1 - MOTOR HOUSING
BSD-2605104116.A8
2605104116
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-2604220445.A5
2604220445
|
£27.23
|
£32.68
|
|
|
4 - ON-OFF SWITCH
BSD-2607200137.A48
2607200137
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1654
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1064
2601035001
|
£1.66
|
£1.99
|
|
|
9 - STICKER
BSD-3601110118.A4
3601110118
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329110.A5
2607329110
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A1303
1900905018
|
£18.96
|
£22.75
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A729
2600905021
|
£8.67
|
£10.41
|
|
|
16 - SUPPRESSOR BOX L=93/85 MM
BSD-2604465071.A36
2604465071
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A862
2603410001
|
£1.66
|
£1.99
|
|
|
19 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2457
2910211019
|
£1.66
|
£1.99
|
|
|
20 - STICKER
BSD-3601110119.A3
3601110119
|
-
|
|
|
|
25 - COUPLING HALF
BSD-3606490001.A0
3606490001
|
-
|
|
|
|
26 - LEAF SPRING
BSD-2601250001.A40
2601250001
|
£3.72
|
£4.47
|
|
|
27 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A524
1903230003
|
£1.95
|
£2.34
|
|
|
28 - SEAL RING
BSD-2600283012.A26
2600283012
|
£2.80
|
£3.36
|
|
|
29 - PROTECTIVE CAP
BSD-3600502003.A2
3600502003
|
-
|
|
|
|
32 - DRIVE BUSHING
BSD-2606445008.A7
2606445008
|
-
|
|
|
|
34 - THREADED SLEEVE
BSD-3600390013.A1
3600390013
|
-
|
|
|
|
35 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A555
1903230006
|
£1.95
|
£2.34
|
|
|
36 - RETAINING RING
BSD-2600224010.A8
2600224010
|
-
|
|
|
|
37 - NEEDLE BEARING
BSD-2600910000.A22
2600910000
|
-
|
|
|
|
38 - GEAR HOUSING
BSD-3605806102.A4
3605806102
|
-
|
|
|
|
42 - GROOVE BALL BEARING dia 8 MM
BSD-2600900008.A1
2600900008
|
-
|
|
|
|
43 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A906
2916660008
|
£1.95
|
£2.34
|
|
|
44 - COVER DISC
BSD-2601328033.A147
2601328033
|
-
|
|
|
|
45 - SPHERICAL WASHER
BSD-3600114010.A3
3600114010
|
-
|
|
|
|
46 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A28
1903230007
|
£1.66
|
£1.99
|
|
|
47 - BALL DIN 5401-6 G28
BSD-1903230011.A91
1903230011
|
£1.66
|
£1.99
|
|
|
48 - SUPPORTING DISC
BSD-2600103016.A13
2600103016
|
-
|
|
|
|
49 - COMPRESSION SPRING
BSD-2604619010.A9
2604619010
|
-
|
|
|
|
50 - RETAINING SNAP RING
BSD-2600501032.A9
2600501032
|
-
|
|
|
|
52 - CAPSULE
BSD-2600516010.A7
2600516010
|
-
|
|
|
|
55 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A413
2600914010
|
£2.80
|
£3.36
|
|
|
56 - SHIM 0.3 MM
BSD-2600100607.A891
2600100607
|
£1.66
|
£1.99
|
|
|
58 - HEADLESS SCREW
BSD-2603435018.A25
2603435018
|
-
|
|
|
|
59 - HEADLESS SCREW
BSD-2603435017.A48
2603435017
|
£2.33
|
£2.80
|
|
|
64 - RECEPTACLE
BSD-2600400008.A261
2600400008
|
£1.66
|
£1.99
|
|
|
65 - INTERMEDIATE FLANGE
BSD-2605700212.A2
2605700212
|
-
|
|
|
|
66 - FELT WASHER
BSD-2600108077.A93
2600108077
|
£1.66
|
£1.99
|
|
|
67 - CUPPED WASHER
BSD-2600500002.A55
2600500002
|
£1.66
|
£1.99
|
|
|
68 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A209
2603435015
|
£1.66
|
£1.99
|
|
|
69 - HOUSING COVER
BSD-2605132040.A81
2605132040
|
-
|
|
|
|
70 - BRUSH HOLDER
BSD-2604337003.A226
2604337003
|
£1.95
|
£2.34
|
|
|
71 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A95
2910211005
|
£1.66
|
£1.99
|
|
|
72 - CABLE L=130 MM
BSD-2604448005.A500
2604448005
|
£1.66
|
£1.99
|
|
|
73 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A1
2604465086
|
£5.58
|
£6.70
|
|
|
74 - SHIM 0.5 MM
BSD-2600101020.A372
2600101020
|
£1.66
|
£1.99
|
|
|
74 - SHIM 0.2 MM
BSD-2600101022.A260
2600101022
|
£1.66
|
£1.99
|
|
|
74 - SHIM 0.3 MM
BSD-2600101023.A303
2600101023
|
£1.66
|
£1.99
|
|
|
75 - SHIM
BSD-2600150004.A358
2600150004
|
£1.95
|
£2.34
|
|
|
76 - CABLE
BSD-2604448003.A266
2604448003
|
-
|
|
|
|
77 - CHANGE-OVER SWITCH
BSD-2607200206.A30
2607200206
|
-
|
|
|
|
78 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A1063
2910211021
|
£1.66
|
£1.99
|
|
|
79 - STICKER
BSD-2601110230.A37
2601110230
|
-
|
|
|
|
80 - CONNECTING CABLE L=52MM
BSD-2604448016.A9
2604448016
|
£1.66
|
£1.99
|
|
|
90 - TAPPING SCREW DIN 7971-BZ3.9x25
BSD-2910211022.A21
2910211022
|
£1.66
|
£1.99
|
|
|
96 - FAN
BSD-2606610049.A360
2606610049
|
£1.95
|
£2.34
|
|
|
98 - SHRINKABLE TUBE
BSD-1600712027.A0
1600712027
|
£1.66
|
£1.99
|
|
|
199 - STICKER
BSD-1601110265.A53
1601110265
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-2604321905.A512
2604321905
|
£11.30
|
£13.56
|
|
|
801 - DRIVE SHAFT Z= 48
BSD-2603124902.A7
2603124902
|
-
|
|
|
|
802 - TOOTHED SHAFT Z= 10
BSD-2606309905.A5
2606309905
|
-
|
|
|
|
803 - ASSEMBLY OF SERVICE PARTS
BSD-3607031165.A3
3607031165
|
-
|
|
|
|
810 - ARMATURE 220V
BSD-2604010586.A15
2604010586
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A308
1607000227
|
£23.86
|
£28.63
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1957
160111A3H3
|
£2.33
|
£2.80
|
|
