1 - MOTOR HOUSING
BSD-1615102159.A0
1615102159
|
£33.45
|
£40.14
|
|
|
2 - FIELD 230V
BSD-160422052J.A6
160422052J
|
£68.42
|
£82.10
|
|
|
4 - SWITCH
BSD-1617200048.A69
1617200048
|
£18.96
|
£22.75
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A116
2910011088
|
£1.66
|
£1.99
|
|
|
5 - POWER SUPPLY CORD CN 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460075.A0
1614460075
|
£31.64
|
£37.97
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A216
1610703053
|
£2.33
|
£2.80
|
|
|
7 - FASTENING CLAMP
BSD-1601302019.A9
1601302019
|
£1.66
|
£1.99
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110F47.A0
1611110F47
|
£6.52
|
£7.83
|
|
|
13 - GROOVE BALL BEARING
BSD-2610909310.A9
2610909310
|
£16.41
|
£19.69
|
|
|
14 - NEEDLE-ROLLER BEARING
BSD-1610910089.A29
1610910089
|
-
|
|
|
|
15 - FAN
BSD-1616610083.A15
1616610083
|
£21.52
|
£25.83
|
|
|
16 - RATCHET SLEEVE
BSD-1610499022.A16
1610499022
|
£3.72
|
£4.47
|
|
|
17 - RETAINING SNAP RING
BSD-1610590004.A4
1610590004
|
£12.04
|
£14.45
|
|
|
18 - SPRING RETAINING RING
BSD-1610119010.A8
1610119010
|
£3.72
|
£4.47
|
|
|
19 - CLAMPING-FLANGE
BSD-1615700034.A17
1615700034
|
£70.24
|
£84.29
|
|
|
20 - TOOLHOLDER
BSD-1618597067.A16
1618597067
|
£81.81
|
£98.17
|
|
|
21 - PROTECTIVE CAP
BSD-1610508025.A8
1610508025
|
£4.26
|
£5.11
|
|
|
22 - PROTECTION SLEEVE
BSD-1610499023.A4
1610499023
|
£3.72
|
£4.47
|
|
|
23 - STOP SLEEVE
BSD-1610521011.A17
1610521011
|
£18.96
|
£22.75
|
|
|
25 - STOPPING DEVICE
BSD-1612300025.A4
1612300025
|
£8.67
|
£10.41
|
|
|
26 - INDEXING DISK
BSD-1610290027.A12
1610290027
|
£3.72
|
£4.47
|
|
|
27 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x30-10.9
BSD-2910151246.A5
2910151246
|
£2.33
|
£2.80
|
|
|
28 - COMPRESSION SPRING
BSD-1614621002.A15
1614621002
|
£1.95
|
£2.34
|
|
|
29 - COMPRESSION SPRING
BSD-1614621003.A5
1614621003
|
£2.80
|
£3.36
|
|
|
30 - O-RING 79.5x2.65 MM
BSD-1610210147.A4
1610210147
|
£1.95
|
£2.34
|
|
|
31 - DAMPING RING
BSD-1610290026.A8
1610290026
|
£2.80
|
£3.36
|
|
|
34 - SPACER TUBE
BSD-1610390029.A8
1610390029
|
£18.96
|
£22.75
|
|
|
35 - HAMMER PIPE
BSD-1615806108.A12
1615806108
|
£72.18
|
£86.62
|
|
|
36 - O-RING 64.0x2.5 MM
BSD-1610210127.A5
1610210127
|
£1.66
|
£1.99
|
|
|
37 - O-RING 35.0x3.0 MM
BSD-1610210128.A15
1610210128
|
£1.66
|
£1.99
|
|
|
38 - COVERING HOOD
BSD-1615190128.A0
1615190128
|
£21.68
|
£26.01
|
|
|
39 - ROTARY SHAFT LIP SEAL
BSD-1600A01MK9.A17
1600A01MK9
|
-
|
