6 - DRIVE BUSHING
BSD-2606445005.A13
2606445005
|
-
|
|
|
|
12 - RETAINING RING 16 DIN 9045
BSD-2916600009.A39
2916600009
|
£1.66
|
£1.99
|
|
|
14 - CAPSULE
BSD-2600516009.A9
2600516009
|
-
|
|
|
|
15 - DEPTH-GAUGE
BSD-2600460901.A7
2600460901
|
-
|
|
|
|
17 - NEEDLE BEARING
BSD-2600914015.A7
2600914015
|
-
|
|
|
|
18 - SPHERICAL WASHER
BSD-2600114027.A5
2600114027
|
-
|
|
|
|
19 - SUPPORTING DISC
BSD-2600103015.A12
2600103015
|
£7.36
|
£8.83
|
|
|
20 - RETAINING SNAP RING
BSD-2600501031.A15
2600501031
|
£14.91
|
£17.89
|
|
|
21 - PRESSURE SPINDLE
BSD-2603132002.A12
2603132002
|
-
|
|
|
|
22 - SPRING RETAINING RING
BSD-2604601013.A6
2604601013
|
-
|
|
|
|
23 - STOP SPRING
BSD-2604601012.A27
2604601012
|
£2.52
|
£3.02
|
|
|
24 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A364
1903230003
|
£1.95
|
£2.34
|
|
|
25 - O-RING 21.0x2.0 MM
BSD-2600210028.A45
2600210028
|
£1.32
|
£1.58
|
|
|
26 - COMPRESSION SPRING
BSD-2604611040.A12
2604611040
|
-
|
|
|
|
27 - COMPRESSION SPRING
BSD-2604619009.A10
2604619009
|
£2.80
|
£3.36
|
|
|
28 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A297
1903230006
|
£1.95
|
£2.34
|
|
|
29 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A119
1903230004
|
£1.66
|
£1.99
|
|
|
31 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A256
1903230007
|
£1.66
|
£1.99
|
|
|
32 - BALL DIN 5401-5 G28
BSD-1903230009.A244
1903230009
|
£1.66
|
£1.99
|
|
|
33 - LEAF SPRING
BSD-2601250001.A25
2601250001
|
£3.72
|
£4.47
|
|
|
35 - DISC SPRING
BSD-2600550018.A14
2600550018
|
£2.80
|
£3.36
|
|
|
37 - NEEDLE BEARING dia 12 MM
BSD-2600914016.A12
2600914016
|
£3.72
|
£4.47
|
|
|
38 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A686
2600914010
|
£2.80
|
£3.36
|
|
|
39 - SHIM 0.3 MM
BSD-2600100607.A686
2600100607
|
£1.66
|
£1.99
|
|
|
40 - FELT DISC
BSD-2600108000.A179
2600108000
|
-
|
|
|
|
41 - SEAL BUSHING
BSD-2600300049.A88
2600300049
|
-
|
|
|
|
42 - CUPPED WASHER
BSD-2600500030.A60
2600500030
|
-
|
|
|
|
44 - BALL BEARING 8x22x7
BSD-1900905029.A260
1900905029
|
£21.52
|
£25.83
|
|
|
47 - HOUSING COVER
BSD-2605132017.A31
2605132017
|
-
|
|
|
|
48 - CHANGE-OVER SWITCH
BSD-2607200114.A11
2607200114
|
-
|
|
|
|
49 - POLE SHOE 110-115V
BSD-2604222301.A2
2604222301
|
-
|
|
|
|
50 - ARMATURE 110-115V
BSD-2604010532.A1
2604010532
|
-
|
|
|
|
50/10 - FAN
BSD-2606610021.A0
2606610021
|
-
|
|
|
|
51 - SCREW AND WASHER ASSEMBLY DIN 84-BM 4x35-Z4-8.8
BSD-2914501027.A42
2914501027
|
-
|
|
|
|
52 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A69
2916690003
|
£1.66
|
£1.99
|
|
|
53 - SPRING RETAINING RING
BSD-2600119000.A45
2600119000
|
£1.66
|
£1.99
|
|
|
54 - COVER DISC
BSD-2601328041.A38
2601328041
|
-
|
|
|
|
55 - CABLE CLIP
BSD-2601035001.A358
2601035001
|
£1.66
|
£1.99
|
|
|
56 - POWER SUPPLY CORD GB 110V 2.65m 2 x 1.0mm H05 VV-F
