1 - MOTOR HOUSING
BSD-1615106040.A4
1615106040
|
-
|
|
|
|
4 - ARMATURE 110-115V
BSD-1614011020.A1
1614011020
|
-
|
|
|
|
5 - SEALING DISK
BSD-1610108012.A33
1610108012
|
£1.75
|
£2.10
|
|
|
6 - SHIM 1.0 MM
BSD-1610102013.A11
1610102013
|
£1.75
|
£2.10
|
|
|
7 - BEARING FLANGE
BSD-1615805060.A9
1615805060
|
-
|
|
|
|
8 - FAN
BSD-1616610047.A11
1616610047
|
-
|
|
|
|
9 - ECCENTRIC SHAFT
BSD-1616110032.A2
1616110032
|
£46.82
|
£56.18
|
|
|
11 - CYLINDRICAL GEAR Z=45
BSD-1616317015.A19
1616317015
|
-
|
|
|
|
12 - CYLINDRICAL GEAR Z=47/21
BSD-1616328025.A14
1616328025
|
-
|
|
|
|
13 - SEALING PLATE
BSD-1611015012.A31
1611015012
|
£2.33
|
£2.80
|
|
|
14 - GEAR COVER
BSD-1615808053.A4
1615808053
|
-
|
|
|
|
15 - SEALING CAP
BSD-1615500168.A50
1615500168
|
£2.52
|
£3.02
|
|
|
16 - FAN COVER
BSD-1615500263.A3
1615500263
|
-
|
|
|
|
17 - SWITCH COVER
BSD-1615500261.A20
1615500261
|
£7.78
|
£9.33
|
|
|
18 - SEALING CAP
BSD-1615500262.A2
1615500262
|
-
|
|
|
|
20 - SPIRAL SPRING
BSD-1614652000.A104
1614652000
|
-
|
|
|
|
21 - RUBBER PLATE
BSD-1612392001.A54
1612392001
|
£3.80
|
£4.56
|
|
|
22 - RUBBER PLATE
BSD-1612392000.A12
1612392000
|
£3.80
|
£4.56
|
|
|
23 - HANDLE
BSD-1615133021.A13
1615133021
|
£21.52
|
£25.83
|
|
|
26 - STRIKER
BSD-1618710058.A20
1618710058
|
£41.62
|
£49.95
|
|
|
27 - HAMMER PISTON
BSD-1618700047.A20
1618700047
|
£27.23
|
£32.68
|
|
|
29 - PROTECTIVE TUBE
BSD-1615190018.A5
1615190018
|
-
|
|
|
|
30 - STRIKER PIN
BSD-1613120015.A7
1613120015
|
-
|
|
|
|
31 - STOP DISC
BSD-3606100101.A28
3606100101
|
£12.04
|
£14.45
|
|
|
32 - TOOLHOLDER
BSD-1618597033.A10
1618597033
|
£58.76
|
£70.51
|
|
|
37 - CONNECTING ROD
BSD-1612001029.A4
1612001029
|
-
|
|
|
|
41 - CLAMPING BAND dia 66 MM
BSD-1611316005.A12
1611316005
|
£10.10
|
£12.12
|
|
|
42 - HEX SCREW DIN 933-M8x30-8.8
BSD-2911061246.A15
2911061246
|
£1.75
|
£2.10
|
|
|
43 - HEX NUT DIN 439-BM8-04
BSD-2915051107.A10
2915051107
|
£1.75
|
£2.10
|
|
|
44 - STAR KNOB
BSD-1613349015.A13
1613349015
|
£2.80
|
£3.36
|
|
|
49 - PISTON PIN
BSD-1610300058.A5
1610300058
|
£2.80
|
£3.36
|
|
|
51 - SHIM 1.0 MM
BSD-1610102014.A41
1610102014
|
-
|
|
|
|
54 - COVER DISC dia12xdia26x2.0 MM
BSD-1610113005.A27
1610113005
|
£1.75
|
£2.10
|
|
|
56 - BEARING BOLT
BSD-1610300057.A45
1610300057
|
£4.75
|
£5.70
|
|
|
58 - ROUND-HEAD GROOVED PIN 2x6 DIN 1476-ST
BSD-2917721034.A114
2917721034
|
£1.75
|
£2.10
|
|
|
59 - SPLIT PIN 3.2x18 DIN 94-ST
BSD-1904681350.A49
1904681350
|
£1.75
|
£2.10
|
|
|
61 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H07RN-F
BSD-1614460062.A0
1614460062
|
-
|
|
|
|
62 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A715
3600703011
|
£2.80
|
£3.36
|
|
|
63 - FASTENING CLAMP
BSD-1611302006.A26
1611302006
|
-
|
|
|
|
64 - SUPPRESSION CAPACITOR
BSD-1617328019.A10
1617328019
|
-
|
|
|
|
65 - ON-OFF SWITCH
BSD-1617200021.A15
1617200021
|
-
|
|
|
|
66 - CONNECTING TERMINAL
BSD-1611091002.A14
1611091002
|
£1.75
|
£2.10
|
|
|
68 - GROOVE BALL BEARING 10x32x12
BSD-1610905001.A56
1610905001
|
£14.91
|
£17.89