|
|
|
41 - STRIKER PIN
BSD-1618710071.A3
1618710071
|
£21.68
|
£26.01
|
|
|
43 - BEARING COVER
BSD-1615808084.A1
1615808084
|
£21.68
|
£26.01
|
|
|
54 - CONTROL DISC
BSD-1610190019.A13
1610190019
|
£8.67
|
£10.41
|
|
|
55 - CONTROL BUSHING
BSD-1610420005.A5
1610420005
|
£21.68
|
£26.01
|
|
|
56 - HAMMER PISTON
BSD-1618700064.A4
1618700064
|
£12.04
|
£14.45
|
|
|
57 - STRIKER
BSD-1618710062.A17
1618710062
|
£57.05
|
£68.46
|
|
|
70 - CONNECTING ROD
BSD-1612001033.A9
1612001033
|
£12.04
|
£14.45
|
|
|
71 - STRAIGHT PIN
BSD-1613101006.A9
1613101006
|
£2.33
|
£2.80
|
|
|
72 - ECCENTRIC COG WHEEL Z=60
BSD-1616317045.A13
1616317045
|
£70.24
|
£84.29
|
|
|
75 - HANDLE
BSD-1615132106.A0
1615132106
|
-
|
|
|
|
76 - CONTROL LEVER
BSD-1612026049.A7
1612026049
|
£3.12
|
£3.75
|
|
|
77 - SHIFT PLATE
BSD-1612026107.A0
1612026107
|
£11.30
|
£13.56
|
|
|
80 - SPEED GOVERNOR
BSD-1617233056.A2
1617233056
|
£51.22
|
£61.47
|
|
|
82 - LIGHT CONDUCTOR
BSD-1615510000.A14
1615510000
|
£1.95
|
£2.34
|
|
|
84 - AUXILIARY HANDLE
BSD-160202508D.A28
160202508D
|
£18.96
|
£22.75
|
|
|
86 - HEX SCREW
BSD-2911021267.A15
2911021267
|
£3.72
|
£4.47
|
|
|
87 - CLAMPING BAND
BSD-1611316010.A8
1611316010
|
£6.52
|
£7.83
|
|
|
88 - STAR KNOB M8
BSD-1619P16922.A22
1619P16922
|
£6.45
|
£7.74
|
|
|
89 - CLAMPING PIECE
BSD-1600A00748.A2
1600A00748
|
£2.80
|
£3.36
|
|
|
103 - O-RING 30.0x5.0 MM
BSD-1610210122.A7
1610210122
|
£6.52
|
£7.83
|
|
|
104 - O-RING 22.0x11.0 MM
BSD-1610210123.A13
1610210123
|
£2.80
|
£3.36
|
|
|
111 - BUSHING
BSD-3610501500.A32
3610501500
|
£21.68
|
£26.01
|
|
|
112 - THREADED RING
BSD-3613461500.A18
3613461500
|
£12.04
|
£14.45
|
|
|
113 - SPACER
BSD-1610009007.A17
1610009007
|
£1.95
|
£2.34
|
|
|
114 - O-RING 30.0x2.5 MM
BSD-1610210139.A33
1610210139
|
£1.95
|
£2.34
|
|
|
115 - PROTECTIVE CAP
BSD-1610508027.A30
1610508027
|
£2.80
|
£3.36
|
|
|
123 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913013.A4
1610913013
|
£8.67
|
£10.41
|
|
|
124 - THRUST BEARING DISC
BSD-1610101608.A32
1610101608
|
£1.95
|
£2.34
|
|
|
125 - TORX OVAL-HEAD SCREW 5.5x25
BSD-1613435010.A24
1613435010
|
£1.66
|
£1.99
|
|
|
126 - SCREW 4x16
BSD-2603490022.A2974
2603490022
|
£1.66
|
£1.99
|
|
|
127 - MICROENCAPSULATED SCREW DIN 912-M 5x12-8.8
BSD-2914551117.A34
2914551117
|
£1.66
|
£1.99
|
|
|
129 - SCREW AND WASHER ASSEMBLY 6.3x32
BSD-1613433001.A44
1613433001
|
£1.66
|
£1.99
|
|
|
136 - TORX OVAL-HEAD SCREW M6x30
BSD-1613490029.A16
