1 - MOTOR HOUSING
BSD-1615102155.A0
1615102155
|
£21.42
|
£25.71
|
|
|
2 - FIELD 220-240V
BSD-1614220123.A1
1614220123
|
£40.80
|
£48.96
|
|
|
4 - SWITCH
BSD-1617200095.A4
1617200095
|
£21.68
|
£26.01
|
|
|
5 - POWER SUPPLY CORD GB 230V 4.15m 2 x 1.0mm H07 RN-F
BSD-1604460144.A9
1604460144
|
£37.27
|
£44.72
|
|
|
6 - GROMMET dia8.7-dia9.6x66 MM
BSD-1600703035.A42
1600703035
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A791
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110C41.A4
1611110C41
|
£3.72
|
£4.47
|
|
|
13 - GROOVE BALL BEARING 8x24x8
BSD-1610900026.A3
1610900026
|
£12.04
|
£14.45
|
|
|
14 - GROOVE BALL BEARING 12x32x10
BSD-1610905028.A5
1610905028
|
£16.41
|
£19.69
|
|
|
15 - FAN
BSD-1616610090.A21
1616610090
|
£12.04
|
£14.45
|
|
|
16 - RATCHET SLEEVE
BSD-1610499055.A10
1610499055
|
£7.36
|
£8.83
|
|
|
17 - CATCH DISK
BSD-1610241000.A19
1610241000
|
£3.72
|
£4.47
|
|
|
18 - RETAINING RING
BSD-1614601030.A6
1614601030
|
£2.61
|
£3.13
|
|
|
21 - PROTECTIVE CAP
BSD-1610508038.A24
1610508038
|
£8.13
|
£9.76
|
|
|
22 - PROTECTION SLEEVE
BSD-1610591030.A5
1610591030
|
£5.30
|
£6.36
|
|
|
23 - STOP SLEEVE
BSD-1610520001.A114
1610520001
|
£12.04
|
£14.45
|
|
|
25 - STOPPING DEVICE
BSD-1612300036.A16
1612300036
|
£13.12
|
£15.75
|
|
|
26 - INDEXING DISK
BSD-1610290076.A11
1610290076
|
£6.52
|
£7.83
|
|
|
27 - AIR-DEFLECTOR RING
BSD-1610591028.A29
1610591028
|
£2.61
|
£3.13
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A90
1614621000
|
£2.80
|
£3.36
|
|
|
31 - DAMPING RING
BSD-1610290049.A32
1610290049
|
£2.80
|
£3.36
|
|
|
34 - FLANGE
BSD-1610516013.A24
1610516013
|
£1.75
|
£2.10
|
|
|
37 - BEARING PEDESTAL
BSD-1615500321.A0
1615500321
|
£5.30
|
£6.36
|
|
|
38 - COVERING HOOD
BSD-1615190105.A3
1615190105
|
£16.41
|
£19.69
|
|
|
42 - BRUSH HOLDER
BSD-1614336046.A8
1614336046
|
£37.27
|
£44.72
|
|
|
43 - FAN COVER
BSD-1615500410.A20
1615500410
|
£13.12
|
£15.75
|
|
|
53 - SUPPORT DISC
BSD-1610102054.A3
1610102054
|
£3.72
|
£4.47
|
|
|
57 - STRIKER
BSD-1618710073.A5
1618710073
|
£27.23
|
£32.68
|
|
|
69 - RETAINING BRACKET
BSD-1610099005.A16
1610099005
|
£2.16
|
£2.59
|
|
|
72 - ECCENTRIC COG WHEEL
BSD-1616317062.A8
1616317062
|
£51.22
|
£61.47
|
|
|
73 - HOUSING COVER
BSD-1615500360.A3
1615500360
|
£16.74
|
£20.09
|
|
|
75 - HANDLE
BSD-1615132087.A9
1615132087
|
£45.67
|
£54.80
|
|
|
80 - SPEED GOVERNOR 220-240V
BSD-1617233037.A4
1617233037
|
£68.42
|
£82.10
|
|
|
81 - HANDLE COVER
BSD-1615132088.A0
1615132088
|
£21.68
|
£26.01
|
|
|
