1 - MOTOR HOUSING
BSD-1615102142.A14
1615102142
|
£21.52
|
£25.83
|
|
|
2 - FIELD 220-230V
BSD-1604220343.A79
1604220343
|
£33.74
|
£40.49
|
|
|
4 - SWITCH
BSD-1617200048.A108
1617200048
|
£18.96
|
£22.75
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A133
2910011088
|
£1.75
|
£2.10
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07 RN-F
BSD-1604460449.A24
1604460449
|
£27.23
|
£32.68
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A174
1610703053
|
£2.61
|
£3.13
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A759
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A779
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110704.A5
1611110704
|
£3.34
|
£4.01
|
|
|
13 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A161
1610900025
|
£16.41
|
£19.69
|
|
|
14 - GROOVE BALL BEARING 15x32x9
BSD-1610905027.A12
1610905027
|
-
|
|
|
|
15 - FAN
BSD-1616610071.A59
1616610071
|
£9.49
|
£11.39
|
|
|
16 - RATCHET SLEEVE
BSD-1610499016.A11
1610499016
|
-
|
|
|
|
17 - RETAINING SNAP RING
BSD-1610590002.A20
1610590002
|
£3.72
|
£4.47
|
|
|
18 - SPRING RETAINING RING DIN 472 37x1.5MM
BSD-2916660016.A23
2916660016
|
£2.61
|
£3.13
|
|
|
19 - CLAMPING-FLANGE
BSD-1615700033.A28
1615700033
|
-
|
|
|
|
20 - TOOLHOLDER
BSD-1618597069.A17
1618597069
|
-
|
|
|
|
21 - PROTECTIVE CAP
BSD-1610508017.A79
1610508017
|
£3.72
|
£4.47
|
|
|
22 - PROTECTION SLEEVE
BSD-1610499015.A20
1610499015
|
-
|
|
|
|
23 - STOP SLEEVE
BSD-1610520001.A127
1610520001
|
£12.04
|
£14.45
|
|
|
25 - STOPPING DEVICE
BSD-1612300027.A39
1612300027
|
£11.30
|
£13.56
|
|
|
26 - INDEXING DISK
BSD-1610290025.A98
1610290025
|
£6.52
|
£7.83
|
|
|
27 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x20-8.8
BSD-2910141201.A179
2910141201
|
£2.61
|
£3.13
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A121
1614621000
|
£2.80
|
£3.36
|
|
|
29 - COMPRESSION SPRING
BSD-1614615002.A14
1614615002
|
£1.95
|
£2.34
|
|
|
30 - O-RING 60.0x2.5 MM
BSD-1610210136.A4
1610210136
|
-
|
|
|
|
31 - SPACER TUBE
BSD-1610390015.A28
1610390015
|
-
|
|
|
|
32 - CYLINDER SLEEVE
BSD-1610202016.A76
1610202016
|
-
|
|
|
|
34 - SPACER TUBE
BSD-1610390030.A19
1610390030
|
-
|
|
|
|
35 - HAMMER PIPE
BSD-1615806086.A24
1615806086
|
-
|
|
|
|
36 - O-RING 48.0x2.0 MM
BSD-1610210022.A20
1610210022
|
£1.66
|
£1.99
|
|
|
37 - O-RING 30x2.5 MM
BSD-1900210131.A66
1900210131
|
£4.26
|
£5.11
|
|
|
38 - COVERING HOOD
BSD-1615190073.A2
1615190073
|
£11.30
|
£13.56
|
|
|
39 - ROTARY SHAFT LIP SEAL
BSD-1610283027.A28
1610283027
|
£4.75
|
£5.70
|
|
|
41 - STRIKER PIN
BSD-1618710052.A28
1618710052
|
£16.74
|
£20.09
|
|
|
45 - HOUSING COVER
BSD-1615500294.A8
1615500294
|
-
|
|
|
|
47 - COVER
BSD-1610591012.A64
1610591012
|
£1.75
|
£2.10
|
|
|
54 - CONTROL DISC
BSD-1610190010.A21
1610190010
|
-
|
|
|
|
55 - CONTROL BUSHING