|
|
|
69 - GROOVE BALL BEARING
BSD-1610900013.A49
1610900013
|
£11.30
|
£13.56
|
|
|
70 - NEEDLE-ROLLER BEARING
BSD-1610910049.A21
1610910049
|
£37.26
|
£44.71
|
|
|
72 - NEEDLE-ROLLER BEARING
BSD-1610910007.A40
1610910007
|
£21.68
|
£26.01
|
|
|
73 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913001.A25
1610913001
|
£11.30
|
£13.56
|
|
|
75 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A785
2916660013
|
£2.16
|
£2.59
|
|
|
77 - SPRING RETAINING RING 40x1.75 MM. DIN 472
BSD-2916660018.A34
2916660018
|
£2.61
|
£3.13
|
|
|
78 - LOCKING WASHER DIN 6799-12-FST
BSD-2916080014.A66
2916080014
|
£1.75
|
£2.10
|
|
|
82 - SPRING LOCK WASHER DIN 128-A8-FST
BSD-2916690007.A15
2916690007
|
£1.75
|
£2.10
|
|
|
84 - O-RING 70x3 MM
BSD-1900210160.A9
1900210160
|
£5.58
|
£6.70
|
|
|
85 - O-RING 55x3 MM
BSD-1900210152.A48
1900210152
|
£3.72
|
£4.47
|
|
|
86 - O-RING 30x2 MM
BSD-1900210130.A29
1900210130
|
£3.72
|
£4.47
|
|
|
87 - O-RING 21.0x3.0 MM
BSD-1610210041.A15
1610210041
|
£6.52
|
£7.83
|
|
|
88 - O-RING 22.0x6.0 MM
BSD-1610210042.A0
1610210042
|
£1.75
|
£2.10
|
|
|
90 - HEX NUT DIN 985-M8-8
BSD-2915061005.A49
2915061005
|
£2.61
|
£3.13
|
|
|
95 - OVAL-HEAD SCREW 4x18 MM.TORX T20
BSD-2914201506.A51
2914201506
|
£1.75
|
£2.10
|
|
|
96 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A124
2910021118
|
£1.75
|
£2.10
|
|
|
98 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A10
1613412001
|
£1.75
|
£2.10
|
|
|
99 - MICROENCAPSULATED SCREW DIN 84 M6x30-8.8
BSD-2914551114.A8
2914551114
|
£2.61
|
£3.13
|
|
|
100 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x20-8.8
BSD-2910141201.A137
2910141201
|
£2.61
|
£3.13
|
|
|
101 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A13
2910141244
|
£1.75
|
£2.10
|
|
|
102 - HEX SOCKET HEAD CAP SCREW M 8x25`MM
BSD-1613414009.A11
1613414009
|
£1.75
|
£2.10
|
|
|
104 - REFERENCE PLATE
BSD-1611110217.A1
1611110217
|
-
|
|
|
|
129 - STICKER
BSD-1601110265.A351
1601110265
|
-
|
|
|
|
135 - REFERENCE PLATE
BSD-1611110387.A70
1611110387
|
£1.75
|
£2.10
|
|
|
650 - PARTS SET
BSD-1617000103.A3
1617000103
|
-
|
|
|
|
650/1 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A197
1907950007
|
£5.30
|
£6.36
|
|
|
650/2 - PROTECTIVE CAP
BSD-2600508042.A5
2600508042
|
-
|
|
|
|
801 - TOOL HOLDER SET
BSD-1617000037.A7
1617000037
|
£103.14
|
£123.77
|
|
|
802 - LOCKING BOLT SET
BSD-1617000014.A24
1617000014
|
£24.45
|
£29.34
|
|
|
803 - WEAR AND TEAR PART SET
BSD-1617000036.A7
1617000036
|
-
|
|
|
|
805 - SEAL KIT
BSD-1617031004.A31
1617031004
|
-
|
|
|
|
807 - FIELD 110-115V
BSD-1617031010.A1
1617031010
|
-
|
|
|
|
808 - CARBON-BRUSH SET
BSD-1617014110.A42
1617014110
|
£18.96
|
£22.75
|
|
|
810 - AUXILIARY HANDLE dia 66 MM
BSD-1612025027.A6
1612025027
|
£27.23
|
£32.68
|
|
|
812 - POLE HOUSING
BSD-1617000059.A8
1617000059
|
-
|
|
|
|
828 - HAMMER PIPE
BSD-1617000919.A1
1617000919
|
-
|
|
|
|
881 - SEAL KIT
BSD-1617000172.A4
1617000172
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3HC.A150
160111A3HC
|
£2.61
|
£3.13
|
|