84 - AUXILIARY HANDLE
BSD-160202508D.A22
160202508D
|
£18.96
|
£22.75
|
|
|
86 - HEX SCREW
BSD-2911021267.A20
2911021267
|
£3.72
|
£4.47
|
|
|
87 - CLAMPING BAND
BSD-1611316022.A8
1611316022
|
£10.10
|
£12.12
|
|
|
88 - STAR KNOB M8
BSD-1619P16922.A29
1619P16922
|
£6.45
|
£7.74
|
|
|
89 - CLAMPING PIECE
BSD-1600A00748.A20
1600A00748
|
£2.80
|
£3.36
|
|
|
95 - O-RING 32.0x1.5 MM
BSD-1610210173.A31
1610210173
|
£2.16
|
£2.59
|
|
|
104 - O-RING 55.0x2.0 MM
BSD-1610210095.A40
1610210095
|
£2.61
|
£3.13
|
|
|
111 - BUSHING
BSD-1610290064.A12
1610290064
|
£1.75
|
£2.10
|
|
|
112 - HEX NUT DIN 936-M8x1-8
BSD-1613300008.A6
1613300008
|
£2.61
|
£3.13
|
|
|
113 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A158
1613435009
|
£1.75
|
£2.10
|
|
|
116 - INNER RING
BSD-1610311017.A23
1610311017
|
£6.52
|
£7.83
|
|
|
121 - BUSHING
BSD-1610328018.A4
1610328018
|
£14.91
|
£17.89
|
|
|
126 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A634
2910211019
|
£1.75
|
£2.10
|
|
|
138 - SEALING FRAME
BSD-1611015050.A11
1611015050
|
£9.47
|
£11.36
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290066.A12
1610290066
|
£10.10
|
£12.12
|
|
|
142 - ROTARY SHAFT LIP SEAL
BSD-1610290061.A12
1610290061
|
£5.58
|
£6.70
|
|
|
143 - RETAINING RING DIN 7993-28x2
BSD-1614601021.A60
1614601021
|
£7.36
|
£8.83
|
|
|
144 - SUPPORTING DISC
BSD-1610251006.A10
1610251006
|
£5.58
|
£6.70
|
|
|
145 - SPRING RETAINING RING
BSD-1610119012.A23
1610119012
|
£2.61
|
£3.13
|
|
|
150 - RETAINING RING
BSD-1614601041.A9
1614601041
|
£1.75
|
£2.10
|
|
|
154 - SPRING RETAINING RING 55x2MM. DIN 472
BSD-2916660024.A22
2916660024
|
£5.30
|
£6.36
|
|
|
160 - DAMPING RING
BSD-1610210172.A13
1610210172
|
£6.52
|
£7.83
|
|
|
162 - O-RING 24.0x4.0 MM
BSD-1610210091.A37
1610210091
|
£3.72
|
£4.47
|
|
|
163 - SEAL RING
BSD-1610290065.A49
1610290065
|
£8.13
|
£9.76
|
|
|
164 - O-RING 22.0x3.0 MM
BSD-1610210144.A28
1610210144
|
£5.30
|
£6.36
|
|
|
165 - O-RING 25.0x4.0 MM
BSD-1610210153.A2
1610210153
|
£7.36
|
£8.83
|
|
|
167 - ROTARY SHAFT LIP SEAL
BSD-1610290062.A10
1610290062
|
£3.72
|
£4.47
|
|
|
171 - TORX OVAL-HEAD SCREW M5x16-TORX.T25
BSD-1613435014.A3
1613435014
|
£2.16
|
£2.59
|
|
|
172 - TORX OVAL-HEAD SCREW M6x30-TORX.T30
BSD-1613435013.A58
1613435013
|
£2.16
|
£2.59
|
|
|
174 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A6
1613435012
|
£2.16
|
£2.59
|
|
|
175 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A181
2912401018
|
£1.75
|
£2.10
|
|
|
176 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A7