BSD-1610420004.A21
1610420004
|
-
|
|
|
|
56 - HAMMER PISTON
BSD-1618700057.A19
1618700057
|
-
|
|
|
|
57 - STRIKER
BSD-1618710077.A21
1618710077
|
-
|
|
|
|
70 - CONNECTING ROD
BSD-1612001031.A22
1612001031
|
-
|
|
|
|
71 - STRAIGHT PIN
BSD-1613101005.A17
1613101005
|
£1.32
|
£1.58
|
|
|
72 - ECCENTRIC COG WHEEL Z=43
BSD-1616317051.A6
1616317051
|
-
|
|
|
|
75 - HANDLE
BSD-1615132043.A18
1615132043
|
-
|
|
|
|
76 - CONTROL LEVER
BSD-1612026029.A27
1612026029
|
£5.30
|
£6.36
|
|
|
79 - BEARING PEDESTAL
BSD-1615819016.A27
1615819016
|
-
|
|
|
|
80 - SPEED GOVERNOR 220-240V
BSD-1617233026.A27
1617233026
|
£46.82
|
£56.18
|
|
|
82 - LIGHT CONDUCTOR
BSD-1615510000.A17
1615510000
|
£2.16
|
£2.59
|
|
|
84 - STRAP-SHAPED HANDLE
BSD-1615132044.A3
1615132044
|
£14.91
|
£17.89
|
|
|
86 - HEX SCREW DIN 931-M8x130-8.8
BSD-2911011270.A59
2911011270
|
£4.26
|
£5.11
|
|
|
88 - STAR KNOB M8
BSD-1619P16922.A13
1619P16922
|
£6.45
|
£7.74
|
|
|
89 - CLAMPING PIECE
BSD-1618040068.A1
1618040068
|
£5.01
|
£6.01
|
|
|
103 - O-RING 24.0x4.0 MM
BSD-1610210091.A19
1610210091
|
£3.72
|
£4.47
|
|
|
104 - O-RING 17.0x8.0 MM
BSD-1610210093.A27
1610210093
|
£1.75
|
£2.10
|
|
|
111 - O-RING 10.0x1.0 MM
BSD-1610210081.A68
1610210081
|
£3.72
|
£4.47
|
|
|
112 - THREADED RING M24x1.5MM. SW10
BSD-1613461001.A28
1613461001
|
-
|
|
|
|
113 - BUSHING
BSD-1610501036.A27
1610501036
|
£8.67
|
£10.41
|
|
|
122 - NEEDLE BEARING
BSD-1610910088.A4
1610910088
|
£5.58
|
£6.70
|
|
|
123 - NOZZLE SOCKET
BSD-1610910087.A11
1610910087
|
-
|
|
|
|
124 - THRUST BEARING DISC 1.0 MM
BSD-1610101008.A84
1610101008
|
-
|
|
|
|
125 - TAPPING SCREW DIN7981-ST4.8x25-C-Z
BSD-2912401036.A53
2912401036
|
£1.32
|
£1.58
|
|
|
126 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A611
2910211019
|
£1.75
|
£2.10
|
|
|
127 - MICROENCAPSULATED SCREW DIN 912-M 5x12-8.8
BSD-2914551117.A20
2914551117
|
£1.75
|
£2.10
|
|
|
129 - TAPPING SCREW DIN7981-ST4.8x25-C-Z
BSD-2912401036.A52
2912401036
|
£1.32
|
£1.58
|
|
|
131 - MANUFACTURER'S NAMEPLATE
BSD-1611110705.A2
1611110705
|
-
|
|
|
|
136 - TAPPING SCREW DIN 7971-ST4.8x25-C
BSD-2910211236.A20
2910211236
|
£1.75
|
£2.10
|
|
|
137 - O-RING 26.0x2.0 MM
BSD-1610210101.A10
1610210101
|
£2.80
|
£3.36
|
|
|
138 - O-RING 33.0x2.0 MM
BSD-1610210103.A27
1610210103
|
£2.61
|
£3.13
|
|
|
139 - FELT WASHER
BSD-1610108021.A6
1610108021
|
-
|
|
|
|
140 - SUPPORT PLATE
BSD-1611098004.A30
1611098004
|
-
|
|
|
|
141 - HEADED BUSH
BSD-1613344005.A6
1613344005
|
-
|
|
|
|
143 - FELT WASHER
BSD-1610108024.A9
1610108024
|
-
|
|
|
|
151 - O-RING 21.0x2.0 MM
BSD-2600210028.A6
2600210028
|
£1.32
|
£1.58
|
|
|
152 - COVER
BSD-1610508030.A6
1610508030
|
-
|
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A147
1615430010
|
£6.52
|
£7.83
|
|
|
750 - CARRYING CASE
BSD-2605438260.A4
2605438260
|
