3/60 - FAN
BSD-1606610116.A206
1606610116
|
£2.52
|
£3.02
|
|
|
4 - SWITCH
BSD-1617200070.A1
1617200070
|
-
|
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A236
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1902
2601035001
|
£1.66
|
£1.99
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116704.A0
2601116704
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A326
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A116
1900905018
|
£18.96
|
£22.75
|
|
|
14 - BALL BEARING 9x24x7
BSD-2600905095.A282
2600905095
|
£12.04
|
£14.45
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A75
2604337003
|
£1.95
|
£2.34
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1862
2603410001
|
£1.66
|
£1.99
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1937
2603490022
|
£1.66
|
£1.99
|
|
|
20 - REFERENCE PLATE
BSD-2601116705.A0
2601116705
|
-
|
|
|
|
26 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A114
2603490025
|
£1.66
|
£1.99
|
|
|
29 - COVER DISC
BSD-3600590505.A27
3600590505
|
£1.66
|
£1.99
|
|
|
30 - RUBBER BUFFER
BSD-3602391503.A33
3602391503
|
-
|
|
|
|
37 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A99
2603410048
|
£1.66
|
£1.99
|
|
|
38 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A620
2603490023
|
£1.66
|
£1.99
|
|
|
40 - CABLE L=130 MM
BSD-2604448005.A285
2604448005
|
£1.66
|
£1.99
|
|
|
41 - SEALING DISK
BSD-3601016504.A0
3601016504
|
£1.32
|
£1.58
|
|
|
44 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A154
2916650003
|
£1.66
|
£1.99
|
|
|
49 - NEEDLE BEARING
BSD-2600917004.A68
2600917004
|
£3.72
|
£4.47
|
|
|
52 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A653
2603490017
|
£1.66
|
£1.99
|
|
|
53 - CONNECTING CABLE L=98 MM
BSD-2604448074.A99
2604448074
|
£1.66
|
£1.99
|
|
|
54 - CONNECTING CABLE L=68 MM
BSD-2604448100.A151
2604448100
|
£1.66
|
£1.99
|
|
|
65 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A235
2604465086
|
£5.58
|
£6.70
|
|
|
66 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A109
2604465097
|
£5.58
|
£6.70
|
|
|
69 - EARTH CONDUCTOR
BSD-2604448097.A0
2604448097
|
£1.66
|
£1.99
|
|
|
70 - CLIP
BSD-3600690503.A3
3600690503
|
-
|
|
|
|
71 - O-RING
BSD-2600210043.A21
2600210043
|
£1.66
|
£1.99
|
|
|
72 - SPACER SLEEVE
BSD-3600360505.A15
3600360505
|
£7.78
|
£9.33
|
|
|
74 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A129
1903230006
|
£1.95
|
£2.34
|
|
|
75 - BALL SUPPORT
BSD-3600034504.A21
3600034504
|
£2.52
|
£3.02
|
|
|
77 - LOCKING RING
BSD-3600390502.A24
3600390502
|
£6.61
|
£7.93
|
|
|
78 - SEAL RING
BSD-3600290502.A1
3600290502
|
£3.72
|
£4.47
|
|
|
82 - RETAINING RING
BSD-3600200516.A19
3600200516
|
£1.66
|
£1.99
|
|
|
83 - SPRING
BSD-3604613507.A15
3604613507
|
£1.95
|
£2.34
|
|
|
84 - SPRING RETAINING RING
BSD-3600118502.A23
3600118502
|
£2.33
|
£2.80
|
|
|
87 - TOOLHOLDER 1/4
BSD-3603008500.A2
3603008500
|
£14.91
|
£17.89
|
|
|
88 - SCREWDRIVER BIT
BSD-2607000366.A3
2607000366
|
-
|
|
|
|
89 - BALL DIN 5401-6 G28
BSD-1903230011.A439
1903230011
|
£1.66
|
£1.99
|
|
|
91 - SPRING
BSD-3604613506.A19
3604613506
|
£1.95
|
£2.34
|
|
|
92 - INSULATING SLEEVE
BSD-3600113506.A14
3600113506
|
£1.66
|
£1.99
|
|
|
94 - SEAL RING
BSD-3600290503.A19
3600290503
|
£2.52
|
£3.02
|
|
|
95 - BUSHING
BSD-3600301510.A6
3600301510
|
£1.95
|
£2.34
|
|
|
801 - HOUSING SET
BSD-2605105072.A0
2605105072
|
-
|
|
|
|
802 - FIELD 230-240V
BSD-2604220526.A6
2604220526
|
£21.68
|
£26.01
|
|
|
803 - ARMATURE 240V
BSD-3604011587.A7
3604011587
|
£46.37
|
£55.64
|
|
|
805 - POWER SUPPLY CORD EU 2.6m 2 x 1.0 mm
BSD-1607000385.A47
1607000385
|
£14.91
|
£17.89
|
|
|
808 - NAMEPLATE
BSD-2601116703.A0
2601116703
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A122
2604321905
|
£11.30
|
£13.56
|
|
|
825 - GEAR HOUSING
BSD-3605190512.A7
3605190512
|
-
|
|
|
|
828 - BEARING BRACKET
BSD-3605806541.A0
3605806541
|
£16.74
|
£20.09
|
|
|
846 - DRIVE SHAFT Z=17
BSD-3606120565.A1
3606120565
|
£21.42
|
£25.71
|
|
|
858 - CHANGE-OVER SWITCH
BSD-2607200607.A1
2607200607
|
-
|
|
|
|
873 - CLUTCH
BSD-3605190520.A8
3605190520
|
-
|
|
|
|
877 - DEPTH-GAUGE
BSD-3600552509.A3
3600552509
|
£24.45
|
£29.34
|
|
|
879 - DEPTH-GAUGE
BSD-2610906321.A10
2610906321
|
£10.82
|
£12.99
|
|
|
886 - CLUTCH
BSD-3606441503.A20
3606441503
|
-
|
|
|
