An exploded drawing and listing for the Bosch GSB 18-2 RE / 060117A650 / I 230 Volt
Ex VAT Inc VAT
1 - HOUSING SECTION BSD-2605104760.A13 2605104760 £37.27 £44.72
2 - FIELD 230-240V BSD-2604220689.A29 2604220689 £21.52 £25.83
3 - ARMATURE 230-240V BSD-2604011166.A31 2604011166 £45.67 £54.80
3/60 - FAN BSD-2606610029.A5 2606610029 £2.61 £3.13
4 - SWITCH BSD-2607200601.A20 2607200601 £19.45 £23.34
5 - POWER SUPPLY CORD I/BR 230V 4.15m 2 x 1.0mm H05 RN-F BSD-2604460287.A3 2604460287 £21.52 £25.83
6 - GROMMET dia6.2-dia6.9x90 MM BSD-2600707066.A2 2600707066 £2.48 £2.97
9 - MANUFACTURER'S NAMEPLATE BSD-2601116359.A3 2601116359 £3.34 £4.01
14 - NEEDLE BEARING BSD-2600914019.A95 2600914019 £5.30 £6.36
16 - BRUSH PLATE BSD-2604337061.A27 2604337061 £14.91 £17.89
20 - REFERENCE PLATE BSD-2601116360.A5 2601116360 £4.75 £5.70
22 - CHANGE-OVER SWITCH BSD-2602098008.A136 2602098008 £1.75 £2.10
24 - TAPPING SCREW DIN 7981-ST2.2x9.5-C-H BSD-2910611002.A190 2910611002 £1.75 £2.10
25 - O-RING 5.0x1.5 MM BSD-1900210000.A580 1900210000 £1.75 £2.10
27 - DAMPING ELEMENT BSD-2603239024.A8 2603239024 £1.75 £2.10
28 - OVAL-HEAD SCREW BSD-2603429006.A9 2603429006 £1.32 £1.58
29 - HANDLE COVER BSD-2608040177.A6 2608040177 £5.87 £7.04
30 - DRILLING SPINDLE BSD-2606135116.A2 2606135116 £18.96 £22.75
31 - LOCKING WASHER 0.6 MM BSD-2600118001.A124 2600118001 £1.75 £2.10
31 - LOCKING WASHER 0.8 MM BSD-2600118002.A113 2600118002 £1.75 £2.10
31 - LOCKING WASHER 0.3 MM BSD-2600118006.A124 2600118006 -
32 - COMPRESSION SPRING BSD-2604616006.A152 2604616006 £1.75 £2.10
33 - GROOVE BALL BEARING 17x35x10 BSD-1900905163.A439 1900905163 £11.30 £13.56
34 - CYLINDRICAL GEAR BSD-2606317082.A21 2606317082 £13.12 £15.75
35 - CYLINDRICAL GEAR BSD-2606317083.A35 2606317083 £11.30 £13.56
36 - SHIM 0.5 MM BSD-2600100695.A220 2600100695 £1.75 £2.10
37 - SHIM 0.3 MM BSD-2600101047.A497 2600101047 £1.75 £2.10
38 - CONTACT STRAP BSD-2601329072.A6 2601329072 -
39 - RETAINING WASHER BSD-2600101084.A50 2600101084 £1.75 £2.10
40 - FLAT KEY BSD-2602300034.A34 2602300034 -
41 - GUIDING PLATE BSD-2601098031.A35 2601098031 £1.75 £2.10
42 - CATCH DISK BSD-2600190070.A31 2600190070 £5.58 £6.70
44 - BALL DIN 5401-5.5MM-III-ST BSD-1903230010.A590 1903230010 £1.75 £2.10
45 - INDEXING DISK BSD-2601990041.A8 2601990041 £1.75 £2.10
46 - PRESSURE PLATE BSD-2601074003.A62 2601074003 £1.75 £2.10
52 - SHIM 0.3 MM BSD-2600100607.A971 2600100607 £1.75 £2.10
54 - BEARING SLEEVE BSD-2600400027.A103 2600400027 £4.26 £5.11
56 - FORK LEVER BSD-2601990009.A32 2601990009 £2.29 £2.75
57 - ROTARY KNOB BSD-2602026119.A8 2602026119 -
58 - RATCHET CAP BSD-2600590006.A1177 2600590006 £1.75 £2.10
62 - DRIVER PIN BSD-2601335001.A9 2601335001 £2.16 £2.59
63 - LOCKING WASHER 4 DIN 6799 BSD-2916080907.A7 2916080907 £2.16 £2.59
64 - SHIM WASHER BSD-2600100618.A232 2600100618 £1.75 £2.10
66 - BEARING BRACKET BSD-2605807085.A7 2605807085 £19.45 £23.34
67 - CATCH DISK BSD-2600190071.A36 2600190071 £6.52 £7.83
68 - NEEDLE-ROLLER BEARING dia6 MM BSD-2600914010.A534 2600914010 £2.80 £3.36
76 - FELT STRIP BSD-2601005011.A42 2601005011 -
77 - FELT STRIP BSD-2601005021.A15 2601005021 £1.32 £1.58
80 - KEY CHUCK BSD-2608571065.A23 2608571065 £37.27 £44.72
80/700 - CHUCK WRENCH SG2 BSD-2607950007.A1033 2607950007 £6.52 £7.83
90 - PVC-INSULATED CABLE L=120 MM BSD-2604448228.A131 2604448228 £2.16 £2.59
91 - PVC-INSULATED CABLE L=95 MM BSD-1614431025.A45 1614431025 £2.61 £3.13
96 - PLAIN WASHER BSD-2600100066.A53 2600100066 £1.75 £2.10
653 - AUXILIARY HANDLE dia43 MM BSD-2602025118.A124 2602025118 £14.91 £17.89
653/120 - AUXILIARY HANDLE M8 BSD-1612025019.A53 1612025019 £6.52 £7.83
653/124 - CLAMPING BAND dia43 MM BSD-1611316006.A388 1611316006 £2.61 £3.13
653/125 - T-HEAD BOLT M8x40 MM BSD-1613490002.A194 1613490002 £4.26 £5.11
653/802 - SUPPORT CLAMP dia43 MM BSD-2608040176.A126 2608040176 £6.52 £7.83
655 - DEPTH-GAUGE SW 6x210 MM BSD-1613001009.A675 1613001009 £3.72 £4.47
808 - MARKING PLATE BSD-2601116379.A0 2601116379 £2.33 £2.80
816/04 - BRUSH HOLDER BSD-1607000CJ1.A51 1607000CJ1 -
819 - TAPPING SCREW DIN 7981-ST2.9x13-C-H BSD-2910611006.A180 2910611006 £1.75 £2.10
823 - TAPPING SCREW DIN 7981-ST3.9x19-C-H BSD-2910611020.A471 2910611020 £1.75 £2.10
849 - TOOTHED SHAFT BSD-2606309935.A6 2606309935 £21.52 £25.83
849/50 - HELICAL GEAR Z=29 BSD-2606319080.A4 2606319080 £6.52 £7.83
866 - BEARING BRACKET BSD-2605807934.A20 2605807934 -
890 - FASTENING PARTS KIT BSD-2607001305.A133 2607001305 £4.26 £5.11
891 - CROSS RECESSED-HEAD SCREW M3x5 BSD-2603410046.A182 2603410046 £2.16 £2.59