BSD-3604460069.A15
3604460069
|
£37.72
|
£45.27
|
|
|
58 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1582
2910211019
|
£1.66
|
£1.99
|
|
|
59 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A643
2910211021
|
£1.66
|
£1.99
|
|
|
60 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A264
2910211020
|
£1.66
|
£1.99
|
|
|
61 - SWITCH
BSD-2607200148.A1
2607200148
|
-
|
|
|
|
62 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A414
2603410023
|
-
|
|
|
|
63 - SUPPRESSION CAPACITOR
BSD-2607329097.A4
2607329097
|
-
|
|
|
|
64 - SHIM
BSD-2600150004.A150
2600150004
|
£1.95
|
£2.34
|
|
|
65 - SHIM 0.3 MM
BSD-2600101023.A181
2600101023
|
£1.66
|
£1.99
|
|
|
65 - SHIM 0.2 MM
BSD-2600101022.A438
2600101022
|
£1.66
|
£1.99
|
|
|
65 - SHIM 0.5 MM
BSD-2600101020.A211
2600101020
|
£1.66
|
£1.99
|
|
|
66 - BALL BEARING 7x22x7
BSD-1900905018.A923
1900905018
|
£18.96
|
£22.75
|
|
|
70 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A76
2603435016
|
-
|
|
|
|
71 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A194
2914501011
|
£1.66
|
£1.99
|
|
|
72 - SPIRAL SPRING
BSD-2604652003.A4
2604652003
|
-
|
|
|
|
73 - SHIM
BSD-2916010005.A1
2916010005
|
-
|
|
|
|
75 - CABLE
BSD-2604411530.A59
2604411530
|
-
|
|
|
|
77 - CABLE
BSD-2604411523.A37
2604411523
|
-
|
|
|
|
78 - COMPRESSION SPRING
BSD-2604611026.A243
2604611026
|
-
|
|
|
|
79 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A384
1903201042
|
£1.95
|
£2.34
|
|
|
81 - MANUFACTURER'S NAMEPLATE
BSD-2601110099.A13
2601110099
|
-
|
|
|
|
82 - CABLE
BSD-2604411524.A38
2604411524
|
-
|
|
|
|
83 - GROOVED NAIL
BSD-3603133000.A371
3603133000
|
£1.95
|
£2.34
|
|
|
85 - STICKER
BSD-2601110230.A114
2601110230
|
-
|
|
|
|
87 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A352
1900452012
|
£1.66
|
£1.99
|
|
|
88 - CENTERING SLEEVE
BSD-2600409013.A32
2600409013
|
-
|
|
|
|
653 - GUIDE SLEEVE
BSD-2608548000.A0
2608548000
|
-
|
|
|
|
654 - GUIDE SLEEVE
BSD-2600326007.A12
2600326007
|
-
|
|
|
|
655 - KNURLED NUT
BSD-2600525029.A4
2600525029
|
-
|
|
|
|
800 - MOTOR HOUSING
BSD-2605104954.A16
2605104954
|
-
|
|
|
|
802 - GEAR HOUSING
BSD-2605806964.A5
2605806964
|
-
|
|
|
|
803 - TOOTHED SHAFT Z=10/41
BSD-2606311903.A3
2606311903
|
-
|
|
|
|
804 - COUPLING HALF
BSD-2606490908.A5
2606490908
|
-
|
|
|
|
805 - COUPLING HALF
BSD-2606455902.A15
2606455902
|
-
|
|
|
|
806 - THREADED SLEEVE
BSD-2600390900.A10
2600390900
|
-
|
|
|
|
807 - ADJUSTING SLEEVE
BSD-2600499900.A10
2600499900
|
-
|
|
|
|
808 - DRIVE SHAFT
BSD-2603124900.A1
2603124900
|
-
|
|
|
|
809 - BEARING FLANGE
BSD-2605700925.A1
2605700925
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604320902.A192
2604320902
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A767
160111A3H3
|
£2.33
|
£2.80
|
|