-
|
|
|
|
751 - POINTED CHISEL dia18x280 MM
BSD-1618600023.A6
1618600023
|
£15.76
|
£18.91
|
|
|
751/1 - POINTED CHISEL dia18x400 MM
BSD-1618600011.A3
1618600011
|
-
|
|
|
|
751/2 - POINTED CHISEL dia18x600 MM
BSD-1618600012.A20
1618600012
|
£24.81
|
£29.77
|
|
|
752 - COLD CHISEL 25x400 MM
BSD-1618600202.A17
1618600202
|
-
|
|
|
|
752/1 - COLD CHISEL 25x600 MM
BSD-1618600203.A6
1618600203
|
£19.16
|
£22.99
|
|
|
753 - SPADE-SHAPED CHISEL 50x400 MM
BSD-1618601006.A8
1618601006
|
-
|
|
|
|
753/1 - WIDE CHISEL 80x300 MM
BSD-1618601008.A8
1618601008
|
£35.31
|
£42.37
|
|
|
753/2 - WIDE CHISEL 115x350 MM
BSD-1618601007.A15
1618601007
|
£70.58
|
£84.70
|
|
|
754 - TOOTHED CHISEL 32x7x300 MM
BSD-1618601302.A15
1618601302
|
£33.08
|
£39.70
|
|
|
755 - MORTAR RAKING CHISEL 28x8x300 MM
BSD-1618601303.A8
1618601303
|
-
|
|
|
|
756 - GOUGE 26x300 MM
BSD-1618601101.A15
1618601101
|
£35.13
|
£42.16
|
|
|
757 - GOUGE 32x300 MM
BSD-1618601102.A8
1618601102
|
£44.80
|
£53.76
|
|
|
758 - TILE CHISEL 50x300 MM
BSD-1618601018.A15
1618601018
|
-
|
|
|
|
758/1 - WIDE CHISEL 80x300 MM
BSD-1618601019.A8
1618601019
|
£60.98
|
£73.17
|
|
|
760 - CHISEL HOLDER 65x220 MM
BSD-1618609003.A15
1618609003
|
£35.27
|
£42.32
|
|
|
761 - BUSH HAMMER 60x60 MM. Z= 5x5
BSD-1618623205.A8
1618623205
|
£64.85
|
£77.82
|
|
|
761/1 - BUSH HAMMER 60x60 MM. Z= 7x7
BSD-1618623206.A15
1618623206
|
£64.85
|
£77.82
|
|
|
762 - TAMPING TOOL 120x130 MM
BSD-1618633101.A17
1618633101
|
£87.83
|
£105.40
|
|
|
762/1 - TAMPING TOOL 150x150 MM
BSD-1618633102.A6
1618633102
|
£128.02
|
£153.62
|
|
|
784 - AUXILIARY HANDLE dia 43 MM
BSD-2602025063.A15
2602025063
|
£35.92
|
£43.10
|
|
|
803 - ARMATURE 220-240V
BSD-1614010186.A20
1614010186
|
£103.14
|
£123.77
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2986
160111A3H3
|
£2.61
|
£3.13
|
|
|
824 - BALL DIN 5401-5 MM-III-ST
BSD-1617000239.A24
1617000239
|
-
|
|
|
|
840 - ASSEMBLY OF SERVICE PARTS
BSD-1617000804.A1
1617000804
|
-
|
|
|
|
842 - BRUSH HOLDER
BSD-1614336009.A62
1614336009
|
-
|
|
|
|
842/020 - BRUSH GUIDE
BSD-1614336043.A63
1614336043
|
-
|
|
|
|
842/040 - CARBON-BRUSH SET
BSD-1617014122.A65
1617014122
|
£18.96
|
£22.75
|
|
|
842/040 - CARBON-BRUSH SET 10 x 1 617 014 122
BSD-1607000497.A28
1607000497
|
£120.11
|
£144.13
|
|
|
842/050 - RUBBER BUFFER
BSD-1613212004.A73
1613212004
|
£3.72
|
£4.47
|
|
|
842/080 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A308
2912401005
|
£1.75
|
£2.10
|
|
|
843 - BEARING COVER
BSD-1615808078.A19
1615808078
|
-
|
|
|
|
877 - SHIFT PLATE
BSD-1617000297.A7
1617000297
|
-
|
|
|
|
887 - CLAMPING BAND dia 43 MM
BSD-1617000171.A29
1617000171
|
-
|
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000269.A6
1617000269
|
-
|
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000270.A3
1617000270
|
-
|
|
|
