150
3605108145
|
£27.23
|
£32.68
|
|
|
3 - ARMATURE 240V
BSD-3604010016.A0
3604010016
|
-
|
|
|
|
3/60 - FAN
BSD-1606610122.A77
1606610122
|
£2.94
|
£3.53
|
|
|
4 - SWITCH
BSD-1607200075.A47
1607200075
|
£71.84
|
£86.21
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A7
2910011088
|
£1.84
|
£2.21
|
|
|
5 - POWER SUPPLY CORD GB 2.65m 2 x 1.0mm H07 RN-F
BSD-3604460071.A18
3604460071
|
£22.60
|
£27.12
|
|
|
6 - GROMMET dia7.9-dia12.0x120 MM
BSD-1600703022.A95
1600703022
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A503
1601302014
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-3601110371.A6
3601110371
|
£3.51
|
£4.21
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A261
1607328028
|
£5.57
|
£6.68
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A2096
2600905032
|
£5.57
|
£6.68
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-3600905131.A21
3600905131
|
£11.87
|
£14.24
|
|
|
20 - TORX OVAL-HEAD SCREW
BSD-2914201507.A56
2914201507
|
£1.75
|
£2.10
|
|
|
21 - COMPRESSION SPRING
BSD-1604613006.A58
1604613006
|
£1.75
|
£2.10
|
|
|
24 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A658
2910211019
|
£1.84
|
£2.21
|
|
|
25 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A868
2910021118
|
£1.84
|
£2.21
|
|
|
26 - INTERMEDIATE RING
BSD-1600502011.A348
1600502011
|
£2.74
|
£3.29
|
|
|
29 - ROTARY SHAFT LIP SEAL
BSD-3600283043.A55
3600283043
|
£12.64
|
£15.17
|
|
|
30 - INTERMEDIATE RING
BSD-1600300090.A15
1600300090
|
£3.72
|
£4.47
|
|
|
32 - BEARING COVER
BSD-3605500156.A33
3605500156
|
£5.87
|
£7.04
|
|
|
33 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A448
2910211018
|
£1.75
|
£2.10
|
|
|
34 - AIR-DEFLECTOR RING
BSD-3600499006.A10
3600499006
|
£5.57
|
£6.68
|
|
|
35 - WIRE GUIDE
BSD-3601025003.A27
3601025003
|
£1.75
|
£2.10
|
|
|
36 - LENS HEAD SCREW
BSD-3603435039.A6
3603435039
|
£2.74
|
£3.29
|
|
|
38 - SPIRAL SPRING
BSD-3604652001.A27
3604652001
|
£2.74
|
£3.29
|
|
|
39 - TORX OVAL-HEAD SCREW
BSD-2914201527.A113
2914201527
|
£2.27
|
£2.72
|
|
|
40 - INSULATING PLATE 20x20x50 MM
BSD-1602381006.A137
1602381006
|
£1.75
|
£2.10
|
|
|
40 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A59
1602381001
|
-
|
|
|
|
41 - THREAD-FORMING TAP. SCREW
BSD-3604411040.A4
3604411040
|
£2.61
|
£3.13
|
|
|
43 - MANUFACTURER'S NAMEPLATE
BSD-3601110371.A7
3601110371
|
£3.51
|
£4.21
|
|
|
44 - CONNECTING CABLE L=360 MM
BSD-3604460027.A39
3604460027
|
£6.52
|
£7.83
|
|
|
46 - CONNECTING CABLE L=375 MM
BSD-3604438027.A8
3604438027
|
£10.61
|
£12.73
|
|
|
47 - BLADE TERMINAL
BSD-1604477001.A25
1604477001
|
£1.75
|
£2.10
