3 - FIELD 240V
BSD-2604220398.A16
2604220398
|
-
|
|
|
|
4 - ARMATURE 220V
BSD-2604010529.A1
2604010529
|
-
|
|
|
|
5 - SWITCH
BSD-2607200084.A136
2607200084
|
£10.10
|
£12.12
|
|
|
5 - SWITCH
BSD-2607200260.A257
2607200260
|
£11.30
|
£13.56
|
|
|
6 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A216
2604460053
|
-
|
|
|
|
7 - GROMMET dia11.6-dia12.5x84 MM
BSD-2600707060.A218
2600707060
|
£2.61
|
£3.13
|
|
|
7 - GROMMET dia6.9 MM
BSD-2600707059.A148
2600707059
|
£3.72
|
£4.47
|
|
|
7 - GROMMET dia8.8 MM
BSD-2600707061.A88
2600707061
|
£2.80
|
£3.36
|
|
|
8 - CABLE CLIP
BSD-2601035001.A2626
2601035001
|
£1.75
|
£2.10
|
|
|
11 - STICKER
BSD-2601110079.A10
2601110079
|
-
|
|
|
|
13 - SUPPRESSION CAPACITOR
BSD-2607329095.A5
2607329095
|
-
|
|
|
|
14 - SUPPRESSOR BOX
BSD-2604465099.A78
2604465099
|
-
|
|
|
|
14 - BRUSH HOLDER
BSD-1604449002.A11
1604449002
|
£1.75
|
£2.10
|
|
|
18 - CHUCK WRENCH SG2
BSD-2607950007.A811
2607950007
|
£6.52
|
£7.83
|
|
|
18 - KEYLESS CHUCK dia 1-10 MM. 3/8
BSD-1608572018.A3
1608572018
|
-
|
|
|
|
23 - STICKER
BSD-2601110080.A12
2601110080
|
-
|
|
|
|
25 - O-RING 54.0x3.0 MM
BSD-1600210004.A236
1600210004
|
£2.80
|
£3.36
|
|
|
27 - FELT WASHER
BSD-2600205002.A14
2600205002
|
-
|
|
|
|
31 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A252
2916650001
|
£2.61
|
£3.13
|
|
|
32 - GROOVE BALL BEARING 6200-2Z DIN 625
BSD-1900905232.A139
1900905232
|
£21.68
|
£26.01
|
|
|
33 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A717
2603490018
|
£1.75
|
£2.10
|
|
|
37 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A48
2600917003
|
£2.80
|
£3.36
|
|
|
38 - BALL DIN 5401-5 G28
BSD-1903230009.A530
1903230009
|
£1.75
|
£2.10
|
|
|
43 - CARB BRUSH HOLD W-SUPR
BSD-2604465081.A20
2604465081
|
-
|
|
|
|
45 - SINTERED-METAL BUSHING
BSD-1900301004.A83
1900301004
|
£13.41
|
£16.09
|
|
|
46 - INTERMEDIATE PLATE 0.3 MM
BSD-2601000018.A30
2601000018
|
-
|
|
|
|
47 - PRESSURE PLATE 1.5 MM
BSD-1601000013.A63
1601000013
|
-
|
|
|
|
48 - LUBRICATING FELT
BSD-2601020005.A83
2601020005
|
-
|
|
|
|
51 - O-RING 8.0x2.5 MM
BSD-1610210014.A141
1610210014
|
-
|
|
|
|
54 - DAMPING PLATE
BSD-2601022000.A122
2601022000
|
£1.75
|
£2.10
|
|
|
64 - SCREW 4x16
BSD-2603490022.A2274
2603490022
|
£1.75
|
£2.10
|
|
|
66 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A34
2603490025
|
£1.75
|
£2.10
|
|
|
68 - CONNECTING CABLE L=154 MM
BSD-2604448000.A132
2604448000
|
-
|
|
|
|
69 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2568
2603410001
|
£1.75
|
£2.10
|
|
|
70 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A63
2910211019
|
£1.75
|
£2.10
|
|
|
71 - CABLE
BSD-2604448003.A94
2604448003
|
-
|
|
|
|
75 - FAN
BSD-2606610047.A65
2606610047
|
-
|
|
|
|
85 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A42
2915011007
|
-
|
|
|
|
86 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A67
1900452012
|
£1.75
|
£2.10
|
|
|
801 - HOUSING SECTION
BSD-2605104949.A26
2605104949
|
-
|
|
|
|
802 - DRILLING SPINDLE Z=46
BSD-2606135901.A14
2606135901
|
-
|
|
|
|
803 - BEARING BRACKET
BSD-2605807904.A47
2605807904
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321904.A110
2604321904
|
£10.10
|
£12.12
|
|
|
825 - RUBBER PLUG
BSD-2603239010.A7
2603239010
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A4337
160111A3H3
|
£2.61
|
£3.13
|
|
