1 - MOTOR HOUSING
BSD-1618B00A04.A7
1618B00A04
|
£31.64
|
£37.97
|
|
|
2 - FIELD 220-240V
BSD-1604220456.A12
1604220456
|
£21.68
|
£26.01
|
|
|
6 - CABLE SLEEVE dia6.4-dia7.0x66 MM
BSD-2600707075.A11
2600707075
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C2US.A0
160111C2US
|
-
|
|
|
|
19 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A524
2603490017
|
£2.27
|
£2.72
|
|
|
20 - REFERENCE PLATE
BSD-1618B00029.A3
1618B00029
|
-
|
|
|
|
24 - DRILLING SPINDLE
BSD-2606135138.A1
2606135138
|
£17.22
|
£20.67
|
|
|
26 - COMPRESSION SPRING
BSD-2604616006.A182
2604616006
|
£1.84
|
£2.21
|
|
|
27 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A122
1900905163
|
£11.30
|
£13.56
|
|
|
28 - SHIM 0.5 MM
BSD-2600100695.A58
2600100695
|
£1.84
|
£2.21
|
|
|
29 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A78
2916650008
|
£1.84
|
£2.21
|
|
|
30 - FLAT KEY
BSD-2602300032.A8
2602300032
|
£3.72
|
£4.47
|
|
|
31 - RETAINING WASHER
BSD-2600101671.A102
2600101671
|
£1.84
|
£2.21
|
|
|
33 - CYLINDRICAL GEAR
BSD-2606317084.A31
2606317084
|
£13.78
|
£16.54
|
|
|
34 - CYLINDRICAL GEAR
BSD-2606317098.A40
2606317098
|
£12.64
|
£15.17
|
|
|
35 - SHIM 0.3 MM
BSD-2600101047.A88
2600101047
|
£1.84
|
£2.21
|
|
|
36 - CATCH DISK
BSD-2600190105.A22
2600190105
|
£2.74
|
£3.29
|
|
|
38 - SHIM WASHER 1.0 MM
BSD-2600000021.A37
2600000021
|
£1.84
|
£2.21
|
|
|
38 - SHIM WASHER 1.35 MM
BSD-2600000030.A36
2600000030
|
£1.75
|
£2.10
|
|
|
38 - SHIM WASHER 1.7 MM
BSD-2600000031.A106
2600000031
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5 G28
BSD-1903230009.A656
1903230009
|
£1.84
|
£2.21
|
|
|
40 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A265
1903230010
|
£1.84
|
£2.21
|
|
|
40 - BALL 5.25 MM
BSD-2603230007.A72
2603230007
|
£1.75
|
£2.10
|
|
|
41 - SLIDE SWITCH
BSD-1618B00800.A3
1618B00800
|
£1.84
|
£2.21
|
|
|
42 - PRESSURE PLATE
BSD-2601074008.A7
2601074008
|
£1.75
|
£2.10
|
|
|
44 - SEAL
BSD-2601015099.A14
2601015099
|
£5.58
|
£6.70
|
|
|
46 - TAPPING SCREW
BSD-2603435095.A1
2603435095
|
-
|
|
|
|
47 - HOUSING COVER
BSD-1618B00A02.A5
1618B00A02
|
£15.65
|
£18.78
|
|
|
53 - DISC SPRING
BSD-2600550008.A40
2600550008
|
£1.84
|
£2.21
|
|
|
59 - TRANSMISSION
BSD-1600A00MM2.A3
1600A00MM2
|
£37.72
|
£45.27
|
|
|
61 - SHIM 0.3 MM
BSD-2600100607.A524
2600100607
|
£1.75
|
£2.10
|
|
|
63 - HEADLESS SCREW
BSD-2603435085.A10
2603435085
|
£1.84
|
£2.21
|
|
|
65 - STRAIGHT PIN
BSD-2603105200.A11
2603105200
|
£1.75
|
£2.10
|
|
|
66 - ADJUSTING SLIDE
BSD-1618B00807.A12
1618B00807
|
£1.84
|
£2.21
|
|
|
68 - COMPRESSION SPRING
BSD-2604616014.A15