|
|
|
48 - ROTARY KNOB
BSD-3603231004.A10
3603231004
|
£22.60
|
£27.12
|
|
|
50 - STRAIGHT PIN DIN 6325-4m6x20
BSD-2917550099.A7
2917550099
|
£1.75
|
£2.10
|
|
|
51 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A48
1903230010
|
£1.84
|
£2.21
|
|
|
53 - CYLINDRICAL GEAR
BSD-3606317051.A5
3606317051
|
-
|
|
|
|
54 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A303
1600910018
|
£5.57
|
£6.68
|
|
|
55 - SHIM 0.5 MM
BSD-1600100617.A35
1600100617
|
£1.75
|
£2.10
|
|
|
56 - TOOTHED SHAFT Z=9
BSD-3606309014.A6
3606309014
|
£42.84
|
£51.41
|
|
|
57 - CYLINDRICAL GEAR Z=21
BSD-3606317024.A12
3606317024
|
£42.84
|
£51.41
|
|
|
58 - LOCATING WASHER
BSD-3600390015.A11
3600390015
|
£47.95
|
£57.54
|
|
|
59 - LOCATING WASHER
BSD-3600190009.A4
3600190009
|
£33.22
|
£39.87
|
|
|
60 - COUPLING PLATE
BSD-3600101030.A4
3600101030
|
£10.10
|
£12.12
|
|
|
62 - CYLINDRICAL GEAR Z=43
BSD-3606317022.A17
3606317022
|
£48.38
|
£58.06
|
|
|
63 - BALL PIN
BSD-3603126000.A13
3603126000
|
£5.30
|
£6.36
|
|
|
64 - COMPRESSION SPRING
BSD-3604610026.A14
3604610026
|
£2.27
|
£2.72
|
|
|
65 - SEAL
BSD-3601015009.A27
3601015009
|
£2.74
|
£3.29
|
|
|
66 - PRESSURE DISK
BSD-3600101029.A14
3600101029
|
£5.58
|
£6.70
|
|
|
67 - COLLAR SLEEVE
BSD-3600320009.A12
3600320009
|
£11.87
|
£14.24
|
|
|
68 - ROTARY KNOB
BSD-3603231005.A3
3603231005
|
£4.26
|
£5.11
|
|
|
69 - SHIM 0.2 MM
BSD-2600100575.A9
2600100575
|
£2.16
|
£2.59
|
|
|
69 - SHIM 0.3 MM
BSD-2600100576.A308
2600100576
|
-
|
|
|
|
69 - SHIM 0.5 MM
BSD-2600100577.A9
2600100577
|
£1.84
|
£2.21
|
|
|
70 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A105
2916650001
|
£2.74
|
£3.29
|
|
|
71 - STRAIGHT PIN 5 H 8x18 DIN 7
BSD-2917500121.A41
2917500121
|
£1.75
|
£2.10
|
|
|
72 - GROOVE BALL BEARING 15x32x9
BSD-1900905162.A58
1900905162
|
£18.96
|
£22.75
|
|
|
73 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A528
2916660013
|
£2.16
|
£2.59
|
|
|
74 - COMPRESSION SPRING
BSD-2604617000.A4
2604617000
|
£2.61
|
£3.13
|
|
|
75 - DISC SPRING
BSD-3600550004.A10
3600550004
|
£3.91
|
£4.69
|
|
|
77 - RATCHET CAP
BSD-2600590006.A101
2600590006
|
£1.84
|
£2.21
|
|
|
78 - NEEDLE BEARING
BSD-3600913008.A1
3600913008
|
£3.91
|
£4.69
|
|
|
80 - CONNECTING CABLE L=290 MM
BSD-1604445006.A35
1604445006
|
£5.58
|
£6.70
|
|
|
82 - RETAINING RING
BSD-3600224008.A10
3600224008
|
£2.16
|
£2.59
|
|
|
83 - HOLDING PLATE
BSD-3600190010.A14
3600190010
|
£1.75
|
£2.10
|
|
|
84 - COMPRESSION SPRING
BSD-3604611030.A2
3604611030
|
-
|
|
|
|
85 - DRIVING PIN
BSD-3603123018.A3
3603123018
|
-
|
|
|
|
86 - BUSHING
BSD-3600200011.A11
3600200011
