2 - FIELD 220V
BSD-2604222302.A28
2604222302
|
-
|
|
|
|
3 - ARMATURE 220V
BSD-2604010533.A27
2604010533
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200073.A28
2607200073
|
-
|
|
|
|
5 - ELEC. CABLE W/CONNECTION CH 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460053.A94
2604460053
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1657
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1061
2601035001
|
£1.66
|
£1.99
|
|
|
9 - STICKER
BSD-2601110414.A4
2601110414
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329002.A12
2607329002
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A1299
1900905018
|
£18.96
|
£22.75
|
|
|
14 - BALL BEARING 8x22x7
BSD-1900905029.A176
1900905029
|
£21.52
|
£25.83
|
|
|
18 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A480
2603410023
|
-
|
|
|
|
19 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2461
2910211019
|
£1.66
|
£1.99
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-2601110099.A5
2601110099
|
-
|
|
|
|
25 - COUPLING HALF
BSD-2606490043.A2
2606490043
|
-
|
|
|
|
26 - LEAF SPRING
BSD-2601250001.A34
2601250001
|
£3.72
|
£4.47
|
|
|
27 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A518
1903230003
|
£1.95
|
£2.34
|
|
|
28 - DRIVE BUSHING
BSD-2606445005.A3
2606445005
|
-
|
|
|
|
29 - PROTECTIVE CAP
BSD-2600502001.A0
2600502001
|
-
|
|
|
|
30 - SPHERICAL WASHER
BSD-2600114029.A3
2600114029
|
-
|
|
|
|
31 - DISC SPRING
BSD-2600550018.A5
2600550018
|
£2.80
|
£3.36
|
|
|
32 - COMPRESSION SPRING
BSD-2604619009.A4
2604619009
|
£2.80
|
£3.36
|
|
|
33 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A549
1903230006
|
£1.95
|
£2.34
|
|
|
34 - RETAINING SNAP RING
BSD-2600501031.A8
2600501031
|
£14.91
|
£17.89
|
|
|
35 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A6
1903230004
|
£1.66
|
£1.99
|
|
|
36 - RETAINING RING 16 DIN 9045
BSD-2916600009.A22
2916600009
|
£1.66
|
£1.99
|
|
|
37 - CUPPED WASHER
BSD-2600500030.A1
2600500030
|
-
|
|
|
|
38 - BEARING FLANGE
BSD-2605700925.A35
2605700925
|
-
|
|
|
|
39 - CHANGE-OVER SWITCH
BSD-2607200114.A4
2607200114
|
-
|
|
|
|
40 - HOUSING COVER
BSD-2605132017.A83
2605132017
|
-
|
|
|
|
41 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A12
2910211020
|
£1.66
|
£1.99
|
|
|
42 - SHIM 0.5 MM
BSD-2600101020.A366
2600101020
|
£1.66
|
£1.99
|
|
|
42 - SHIM 0.2 MM
BSD-2600101022.A266
2600101022
|
£1.66
|
£1.99
|
|
|
42 - SHIM 0.3 MM
BSD-2600101023.A297
2600101023
|
£1.66
|
£1.99
|
|
|
43 - SHIM
BSD-2600150004.A356
2600150004
|
£1.95
|
£2.34
|
|
|
44 - COVER DISC
BSD-2601328041.A42
2601328041
|
-
|
|
|
|
45 - SPRING RETAINING RING
BSD-2600119000.A85
2600119000
|
£1.66
|
£1.99
|
|
|
46 - CENTERING SLEEVE
BSD-2600409013.A68
2600409013
|
-
|
|
|
|
47 - FELT DISC
BSD-2600108000.A259
2600108000
|
-
|
|
|
|
48 - SEAL BUSHING
BSD-2600300049.A7
2600300049
|
-
|
|
|
|
49 - GEAR HOUSING
BSD-2605806339.A2
2605806339
|
-
|
|
|
|
50 - SCREW AND WASHER ASSEMBLY DIN 84-BM 4x35-Z4-8.8
BSD-2914501027.A33
2914501027
|
-
|
|
|
|
51 - GROOVED NAIL
BSD-3603133000.A214
3603133000
|
£1.95
|
£2.34
|
|
|
53 - CAPSULE
BSD-2600516009.A14
2600516009
|
-
|
|
|
|
56 - SUPPORTING DISC
BSD-2600103015.A5
2600103015
|
£7.36
|
£8.83
|
|
|
57 - BALL DIN 5401-5 G28
BSD-1903230009.A93
1903230009
|
£1.66
|
£1.99
|
|
|
58 - SEAL RING
BSD-2600283012.A29
2600283012
|
£2.80
|
£3.36
|
|
|
59 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A35
1903230007
|
£1.66
|
£1.99
|
|
|
61 - THREADED SLEEVE
BSD-2600390022.A1
2600390022
|
-
|
|
|
|
62 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A40
2603435016
|
-
|
|
|
|
63 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A113
2914501011
|
£1.66
|
£1.99
|
|
|
64 - SPIRAL SPRING
BSD-2604652003.A54
2604652003
|
-
|
|
|
|
69 - CABLE
BSD-2604411524.A55
2604411524
|
-
|
|
|
|
70 - COMPRESSION SPRING
BSD-2604611026.A185
2604611026
|
-
|
|
|
|
71 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A415
2600914010
|
£2.80
|
£3.36
|
|
|
72 - SHIM 0.3 MM
BSD-2600100607.A898
2600100607
|
£1.66
|
£1.99
|
|
|
75 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A459
1903201042
|
£1.95
|
£2.34
|
|
|
77 - NEEDLE BEARING dia 12 MM
BSD-2600914016.A8
2600914016
|
£3.72
|
£4.47
|
|
|
78 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A545
1900452012
|
£1.66
|
£1.99
|
|
|
79 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A1060
2910211021
|
£1.66
|
£1.99
|
|
|
80 - SUPPRESSOR BOX
BSD-2604465027.A61
2604465027
|
-
|
|
|
|
81 - SUPPRESSOR BOX
BSD-2604465026.A4
2604465026
|
-
|
|
|
|
82 - STICKER
BSD-2601110230.A31
2601110230
|
-
|
|
|
|
199 - STICKER
BSD-1601110265.A54
1601110265
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-2604320902.A270
2604320902
|
-
|
|
|
|
801 - DRIVE SHAFT
BSD-2603124900.A7
2603124900
|
-
|
|
|
|
802 - TOOTHED SHAFT Z=10/41
BSD-2606311903.A9
2606311903
|
-
|
|
|
|
803 - ASSEMBLY OF SERVICE PARTS
BSD-3607031164.A3
3607031164
|
-
|
|
|
|
805 - MOTOR HOUSING
BSD-2605104954.A7
2605104954
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1956
160111A3H3
|
£2.33
|
£2.80
|
|