2604616014
|
£1.75
|
£2.10
|
|
|
69 - ROTARY KNOB
BSD-2602026157.A5
2602026157
|
£2.27
|
£2.72
|
|
|
71 - RATCHET CAP
BSD-2600590006.A586
2600590006
|
£1.84
|
£2.21
|
|
|
72 - TORX OVAL-HEAD SCREW 4x40
BSD-2603490027.A49
2603490027
|
£1.84
|
£2.21
|
|
|
73 - SCREW 4x16
BSD-2603490022.A2736
2603490022
|
£1.84
|
£2.21
|
|
|
74 - SWITCH CONTACT
BSD-2601324062.A10
2601324062
|
£1.75
|
£2.10
|
|
|
75 - CONTACT
BSD-2601099259.A15
2601099259
|
£1.84
|
£2.21
|
|
|
76 - CONTACT
BSD-2601099260.A4
2601099260
|
£2.16
|
£2.59
|
|
|
78 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A63
2916660014
|
£1.75
|
£2.10
|
|
|
85 - KEYLESS CHUCK
BSD-2608572142.A4
2608572142
|
£52.15
|
£62.58
|
|
|
86 - CONNECTING CABLE
BSD-1600A01C9E.A1
1600A01C9E
|
-
|
|
|
|
87 - CONNECTING CABLE 72 mm
BSD-2604448330.A3
2604448330
|
£2.16
|
£2.59
|
|
|
88 - HOLDING PLATE
BSD-1618B00808.A2
1618B00808
|
£2.27
|
£2.72
|
|
|
89 - BULB SHIELD
BSD-1618B00A06.A12
1618B00A06
|
£5.30
|
£6.36
|
|
|
90 - BULB SHIELD
BSD-2605510269.A5
2605510269
|
£3.72
|
£4.47
|
|
|
93 - THREAD-FORMING TAP. SCREW
BSD-2914491411.A7
2914491411
|
£1.84
|
£2.21
|
|
|
95 - CLIP
BSD-2601329118.A4
2601329118
|
£1.75
|
£2.10
|
|
|
653 - AUXILIARY HANDLE
BSD-2602025175.A10
2602025175
|
£16.41
|
£19.69
|
|
|
653/30/1 - HANDLE
BSD-2602025180.A14
2602025180
|
-
|
|
|
|
653/30/2 - HEX SCREW M8x45
BSD-2911061252.A4
2911061252
|
£1.38
|
£1.66
|
|
|
655 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A394
1613001009
|
£3.91
|
£4.69
|
|
|
803 - ARMATURE 230-240V
BSD-2604011914.A2
2604011914
|
£57.14
|
£68.57
|
|
|
804 - SWITCH
BSD-160720032L.A7
160720032L
|
£39.13
|
£46.96
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A504
1607000386
|
£22.60
|
£27.12
|
|
|
808 - NAMEPLATE
BSD-160111A6FZ.A0
160111A6FZ
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1617000525.A66
1617000525
|
£11.87
|
£14.24
|
|
|
810 - CARBON-BRUSH SET 10 x 1 617 000 525
BSD-1607000485.A120
1607000485
|
£75.79
|
£90.95
|
|
|
816 - BRUSH PLATE
BSD-1614336086.A19
1614336086
|
£19.91
|
£23.89
|
|
|
825 - GEAR HOUSING
BSD-2605806884.A2
2605806884
|
£37.27
|
£44.72
|
|
|
843 - BEARING BRACKET
BSD-1600A0018A.A2
1600A0018A
|
£35.42
|
£42.51
|
|
|
845 - AIR GUIDE PLATE
BSD-2600148012.A2
2600148012
|
£7.36
|
£8.83
|
|
|
867 - LINK GUIDE
BSD-2602033900.A9
2602033900
|
£5.57
|
£6.68
|
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A321
2607001305
|
£4.48
|
£5.37
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A28
2603410046
|
£2.27
|
£2.72
|
|
|
895 - GREASE TUBE Albida
BSD-3605430003.A42
3605430003
|
£27.23
|
£32.68
|
|