|
£7.72
|
£9.27
|
|
|
87 - O-RING 6.0x2.0 MM
BSD-3600210028.A24
3600210028
|
£2.27
|
£2.72
|
|
|
88 - O-RING 27.0x3.0 MM
BSD-3600210027.A9
3600210027
|
£1.84
|
£2.21
|
|
|
90 - TAB WASHER
BSD-1601030022.A552
1601030022
|
£1.84
|
£2.21
|
|
|
92 - SHRINKABLE TUBE
BSD-3600707022.A51
3600707022
|
£3.72
|
£4.47
|
|
|
152 - FELT WASHER
BSD-3600200044.A14
3600200044
|
£2.94
|
£3.53
|
|
|
153 - COVER DISC
BSD-3600150027.A15
3600150027
|
£3.91
|
£4.69
|
|
|
651 - KEY CHUCK dia3-16MM.5/8
BSD-1608571083.A7
1608571083
|
£72.18
|
£86.62
|
|
|
651/8 - CHUCK WRENCH SG2
BSD-2607950011.A41
2607950011
|
£11.30
|
£13.56
|
|
|
652 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001008.A79
1613001008
|
£9.11
|
£10.93
|
|
|
653 - AUXILIARY HANDLE dia 43 MM
BSD-3602025012.A14
3602025012
|
£28.59
|
£34.31
|
|
|
653/10 - AUXILIARY HANDLE M8
BSD-1612025019.A116
1612025019
|
£6.85
|
£8.22
|
|
|
653/10/1 - AUXILIARY HANDLE
BSD-160202507H.A296
160202507H
|
£11.87
|
£14.24
|
|
|
653/20 - SUPPORT CLAMP
BSD-1618040077.A57
1618040077
|
-
|
|
|
|
653/30 - STUD BOLT M8
BSD-1613521001.A59
1613521001
|
£5.58
|
£6.70
|
|
|
653/40 - CLAMPING BAND dia43 MM
BSD-3601038048.A68
3601038048
|
£19.91
|
£23.89
|
|
|
653/50 - STRAIGHT PIN
BSD-1613100012.A129
1613100012
|
£2.61
|
£3.13
|
|
|
802 - FIELD 240V
BSD-3604220128.A0
3604220128
|
-
|
|
|
|
806 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A54
1900452003
|
£2.61
|
£3.13
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A4976
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-3607014012.A41
3607014012
|
£25.05
|
£30.06
|
|
|
816 - BRUSH HOLDER
BSD-3604336012.A152
3604336012
|
£5.58
|
£6.70
|
|
|
822 - SPINDLE HOUSING
BSD-3605806179.A8
3605806179
|
£85.90
|
£103.08
|
|
|
823 - SEALING CAP
BSD-3605500063.A141
3605500063
|
£4.48
|
£5.37
|
|
|
825 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A861
2910021118
|
£1.84
|
£2.21
|
|
|
827 - HANDLE
BSD-3605133012.A63
3605133012
|
-
|
|
|
|
828 - DRILLING SPINDLE 5/8. SW17
BSD-3607030413.A2
3607030413
|
£72.18
|
£86.62
|
|
|
831 - ROTARY SHAFT LIP SEAL
BSD-3600290070.A77
3600290070
|
£12.64
|
£15.17
|
|
|
832 - BEARING COVER
BSD-3605500043.A29
3605500043
|
£4.48
|
£5.37
|
|
|
837 - INTERMEDIATE BEARING
BSD-3605820078.A7
3605820078
|
£142.02
|
£170.42
|
|
|
851 - SPRING WASHER DIN 137-A 4-ST
BSD-2916060005.A70
2916060005
|
£1.84
|
£2.21
|
|
|
853 - CYLINDRICAL GEAR
BSD-3607030411.A17
3607030411
|
£50.80
|
£60.96
|
|
|
856 - CONTROL SHAFT
BSD-3607031177.A8
3607031177
|
£142.02
|
£170.42
|
|
|
861 - CYLINDRICAL GEAR Z=33
BSD-3607030274.A9
3607030274
|
£57.14
|
£68.57
|
|