1613490029
|
£1.66
|
£1.99
|
|
|
138 - O-RING 32.0x2.5 MM
BSD-1610210130.A16
1610210130
|
£7.36
|
£8.83
|
|
|
139 - FELT WASHER
BSD-1610108020.A19
1610108020
|
£8.67
|
£10.41
|
|
|
140 - TORX OVAL-HEAD SCREW 5.5x25
BSD-1613435010.A25
1613435010
|
£1.66
|
£1.99
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290028.A4
1610290028
|
£3.72
|
£4.47
|
|
|
142 - BUSHING
BSD-1610300063.A8
1610300063
|
£16.41
|
£19.69
|
|
|
143 - RETAINING RING DIN 7993 A 30
BSD-2916540017.A23
2916540017
|
£1.66
|
£1.99
|
|
|
144 - SUPPORTING DISC
BSD-1610102029.A13
1610102029
|
£3.72
|
£4.47
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A164
1615430010
|
£6.52
|
£7.83
|
|
|
802 - SUBASSEMBLY
BSD-1607000C3V.A5
1607000C3V
|
£89.79
|
£107.75
|
|
|
803 - ARMATURE 220-240V
BSD-1614011072.A10
1614011072
|
£187.56
|
£225.07
|
|
|
805 - POWER SUPPLY CORD
BSD-1617000723.A84
1617000723
|
£27.23
|
£32.68
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A158
160111A3HC
|
£2.33
|
£2.80
|
|
|
823 - NEEDLE-ROLLER ASSEMBLY
BSD-1617000403.A4
1617000403
|
£21.68
|
£26.01
|
|
|
824 - BALL DIN 5401-6.5MM-III-ST
BSD-1617000240.A7
1617000240
|
£2.80
|
£3.36
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000969.A19
1617000969
|
£187.56
|
£225.07
|
|
|
842 - BRUSH HOLDER
BSD-1600A005AF.A10
1600A005AF
|
£40.80
|
£48.96
|
|
|
842/020 - BRUSH GUIDE
BSD-1614336017.A17
1614336017
|
£12.04
|
£14.45
|
|
|
842/030 - SPIRAL SPRING
BSD-1614652004.A27
1614652004
|
£7.36
|
£8.83
|
|
|
842/050 - CARBON-BRUSH SET
BSD-1617014126.A18
1617014126
|
£14.91
|
£17.89
|
|
|
842/080 - TAPPING SCREW DIN 7981-ST3.5x16-C-H
BSD-2910611012.A60
2910611012
|
-
|
|
|
|
845 - HOUSING COVER
BSD-1617000418.A16
1617000418
|
£12.04
|
£14.45
|
|
|
884 - AUXILIARY HANDLE
BSD-160202508E.A7
160202508E
|
£40.80
|
£48.96
|
|
|
886 - HEX SCREW DIN 931-M8x130-8.8
BSD-2911011270.A43
2911011270
|
£4.26
|
£5.11
|
|
|
887 - CLAMPING BAND dia50 MM
BSD-1617000188.A11
1617000188
|
£10.10
|
£12.12
|
|
|
889 - CLAMPING PIECE
BSD-1618040053.A15
1618040053
|
£3.72
|
£4.47
|
|
|
890 - CATCH DISK
BSD-1610190053.A14
1610190053
|
£2.49
|
£2.99
|
|
|
892 - GREASE TUBE 45 ML
BSD-1615430014.A8
1615430014
|
£11.30
|
£13.56
|
|
|
895 - OIL RETURN RING
BSD-3613344500.A2
3613344500
|
£10.10
|
£12.12
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000189.A9
1617000189
|
£37.27
|
£44.72
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000190.A7
1617000190
|
£57.05
|
£68.46
|
|