1613435012
|
£2.16
|
£2.59
|
|
|
177 - TAPPING SCREW ST3.9x32
BSD-1603435051.A90
1603435051
|
£1.95
|
£2.34
|
|
|
195 - TORX OVAL-HEAD SCREW
BSD-1613435020.A14
1613435020
|
-
|
|
|
|
200 - BELLOWS
BSD-1610284000.A32
1610284000
|
£10.10
|
£12.12
|
|
|
203 - SUPPORT DISC
BSD-1610322009.A1
1610322009
|
£2.33
|
£2.80
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A173
1615430010
|
£6.52
|
£7.83
|
|
|
691 - CARRYING CASE
BSD-16054381CC.A2
16054381CC
|
£45.67
|
£54.80
|
|
|
803 - ARMATURE 220-240V
BSD-1614011098.A7
1614011098
|
£103.14
|
£123.77
|
|
|
806 - END SPLICE
BSD-3604477009.A12
3604477009
|
£2.61
|
£3.13
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A219
160111A3H5
|
£2.61
|
£3.13
|
|
|
811 - CARBON-BRUSH SET
BSD-1617014144.A33
1617014144
|
£21.52
|
£25.83
|
|
|
811 - CARBON-BRUSH SET 10 x 1 617 014 144
BSD-1607000492.A14
1607000492
|
£120.11
|
£144.13
|
|
|
815 - SOCKET HEAD CAP SCREW
BSD-1609271281.A5
1609271281
|
£1.75
|
£2.10
|
|
|
817 - SPIRAL SPRING
BSD-1614652004.A15
1614652004
|
£7.36
|
£8.83
|
|
|
818 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A41
2910011082
|
£1.75
|
£2.10
|
|
|
821 - BUSHING
BSD-1617000835.A6
1617000835
|
£21.68
|
£26.01
|
|
|
835 - HAMMER PIPE
BSD-1617000432.A6
1617000432
|
£179.37
|
£215.24
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000837.A5
1617000837
|
£57.02
|
£68.42
|
|
|
841 - STRIKER PIN
BSD-1617000452.A6
1617000452
|
£40.80
|
£48.96
|
|
|
854 - STOP DISC
BSD-1617000442.A9
1617000442
|
£37.27
|
£44.72
|
|
|
856 - HAMMER PISTON
BSD-1617000836.A9
1617000836
|
£27.23
|
£32.68
|
|
|
874 - HOLDING-DOWN-APPLIANCE
BSD-1617000422.A6
1617000422
|
£13.12
|
£15.75
|
|
|
883 - AUXILIARY HANDLE
BSD-1615132109.A3
1615132109
|
£23.86
|
£28.63
|
|
|
884 - AUXILIARY HANDLE
BSD-1602025097.A14
1602025097
|
£40.80
|
£48.96
|
|
|
885 - CATCH DISK
BSD-1610190053.A10
1610190053
|
£2.49
|
£2.99
|
|
|
886 - HEX SCREW DIN 931-M8x130-8.8
BSD-2911011270.A38
2911011270
|
£4.26
|
£5.11
|
|
|
889 - CLAMPING PIECE
BSD-1618040084.A8
1618040084
|
£2.80
|
£3.36
|
|
|
890 - MOUNTING SLEEVE
BSD-1609244B42.A19
1609244B42
|
-
|
|
|
|
891 - SPRING PACK
BSD-1617000853.A1
1617000853
|
£21.68
|
£26.01
|
|
|
892 - BOW
BSD-1609244B43.A3
1609244B43
|
-
|
|
|
|
895 - OIL RESERVOIR 1000 ML
BSD-1615430019.A45
1615430019
|
£59.53
|
£71.44
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000431.A3
1617000431
|
£27.23
|
£32.68
|
|
|
898 - OIL RESERVOIR 50 ML
BSD-1615437512.A11
1615437512
|
£13.12
|
£15.75
|
|
